ThinkPad 365 (CD-ROM models) - withdrawn
IBM ThinkPad
10.4" dual scan - CD-ROM
Processor Cyrix Cx 486DX4 75/25 MHz / integrated math coprocessor
Processor upgrade None
Memory cache 8 KB in DX4 (write-back) / no L2 cache
Diskette (not internal) External 3.5" 1.44 MB (connects to back of system) / use simultaneously w/ CD-ROM
CD-ROM (not remove) 5.25" CD-ROM / double speed / multi-session / XA / front loaded / ATAPI
Price
Type - model all 2625 2625-A05
Part number 38H5724
Preload (see side) SelectaSystem
Disk - capacity 540 MB
Disk - ms / interface 13 ms / EIDE
Avail / withdrawn date Nov 1995 / Jun 96 Nov 95 / Jun 96
Display - diagonal size 10.4" Dual scan
Display - type VGA color / 640 x 480
Display - color 256 simultaneous colors
Display - contrast 30 to 1
Graphics - controller Chips and Technologies 65545 with 1 MB DRAM
Graphics - external External SVGA to 1024 x 768 w/ 256 colors up to 70 Hz
Graph - arch/data path VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
Memory - std / max 8 MB / 24 MB 70 ns / non-parity / 3.3 volt / fast page
Mem - upgrade 1 socket for one JEDEC 72 pin SO DIMM of 4 or 16 MB
Keyboard / # of keys Full size alp/num / 85 (8 Fn key functions)
Keyboard slope Yes (legs pop out)
Pointing TrackPoint III
Ext keyboard support Yes (with option cable or Port Replicator)
Dimensions (cubic in) 11.7 x 8.3 x 2.0" (194 cubic inches)
Weight (with battery) 6.4 pounds
Battery - type NiMH / non-intelligent
Battery - life 2.5 to 9 hours
Charge time - on / off 6 hrs / 2 hrs
Architecture ISA (audio, PCMCIA, diskette, serial, parallel, 240 pin external expansion)
VL-Bus 2.0 / 32 bit / 25 MHz (graphics, disk)
Docking Station None
Port replicator Port Replicator and Charger (with built-in battery charger and palm rest)
PCMCIA 2.1 slots 2 Type I or 2 Type II or 1 Type III
Serial / parallel ports One 9 pin; 16550A / one (IEEE P1284, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter (35 watts) / Phoenix BIOS
Other features
MPEG decoder None
Data/fax modem None
Audio support 16 bit audio chip / 18 voice MIDI FM Synthesis / ESS1688 with OPL3
Internal speaker / .5 watt / dial volume control / internal microphone
Audio in/out jacks Input jack (stereo) / microphone jack / output jack (stereo)
Joystick/MIDI port (includes Joystick/MIDI cable)
Infrared ports Infrared port in back / IrDA 1.0 compatible / up to 115 Kbps
Security Power-on password / Supervisor password / Locking device keyhole
(Kensington MicroSaver cable lock) / keyboard lock (requires Kensington)
Preinstalled software Choice of two preloaded configurations (listed to right)
Warranty 1 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
The Port Replicator and Charger provide
cable management, a battery charger for an
optional second battery, a palm rest when
installed on the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator, it will attempt to recharge the battery
in ThinkPad first (if there is one) before
charging the battery in the Port Replicator.
Port Replicator and Charger connectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
- Keyboard
- Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Spare battery connector (to charge 2nd battery)
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
= Withdrawn from marketing
365CSD
2625-W14
41H8663
Windows 95
540 MB
13 ms / EIDE
Options for ThinkPad 365:
- 4 MB SO DIMM 3.3v non-parity 72 pin
- 16 MB SO DIMM 3.3v non-parity 72 pin
- 720 MB EIDE HDD 13 ms PIO Mode 3 38H6306
- 810 MB EIDE HDD 13 ms PIO Mode 4 42H4012
- 1.08 GB EIDE HDD 13 ms Mode 4
- Port Replicator and Charger
- NiMH Battery Pack
Setup is entered by Ctrl + Alt + F11 from any
full-screen DOS prompt
Fn + F2 = Battery guage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 = LCD/CRT/Simultaneous
Fn + F8 = Reverse video
Fn + F11 = Power mgmt
Fn + F12 = Hibernation
PgUp = Speaker enable
PgDn = Speaker disable
System enters hibernation mode when keyboard
is lifted up.
365CD
10.4" TFT - CD-ROM
2625-B05 2625-W15
38H5726 41H8664
SelectaSystem Windows 95
540 MB 540 MB
13 ms / EIDE 13 ms / EIDE
Nov 95 / Jun 96 Nov 95 / Jun 96
10.4" Black Matrix TFT - active matrix
VGA color / 640 x 480
262,144 simultaneous colors
100 to 1
Liftable (pop-up) keyboard to
access and remove battery
(and upgrade memory and
disk);
CD-ROM is not removable
6.3 pounds
92G7287
92G7293
69H7956
38H6303
38H6304
ThinkPad 365 (CD-ROM models) strengths:
Entry-priced CD-ROM notebook
Integrated audio, microphone, speaker
Simultaneous external diskette
Joystick/MIDI port
Infrared port
SELECTASYSTEM PRELOAD
- IBM DOS 7.0
- Windows 3.11
- OS/2 Warp 3.0 (dual boot) with
selected BonusPak applications
- IBM PC Card Director 1.4
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad features ; Diskette Factory
1. Lotus cc:Mail , e-mail for IBM Global
Network
2. Lotus Organizer
3. Lotus ScreenCam
4. Triton CoSession Host
5. PRODIGY
6. SofNet FaxWorks
7. Video For Windows Runtime
8. Puma TranXit
9. Compuserv for Windows
10. NetFinity for Windows and OS/2
WINDOWS 95 PRELOAD
- Microsoft Windows 95
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad features; Diskette Factory
1. Lotus cc:Mail , e-mail for IBM Global
Network
2. Lotus Organizer
3. Lotus ScreenCam
4. Triton CoSession Host
5. PRODIGY
6. SofNet FaxWorks
7. Puma TranXit
8. Compuserve for Windows
Disk is not removable (like 755/760
systems), but it can be upgraded via tools
FEATURES OF 365 MODELS
Product Map
LED indicator panel
Plug and Play 1.0a
Non-disruptive battery exchange
Doze, standby, suspend, safe suspend,
and hibernation modes
US EPA Energy Star compliant
Personalized nameplate in indention
Personalization screen at startup
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBM or dealer warranty/service
Online Housecall (remote diagnostics)
30 day money back guarantee
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365CD) Compiled by Roger Dodson, IBM. June 1996
