ThinkPad 755CX - withdrawn
✂ 755CX
         
: : : : :
IBM ThinkPad
No DSP - 640 x 480
Processor type Pentium
Coprocessor socket N/A (standard in Pentium)
L2 cache 256 KB / write-through / direct mapped / 12 ns / soldered
Internal 3.5" 1.44 MB ❍ / supports internal 2.88 MB diskette
Removable diskette
Supports PCMCIA Cartridge or CDPD in diskette bay
Removable CD-ROM Not supported
$ 3,749 ➷
Price (retail USD)
Type - model 9545-SBJ
Part number 84G6381
Removable disk - size 540 MB
14 ms ❍
Removable disk - spd
Avail / withdrawn date Jun 95 / Jun 96 Jun 95 / Jun 96
Display - type VGA color / 640 x 480
Display - colors 65,536 simultaneous colors
Display - techology Black Matrix TFT - active matrix
Display - diagonal size 10.4 inch / 100 to 1 contrast ratio
Graphics - controller WD90C24A (Rev C) with 1 MB DRAM
Graphics - vendor Western Digital / External SVGA to 1024 x 768 w/ 256 colors (up to 75 Hz)
Graph - arch/data path VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
Memory - std / max 8 MB / 40 MB 70 ns / non-parity / 5 volt
Mem - sockets empty 1 socket (parity memory supported but w/o parity)
Mem-options available 2, 4, 8, 16, 32 MB ICs or 4, 8,16 MB DIMMs that
Keyboard / # of keys Full size alp/num / 85 (8 Fn key functions)
Keyboard slope Yes (legs pop out)
Mouse/pointing TrackPoint III
Ext keyboard support Yes (with option cable)
Dimensions 11.7 x 8.3 x 1.96" (190 cubic inches)
\Weight (with battery) 6.1 pounds
Battery - type NiMH / intelligent
Battery - life 2.6 to 8 hours
Charge time - on / off 1.7 hrs / 1.2 hrs
Architecture AT bus (ISA)
Docking Station Dock I and II
Port replicator Port Replicator I and II
PCMCIA 2.1 slots 2 Type I or 2 Type II or 1 Type III
Serial / parallel ports One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / Universal AC adapter (35 watts) / Selectable boot
Video function None
DSP function None (but can order DSP upgrade) Mwave MDSP2780 DSP with modem, fax, audio, telephony function
Data/fax modem None (but can order DSP upgrade) Data/fax modem function via DSP
Audio support None (but can order DSP upgrade) 16 bit audio chip on planar with Mwave DSP
Audio in/out jacks None (but can order DSP upgrade) Input jack supports microphone / Output jack supports headphone/speakers
Telephone None (but can order DSP upgrade) Telephone (w/ opt headset) / answering machine / full duplex speakerphone
Infrared ports Infrared ports (front and back) / IRDA compatible / up to 115 kbs
Power-on password / Hard disk password / Supervisor password / Hardware
Security
security loop / Keyboard lock / locking device keyhole (Kensington lock) /
PCMCIA card lock
IBM DOS 7.0, Windows
Preinstalled software
3 year - ThinkPad EasyServ (optional Overnight Repair Service) or carry-in
Warranty
Upgradeable or Integrated Mwave DSP
provides:
x Data modem function
- V.22bis (2400 bps)
- V.32 (9600 bps)
- V.32bis (14.4 Kbps)
y Fax modem function
- G3 fax send/receive (14.4 Kbps)
z Audio function
- Stereo waveform record and playback
- Qsound support (3-D effect)
- 32 voice MIDI wave table synthesizer
- SoundBlaster support
- Text to speech (via Monologue)
{ Telephone function
- Full telephone (can use opt headset)
- Telephone answering machine
- Full duplex speakerphone
➮ Software upgradeable (to 28.8 and DSVD)
Easy-Setup is entered by holding F1 when
turning on.
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business days average turnaround). Overnight repair option in US available for $99.
❏ ❏ ❏ ❏ ❏ = Upgradeable ❍ = Removable
✂ = Withdrawn from marketing effective June 1996
✂ 755CX
DSP - 800 x 600
    
75/50 MHz
(Diskette bay is called UltraBay)
$ 4,149 ➷
$ 4,849
9545-SBK 9545-HBD 9545-HBE
85G1669 85G8555
❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏
❍ ❍
810 MB 540 MB
14 ms ❍ 14 ms ❍
SVGA color / 800 x 600
10.4 inch / 110 to 1 contrast ratio
work on optional Memory Module Adapter
Lithium ion / intelligent
Supports optional 3 to 9 hours
Li-Ion battery 2-2.5 hrs / 1.5-2 hrs
None
Internal speaker (with dial volume control) and internal microphone

3.11, OS/2 Warp Version 3 and all appls listed to right:
Compatible in all ThinkPad 360 family, 750 family,
755 family:
- Disks:
- Dock I
- Dock II (2 slot / 2 bay)
- Port Replicator I (w/ PCMCIA)
- Port Replicator II
- 1.44 MB diskette
- 2.88 MB diskette
Options for 755CX:
- PCMCIA Cartridge
- FDD External Attachment Kit
- CDPD Communications Module 71G2560
- Mwave DSP Upgrade
ThinkPad IC DRAM memory for 700, 720, 750,
755 families are all compatible
➷ Price decrease effective November 7, 1995
$ 5,249 $ 5,699
9545-HBL
85G8524 85G7518
❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏ ❏
1.2 GB ❍
810 MB
14 ms ❍
12 ms
May 1995 May 1995 Sept 95 / Jun 96
Memory upgraded via
x 1 open socket for IC mem-
ory card for 40 MB max or
y new DIMM technology for
max of 40 MB with 4, 8, or
16 MB JEDEC 72 pin SO
DIMMs on optional Memory
Module Adapter.
Supports optional
NiMH battery
Intelligent battery with a processor to
allow accurate monitoring of battery
condition and accurate fuel guage.
170 MB IDE 66G2847
250 MB IDE 84G2391
340 MB IDE 66G2849
540 MB IDE 84G2150
810 MB IDE 84G8250
1.2 GB IDE 85G8562
(1 slot / 1 bay) 3545001
3546001
66G3510
66G3520
std in newer
66G0108
84G1301
66G3618
2420801
Same as ThinkPad 755CE except includes:
➭ ➭ ➭ ➭ ➭ Pentium 75/50 MHz
➭ ➭ ➭ ➭ ➭ 256 KB L2 cache
➭ ➭ ➭ ➭ ➭ SVGA 800 x 600 LCD (on some models)
➭ ➭ ➭ ➭ ➭ Non-parity memory
➭ ➭ ➭ ➭ ➭ Lithium ion battery (on two models)
➭ ➭ ➭ ➭ ➭ DOS 7.0 (instead of DOS 6.3) and Mind Path Pro
PREINSTALLED APPLICATIONS
- IBM DOS 7.0
- Windows 3.11
- OS/2 Warp 3.0 (dual boot) w/ selected
BonusPak
- IBM PC Card Directorä for PCMCIA
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad features; Diskette Factory
    
1. Lotus cc:Mail, e-mail for Global
network
2. Lotus Organizer 1.12
3. Lotus ScreenCam 1.0
4. Official Airline Guide
5. Triton CoSession Host

6. PRODIGY ; 7. America Online
8. SofNet FaxWorks Voice 3.0
9. Video For Windows 1.1 Runtime
10. Monologue (text to speech)
11. Puma TranXit (infrared function)
12. Taxi
13. Second Nature Screen Saver

14. Farallon Replica
15. AlphaNet FollowFax
16. SEDONA REPRINT
17. COMPEL Personal Edition

18. Audiofile TalkWorks
SM
19. Reuters Money
20. Mind Path Presentation F/X Pro
ThinkPad 755CX supported batteries:
- NiMH Battery Pack II
- Lithium Ion
- Li-Ion Battery Pack II
- Travel Quick Charger
(for NiMH or Li-Ion)
FEATURES OF 755CX MODELS
Discharge battery via mouse click
Battery life indicator
Non-disruptive battery exchange
Standby, suspend, and hibernation modes
US EPA Energy Star compliant
Personalized nameplate in molded indention
Personalization screen at startup
3 year warranty
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBM or dealer warranty/service
Online Housecall (remote diagnostics)
30 day money back guarantee
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(755CX) Compiled by Roger Dodson, IBM. June 1996
SelectaSystem
    
    

Flight Disk 1.0


Network
85G1513
85G8561
29H9329
85G1522
