IBM
ThinkPad 600
â â
IBM ThinkPad
Intel â Pentium â MMX
Processor type/path
Processor features No upgrade / processor, L2 cache, and mem cntr (North Bridge) on Mobile Module
L2 cache 512KB / sync pipelined burst (66MHz for Pentium / ECC and half speed for Pent II)
Diskette (removable) 3.5" 1.44MB / use in UltraslimBay (CD-ROM models include external diskette enclosure)
External FDD port External diskette port on right side (can use simultaneously with internal CD-ROM)
CD-ROM (removble) Standard or option: 5.25" CD-ROM / 24X-10X
EIDE (ATAPI) / PIO Mode 4 for W95; DMA Mode 2 for NT / use in UltraslimBay
19 Option: 2X
DVD (removable)
SuperDisk (LS-120) Option: Removable UltraslimBay option / supports 1.44MB and 120MB diskette
Type - model
Processor Pent 233/66
Display (diagonal) 13.0" HPA XGA 12.1 TFT SVGA 12.1 TFT SVGA 13.3" TFT XGA 13.3"TFT XGA 13.3"TFT XGA
Disk (removable) 3.2GB
Preload (see side) W95 OSR2.1
CD-ROM CD-ROM std
Modem 56Kbps
Avail / withdr date Apr 98/Dec 98 Apr 98/Dec 98
Memory - std / max 32MB / 256MB
Memory - upgrade SDRAM / non-parity / 66MHz / 3.3v / 2 sockets available for two JEDEC 144-pin
SDRAM SO-DIMMs / sockets accessed by removing screw on bottom
Display (See below) SVGA or XGA color / TFT or HPA / 180 degree tilt
Graphics - controller NeoMagic
Graphics - arch 2MB / iDRAM
Graphics - features Support for DirectX 5.0, DDC2B, color space conversion
Graphics - external External SVGA to 1024x768 with 65,536 colors (800x600 with 16.7 million colors)
Disk Left front / removable via coin screw or 2.5mm Allen wrench / SMART / upgradeable
Disk controller Enhanced IDE / busmaster / PCI 2.1 / South Bridge / PIIX4
DMA Mode 2, Ultra DMA/33, or PIO Mode 4 / supports 2nd disk in opt HDD adapter
Keyboard / Fn keys Full size alp/num keys / 9 Fn key functions / integrated palm rest
Keyboard slope Flat keyboard (does not lift up)
TrackPoint â / Press-to-Select / Release-to-Select / dragging / click pace /
Pointing device
center click button for scrolling or magnifying glass / suspension top / spare caps
Dimensions 36 Approximately 11.8 x 9.4 x 1.4" (155 cubic inches); 300mm x 240mm x 36.5mm
2
Weight 4.72 lb (2.14 kg) to 5.62 lb (2.55 kg)
Battery - type Lithium Ion / intelligent / remove from base / locked with latch
10
Battery - life 3.0 hrs / no non-disruptive battery exchange
Charge time - on / off 2 to 3 hrs / 1.5 to 2.5 hrs
Architecture Intel 430TX, PIIX4 for Pentium systems / Intel 440BX, PIIX4 for Pent II systems
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, CardBus, USB, ext expansion)
TI PCI1250A for CardBus / LM75 digital thermometer / PC97338 Super I/O /
ISA (audio, modem, diskette, serial, parallel, infrared, ext expansion)
Port replicator SelectaBase 600 / PC Card Enabler
Docking Station SelectaDock III / SelectaDock I and II
PC Card Std slots 2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit / PCMCIA 2.1 / Zoomed Video
USB / serial / parallel One USB / one 9 pin serial; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / AC Adapter barrel, 3 prong (56 watts) / Selectable boot
Video in/out None
MPEG decoder None (software support for MPEG-1 in Windows 95)
Some models: 56Kbps (x2, upgradeable to v.90
Data/fax modem
Audio support CS4237B / 16-bit / SRS 3D audio / FM synthesis
Int stereo speakers (front) / .5 watt / Fn+PgUp and PgDn (volume) / int microphone
Jacks Input jack (3.5 mm) / Output jack (3.5 mm) / full duplex
Infrared ports Infrared port (on right) / IrDA 1.1 compatible / up to 4Mbps
Security Power-on password / hard disk password / supervisor password / security keyhole /
personalization / phillips-head screw on base for memory / opt Allen screw for disk
11
Limited warranty 3 year - carry-in or ThinkPad EasyServ
average turnaround)
15
Service options On-site
13.0" (330.2 mm) HPA XGA color
- HIgh Performance Addressing (Dual Scan)
- 640x480 (16 million), 800x600 (16 million),
or 1024x768 (65,536 simultaneous colors)
- 150ms; 40 to 1 contrast ratio
- 70 nits (AC), 40 nits (battery)
12.1" (307.5 mm) TFT SVGA color
- Active Matrix TFT
- 640x480 (16 million) or 800x600 (16 million
simultaneous colors)
- 75ms; 100 to 1 contrast ratio
- 110 nits (AC), 70 nits (battery)
13.3" (337.8 mm) TFT XGA color
- Active Matrix TFT
- 640x480 (16 million), 800x600 (16 million),
or 1024x768 (65,536 simultaneous colors)
- 75ms; 100 to 1 contrast ratio
- 150 nits (AC), 90 nits (battery)
All trademarks are the property of their respective owners
= Announced August 18, 1998
- withdrawn
ä
233/66MHz
5
DVD-ROM drive / removable UltraslimBay option / warm swap
2645-21U 2645-31U
Pent 233/66
4 / PIO4 3.2GB / PIO4
W95 OSR2.1
Optional
Opt PC Card
Aug 98/Mar 99 Apr 98/Aug 98 Apr 98/Mar 99 Apr 98/Aug 98
3 (TX max=256)
ä ä
MagicGraph128XD
ä
(embedded) / Zoomed Video support
integrated Mwave â 3780i DSP / international programmable DAA / modem cable
32
, M-F, 8-5, next bus day (72 cities) / serv up to 5 yrs from purchase date
- 6.4GB disk, 13ms, Ultra DMA/33
- 10GB disk, 12ms, Ultra DMA/33
- SelectaBase 600
- PC Card Enabler
- PC Card Enabler with EtherJet
- SelectaDock I
- SelectaDock II
- SelectaDock III
- 56 watt AC Adapter (barrel; 3 prong)
- 24X-10X CD-ROM (UltraslimBay;
includes external diskette enclosure)
- 16MB SO DIMM 3.3v NP SDRAM
- 32MB SO DIMM 3.3v NP SDRAM
- 64MB SO DIMM 3.3v NP SDRAM
- ThinkPad 600 Li-Ion Battery
- UltraslimBay HDD adapter (for 2nd disk) 05K5336
- SuperDisk LS-120 (UltraslimBay)
- 2X DVD Drive (UltraslimBay)
- Zip 100MB UltraslimBay Drive
1 or Pentium II 233/66 or 266/66MHz
5 speed / bootable / warm swap
2645-35U 2645-41U
PII 233/66MHz PII 233/66MHz PII 266/66MHz PII 266/66MHz
3.2GB / PIO4 3.2GB / PIO4
W95 OSR2.1 W95 OSR2.1
CD-ROM std CD-ROM std
56Kbps 56Kbps
32MB std / 288MB maximum
(NM2160B) / 128-bit SVGA accelerator
17 / PC Card Enabler with Advanced EtherJet
9
) / 14.4Kbps fax / voice-capable /
ä
31
Rapid Depot Repair (3 business day
17
ä
17
17
The right bay (UltraslimBay) has LED on
release latch to provide status; supports
warm swapping:
·
std diskette and travel cover
·
std or optional CD-ROM
·
optional DVD drive
·
opt LS-120 SuperDisk drive (cold swap)
·
optional Zip 100MB drive (cold swap)
·
optional HDD adapter (cold swap)
·
optional ThinkPad Proven
2645-51U 2645-A1U
4.0GB / PIO4 None (AAP)
W95 OSR2.1 Blank (no disk)
CD-ROM std None (AAP)
56Kbps 56Kbps
WINDOWS 95 PRELOAD
- Microsoft â Windows â 95 OSR2.1
·
Internet Explorer 4.01
·
Online User's Guide
·
ThinkPad Configuration Program
·
ThinkPad Customization Center
·
Puma IntelliSync 97 (infrared)
·
IBM AntiVirus 3.02 (not installed)
·
ConfigSafe 1.05 (must install)
·
IBM Global Network Dialer 4.15.6 with
Netscape Navigator web browser
Intel LANDesk â Client Manager 3.1
·
(not installed)
·
PointCast with ThinkPad channel
·
Ergonomics
·
Netfinity 5.1 for Windows 95 (not
installed)
·
Tivoli Light Client Framework (not
installed)
Lotus â SmartSuite 97
·
·
Ring Zero RingCentral 4.10
·
Intel Video Phone 2.0.1
·
IBM Update Connector
·
IBM Product Registration
Customization CD-ROM (apps/drivers)
Recovery CD-ROM with boot diskette
17
System does not have non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation, or under AC power.
ThinkPad 600 supported disks:
- 3.2GB 13ms read/14ms write
9.5 mm PIO Mode 4 or Ultra DMA/33
- 4.0GB 13ms read/14ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
- 6.4GB 13ms read/14ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
PC 97 compliant
DMI 2.0 compliant
DMI instrumentation (thermal monitoring)
ACPI 1.0 compliant
Wired for Management 1.1a
02K0518
Wake on LAN
36L9293
C: is 1.99GB, D: is up to 1.99GB, etc.
12J2467
Setup Guide, User's Reference, Quick
83H6741
Reference and Service Information
05K4820
Card, Options by IBM Catalog,
3547001
Windows 95 manual
3547002
Plug and Play 1.0a
3547003
Standby, suspend, safe suspend, and
83H6739
hibernation modes
12J2471
ENERGY STAR compliant
International Warranty Service
76H0293
IBM SystemXtra
76H0294
24 hour / 7 day telephone
76H0295
board, fax, electronic, and Internet
12J2464
(www.ibm.com/pc/us) support
20L1929
05K8890
37L1504
No warranties are expressed or implied in this summary
19
ä
12
solutions
All models:
- C: drive is FAT16 of 2GB
- D: drive is FAT32 of
remaining space
16
20
FEATURES
ä
28
support
14
ä
35
30
, bulletin
(600) IBM Corp. April 1999
