ThinkPad 390X (Pentium III) - withdrawn
 
IBM ThinkPad
Processor Intel
Processor features No upgrade / processor, L2 cache, and memory controller (North Bridge) on Intel Mobile Module (MMC2)
L2 cache 256KB / at processor speed / sync pipelined burst / ECC / write-back
Diskette drive Internal 3.5" 1.44MB / removable from UltraBay FX / on right side / integrated with CD-ROM / no external disktte port
CD-ROM CD-ROM / 24X-10X
DVD-ROM Option: Removable UltraBay FX option / 4X-1X
✂ 2626-L0U
Type - model
Processor / MHz Pentium III 450MHz
Disk - size / read ms 12.0GB
Preload (see side) Windows 98 SE
Avail / withdrawn date Dec 1999 / Oct 2000
Display (diagonal) 14.1" TFT XGA
Display - size and type 14.1" TFT color 358mm / Active Matrix
Display - technology XGA / 1024x768 / 20 to 30ms / 120 nits
16.7 million colors /150 to 1 contrast
Graphics controller NeoMagic MagicMedia256AV (NM2200) / 128-bit engine, 256-bit memory interface / 1X AGP / DDC2B /
2.5MB / SGRAM (embedded) / motion compensation / color space conversion / interpolation in X and Y axis /
simultaneous LCD and CRT
Memory - std / max 64MB / 512MB
Memory - features SDRAM / non-parity / 100MHz / PC100-compliant / 3.3 volt / 64-bit /
2 sockets for JEDEC 144-pin SO DIMMs / one socket used by std memory /
sockets accessed from bottom via removing cover held by phillips-head screw
Disk controller EIDE / PCI 2.1 / one internal disk / disk can be removed to upgrade by
customer / supports two internal disks / 13ms read / 14ms write / S.M.A.R.T.
Keyboard Full-size 85-key (7 Fn key functions) / palm rest / keyboard slope with tilt feet
Pointing TrackPoint
center button for scrolling (Internet Scroll Bar) or magnifying glass / spare caps
Dimensions 36 14.1"mod: 12.4 x 10.2 x 1.8" (228 cu in) 15" mod: 12.9 x 10.6 x 1.8" (246 cu)
2
Weight (with batt/disk) 14.1" models: 7.7 lbs (3.5 kg) 15" models: 7.9 lbs (3.6 kg)
Case material PC/ABS plastic
Battery - type Li-Ion / intelligent / left side
Battery - life 10 (1 batt) 14.1" models: 3.7 hrs 15" models: 3.3 hrs
Charge time 10 14.1" models: 5 hrs on / 2.5 hrs off 15" models: 6 hrs on / 3 hrs off
Architecture Intel 440BX AGPset / Intel PIIX4E (EIDE, PCI to ISA bridge, USB) /
Texas Instruments
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA, USB, audio, modem)
ISA (diskette, serial, parallel, infrared)
Docking station None
Port replicator ThinkPad Port Replicator with Advanced EtherJet / Basic Port Replicator
PC Card Std slots 2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit / PCMCIA 2.1 / Zoomed video
USB / serial / parallel One USB / one 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / Ultraslim AC adapter, barrel, 3-prong, 56 watts
Video (TV) out S-Video out connector on side (does not require cable) / Chrontel Ch7004C-T
MPEG decoder None (W98 support for MPEG-2 because 300MHz with motion compensation)
Data/fax modem 56K
conforms to earlier draft specs similar to Mini PCI Type IIIb
Audio 16-bit SoundBlaster Pro support / ESS 1946 / PCI / full duplex
Speakers Two Altec Lansing
Audio features Dial volume control (right side) / internal microphone
Audio in/out jacks Microphone jack (stereo) / headphone jack (stereo) / line-in jack
Infrared ports Infrared port on left side / IrDA 1.1 compatible / up to 4Mbps
Security Power-on password / setup password / disk password /
security keyhole / security screw for UltraBay FX
11
Limited warranty 1 year - carry-in or ThinkPad EasyServ
15
Service options On-site
Color depth LCD
Resolution TFT
640x480 16M
800x600 16M
1024x768 16M
1280x1024 --
The right bay (UltraBay FX) has a device lock
on the bottom of the system and a bay LED
which should be off to safely remove a device;
it supports:
• standard diskette/CD-ROM (warm swap with
Windows 98)
• optional DVD/CD-ROM (warm swap; W98)
• optional second battery (hot swap; W98/NT);
same battery as main one
• optional second disk (cold swap)
• optional ThinkPad Proven solutions
Windows 2000 model:
- C: drive is FAT32 of entire disk
All trademarks are the property of their respective owners
✂ = Withdrawn from marketing
 
Mobile Mobile Pentium
5
speed / ATAPI / bootable / removable from UltraBay FX / on right side / integrated with diskette drive
✂ 2626-LNU
Pentium III 450MHz
4
/ 12ms 12.0GB / 12ms
NT 4.0
Dec 1999 / Oct 2000
14.1" TFT XGA
26 / 150 degree tilt / multiple-monitor support
33

/ Press-to-Select / Release-to-Select / dragging / click pace /

TI1251B PCMCIA controller / NS PC97338 (FDC, IR, I/O)
37
V.90 / integrated in system / PCI / Lucent 1646 / not voice-capable /

stereo speakers (1 watt) on display (on front for 15" mod)
32
, M-F, 8-5, next bus day (72 cities) / serv up to 5 yrs from purchase date
External Monitor
60Hz 75Hz 85Hz - 32MB SO DIMM 100MHz NP SDRAM 20L0253
- 64MB SO DIMM 100MHz NP SDRAM 20L0254
16M 16M 16M
- 128MB SO DIMM 100Mz NP SDRAM 20L0255
16M 16M 16M
- 256MB SO DIMM 100Mz NP SDRAM 33L3069
16M 16M 16M
- Basic (ThinkPad 560) Port Replicator 46H4209
256 -- --
- Port Replicator w/ Advanced EtherJet 05K4872
- ThinkPad 390 Li-Ion Battery
- Ultraslim 56 watt AC Adapter (3-prong) 02K6545
- 6.4GB disk with UltraBay FX adapter
- 10GB disk with UltraBay FX adapter
- 12GB disk with UltraBay FX adapter
- 4X-1X DVD/Diskette (for UltraBay FX) 05K9129
- CD/Diskette (for UltraBay FX)
- 10/100 EtherJet Ready Port CardBus
Adapter with 56K modem
- 10/100 Ethernet CardBus PC Card
12 - Smart Card Security Kit
- IBM Portable Drive Bay
- IBM MultiPort USB Hub
III 450 or 500MHz 1 / 100MHz system bus
5 DVD integrated with a diskette drive
✂ 2626-L2U
Pentium III 450MHz
12.0GB / 12ms
Windows 2000
Feb 2000 / Oct 2000
14.1" TFT XGA
31
(door-to-door depot repair service)
OPTIONS
✂ 2626-M0U ✂ 2626-MNU
Pentium III 500MHz Pentium III 500MHz
12.0GB / 12ms 12.0GB / 12ms
Windows 98 SE NT 4.0
Dec 1999 / Jan 2001 Dec 1999 / Jan 2001
15" TFT XGA 15" TFT XGA
15.0" TFT color 381mm / Active Matrix
XGA / 1024x768 / 10 to 30ms / 120 nits
16.7 million colors / 150 to 1 contrast
26
WINDOWS 98 PRELOAD

- Microsoft Windows
• Access ThinkPad
• Online User's Guide
• ThinkPad Configuration Program
• ThinkPad Utilities
29
• IBM Update Connector
• RingCentral Fax
• ThinkPad on the Net
• Intelliquest Registration
• IBM Global Network Dialer
• Netscape Communicator
• Lotus

SmartSuite
• PC-Doctor
• ConfigSafe

• Norton AntiVirus (OEM Version)
• Universal Management Services (web)
✧Software Selections CD
✧Lotus SmartSuite Millennium CD-ROM
✧Recovery CD-ROM (Windows 98)
✧Recovery CD-ROM (Windows 95)
WINDOWS 2000 PRELOAD

- Windows 2000 Professional
• ThinkPad Utilities
• Online User's Guide
• ThinkPad Configuration Program
• IBM Registration
• PC-Doctor
• RingCentral Fax
• Netscape Communicator
• ConfigSafe
• IBM Update Connector
• SystemSoft CardWizard
• Norton AntiVirus (OEM Version)
• Universal Management Services (web)
✧Lotus SmartSuite Millennium CD
✧Software Selections CD-ROM
✧Recovery CD-ROM (Windows 2000)
✧Recovery CD-ROM (Windows NT)
FEATURES
Wired for Management 1.1a-compliant
DMI 2.0-compliant
02K6513
PC 98-compliant
ACPI ready (APM enabled)
05K8923 
Wake on LAN support
05K8983
Setup Guide, User's Reference, Windows
05K9268
OS manual, and Quick Reference Card
System Status Indicators
05K8986
Plug and Play 1.0a
Standby, suspend, and hibernation modes
34L1301
ENERGY STAR-compliant
08L3147
International Warranty Service
33L5075 , 35
IBM SystemXtra
37L1511
30
24 hour / 7 day telephone, bulletin
00N8215
board, fax, electronic, and Internet
(www.ibm.com/pc/us) support
No warranties are expressed or implied in this summary
(390X2)  IBM Corp. January 2001
