IBM
ThinkPad 701 - withdrawn
IBM ThinkPad
dual scan color
Processor 3.3 volt
80486DX2
Processor speed
50/25 MHz
Coprocessor socket
N/A (math coprocessor std in DX2/DX4)
Memory cache
8 KB in DX2; 16 KB in DX4 / no L2 cache
Diskette
External 3.5" 1.44 MB / hot-pluggable
Removable CD-ROM
Not supported
Price (retail USD)
$ 2,499
Type - model all 2630
US2
Removable disk - size
360 MB 540
Hard disk - spd ms
13
Available date
Mar 95
Display - type
VGA color / 640 x 480
Display - colors
65,536 simultaneous colors
Display - techology
Dual scan
Display - diagonal size
10.4 inch / 20 to 1 contrast ratio
Graphics - controller
CT-65545 with 1 MB DRAM
Graphics - vendor
Chips & Technologies / External SVGA to 1024 x 768 256 colors (up to 70 Hz)
Graph - arch/data path
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
Memory - std / max
4 / 36 MB
Memory - type
70 ns / non-parity / 3.3 volt
Mem - sockets empty
1 socket
Mem-options available
4, 8, 16, 32 MB SO-DIMMs
Keyboard / # of keys
Full size alp/num / 85 key (15 Fn key functions)
Keyboard slope
Yes (use MultiPort II stand that flips out)
Mouse/pointing
TrackPoint III on TrackWrite keyboard
Ext keyboard support
Yes (no cable required)
Dimensions
9.7 x 7.9 x 1.7" (130 cubic inches)
Color
Black
Weight (with battery)
4.5 pounds
Battery - type
Super NiCad or NiMH (DX4 mdls built after 9/95)
Battery - life
2.5 to 7 hours
Charge time - on / off
1.5 hrs / battery will not charge if unit is off
Architecture
AT bus (ISA)
Docking Station
Dock II (requires optional Dock II Adapter Kit)
Port replicator
None (use standard MultiPort II)
PCMCIA 2.1 slots
2 Type I or 2 Type II or 1 Type III
Serial / parallel ports
One 9 pin; 16550A / ECP/EPP parallel 36 pin (IEEE 1284); non-DMA
Other features
APM-aware BIOS / Wallmount AC adapter (30 watts) w/ 2 prongs / Selectable boot
Functions
Data modem, fax modem, audio, telephony function
Data/fax modem
14.4/14.4 data/fax modem function (with RJ11 jack)
Audio support
16 bit audio chip on planar (ESS688 and Yamaha OPL3) / FM Synthesis
Internal speaker (with Fn key volume control) and internal microphone
Audio in/out jacks
Input jack / microphone jack / output jack
Telephone
Telephone / answering machine / full duplex speakerphone
Infrared ports
Infrared port (on back) / IRDA 1.0 compatible / up to 115.2 Kbps
Security
Power-on password / locking device keyhole also called MicroSaver security
connector (Kensington lock)
Preinstalled software
IBM DOS 6.3, Windows 3.11, (and OS/2 Warp on DX4 models),
and all appls listed to right:
Warranty
3 year - EasyServ only (optional onsite special bid only)
Configuration Utility is entered by Fn+F1 at any
time
MultiPort II (ships standard) is 1.7 x .9 x 10" and
has ports for:
- Mouse/Numpad connector (6 pin)
- External keyboard connector (6 pin)
- EPP parallel port (25 pin)
- Serial connector (RS-232D - 9 pin)
- Audio line in (3.5 mm)
- Audio line out (3.5 mm)
- External display connector (15 pin)
- DC input connector
ECP/EPP port (36 lines) connects either the
external floppy or a printer. The standard
External Diskette Drive Cable (13.2") has a
36-pin and a 26-pin connector. The Standard
Printer Cable Adapter (7.1") has a 36-pin
connector and a 25-pin connector (so a
conventional printer cable is needed)
Withdrawn from marketing eff December 1995
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business days average turnaround). Overnight repair option in US available for $99.
= Upgradeable;
= Removable;
= Withdrawn from marketing on or before June 1996
701CS
IntelDX4
75/25 MHz
2,749
1,499
1,649 1,799
US5
2SU
5SU
7SU
360
540
720
13
13
13
13
Mar 95 Mar95 Mar95 Sep95
8 / 40 MB
With keyboard open it
expands from 9.7" to 11.5"
or optional NiMH
Compatible in all 701 models:
-
Disks: 540 MB disk 13 ms
-
Dock II (2 slot / 2 bay)
-
Dock II Adapter Kit
-
4 MB SO-DIMM 3.3v
-
8 MB SO-DIMM 3.3v
-
16 MB SO-DIMM 3.3v
-
32 MB SO-DIMM 3.3v
-
Universal AC Adapter 30 watts 04H8367
-
AC Adapter 30 w, wall, 2 pin 10H4020
-
AC Adapter 35 w, ww, 3 pin
-
Super NiCad Battery
-
NiMH Battery
-
MultiPort II
-
External diskette with cable
-
EPP Printer Cable &
Cable Pack
ThinkPad 360, 750, 755 family disks, batteries,
memory, and Dock I are NOT compatible
in the ThinkPad 701 family
DX4 models had price decrease effective Feb 9, 1996
701C
TFT color
80486DX2
IntelDX4
50/25 MHz
75/25
The 701 has a External Bus
Connector to attach either
standard MultiPort II or (with
optional Adapter Kit) Dock II
$ 2,999
3,299 1,999
2,149
UT2
UT5
2TU
5TU
360
540
360
540
13
13
13
13
Mar95
Mar95 Mar95 Mar95 Sep95
VGA color / 640 x 480
65,536 simultaneous colors
TFT - active matrix
10.4 inch / 100 to 1 contrast ratio
4 / 36 MB
8 / 40 MB
The two wings (ends) of the
TrackWrite keyboard slide
into position automatically
every time the lid is opened
or closed
Fn key functions:
- Configuration Utility
- Battery Status
- Standby/Suspend
- Hibernation
- Speaker off (audio mute)
- Hard disk off
- LCD or CRT or both
- Reverse appearance
- Increase/decrease contrast
- Brighten/dim LCD
- Speaker volume up/down
04H6894
720 MB disk 13 ms
10H4096
84G3587
04H6196
92G7259
92G7261
92G7263
92G7281
85G6680
10H4019
25H4862
10H4021
10H4068
10H4069
ThinkPad 701CS / 701C strengths:
Full sized, folding TrackWrite keyboard
Full sized 10.4" color dual scan or TFT display
Subnotebook size and weight (4.5 pounds)
Audio, 14.4/14.4 data/fax modem, telephony
Infrared communication
TrackPoint III and removeable disk
Integrated chipsets provide:
2,299
Data modem function
7TU
- V.22bis (2400 bps)
720
- V.32 (9600 bps)
13
- V.32bis (14.4 Kbps)
Fax modem function
- Class 1 fax send/receive (14.4 Kbps)
Audio function
- 16 bit audio / 44.1 kHz sampling rate
- Stereo waveform record and playback
- 18 voice MIDI wave table synthesizer
- SoundBlaster support
- Text to speech (via Monologue)
Telephone function
- Full telephone (can use opt headset)
- Telephone answering machine
- Full duplex speakerphone
PREINSTALLED APPLICATIONS
- IBM DOS 6.3
- Windows 3.11
DX4 systems include OS/2 Warp 3.0
(dual boot) with selected BonusPak
- IBM PC Card Director for PCMCIA
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad Features
- Diskette Factory
1. Lotus cc:Mail , e-mail for the Global
network
2. Lotus Organizer 1.12
3. Lotus ScreenCam 1.0
4. Triton CoSession Host
5. PRODIGY ; 6. America Online
7. SofNet FaxWorks Voice 3.0
8. Video For Windows 1.1 Runtime
9. Monologue (text to speech)
10. Puma TranXit (infrared function)
11. Taxi
12. AlphaNet FollowFax
13. SEDONA REPRINT
14. COMPEL Personal Edition
15. Audiofile TalkWorks
SM
16. Reuters
Money Network
FEATURES OF 701CS / 701C MODELS
Battery life indicator
Non-disruptive battery exchange
Standby, suspend, hibernation, and
RediSafe modes
US EPA Energy Star compliant
Personalized nameplate in molded indention
HELPWARE
3 year warranty
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, electronic,and Internet
(http://www.pc.ibm.com) support
IBM or dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(701) Compiled by Roger Dodson, IBM. June 1996
