ThinkPad 600 - September 1998 - withdrawn
â â
IBM ThinkPad
Intel â Mobile Pentium â II 300MHz
Processor type/path
Processor features No upgrade / processor, L2 cache, and mem cntr (North Bridge) on Mobile Module
L2 cache 512KB / sync pipelined burst / ECC / 150MHz (half speed)
Diskette (removable) 3.5" 1.44MB / use in UltraslimBay / ships in external diskette enclosure with a cable
External FDD port External diskette port on right side (can use simultaneously with internal CD-ROM)
CD-ROM (removble) 5.25" CD-ROM / 24X-10X
EIDE (ATAPI) / PIO Mode 4 for W95; DMA Mode 2 for NT / use in UltraslimBay
19 Option: 2X
DVD (removable)
SuperDisk (LS-120) Option: Removable UltraslimBay option / supports 1.44MB and 120MB diskette
Type - model 2645-45U
Preload (see side) Windows 98
Disk (removable) 5.1GB
Avail / withdr date September 1998 / June 1999
Memory 64MB std / 288MB
Two 144-pin sockets / 32MB on planar and 1 socket used by 32MB SO-DIMM /
1 socket available / sockets accessed by removing screw on bottom
Display 13.3" (337.8mm) TFT color / Active Matrix / XGA / 75ms / 100 to 1 contrast ratio/
640x480 or 800x600 (16.7 million colors), 1024x768 (65,536 colors) /
150 nits (AC), 90 nits (battery) / 180 degree tilt
Graphics - controller NeoMagic
Graphics - arch 2MB / iDRAM
Graphics - features Support for DirectX 5.0, DDC2B, color space conversion
Graphics - external External SVGA to 1024x768 with 65,536 colors (800x600 with 16.7 million colors)
Disk Left front / removable via coin screw or 2.5mm Allen wrench / SMART / upgradeable
Disk controller Enhanced IDE / busmaster / PCI 2.1 / South Bridge / PIIX4
DMA Mode 2, Ultra DMA/33, or PIO Mode 4 / supports 2nd disk inopt HDD adapter
Keyboard / Fn keys Full size alp/num keys / 9 Fn key functions / integrated palm rest
Keyboard slope Flat keyboard (does not lift up) / optional Port Replicator adds slope
TrackPoint â / Press-to-Select / Release-to-Select / dragging / click pace /
Pointing device
center click button for scrolling or magnifying glass / suspension top / spare caps
Dimensions 36 Appoximately 11.8 x 9.4 x 1.4" (155 cubic inches); 300mm x 240mm x 36.5mm
2
Weight 5.01 lbs (2.27 kg) with travel cover and battery only
Battery - type Lithium Ion / intelligent / remove from base / locked with latch
Battery - life 10 3.0 hrs / no non-disruptive battery exchange
Charge time - on / off 2 to 3 hrs / 1.5 to 2.5 hrs
Architecture Intel 440BX and PIIX4 (EIDE, ISA Bridge, USB)
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, CardBus, USB, ext expansion)
TI PCI1250A for CardBus / LM75 digital thermometer / PC97338 Super I/O /
ISA (audio, modem, diskette, serial, parallel, infrared, ext expansion)
Port replicator SelectaBase 600 / PC Card Enabler
Docking Station SelectaDock III / SelectaDock I and II
PC Card Std slots 2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit / PCMCIA 2.1 / Zoomed Video
USB / serial / parallel One USB / one 9 pin serial; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / AC Adapter barrel, 3 prong (56 watts) / Selectable boot
Video in/out None
MPEG decoder None (software support for MPEG-1 in Windows 98)
Data/fax modem 56K (x2, upgradeable to v.90
integrated Mwave â 3780i DSP / international programmable DAA / modem cable
Audio support CS4237B / 16-bit / SRS 3D audio / FM synthesis
Int stereo speakers (front) / .5 watt / Fn+PgUp and PgDn (volume) / int microphone
Jacks Input jack (3.5 mm) / Output jack (3.5 mm) / full duplex
Infrared ports Infrared port (on right) / IrDA 1.1 compatible / up to 4Mbps
Security Power-on password / hard disk password / supervisor password / security keyhole /
personalization / phillips-head screw on base for memory / opt Allen screw for disk
11
Limited warranty 3 year - carry-in or ThinkPad EasyServ
average turnaround)
15
Service options On-site
purchase date
- 56K PC Card Modem Kit
- 56K PC Card Modem/Cellular capab
- V.90 PC Card Modem with XJACK
- EtherJet PC Card Combo
- IBM 10/100 EtherJet CardBus PC Cd
- UltraslimBay HDD adapter (for 2nd disk)05K5336
- SuperDisk LS-120 (UltraslimBay)
- 2X DVD Drive (UltraslimBay)
The right bay (UltraslimBay) has LED on release
latch to provide status; supports warm swapping:
·
std diskette and weight-saver bezel
·
std or optional CD-ROM
·
optional DVD drive 19
·
optional Zip 100MB drive (cold swap)
·
opt LS-120 SuperDisk drive (cold swap)
·
opt HDD adapter; second disk (cold swap)
·
optional ThinkPad Proven
All trademarks are the property of their respective owners
1
5 speed / bootable / warm swap
5
DVD-ROM drive / removable UltraslimBay option / warm swap
2645-85U
Windows NT 4.0
4
/ 12ms (read);13ms (write) / upgradeable
25
maximum / SDRAM / non-parity / 66MHz / 3.3v
ä ä
MagicGraph128XD (NM2160B) / 128-bit SVGA accelerator
ä
(embedded) / Zoomed Video support
9
) / 14.4Kbps fax / telephony / voice-capable
32
, M-F, 8-5, next bus day (72 cities) / service agreements up to 5 years from
04K0052 - 6.4GB disk, 13ms, Ultra DMA/33
02K4196 - 10GB disk, 12ms, Ultra DMA/33
24
10L7393 - SelectaBase 600
72H4534 - PC Card Enabler
08L3147 - PC Card Enabler with EtherJet
- SelectaDock I
20L1929 - SelectaDock II
05K8890 - SelectaDock III
- 56 watt AC Adapter (barrel; 3 prong)
- 24X-10X CD-ROM (UltraslimBay;
includes external diskette enclosure)
- 16MB SO DIMM 3.3v NP SDRAM
- 32MB SO DIMM 3.3v NP SDRAM
- 64MB SO DIMM 3.3v NP SDRAM
- 64MB SO DIMM 3.3v NP SDRAM
- 128MB SO DIMM 3.3v NP SDRAM
- ThinkPad 600 Li-Ion Battery
ä
12
solutions
- External Battery Charger
- Zip 100MB UltraslimBay Drive
/ 66MHz system bus
All models:
- C: drive is FAT16 of 2GB
- D: drive is FAT32 (if W98) or
FAT16 (if NT) of remaining space
17
/ PC Card Enabler with Advanced EtherJet
ä
31
Rapid Depot Repair (3 business day
17
ä
17
17
WINDOWS 98 PRELOAD
- Microsoft â Windows â 98
·
Online User's Guide
·
ThinkPad Utilities
·
ThinkPad Configuration Program
·
RingCentral
·
Ergonomics
·
IBM Product Registration
·
Puma IntelliSync 97 (infrared)
·
IBM Global Network Dialer
·
Netscape Navigator web browser
·
IBM Update Connector
·
Artisoft ConfigSafe
·
Norton AntiVirus
Lotus â SmartSuite Millennium CD-ROM
Customization Center CD-ROM
Product Recovery CD-ROM (with boot
diskette)
WINDOWS NT PRELOAD
- Windows NT â Workstation 4.0
·
Online User's Guide
·
ThinkPad Utilities
·
ThinkPad Configuration Program
·
Puma IntelliSync 97 (infrared)
·
ConfigSafe
·
IBM Global Network Dialer
·
Netscape Navigator web browser
·
Norton AntiVirus (OEM Version)
·
Ergonomics
·
IBM Product Registration
·
SystemSoft CardWizard
Lotus SmartSuite Millennium CD-ROM
Customization CD-ROM (apps/drivers)
Product Recovery CD-ROM (with boot
diskette)
17
System does not have non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation, or under AC power.
ThinkPad 600 supported disks:
- 3.2GB 13ms read/14ms write
9.5 mm PIO Mode 4 or Ultra DMA/33
- 4.0GB 13ms read/14ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
- 5.1GB 12ms read/13ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
- 6.4GB 13ms read/14ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
FEATURES
Wired for Management 1.1a
PC 97 compliant
DMI 2.0 compliant
DMI instrumentation (thermal monitoring)
02K0518
ACPI ready (APM enabled)
36L9293
Wake on LAN â support
12J2467
C: is 1.99GB, D: is up to 1.99GB, etc.
83H6741
Setup Guide, User's Reference, Quick
05K4820
Reference and Service Information
3547001
Card, Options by IBM Catalog,
3547002
Windows 98 or NT manual
3547003
Plug and Play 1.0a
83H6739
Standby, suspend, safe suspend, and
12J2471
hibernation modes
ENERGY STAR compliant
76H0293
International Warranty Service
76H0294
IBM SystemXtra â
35
76H0295 ,
24 hour / 7 day telephone
20L0241
board, fax, electronic, and Internet
01K1150
(www.ibm.com/pc/us) support
12J2464
02K6499
37L1504
No warranties are expressed or implied in this summary
(60098)
16
16
28
14
30
, bulletin
