ThinkPad 385XD (Retail models) - withdrawn
IBM ThinkPad
Processor type
Processor features
L2 cache
Diskette drive
External FDD port
CD-ROM
Type - model
UPC code
Processor
Avail / withdrawn date
Disk - size / ms
Disk controller
Display - size and type
Display - techology
Graphics - controller
Graph - arch/data path
Graphics - features
Memory - std / max
Memory - features
Keyboard / # of keys
External keyboard
Pointing / palm rest
2
Dimensions / weight
Battery - type / life 10
Charge time - on / off
Architecture
Docking station
Port replicator
PCMCIA slots
USB / serial / parallel
Other features
Video in/out
MPEG decoder
Data/fax modem
Audio
Speakers
Audio features
Audio in/out jacks
Infrared ports
Security
Preinstalled software
11
Limited warranty
Service options 15
The ThinkPad Enhanced Port Replicator
provide cable management, additional I/O ports,
and CardBus PC Card slots. Features include:
- Dual IBM lock slots to secure the ThinkPad,
PC Cards, and Port Replicator
Port Replicator connectors:
- USB, serial (9 pin), parallel ( 25 pin)
- External display (15 pin)
- Keyboard and mouse
- Audio in (3.5 mm) and audio out (3.5 mm)
- Joystick/MIDI port (15 pin) - not on system
- External diskette drive conntr - not on system
- Power connector (requires AC power; can not
run on battery)
Features of the PC Card slots:
- Two Type III slots (side by side)
- PC Card Standard 95 compliant
- CardBus compliant (PCI 2.1 / 32-bit)
- 8/16-bit PC Card support (no Zoomed Video)
- Texas Instruments PCI1131 controller
- Requires no PCI-to-PCI bridge
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad in
most North American locations, IBM repairs and mails back (no shipping charges, most shipping
is overnight, 3 business day average turnaround)
Pentium 233/66 1 with MMX technology, 266/66MHz with MMX technology, or Pentium II 266/66MHz
No upgrade / processor, L2 cache, and memory controller (North Bridge) on Mobile Module
512KB / sync pipelined burst (66MHz for Pentium / ECC and 133MHz for Pentium II)
Internal 3.5" 1.44MB / use simultaneously with CD-ROM / on right side
None since diskette internal
5.25" CD-ROM / 24X-10X 5 speed / CAV / multi-session / XA / ATAPI / bootable / not removable / on right side
2635-8EU
0-87944-40513-9
Pentium 233/66MHz
March 1998 / Sept 1998
4
2.1GB / 13ms / PIO Mode 4
EIDE / PCI 2.1 / supports one internal disk / no DMA or busmaster support / disk can be removed and upgraded by customer
12.1 inch HPA (High Performance Addressing) color
SVGA / 640x480 or 800x600 / 150ms / 100 nits /
16.7 million simultaneous colors / 50 to 1 contrast
NeoMagic MagicGraph128XD (NM2160B) / 128-bit SVGA accelerator / Zoomed Video support / DDC1 and DDC2B
2MB / iDRAM (embedded) / color space conversion and interpolation in X and Y axis / support for DCI, DirectDraw
PCI 2.1 / 32-bit / external SVGA to 1024x768 with 65,536 colors
Simultaneous LCD and CRT / 150 degree tilt
32MB / 96MB / non-parity / 3.3 volt / EDO / 60ns
1 socket for one JEDEC 144 pin EDO SO DIMM of 8, 16, 32, or 64MB
Full size alp/num / 85 (6 Fn key functions) / keyboard slope with Port Replicator
External keyboard support with option cable 06G8619 or Port Replicator
TrackPoint III / no drag lock keys
11.8 x 9.2 x 2.4" (260 cubic inches) / 8EU/9EU: 7.1 pounds; DEU: 7.2 lbs
Li-Ion / non-intelligent / 3.0 hrs
4.2 to 12 hrs / 3.3 hrs
Intel Triton 430TX, PIIX4 for Pentium systems / Intel 440BX, PIIX4 for Pent II
PIIX4 (EIDE, USB, PCI to ISA bridge)TI TI1250A PCMCIA controller
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA, USB)
ISA (audio, diskette, serial, parallel, infrared) / NS PC97338 (FDC, IR, I/O)
None
ThinkPad Enhanced Port Replicator,
ThinkPad 380/385 Port Replicator
2 Type I or 2 Type II or 1 Type III / CardBus 32-bit PCI / Zoomed video
PCMCIA 2.1 compatible / PC Card Standard 95
One USB / one 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter; barrel (56 watts) / 35 watt supported
None
None (software support for MPEG-1 in Windows 95)
56KB PC Card Modem / Cellular Capable / x2 / XJACK connecor (02K4196)
16-bit / CS4237B / SRS 3D audio / FM synthesis
Two front stereo speakers (.5 watt) / one subwoofer above keyboard (1 watt)
Dial volume control (left side) / internal microphone / full duplex spk/mic
Input/microphone jack (stereo) / output jack (stereo) / no joystick port
Infrared port on left side / IrDA 1.1 compatible / up to 4Mbps
Power-on password / supervisor password / hard disk password /
security keyhole / personalization screen at startup
Microsoft Windows 95 OSR2.1 wth applications (listed on right)
1 year - ThinkPad EasyServ (door-to-door depot repair service) or carry-in
On-site, M-F, 8-5, next bus day (71 cities) / warranty extension to 3 or 5 years
- 8MB SO DIMM 3.3v NP EDO 64-bit
- 16MB SO DIMM 3.3v NP EDO 64-bit 92G7341
- 16MB SO DIMM NP EDO 64-bit (new)01K1124
- 32MB SO DIMM 3.3v NP EDO 64-bit 92G7342
- 64MB SO DIMM 3.3v NP EDO 64-bit 76H0268
- ThinkPad 560 Port Replicator
- ThinkPad 380/385 Port Replicator
- ThinkPad Enhanced Port Replicator
- ThinkPad 380/385 Li-Ion Battery (old) 73H9793
- ThinkPad 380/385 Li-Ion Battery
- 56 watt AC Adapter (barrel; 3 prong) 83H6739
- 6.4GB disk, 13ms, Ultra DMA/33
- 33.6Kbps Modem with XJACK
- 56K PC Card Modem Kit
- 56K PC Card Modem/Cellular Capable 02K4196
Easy-Setup is entered by holding F1 when
turning on.
2635-9EU
0-87944-40514-6
Pentium 266/66MHz
March 1998 / Sept 1998
3.2GB / 13ms / PIO Mode 4
ThinkPad 560 Port Replicator,
OPTIONS
2635-DEU All-in-one integration means the
disk, diskette drive, and CD-ROM
0-87944-41973-0
Pentium II 266/66MHz are all within the covers of the
May 1998 / Sept 1998 notebook; removable disk;
keyboard does not lift up
3.2GB / 13ms / PIO 4
12.1 inch TFT color / Active Matrix
SVGA / 640x480 or 800x600 / 75ms / 100 nits
16.7 million simultaneous colors / 100 to 1 contrast
WINDOWS 95 PRELOAD
- Microsoft Windows 95 OSR2.1 (FAT16)
Internet Explorer 4.0
Online User's Guide
ThinkPad Configuration Program
SystemSoft CardWorks
Diskette Factory and Utilities
Artisoft ConfigSafe
Update Connector
Puma TranXit
IBM Anti-Virus
IBM Global Network (IGN Dialer)
Netscape Navigator browser
Media Player
IntelliQuest Registration Mailer
Ergonomics
PointCast (with ThinkPad channel)
Marketing Demo
Expensable
ThinkPad on the Net
Personalization Editor
ThinkPad Customization
Lotus SmartSuite 97
Voyetra Audio Station
Rand McNally's Trip Maker
Quicken 98 (subject to change)
EA Sports PGA Tour Golf CD-ROM
Recovery CD-ROM with boot diskette
Windows 95 CD-ROM (no installation)
3.2GB = DMA Mode 2 or PIO Mode 4
4.0GB = DMA Mode 2 or PIO Mode 4
5.1GB = Ultra DMA/33 or PIO Mode 4
All disks are SMART compliant
Fn + F2 = Battery guage
Fn + F3 = Standby
Fn + F4 = Suspend
92G7340
Fn + F7 = LCD/CRT/Simultaneous
Fn + F11 = Power mgmt
Fn + F12 = Hibernation
46H4209
DMI 2.0 compliant (via software upgrade)
84G1316
11J8997 PC 97 compliant
Wired for Management 1.1a
02K6507 Setup Guide, User's Guide, Options by
IBM catalog, Windows 95 book
02K0518 System Status Indicators
Plug and Play 1.0a
55H6759
04K0052 Standby, suspend, safe suspend (RediSafe),
and hibernation modes
ENERGY STAR compliant
International Warranty Service
24 hour / 7 day telephone
board, fax, electronic, and Internet
(www.ibm.com/pc/us) support
IBM and dealer warranty/service
