ThinkPad 760ED
          ✂ 760ED
: : : : :
IBM ThinkPad
12.1" XGA TFT - 6 x CD-ROM - Enhanced Video - MPEG
Processor type Pentium
Processor upgrade None
L2 cache 256 KB / write-back / direct mapped / 10 ns / synchronous pipelined burst
3.5" 1.44 MB ❍ / use in UltraBay or attach externally via rear ext FDD port
Removable diskette
External FDD port External FDD port (includes Floppy Disk Drive Enclosure)
5.25" CD-ROM ❍ ❍ ❍ ❍ ❍ / 6 x speed / multi-session / XA / play with eject button
Removable CD-ROM
EIDE / PIO Mode 3 (ATAPI) / in UltraBay which supports several devices
Type - model 9546-U9A
Preload (see side) Windows 95
2.1 GB / 12 ms ❍ / DMA Mode 2 or PIO Mode 4
Remv disk - size / ms
Disk controller Enhanced IDE / busmaster / PCI 2.1 / supports two internal disks for 4.2 GB
Avail / withdrawn date October 1996 / October 1997
Display - size and type 12.1 inch XGA color / 640 x 480, 800 x 600 or 1024 x 768 / 65,536 siml colors
Display - techology Black Matrix TFT - active matrix / 100 to 1 contrast ratio
Graphics - controller Trident CYBER9385 / 64 bit SVGA accelerator / 2 MB EDO DRAM / 70 ns
Graph - arch/data path PCI 2.1 / 32 bit / DCI, DirectDraw, EnDIVE support
Gaphics - features Simultaneous LCD and CRT / 180 degree tilt
Graphics - external External SVGA to 1280 x 1024 w/ 256 colors or 1024 x 768 w/ 65,536 colors
Memory - std / max 16 MB / 80 MB (104 MB w/ ThinkPad Proven option) 70 ns / non-parity / 3.3v / EDO
Memory - upgrade 2 sockets for two JEDEC 144 pin EDO SO DIMMs of 8, 16, 32 MB
Keyboard / # of keys Full size alp/num / 85 (8 Fn key functions)
Keyboard slope Automated tilt up keyboard (5.5 degrees)
Pointing / palm rest TrackPoint III / integrated palm rest
Ext keyboard support Yes (with option cable)
Dimensions 11.7 x 8.3 x 2.0" (194 cubic inches)
Weight (with CD-ROM) 6.65 pounds (3.02 kg)
Battery - type Lithium Ion / intelligent
Battery - life (1 batt) 2.2 hours
Battery - life (2 batt) 4.4 hours
Charge time - on / off 2 to 3 hrs / 1.5 to 2.5 hrs
Architecture ISA (audio, diskette, serial, parallel, infrared, ext expansion)
PCI 2.1 / 32 bit / 33 Mhz (EIDE, graphics, CardBus, MPEG, ext expansion)
Docking Station Dock I and II / SelctaDock I and II and III
Port replicator Port Replicator I and II / SelctaDock Base Model I
PC Card Standard slots 2 Type I or 2 Type II or 1 Type III / CardBus 32 bit PCI / PCMCIA 2.1 compatible
Serial / parallel ports One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / Slim AC Adapter 2 prong (35 watts) / Selectable boot
Video in/out Composite and S-Video in/out / game port
MPEG decoder MPEG-1 & MPEG-2 Half Horizontal Resolution (HHR) decoder (MPEGCD1)
DSP function Mwave MDSP2780 DSP with modem, fax, audio, telephony function
Data/fax modem Data/fax modem function via DSP (v.34 to 33.6 Kbps) / Mwave 2.1
Audio support 16 bit audio chip on planar with Mwave DSP
Int stereo speakers / .5 watt / slide volume control / internal microphone
Jacks Input jack (3.5 mm) / Output jack (3.5 mm) / Joystick/MIDI port (includes cable)
Telephone Telephone / answering machine / full duplex speakerphone / DSVD
Infrared ports Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Security Power-on password / Hard disk password / Supervisor password /
Security keyhole (requires cable) / Security latch for keyboard and
DIMMS (requires cable) / PC Card lock / Personalization / Security Plate
Preinstalled software Windows 95 with applications (listed on right)
Warranty
Enhanced Video Card in 760ED provides:
- Composite in and S-Video in (NTSC or PAL)
for video capture (capture and digitize video
from a TV or VCR), still image capture (capture
and digitize still photo images), and overlay.
- Composite out and S-Video out to TV
(connect to video out port; NTSC or PAL);
or record on VCR the screen of ThinkPad.
- Mini game port for MIDI or joystick
- Includes video in and video out ports
(includes one video in/out cable)
- Use software called Digital Video Producer
- Hardware acceleration of 'Video for
Windows' formerly done by a separate ASCII
chip (as in 755CD and 760CD) has now been
integrated into the 9385 graphics controller;
interpolation in X and Y axis; color space
conversion when DCI enabled
- Plays back MPEG motion videos, CD-I
movies, video CD's, and Karaoke MPEG
video titles
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍
= Removable
(XGA) - withdrawn
    
133/66 (P54CSLM) / 64 bit to L2 cache / 64 bit to memory
optional
NiMH
Compatible in ThinkPad 760ED family:
- Second HDD Adapter
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- IDE Conversion Card (for Dock I/II) 46H5994
- SelectaDock I
- SelectaDock II
- SelectaDock III
- Port Replicator I (w/ PCMCIA slots) 66G3510
- Port Replicator II
- SelectaDock Base Model I
- 2.88 MB diskette drive
- PCMCIA Cartridge (one Type III)
- FDD External Attachment Kit
- 35 watt AC Adapter (slim, 4 pin)
- 4 x CD-ROM (UltraBay)
- 6 x CD-ROM (UltraBay)
- 8 x CD-ROM (UltraBay)
- 8 - 20 x CD-ROM (UltraBay)
- 8 MB SO DIMM 3.3v NP EDO 64 bit 92G7340
- 16 MB SO DIMM 3.3v NP EDO 64 bit 92G7341
- 32 MB SO DIMM 3.3v NP EDO 64 bit 92G7342
The left bay (UltraBay) supports:
x 2nd disk; y 2nd battery
z std diskette drive; { CD-ROM
➄ 2.88 MB diskette (option)
➅ PCMCIA Cartridge (option)
➆ IBM Wireless Modem ARDIS (option)
➇ IBM Wireless Modem for Cellular/
CDPD (option)
Liftable (pop-up) keyboard to access
and remove CD-ROM, diskette drive,
1st/2nd disk, and 1st/2nd battery
29H9333
3545001
3546001
3547001
3547002
3547003
66G3520
39H7405
66G0108
84G1301
66G3618
76H0119
39H7413
85G1957
45H8786
00K7903
ThinkPad 760ED strengths over 760CD:
➭ ➭ ➭ ➭ ➭ Pentium 133/66 MHz (vs 120/60 MHz)
➭ ➭ ➭ ➭ ➭ PCI bus (vs VL-Bus)
➭ ➭ ➭ ➭ ➭ 16 MB EDO memory (vs 8 MB fast page)
➭ ➭ ➭ ➭ ➭ 64 bit path to memory (vs 32 bit)
➭ ➭ ➭ ➭ ➭ 9385 64 bit graphics with 2 MB EDO
➭ ➭ ➭ ➭ ➭ CardBus PC Card support (32 bit PCI)
Integrated Mwave DSP provides:
x Data modem function
- V.22bis, V.32, V.32bis, v.34 (28.8 Kbps)
y Fax modem function
- G3 fax send/receive (14.4 Kbps)
z Audio function
- Stereo waveform record and playback
- Qsound support (3-D effect)
- 32 voice MIDI wave table synthesizer
- SoundBlaster support / text to speech
- MPEG audio decode
{ Telephone function
- Full telephone (can use opt headset)
- Telephone answering machine
- Full duplex speakerphone
➄ Digital Simultaneous Voice Data
WINDOWS 95 PRELOAD
- Microsoft Windows 95
- Online User's Guide
- ThinkPad Features
- PC Card Director 4.0
- Diskette Factory
1. Triton CoSession Host
2. SofNet FaxWorks Voice
3. Puma TranXit
4. Compuserv for Windows
5. NetFinity for Windows 95

6. Asymetrix Digital Video Producer
7. MPEG Sampler (CD-ROM)
- Lotus SmartSuite 96 CD-ROM
Easy-Setup is entered by holding F1 when
turning on.
ThinkPad 760ED supported batteries:
- 760 NiMH Battery (black)
- Li-Ion Battery Pack II (gray)
- Travel Quick Charger
- Car Battery Adapter
ThinkPad 760ED supported disks:
- (360/750/755 IDE disks not supported)
- 720 MB HDD II EIDE 12.5 mm 29H9383
- 810 MB HDD II EIDE 12.5 mm 29H9313
- 1.08 GB HDD II EIDE 12.5 mm 29H9319
- 1.2 GB (1.96"+ models) 17 mm
- 1.4 GB HDD 3L EIDE 12.5 mm 69H8412
- 2.1 GB (1.96"+ models) 17 mm
- 3.0 GB (1.96"+ models) 17 mm
- 5.1 GB (1.96"+ models) 17 mm
FEATURES OF 760 MODELS
Setup Pointer (single page)
LCD indicator panel
Plug and Play 1.0a
Discharge battery via mouse click
Non-disruptive battery exchange
Standby, suspend, safe suspend, and
hibernation modes
US EPA Energy Star compliant
Personalized nameplate in indention
Personalization screen at startup
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, electronic, and Internet
(http://www.pc.ibm.com) support
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(760ED96) Compiled by Roger Dodson, IBM. October 1997
