ThinkPad 570E - withdrawn
 
IBM ThinkPad
Processor Intel
Processor features No upgrade / processor in Ball Grid Array (BGA) / North and South Bridge cores
L2 cache 256KB / onboard (at processor speed) / sync pipelined burst / write-back / ECC
Diskette drive External 3.5" 1.44MB / use externally with std cable or in UltraBase
CD-ROM Option: CD-ROM / 24X-10X
Option: 6X-2X
DVD-ROM
✂ 2644-5AU
Type - model
Processor Pentium III 450
Preload (see side) Windows 98 SE
Disk (removable) 6.0GB
All disks: 12ms read / 14ms write / ATA-66 or PIO4 / 9.5mm / S.M.A.R.T.
Avail / withdrawn date February 2000 / 5AU and 5BU on July 2000, 6AU and 6BU on February 2001
Memory (std / max) 64MB std / 320MB max
SDRAM / non-parity / 100MHz / 3.3v / sockets accessed by removing screw on base
One 144-pin socket / 64MB on planar / 1 socket available
Display 13.3" (337.8mm) TFT color / Active Matrix
XGA / 1024x768 / 150 to 1 contrast ratio
Display - features 16.7 million simultaneous colors / 30ms refresh rate / 150 degree tilt /
125 nits (AC), 70 nits (battery)
Graphics - controller NeoMagic MagicMedia256AV (NM2200) / Accelerated Graphics Port
2.5MB / SGRAM (embedded) / 128-bit engine, 256-bit memory interface
Graphics - features AGP 1X / no sideband signaling / motion compensation / DDC2B /
simultaneous LCD and CRT
Disk Left front / removable via coin screw or 2.5mm Allen wrench / SMART
Disk controller Enhanced IDE / busmaster / PCI 2.1 / South Bridge / PIIX4M /
DMA Mode 2, Ultra DMA/33, or PIO Mode 4 / supports 2nd disk in opt UltraBase
Keyboard / Fn keys Full size 85-key keyboard / 10 Fn key functions / integrated palm rest
Keyboard slope Flat keyboard (does not lift up) / optional Port Replicator adds slope
Pointing device TrackPoint
center click button for scrolling or magnifying glass / suspension top / spare caps
36
Dimensions 11.8 x 9.4 x 1.1" (122 cubic inches)
Weight 2 3.97 lbs (1.80 kg) with battery
Weight with optional UltraBase CD-ROM and diskette drives: 6.9 lbs (3.12 kg)
Case material Top: carbon-fiber reinforced plastic; Bottom: glass-fiber reinforced plastic
Battery - type Lithium Ion / intelligent / remove from base / locked with latch
Battery - life 10 3.0 hrs / supports 2nd battery in UltraBase
Charge time - on/off 3 to 4 hrs / 2.5 to 3 hrs / no non-disruptive battery exchange
Architecture Intel 440BX AGPset / Intel 82371EB PIIX4M (EIDE, ISA Bridge, USB) /
TI
PCI 2.1 / 32-bit / 33MHz (EIDE, CardBus, modem, audio, USB, ext expansion) /
PC97338 Super I/O / ISA (diskette, serial, parallel, infrared, ext expansion)
Port replicator (opt) UltraBase / the following are supported by attachment to UltraBase or Direct Dock
Adapter: ThinkPad Port Repl with Advanced EtherJet and Port Replicator
Docking Station None (UltraBase has two bays)
PC Card Std slots 2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit / PCMCIA 2.1 / Zoomed Video
USB / serial / parallel One USB / one 9 pin serial; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features Ultraslim 56 watt AC Adapter, barrel, 3 prong / IBM BIOS Setup Utility (hit F1 at boot)
Video (TV) out None
MPEG-2/DVD Software supported DVD movie playback (via UltraBase and UltraslimBay DVD)
Data/fax modem 56K
international programmable DAA / Mini PCI Type IIIb
Audio support CS4280 / PCI / FM synthesis / 16-bit playback and record / CS4297 (AC97) /
full duplex / int speaker (bottom) / .5 watt / Fn+PgUp and PgDn (volume) / int mic
Jacks (3.5mm) Microphone jack (stereo) / headphone jack (stereo) / line-in jack (stereo)
Infrared ports Infrared port (on right) / IrDA 1.1 compatible / up to 4Mbps
Security Power-on password / hard disk password / supervisor passwrd / security keyhole /
Phillips-head screw on base for memory / optional Allen screw for disk
Limited warranty 11 3 year - carry-in or ThinkPad EasyServ
average turnaround)
Service options 15 On-site
- 6.0GB disk, 12ms, ATA-66
- 12.0GB disk, 12ms, ATA-66
- 18.0GB disk (UltraBase only)
Color depth LCD
Resolution TFT 60Hz 70Hz 75Hz 85Hz
640x480 16M 16M
800x600 16M 16M
1024x768 16M 16M 16M 16M 16M
1280x1024* 256 256
* Virtual screen mode on 13.3" TFT screen
Windows 98 models:
- C: drive is FAT16 of 2GB
- D: drive is FAT32 of remaining space
Windows 2000 models:
- C: drive is FAT32 of entire drive
All trademarks are the property of their respective owners
 
Mobile Pentium III 450 or 500MHz
5 speed / bootable / removable from UltraBase
5
DVD-ROM / bootable / removable from UltraBase
✂ 2644-5BU
Pentium III 450
Windows 2000
4
6.0GB
26 / multiple-monitor support

/ Press-to-Select / Release-to-Select / dragging / click pace /

PCI1450 for CardBus / AGP for graphics / ADM1021 digital thermometer /
22 / V.90 / 14.4K fax / RJ-11 port / voice-capable / integrated Lucent
32 , M-F, 8-5, next bus day (72 cities) / serv up to 5 yrs from purchase date
05K9199 - 32MB SO DIMM 100MHz NP SDRAM
05K9200 - 64MB SO DIMM 100MHz NP SDRAM
37L2993 - 128MB SO DIMM 100MHzNP SDRAM 20L0255
- 256MB SO DIMM 100MHzNP SDRAM 33L3069
External Monitor
- ThinkPad 570 UltraBase
- Direct Dock Adapter (from CompuLock) 00N4650
- Port Replicator
-- 16M 16M
- Port Replicator w/ Advanced EtherJet
-- 16M 16M
- Ultraslim 56 watt AC Adapter (3 prong) 02K6545
- UltraslimBay HDD adapter (for 2nd disk) 05K5336
-- -- --
- SuperDisk LS-120 (UltraslimBay)
- 24X-10X
- 6X-2X
- Zip 100MB Drive 570/600(UltraslimBay) 37L1507
- ThinkPad 570 Li-Ion Battery
- ThinkPad 570 Battery Charger
- IBM 340MB microdrive
1 with 100MHz system bus
✂ 2644-6AU ✂ 2644-6BU
Pentium III 500 Pentium III 500
Windows 98 SE Windows 2000
12.0GB 12.0GB
26 for Windows 98
29
31 Rapid Depot Repair (3 business day
5 CD-ROM (UltraslimBay)
5 DVD Drive (UltraslimBay)
WINDOWS 98 PRELOAD

- Microsoft Windows
• ThinkPad Utilities
• ThinkPad Configuration Program
• IBM Update Connector
• Online User's Guide
• IBM Registration
• RingCentral Fax
• ConfigSafe

• Norton AntiVirus (OEM Version)
• PC-Doctor
• Universal Mgmt Services (web)
29
• Norton Mobile Essentials
• Symantec Mobile Essentials
• Access ThinkPad
✧Software Selections CD-ROM
✧Lotus

SmartSuite
✧Recovery CD-ROM (Windows 98)
✧Recovery CD-ROM (Windows 95)
WINDOWS 2000 PRELOAD
- Windows 2000
• ThinkPad Utilities
• Online User's Guide
• ThinkPad Configuration Program
• IBM Registration
/ upgradeable
• PC-Doctor
• RingCentral Fax
• Netscape Communicator
• Universal Mgmt Services (web)
• ConfigSafe
• IBM Update Connector
• Norton AntiVirus (OEM version)
✧Software Selections CD-ROM
✧Lotus SmartSuite Millennium CD
✧Recovery CD-ROM (Windows 2000)
✧Recovery CD-ROM (Windows NT)
ULTRABASE OPTION
Left bay of UltraBase supports most
UltraslimBay options:
• optional CD-ROM (hot or warm swap)
• optional DVD drive (hot or warm swap)
• optional LS-120 SuperDisk drive (cold
swap only)
• optional Zip 100MB drive (cold swap)
• optional HDD adapter; for second disk

1646 /
(cold swap only)
• optional ThinkPad Proven solutions
UltraBase right bay supports:
• standard diskette drive (hot swap)
• battery (uses standard 570 battery)
Other features
• stereo speakers (0.5 watts)
• security keyhole, UltraBase lock
• MIDI/joystick port, line out, USB port
PC 98 and DMI 2.0 compliant
20L0253
DMI instrumentation
20L0254 ACPI ready (APM enabled)
Wired for Management 1.1a compliant

Wake on LAN
05K5840
Setup Guide, User's Reference, Quick
Reference and Service Info Card,
46H4209
Options catalog, Windows manual
05K4872 Plug and Play 1.0a
Standby, suspend, safe suspend, and
hibernation modes
20L1929
ENERGY STAR compliant
05K9122
Personalized Web-based support
05K9169
International Warranty Service
IBM SystemXtra
02K6546 30
24 hour / 7 day
02K6570
board, fax, electronic, and Internet
00N8073
(www.ibm.com/pc/us) support
No warranties are expressed or implied in this summary
