ThinkPad 760E (XGA) - withdrawn
          ✂ 760E
: : : : :
IBM ThinkPad
12.1" XGA color - thick
Pentium
Processor type
None
Processor upgrade
L2 cache 256 KB / write-back / direct mapped / 10 ns / synchronous pipelined burst
3.5" 1.44 MB ❍ / in UltraBay
Removable diskette
External FDD port External FDD port (requires External FDD Attachment Kit 66G3618)
None / can upgrade with optional CD-ROM into UltraBay
Removable CD-ROM
Price
9546-U9B
Type - model
Preload (see side) Windows 95
2.1 GB / 12 ms ❍
Remv disk - size / ms
EIDE / busmaster / PCI 2.1 / supports two internal disks (so 4.2 GB max)
Disk controller
October 1996 / October 1997
Avail / withdrawn date
12.1 inch XGA color / 640 x 480, 800 x 600, or 1024 x 768 / 65,536 siml colors
Display - size and type
Black Matrix TFT - active matrix / 100 to 1 contrast ratio
Display - techology
Trident CYBER9385 / 64 bit SVGA accelerator / 2 MB EDO DRAM / 70 ns
Graphics - controller
PCI 2.1 / 32 bit / DCI, DirectDraw, EnDIVE support
Graph - arch/data path
Simultaneous LCD and CRT / 180 degree tilt
Graphics - features
External SVGA to 1280 x 1024 w/ 256 colors or 1024 x 768 w/ 65,536 colors
Graphics - external
Memory - std / max 16 MB / 80 MB (104 MB with ThinkPad Proven option)
Memory - features 70 ns / non-parity / 3.3 volt / EDO
2 sockets for two JEDEC 144 pin EDO SO DIMMs of 8, 16, 32 MB
Memory - upgrade
Full size alp/num / 85 (8 Fn key functions)
Keyboard / # of keys
Automated tilt up keyboard (5.5 degrees)
Keyboard slope
Pointing / palm rest TrackPoint III / integrated palm rest / ext keyboard support (w/ optional cable)
11.7 x 8.3 x 2.0" (194 cubic inches)
Dimensions
6.41 pounds (2.91 kg)
Weight
Lithium Ion / intelligent
Battery - type
Battery - life (1 batt) 2.6 hours
Battery - life (2 batt) 5.2 hours
2 to 3 hrs / 1.5 to 2.5 hrs
Charge time - on / off
ISA (audio, diskette, serial, parallel, infrared, ext expansion)
Architecture
PCI 2.1 / 32 bit / 33 Mhz (EIDE, graphics, CardBus, ext expansion)
Dock I and II / SelectaDock I and II and III
Docking Station
Port replicator Port Replicator I and II / SelectaDock Base Model I
PC Card Standard slots 2 Type I or 2 Type II or 1 Type III / CardBus 32 bit PCI / PCMCIA 2.1 compatible
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Serial / parallel ports
APM-aware BIOS / Slim AC Adapter 2 prong (35 watts) / Selectable boot
Other features
None
Video in/out
MPEG decoder None
Mwave MDSP2780 DSP with modem, fax, audio, telephony function
DSP function
Data/fax modem function via DSP (v.34 to 33.6 Kbps) / Mwave 2.1
Data/fax modem
16 bit audio chip on planar with Mwave DSP
Audio support
Int stereo speakers / .5 watt / slide volume control / internal microphone
Jacks Input jack (3.5 mm) / Output jack (3.5 mm)
Telephone / answering machine / full duplex speakerphone / DSVD
Telephone
Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Infrared ports
Power-on password / Hard disk password / Supervisor password /
Security
Security keyhole / Security latch for keyboard and
DIMMS (requires cable lock) / PC Card lock / Personalization / Security Plate
Windows 95 with applications (listed on right)
Preinstalled software
3 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
Warranty
The left bay (UltraBay) supports:
x 2nd disk (requires Second HDD Adapter)
y 2nd battery
z std diskette drive
{ 2.88 MB diskette drive (option)
➄ PCMCIA Cartridge (option)
➅ IBM Wireless Modem for ARDIS (option)
➆ IBM Wireless Modem for Cellular/CDPD
(option)
Maximum internal disk capacity on 760E is
10.2 GB with two 5.1 GB disks
Easy-Setup is entered by holding F1 when
turning on.
Integrated Mwave DSP provides:
x Data modem function (to 28.8 Kbps)
y Fax modem function (to 14.4 Kbps)
z Audio function (wave table synthesis)
{ Telephone function
- Full duplex speakerphone
➄ Digital Simultaneous Voice and Data
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍
= Removable
    
150/60 (P54CSLM) / 64 bit to L2 cache / 64 bit to memory
Liftable (pop-up) keyboard to access
optional
and remove diskette drive, 1st/2nd
NiMH
disk, and 1st/2nd battery (thick
models support CD-ROM)
Compatible in ThinkPad 760E family:
- Second HDD Adapter
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- IDE Conversion Card (for Dock I/II) 46H5994
- SelectaDock I
- SelectaDock II
- SelectaDock III
- Port Replicator I (w/ PCMCIA slots) 66G3510
- Port Replicator II
- SelectaDock Base Model I
- 2.88 MB diskette drive
- PCMCIA Cartridge (one Type III)
- FDD External Attachment Kit
- 35 watt AC Adapter (slim, 4 pin)
- 4 x CD-ROM (UltraBay)
- 6 x CD-ROM (UltraBay)
- 8 x CD-ROM (UltraBay)
- 8 - 20 x CD-ROM (UltraBay)
- 8 MB SO DIMM 3.3v NP EDO 64 bit 92G7340
- 16 MB SO DIMM 3.3v NP EDO 64 bit 92G7341
- 32 MB SO DIMM 3.3v NP EDO 64 bit 92G7342
Key differences between 760E and 760ED:
760E
No std CD-ROM
No video in/out
No joystick/MIDI port
No MPEG decoder
Lighter
Price
WINDOWS 95 PRELOAD
- Microsoft Windows 95
- Online User's Guide
- ThinkPad Features
- PC Card Director 4.0
- Diskette Factory
1. Triton CoSession Host
2. SofNet FaxWorks Voice
3. Puma TranXit
4. Compuserv for Windows
5. NetFinity for Windows 95
- Lotus SmartSuite 96 CD-ROM
Easy-Setup is entered by holding F1
when turning on.
810 MB = DMA Mode 2 or PIO Mode 4
1.08 GB = DMA Mode 2 or PIO Mode 4
1.2 GB = DMA Mode 1 or PIO Mode 3
1.35 GB = DMA Mode 2 or PIO Mode 4
2.1 GB = DMA Mode 2 or PIO Mode 4
ThinkPad 760E supported batteries:
- 760 NiMH Battery (black)
- Li-Ion Battery Pack II (gray)
- Travel Quick Charger
- Car Battery Adapter
ThinkPad 760E supported disks:
- (360/750/755 IDE
- 720 MB HDD II EIDE 12.5 mm 29H9383
- 810 MB HDD II EIDE 12.5 mm 29H9313
- 1.08 GB HDD II EIDE 12.5 mm 29H9319
- 1.2 GB (1.96"+ models) 17 mm
- 1.4 GB HDD 3L EIDE 12.5 mm 69H8412
29H9333
- 2.1 GB (1.96"+ models) 17 mm
3545001
- 3.0 GB (1.96"+ models) 17 mm
3546001
- 5.1 GB (1.96"+ models) 17 mm
3547001 FEATURES OF 760 MODELS
3547002
Setup Pointer (single page)
3547003
LCD indicator panel
Plug and Play 1.0a
66G3520
Discharge battery via mouse click
39H7405
Non-disruptive battery exchange
66G0108
Standby, suspend, safe suspend, and
84G1301
hibernation modes
66G3618
US EPA Energy Star compliant
76H0119
Personalized nameplate in indention
39H7413
Personalization screen at startup
85G1957
International Warranty Service
45H8786
24 hour / 7 day telephone, bulletin
00K7903
board, fax, electronic, and Internet
(http://www.pc.ibm.com) support
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(760E96) Compiled by Roger Dodson, IBM. October 1997
