ThinkPad 755CDV - withdrawn
          ✂ 755CDV
: : : : :
IBM ThinkPad
TFT color - projector LCD - DX4
IntelDX4     100/33 MHz
Processor type
L2 cache None
Processor / L2 upgrade to Pentium 75/50 MHz which
Internal 3.5" 1.44 MB ❍ / supports internal 2.88 MB diskette
Removable diskette
Supports PCMCIA Cartridge in diskette bay
5.25" CD-ROM ❍ ❍ ❍ ❍ ❍ / double speed / multi-session and XA / front loaded
Removable CD-ROM
Price
Type - model / part 9545-ABJ
Removable disk - size 540 MB / 14 ms
Avail / withdrawn date June 95 / Jun 96
Display - type VGA color / 640 x 480 / 65,536 simultaneous colors
Display - techology TFT - active matrix
Display - diagonal size 10.4 inch / 100 to 1 contrast ratio
Display - projector Overhead projector LCD by removing back (includes Stand and Strap)
Graphics - controller WD90C24A2 Rev D with 1 MB DRAM
Graphics - vendor Western Digital / External SVGA to 1024 x 768 w/ 256 colors (up to 75 Hz)
Graph - arch/data path VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
Memory - std / max 8 MB / 40 MB 70 ns / parity
Mem - sockets empty 1 socket / 5 volt
Mem-options available 2, 4, 8, 16, 32 MB ICs or 4, 8, 16 MB DIMMs that
Keyboard / # of keys Full size alp/num / 85 (8 Fn key functions)
Keyboard slope Yes (legs pop out)
Mouse/pointing TrackPoint III
Ext keyboard support Yes (with option cable)
Dimensions 11.7 x 8.3 x 2.2" (213 cubic inches)
Color Black
Weight (with battery) 7.45 pounds
Battery - type Nickel hydride (NiMH) / smart
Battery - life 3 to 9 hours
Charge time - on / off 1.7 hrs / 1.2 hrs
Architecture AT bus (ISA)
Docking Station Dock I and II
Port replicator Port Replicator I and II
PCMCIA 2.1 slots 2 Type I or 2 Type II or 1 Type III
Serial / parallel ports One 9 pin; 16550A / One (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / Universal AC adapter (35 watts) / Selectable boot
Video function (below) Daughtercard with video acceleration, composite in/out, game port
DSP function Mwave MDSP2780 DSP with modem, fax, audio, telephony function
Data/fax modem Data/fax modem function via DSP
Audio support 16 bit audio chip on planar with Mwave DSP
Internal stereo speakers .5w (w/ dial volume control) and int microphone
Audio in/out jacks Input jack / output jack
Telephone Telephone / answering machine / full duplex speakerphone
Infrared ports Infrared ports (front and back) / IRDA compatible / up to 115 kbs
Security Power-on password / Hard disk password / Supervisor password / Hardware
security loop / Keyboard lock / Locking device keyhole (Kensington
Microsaver cable lock) / PCMCIA card lock
Preinstalled software IBM DOS 7.0, Windows 3.11, OS/2 Warp Version 3 and all appls listed to right:
Warranty 3 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
Enhanced Video Card in 755CDV provides:
- Acceleration of 'Video for Windows'ä motion
video with scaling and interpolation of image.
Video may be scaled up to full screen without
frame rate degredation.
- Composite in and S-Video in for video
capture (capture and digitize video from a TV
or VCR), still image capture (capture and
digitize still photo images), and overlay (view
video on LCD like with a TV, VCR, or
camcorder without capturing it to disk). So
can hook up a TV or VCR and run it on the
ThinkPad screen.
- Composite out and S-Video out to TV
meaning use a TV as if an external display
(connect to video out port; NTSC or PAL);
or record on a VCR the contents of the
755CD screen.
- Mini game port for MIDI or joystick (includes
MIDI/joystick cable)
- Includes a video in and video out port
(includes two video in/out cables)
- Use software called Digital Video Producerä
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business days average turnaround). Overnight repair option in US available for $99.
❏ ❏ ❏ ❏ ❏ ❍
= Upgradeable
includes 256 KB L2 cache
9545-ABK
810 MB / 14
Jun95 / Jun96
work on optional Memory Module Adapter
Includes Mind
Path Remote
Control IR55 F/X
Supports opt
Lithium ion
Compatible in all ThinkPad 360 family, 750
family, 755 family:
- Disks:
- Dock I
- Dock II
- Port Replicator I (w/ PCMCIA)
- Port Replicator II
- 2.88 MB diskette
Options for 755CDV:
- NiMH Battery Pack II
- Lithium Ion battery
- Li-Ion Batt Pack II (Pentium only) 29H9329
- CDPD Mobile Module
- PCMCIA Cartridge
- Pentium/L2 upgrade (DX4 mod) 29H8755
- Cooling Fan Kit (for overhead)
ThinkPad IC DRAM memory for 700, 720, 750,
755 families are all compatible.
= Removable; ✂ = Withdrawn from marketing
✂ 755CDV
TFT color - projector LCD - Pentium
    
Pentium 75/50 MHz
256 KB write-through / 12ns
direct mapped / soldered
64 bit to L2 / 32 bit to mem
9545--GBK 9545-GBL
810 MB / 14 ms 1.2 GB / 12ms
Sept 95 / Oct 96 Sept 95 / Oct 96
non-parity
Memory upgraded via
x 1 open socket for IC mem-
ory card for 40 MB max or
y new DIMM technology for
max of 36 MB with 4, 8, or 16
MB JEDEC 72 pin SO DIMMs
on optional Memory Module
Adapter.
Nickel hydride (NiMH) / smart
Supports opt
2.5 to 8 hours
Lithium ion
1.7 hrs / 1.2 hrs
Easy-Setup is entered by holding F1
when turning on.
170 MB IDE
250 MB IDE
340 MB IDE
540 MB IDE
810 MB IDE
1.2 GB IDE
(1 slot / 1 bay)
(2 slot / 2 bay)
Same features as ThinkPad 755CD except
includes:
➭ ➭ ➭ ➭ ➭ Overhead projector LCD
➭ ➭ ➭ ➭ ➭ Supports optional lithium ion battery
➭ ➭ ➭ ➭ ➭ Mind Path     Remote Control IR55 F/X
Integrated Mwave DSP provides:
x Data modem function
- V.22bis (2400 bps)
- V.32 (9600 bps)
- V.32bis (14.4 Kbps)
y Fax modem function
- G3 fax send/receive (14.4 Kbps)
z Audio function
- Stereo waveform record and playback
- Qsound support (3-D effect)
- 32 voice MIDI wave table synthesizer
- SoundBlaster support; Text to speech
{ Telephone function
- Full telephone (can use opt headset)
- Telephone answering machine
- Full duplex speakerphone
➮ Software upgradeable (to 28.8 & DSVD)
PREINSTALLED APPLICATIONS
- IBM DOS 7.0
- Windows 3.11
- OS/2 Warp 3.0 (dual boot) w/ selected
BonusPak
- IBM PC Card Director for PCMCIA
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad Features; Diskette Factory
    
1. Lotus cc:Mail, e-mail for Global
network; 2. Lotus Organizer 1.12
3. Lotus ScreenCam 1.0
4. Triton CoSession Host

5. PRODIGY
7. SofNet FaxWorks Voice 3.0
8. Video For Windows 1.1 Runtime
9. Monologue (text to speech)
10. Puma TranXit; 11. Taxi
12. AlphaNet FollowFax
13. REPRINT; 14. COMPEL PE
15. TalkWorks; 16. Reuters

17. Asymetrix Digital Video Producer
18. Mind Path Presentation F/X Pro
19. Asymetrix 3D F/X
20. CD-ROM Catalog/Sampler
The left bay (UltraBay) supports either the
standard diskette drive or standard
CD-ROM. CD-ROM ships in this bay from
factory.
To use diskette and CD-ROM simultane-
ously, need FDD External Kit and one of four
docking solutions
Liftable (pop-up) keyboard to access and
remove CD-ROM, diskette drive, disk,
66G2847/9
battery, and memory
84G2391
66G2849
Exceeds MPC2 standard
84G2150
84G8250
85G8562
3545001
FEATURES OF 755CDV MODELS
3546001
66G3510 Discharge battery via mouse click
66G3520 Battery life indicator
Non-disruptive battery exchange
66G0108
Standby, suspend, and hibernation modes
US EPA Energy Star compliant
85G1513
Personalized nameplate in molded indention
85G8561
Personalization screen at startup
International Warranty Service
71G2560
24 hour / 7 day telephone, bulletin
84G1301
board, fax, electronic, and Internet
(http://www.pc.ibm.com) support
29H8000
IBM warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(755CDV) Compiled by Roger Dodson, IBM. October 1996
