ThinkPad 760EL (Fall 1996 models) - withdrawn
         
: : : : :
IBM ThinkPad
Processor type
Processor upgrade
L2 cache
Removable diskette
External FDD port
Removable CD-ROM
Price
Type - model
Preload (see side)
Avail / withdrawn date
Pentium speed
Remv disk - size / ms
Disk controller
Display - size and type
Display - techology
Graphics - controller
Graph - arch/data path
Graphics - features
Memory - std / max
Memory - features
Keyboard / # of keys
Keyboard slope
Pointing / palm rest
Dimensions
Weight
Battery - type
Battery - life (1 batt)
Battery - life (2 batt)
Charge time - on / off
Architecture
Docking Station
Port replicator
PC Card Standard slots
Serial / parallel ports
Other features
Video in/out
MPEG decoder
DSP function
Data/fax modem
Audio support
Jacks
Telephone
Infrared ports
Security
Preinstalled software
Warranty
The left bay (UltraBay) supports:
x 2nd disk (requires Second HDD Adapter)
y 2nd battery
z std diskette drive
{ 2.88 MB diskette drive (option)
➄ PCMCIA Cartridge (option)
➅ IBM Wireless Modem for ARDIS (option)
➆ IBM Wireless Modem for Cellular/CDPD
(option)
Maximum internal disk capacity on 760EL is
4.2 GB with two 2.1 GB disks
Easy-Setup is entered by holding F1 when
turning on.
810 MB = DMA Mode 2 or PIO Mode 4
1.08 GB = DMA Mode 2 or PIO Mode 4
1.2 GB = DMA Mode 1 or PIO Mode 3
1.35 GB = DMA Mode 2 or PIO Mode 4
2.1 GB = DMA Mode 2 or PIO Mode 4
Maximum is 80 MB or 104 MB on all
models, but 104 MB requires a ThinkPad
Proven vendor option.
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍
= Removable
✂ 760EL
11.3" SVGA DSTN or 12.1" SVGA TFT - thick
    
Pentium 120/60 or 133/66 / 64 bit to L2 cache / 64 bit to memory
to Pentium 133/66 MHz which includes 256 KB L2 cache
None (not separately upgradeable) 256 KB / write-back / direct mapped / 10 ns / synchronous pipelined burst
3.5" 1.44 MB ❍ / use in UltraBay or attach externally via rear ext FDD port
External FDD port (requires FDD External Attachment Kit 66G3618)
None / can upgrade to optional CD-ROM into UltraBay
9547-U6H
Windows 95
October 1996 / July 1997
120/66 MHz
1.35 GB / 13 ms ❍
EIDE / busmaster / PCI 2.1 / supports two internal disks
11.3 inch DSTN
11.3" SVGA color / 640 x 480 or 800 x 600
256 simultaneous colors / Dual Scan / 30 to 1 contrast ratio
Trident CYBER9320 / 32 bit SVGA / 1 MB EDO DRAM / 70 ns Trident CYBER9385/64 bit SVGA/1 MB EDO DRAM/70 ns
PCI 2.1 / external SVGA to 1024 x 768 w/ 256 colors
Simultaneous LCD and CRT / 180 degree tilt
8 MB / 72 MB or 104 MB
70 ns / non-parity / 3.3 volt / EDO / 2 sockets for 2 JEDEC 144 pin EDO SO DIMMs of 8, 16, 32 MB
Full size alp/num / 85 (8 Fn key functions)
Automated tilt up keyboard (5.5 degrees)
TrackPoint III / integrated palm rest / ext keyboard support (with option cable)
11.3" models: 11.7 x 8.3 x 1.98" (192) 12.1" models: 11.7 x 8.3 x 2.0" (194)
11.3" models: 6.7 pounds (3.04 kg)
Lithium Ion / intelligent (optional NiMH battery supported)
11.3" models: 2.7 hours
11.3" models: 5.4 hours
2 to 3 hrs / 1.5 to 2.5 hrs
ISA (audio, diskette, serial, parallel, infrared, ext expansion)
PCI 2.1 / 32 bit / 33 Mhz (EIDE, graphics, CardBus, ext expansion)
Dock I and II / SelectaDock I and II and III
Port Replicator I and II / SelectaDock Base Model I
2 Type I or 2 Type II or 1 Type III / CardBus 32 bit PCI / PCMCIA 2.1 compatible
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Slim AC Adapter 2 prong (35 watts) / Selectable boot
None
Liftable (pop-up) keyboard to access and
None
remove diskette drive, 1st/2nd disk, and
None
1st/2nd battery, and other UltraBay options
None
16 bit audio chip / 20 voice MIDI FM synthesis / ESS1688
Int stereo speakers / .5 watt / slide volume control / internal microphone
Input jack (3.5 mm) / output jack (3.5 mm)
None
Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Power-on password / Hard disk password / Supervisor password /
Security keyhole (requires cable) / Security latch for keyboard and
DIMMS (requires cable) / PC Card lock / Personalization / Security Plate
Windows 95 with applications (listed on right)
3 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
Compatible in ThinkPad 760EL family:
- Second HDD Adapter
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- IDE Conversion Card (for Dock II) 46H5994
- SelectaDock I
- SelectaDock II
- SelectaDock III
- Port Replicator I (w/ PCMCIA slots) 66G3510
- Port Replicator II
- SelectaDock Base Model I
- 2.88 MB diskette
- PCMCIA Cartridge (one Type III)
- FDD External Attachment Kit
- Pentium 133/66 MHz/L2 upgrade
- 35 watt AC Adapter (slim, 4 pin)
- 4 x CD-ROM (UltraBay)
- 6 x CD-ROM (UltraBay)
- 8 x CD-ROM (UltraBay)
- 8 - 20 x CD-ROM (UltraBay)
- 8 MB SO DIMM 3.3v NP EDO 64 bit 92G7340
- 16 MB SO DIMM 3.3v NP EDO 64 bit 92G7341
- 32 MB SO DIMM 3.3v NP EDO 64 bit 92G7342
9547-U4G
Windows 95
October 1996 / October 1997
133/66 MHz
2.1 GB / 13 ms ❍
12.1 inch TFT
12.1" SVGA color / 640 x 480, 800 x 600 / 65,536 colors
Black Matrix TFT - active matrix / 100 to 1 contrast ratio
PCI 2.1 / external SVGA to 1024 x 768 w/ 256 colors
16 MB / 72 MB or 104 MB
12.1" models: 6.41 pounds (2.91 kg)
12.1" models: 3.0 hours
12.1" modles: 6.0 hours
Pallette of 24 systems
9547-U4T
Blank (none)
October 1996 / April 1997
133/66 MHz
2.1 GB / 13 ms ❍
12.1 inch TFT
16 MB / 80 MB or 104 MB
WINDOWS 95 PRELOAD
- Microsoft Windows 95
- Online User's Guide
- ThinkPad Features
- PC Card Director 4.0
- Diskette Factory
1. Triton CoSession Host
2. Puma TranXit
3. Compuserv for Windows
4. NetFinity for Windows 95
- Lotus SmartSuite 96 CD-ROM
WINDOWS NT 4.0 PRELOAD
- Microsoft Windows NT 4.0 Workstation
with utilities and device drivers
NT model with 32 MB consists of 8 MB
on planar, 8 MB in memory carrier, and
16 MB via a SO-DIMM. One SO-DIMM
socket is available.
BLANK PRELOAD
- License for SmartSuite
ThinkPad 760EL supported batteries:
- 760 NiMH Battery (black)
- Li-Ion Battery Pack II (gray)
- Travel Quick Charger
- Car Battery Adapter
ThinkPad 760E supported disks:
- (360/750/755 IDE
- 720 MB HDD II EIDE 12.5 mm 29H9383
- 810 MB HDD II EIDE 12.5 mm 29H9313
- 1.08 GB HDD II EIDE 12.5 mm 29H9319
29H9333
- 1.2 GB (1.96"+ models) 17 mm
3545001
- 1.4 GB HDD 3L EIDE 12.5 mm 69H8412
3546001
- 2.1 GB (1.96"+ models) 17 mm
- 3.0 GB (1.96"+ models) 17 mm
3547001
3547002
FEATURES OF 760 MODELS
3547003
Setup Pointer (single page)
LCD indicator panel
66G3520
Plug and Play 1.0a
39H7405
Discharge battery via mouse click
66G0108
Non-disruptive battery exchange
84G1301
Standby, suspend, safe suspend,and
66G3618
hibernation modes
46H5991
US EPA Energy Star compliant
76H0119
Personalized nameplate in indention
39H7413
Personalization screen at startup
85G1957
International Warranty Service
45H8786
24 hour / 7 day telephone, bulletin
00K7903
board, fax, electronic, and Internet
(http://www.pc.ibm.com) support
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(760EL96) Compiled by Roger Dodson, IBM. October 1997
9547-U4K
Windows NT 4.0
Nov 1996 / July 1997
133/66 MHz
2.1 GB / 13 ms ❍
12.1 inch TFT
32 MB/80 MB or 104 MB
1 socket available
41H9720
29H9329
85G1522
49G2167
disks not supported)
29H9325
69H8414
45H8789
