ThinkPad 755CD - withdrawn
         
: : : : :
IBM ThinkPad
Processor type
L2 cache
Processor / L2 upgrade
Removable diskette
Removable CD-ROM
Price
Type - model
Removable disk - size
Avail / withdrawn date
Display - type
Display - techology
Display - diagonal size
Graphics - controller
Graphics - vendor
Graph - arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Keyboard slope
Mouse/pointing
Ext keyboard support
Dimensions
Color
Weight(w/batt/CD-ROM)
Battery - type
Battery - life
Charge time - on / off
Architecture
Docking Station
Port replicator
PCMCIA 2.1 slots
Serial / parallel ports
Other features
Video function (below)
DSP function
Data/fax modem
Audio support
Audio in/out jacks
Telephone
Infrared ports
Security
Preinstalled software
Warranty
Enhanced Video Card in 755CD provides:
- Acceleration of 'Video for Windows' motion
video with scaling and interpolation of image.
Video may be scaled up to full screen without
frame rate degredation.
- Composite in and S-Video in for video
capture (capture and digitize video from a TV
or VCR), still image capture (capture and
digitize still photo images), and overlay (view
video on LCD like with a TV, VCR, or
camcorder without capturing it to disk). So
can hook up a TV or VCR and run it on the
ThinkPad screen.
- Composite out and S-Video out to TV
meaning use a TV as if an external display
(connect to video out port; NTSC or PAL);
or record on a VCR the contents of the
755CD screen.
- Mini game port for MIDI or joystick (includes
MIDI/joystick cable)
- Includes a video in and video out port
(includes two video in/out cables)
- Use software called Digital Video Producer
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❏ ❏ ❏ ❏ ❏ = Upgradeable; ❍ = Removable; ✂ = Withdrawn from marketing
✂ 755CD
TFT color - DX4
IntelDX4     100/33 MHz
None
to Pentium 75/50 MHz which
includes 256 KB L2 cache
Internal 3.5" 1.44 MB ❍ / supports internal 2.88 MB diskette
Supports PCMCIA Cartridge in diskette bay
5.25" CD-ROM ❍ ❍ ❍ ❍ ❍ / double speed / multi-session / XA / front loaded / IDE
9545-9BD 9545-9BE
540 MB / 14 ms 810 MB / 14 ms
Oct 1994 / Jun 96 Oct 94 / Jun 96
VGA color / 640 x 480 / 65,536 simultaneous colors
Black Matrix TFT - active matrix
10.4 inch / 100 to 1 contrast ratio
WD90C24A2 with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 w/ 256 colors (up to 75 Hz)
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 40 MB 70 ns / parity
1 socket / 5 volt
2, 4, 8, 16, 32 MB ICs or 4, 8, 16 MB DIMMs that
work on optional Memory Module Adapter
Full size alp/num / 85 (8 Fn key functions)
Yes (legs pop out)
TrackPoint III
Yes (with option cable)
11.7 x 8.3 x 2.2" (214 cubic inches)
Black
7.3 pounds
Nickel hydride (NiMH) / intelligent
3 to 9 hours
1.7 hrs / 1.2 hrs
AT bus (ISA)
Dock I and II
Port Replicator I and II
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional); non-DMA
APM-aware BIOS / Universal AC adapter (35 watts) / Selectable boot
Daughtercard with video acceleration, composite in/out, game port
Mwave MDSP2780 DSP with modem, fax, audio, telephony function
Data/fax modem function via DSP
16 bit audio chip on planar with Mwave DSP
Int stereo speakers .5 watts (with dial volume control) / int microphone
Input jack / output jack
Telephone / answering machine / full duplex speakerphone
Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Power-on password / Hard disk password / Supervisor password / Hardware
security loop / Keyboard lock / Locking device keyhole (Kensington
MicroSaver cable lock) / PCMCIA card lock
IBM DOS, Windows 3.11, OS/2 Warp 3.0, and all appls listed to right:
3 year - ThinkPad EasyServ (optional Overnight Repair Service) or carry-in
Compatible in all ThinkPad 360 family, 750
family, 755 family:
- Disks:
- Dock I
- Dock II
- Port Replicator I (w/ PCMCIA)
- Port Replicator II
- 1.44 MB diskette
- 2.88 MB diskette
Options for 755CD:
- PCMCIA Cartridge
- NiMH Battery Pack II
- Lithium Ion Battery (Pentium only) 85G8561
- Li-Ion Batt Pack II (Pentium only) 29H9329
- CDPD Mobile Module
- FDD External Attachment Kit
- Pentium/L2 upgrade (DX4 mod) 29H8755
✂ 755CD
TFT color - Pentium
    
Pentium 75/50 MHz
256 KB write-through / 12 ns
direct mapped / soldered
64 bit to L2 / 32 bit to mem
9545-FBK 9545-FBL
810 MB / 14 ms 1.2 GB / 12 ms
Sept 95 / Jun 96 Sept 95 / Jun 96
non-parity
Memory upgraded via
x 1 open socket for IC mem-
ory card for 20 MB max or
y new DIMM technology for
max of 40 MB with 4, 8, or 16
MB JEDEC 72 pin SO DIMMs
on optional Memory Module
Adapter.
Nickel hydride (NiMH) / intelligent
2.5 to 8 hours Supports
1.7 hrs / 1.2 hrs optional Li-Ion
170 MB IDE 66G2847/9
250 MB IDE 84G2391
340 MB IDE 66G2849
540 MB IDE 84G2150
810 MB IDE 84G8250
1.2 GB IDE 85G8562
(1 slot / 1 bay) 3545001
(2 slot / 2 bay) 3546001
66G3510
66G3520
std in newer
66G0108
84G1301
85G1513
71G2560
66G3618
ThinkPad 755CD strengths over 755CE / CSE:
➭ ➭ ➭ ➭ ➭
Mobile multimedia - exceeds MPC2 standard
➭ ➭ ➭ ➭ ➭
Removable, double speed, 5.25" CD-ROM
➭ ➭ ➭ ➭ ➭
Video card (acceleration, composite in/out)
➭ ➭ ➭ ➭ ➭
Joystick/MIDI port
➭ ➭ ➭ ➭ ➭
Stereo speakers
The left bay (UltraBay) supports either the
standard diskette drive or standard
CD-ROM. CD-ROM ships in this bay from
factory.
Liftable (pop-up) keyboard to access and
remove CD-ROM, diskette drive, disk,
battery, and memory
Integrated Mwave DSP provides:
x Data modem function
- V.22bis, V.32, V.32bis (14.4 Kbps)
y Fax modem function
- G3 fax send/receive (14.4 Kbps)
z Audio function
- Stereo waveform record and playback
- Qsound support (3-D effect)
- 32 voice MIDI wave table synthesizer
- SoundBlaster support;Text to speech
{ Telephone function
- Full telephone (can use opt headset)
- Telephone answering machine
- Full duplex speakerphone
➮ Software upgradeable (to 28.8 & DSVD)
PREINSTALLED APPLICATIONS
- IBM DOS 6.3 (DOS 7.0 on Pentium mod)
- Windows 3.11
- OS/2 Warp 3.0 w/ selected BonusPak
- IBM PC Card Director for PCMCIA
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad Features

1. Lotus cc:Mail, e-mail for Advantis
network; 2. Lotus Organizer 1.12
3. Lotus ScreenCam 1.0
4. Triton CoSession Host

5. PRODIGY ; 6. America Online
7. SofNet FaxWorks Voice 3.0
8. Video For Windows 1.1 Runtime
9. Monologue (text to speech)
10. Puma TranXit; 11. Taxi
12. AlphaNet FollowFax
13. REPRINT; 14. COMPEL PE
15. TalkWorks; 16. Reuters

17. Asymetrix Digital video Producer
18. Mind Path Presentation F/X Pro
19. CD-ROM Catalog/Sampler
To use diskette and CD-ROM simultane-
ously, need FDD External Kit and one of
four docking solutions
ThinkPad IC DRAM memory for 700, 720,
750, 755 families are all compatible
FEATURES OF 755CD MODELS
Discharge battery via mouse click
Battery life indicator
Non-disruptive battery exchange
Standby, suspend, and hibernation modes
US EPA Energy Star compliant
Personalized nameplate in molded
indention
Personalization screen at startup
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, electronic, and Internet
(http:\\www.pc.ibm.com) support
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(755CD) Compiled by Roger Dodson, IBM. June 1996
(dual boot)



SM Money Net
