ThinkPad 360PE - withdrawn
IBM ThinkPad
Processor type
Processor speed
Memory cache
Coprocessor socket
Removable diskette
Removable CD-ROM
Price (retail USD)
Type - model
Removable disk - size
Hard drive - speed
Avail / withdrawn date
Display - type
Display - colors
Display - techology
Display - size (diag)
Display - pen enabled
Graphics - controller
Graphics - vendor
Graph - arch/data path
Memory - std / max
Mem - sockets empty
Mem - options available
Keyboard / # of keys
Fn key functions
Keyboard slope
Mouse/pointing
Ext keyboard support
Dimensions
Cubic inches
Color
Weight (with battery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
Docking Station
Port replicator
PCMCIA 2.1 slots
Serial / parallel ports
Audio support
Audio in/out jack
Other features
Security
Preinstalled software
Warranty
Warranty options
The ThinkPad 360 family has the same
physical design as the ThinkPad 750 and 755
family.
PC Card Director (EasyPlaying) is preinstalled
and on the utility diskette for DOS, Windows and
OS/2. It provides:
automatic config of many PCMCIA cards;
visual/audible confirmation of insertion/
removal of cards;
ability to automatically launch an appl (e.g.
async emulation) when card inserted;
status and info on PCMCIA cards installed.
Easy-Setup is entered by holding F1 when
turning on. Easy-Setup, BIOS, and diagnostics
are located in flash memory.
ThinkPad 360PE supported batteries:
- 360 NiMH battery
- 750 NiMH battery
- 750 QuickCharger
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
= Upgradeable; = Removable;
.
360PE
dual scan color - pen
80486 DX2
50/25 MHz 3.3 volt (SL Enhanced)
8 KB internal (no L2 cache)
Integrated in 486DX2
3.5" 1.44 MB / supports internal 2.88 MB diskette
None
$ 3,699 $ 4,049
2620-BOF 2620-BOG
340 MB 540 MB
14 ms 14 ms
April 1995 / June 96 July 1995 / June 1996
VGA color / 640 x 480
256 simultaneous colors
Dual scan - passive matrix
9.5 inch / 20 to 1 contrast ratio
Pen enabled screen / folds flat / includes untethered batteryless stylus
WD90C24A or A2 with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 with 256 colors (up to 75 Hz)
VL-Bus local bus / 32 bit / Simultaneous LCD and CRT
4 MB / 20 MB 70 ns / non-parity / 5.0 volt
1 socket
4, 8, 16 MB ICs
Full size alp/num / 85 keys Memory options:
8 (in any appl)
4 MB IC DRAM 70 ns 5v parity
Yes (legs pop out)
8 MB IC DRAM 70 ns 5v parity
TrackPoint II
16 MB IC DRAM 70 ns 5v parity
Yes (with optional cable)
4 MB IC DRAM 70 ns 5v non-parity 92G7236
8 MB IC DRAM 70 ns 5v non-parity 92G7237
11.7 x 8.3 x 2.1"
204 inches 16 MB IC DRAM 70 ns 5v non-parity 92G7424
Black
6.8 pounds
Nickel hydride (NiMH)
3 to 7 hours
2 hrs / 1.5 hr
AT bus (ISA)
Dock I and II
Port Replicator I and II
2 Type I or 2 Type II or 1 Type III
Yes (one 9 pin) / Yes (EPP)
16 bit audio codec on planar / Crystal Semiconductor CS4248 / int speaker
Input jack / output jack
APM-aware BIOS / Selectable boot
AC adapter, 35 watts, worlwide, not wallmount
Hibernation mode saves memory to disk and shuts off system
Power-on password / Hard disk password / Hardware security loop (secures
unit, prevents opening keyboard) / PCMCIA card lock / Optional Security Base
IBM DOS 6.3, Windows 3.11, pen op systems, and all appls listed to right:
1 year - ThinkPad EasyServ only
Onsite via special bid only / ThinkPad EasyServ Overnight Repair Option
Compatible in all 360 family, all 750 family, and
all 755 family:
- Disks: 170 MB IDE
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- Port Replicator I (w/ PCMCIA) 66G3510
- Port Replicator II
- 1.44 MB diskette
Options for 360PE:
- AC Adapter, 35 watts
- AC Adapter, 40 watts
- AC Adapter, 40 w, wallmount
- Car Battery Adapter
84G2392
66G2846 Memory from ThinkPad 350, 500, and 510Cs
is NOT compatible in 360. IC DRAM memory
66G2843
from ThinkPad 700, 720, 750, and 755 will
work but without parity.
= Withdrawn from marketing
The ThinkPad 360PE has the same features as 360CSE except:
Pen enabled display
Untethered batteryless stylus (pen)
Display folds down to flat position to write on
16 bit audio codec (vs no audio)
Audio in and audio out jacks
PenDOS, Pen Windows, and Monologue preinstalled
35 watt universal AC adapter (vs 30 watt)
92G7232
92G7233
92G7234
66G2847
250 MB IDE 84G2391
340 MB IDE 66G2849
540 MB IDE 84G2150
810 MB IDE 84G8250
3545001
3546001
66G3520
std in newer
85G6680
49G2165
84G2148
49G2167
ALL 360 MODELS
Liftable (pop-up) keyboard to
access and remove diskette
drive, disk, battery, and
memory
The removed diskette drive can be used
externally via the optional 'FDD External
Kit' (includes cable and enclosure) to the
Port Replicator Model I and II and Dock I
and II.
Diskette drive can be removed
to reduce weight
to add other third party options
PREINSTALLED APPLICATIONS
- IBM PC DOS 6.3
- PenDOS 2.2
- IBM ThinkWrite 1.21
- Windows 3.11
- Windows for Pen computing
- IBM PC Card Director for PCMCIA
- Online Users Guide
- ThinkPad features
1. Lotus cc:Mail, for the IBM Global
network
2. Lotus Organizer 1.12
3. Lotus ScreenCam 1.0
4. Official Airline Guide Flight Disk 1.0
5. Triton CoSession Host
6. PRODIGY
SM
7. America Online
8. SofNet FaxWorks 3.0
9. Taxi
10. Second Nature Screen Saver
11. Farallon Replica
12. AlphaNet FollowFax
13. Sedona REPRINT
14. COMPEL Personal Edition
15. Reuters SM Money Network
16. Monologue
FEATURES OF 360 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalized nameplate in molded indentation
External VGA is ISO capable (75 Hz)
Upgradeable disks: 170 MB, 250 MB, 340MB,
540 MB, 810 MB (all 2.5 inch)
Battery life indicator
Non-disruptive battery exchange
US EPA Energy Star compliant
HELPWARE
1 year warranty
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBM or dealer warranty/service
Online Housecall (remote diagnostics)
30 day money back guarantee
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(360PE) Compiled by Roger Dodson, IBM. June 1996
