ThinkPad 360CSE / CE - withdrawn
IBM ThinkPad
Processor type
Processor speed
Memory cache
Coprocessor socket
Removable diskette
Removable CD-ROM
Price (retail USD)
Type - model
Removable disk - size
Hard drive - speed
Available date
Display - type
Display - colors
Display - techology
Display - size (diag)
Display - contrast ratio
180 degree display tilt
Graphics - controller
Graphics - vendor
Graph - arch/data path
Memory - std / max
Mem - sockets empty
Mem - options available
Keyboard / # of keys
Fn key functions
Keyboard slope
Mouse/pointing
Ext keyboard support
Dimensions
Cubic inches
Color
Weight (with battery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
Docking Station
Port replicator
Modem/serial slot
PCMCIA 2.1 slots
Serial / parallel ports
Other features
Security
Preinstalled software
Warranty
The ThinkPad 360 family has the same
physical design as the ThinkPad 750 and 755
family.
PC Card Director (EasyPlaying) is preinstalled
and on the utility diskette for DOS, Windows and
OS/2. It provides:
automatic config of many PCMCIA cards;
visual/audible confirmation of insertion/
removal of cards;
ability to automatically launch an appl (e.g.
async emulation) when card inserted;
status and info on PCMCIA cards installed.
Easy-Setup is entered by holding F1 when
turning on. Easy-Setup, BIOS, and diagnostics
are located in flash memory.
Battery compatibility:
84G2392 360 NiMH battery Y
66G2846 750 NiMH battery Y
85G1513 NiMH Batt Pack II N
Y = battery supported; N = not supported
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
= Upgradeable; = Removable;
360CSE
dual scan color
80486 DX2
50/25 MHz 3.3 volt (SL Enhanced)
8 KB internal (no L2 cache)
Integrated in 486DX2
3.5" 1.44 MB / supports internal 2.88 MB diskette
None
$ 2,399 $ 2,699 $ 3,049
2620-80D 2620-80F 2620-80G
170 MB 340 MB 540 MB
14 ms 14 ms 14 ms
Oct 94 / withdrawn Dec 95
VGA color / 640 x 480
256 simultaneous colors
Dual scan - passive matrix
9.5 inch
20 to 1
Yes
WD90C24A or A2 with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 with 256 colors (up to 75 Hz)
VL-Bus local bus / 32 bit / Simultaneous LCD and CRT
4 MB / 20 MB 70 ns / non-parity / 5.0 volt
1 socket
4, 8, 16 MB ICs
Full size alp/num / 85 keys
8 (in any appl)
Yes (legs pop out)
TrackPoint II
Yes (with optional cable)
11.7 x 8.3 x 2.0"
194 inches
Black
6.2 pounds
Nickel hydride (NiMH)
2.9 to 7 hours
2 hrs / 1.5 hr
AT bus (ISA)
Dock I and II
Port Replicator I and II
No
2 Type I or 2 Type II or 1 Type III
Yes (one 9 pin) 16550B / Yes (EPP)
APM-aware BIOS / Selectable boot
Some models will have Wallmount AC adapter without powercord with
retractable prongs, 30 watts
Hibernation mode saves memory to disk and shuts off system
Power-on password / Hard disk password / Hardware security loop /
PCMCIA card lock / Optional Security Base
IBM DOS 6.3, Windows 3.11, and all appls listed to right:
1 year - carry in or EasyServ (optional onsite for $40)
Compatible in all 360 family, 360CSE / CE,
750 family, 755 family, 755CSE / CE, 755CD:
- Disks: 170 MB IDE disk
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- Port Replicator I (w/ PCMCIA) 66G3510
- Port Replicator II
- 1.44 MB diskette
- 2.88 MB diskette
Options for 360 (not pen), 360CSE / CE,
750 (not pen), 755, 755CSE / CE:
- CDPD Mobile module
755
755 CE/
Memory from ThinkPad 350, 500, and 510Cs is
All All C/ CSE/
NOT compatible in 360. IC Memory from
360 750 CS CD
ThinkPad 700, 720, 750, and 755 will work
N N N but without parity.
Y Y N
Options only for TFT models - 360C, 360CE,
N N Y
750C, 755C, 755CE, 755CD
- TV Tuner
Price decrease effective February 14, 1995.
360CE
TFT color
Mono, Dual scan, TFT, Pen
486SX - 33 MHz
No math cop possible
170, 340 MB std models
$ 2,799 $ 3,099
2620-90D 2620-90F
170 MB 340 MB
14 ms 14 ms
Oct 94 / withdrawn Dec 95
VGA color / 640 x 480
256 simultaneous colors
TFT - active matrix
8.4 inch
100 to 1
Yes
11.7 x 8.3 x 1.9"
185 inches
Black
6.1 pounds
Nickel hydride (NiMH)
3.2 to 7 hours
2 hrs / 1.5 hr
66G2849
250 MB IDE disk 84G2391
340 MB IDE disk 66G2849
540 MB IDE disk 84G2150
810 MB IDE disk 84G8250
3450001
84G3587
66G3520
std in newer
66G0108
71G2560
66G3689
(360E) Compiled by Roger Dodson, IBM. December 1995
The 360CSE / CE is the same as the
360 (older models) except:
360
Dual scan, TFT
486DX2 - 50/25 MHz
Integrated math cop
170, 340, 540 MB std
More preloaded appls
$ 3,449 ALL 360 MODELS
2620-90G
Liftable (pop-up) keyboard to
540 MB
access and remove diskette
14 ms
drive, disk, battery, and
memory
The removed diskette drive can be used
externally via the optional 'FDD External
Kit' (includes cable and enclosure; $135)
to the Port Replicator Model I and II and
Dock I and II.
Diskette drive can be removed
to reduce weight
to insert cellular modem (CDPD)
to insert TV Tuner (for on screen TV
and VCR playback)
to insert 2.88 MB diskette
to add other third party options
PREINSTALLED APPLICATIONS
- IBM PC DOS 6.3
- Windows 3.11
- IBM PC Card Director for PCMCIA
- IBM ThinkPad Demo
- Online Users Guide
- ThinkPad features
1. Lotus cc:Mail, e-mail for Advantis
network,
2. Lotus Organizer 1.12,
3. Lotus ScreenCam 1.0,
4. Official Airline Guide Flight Disk 1.0,
5. Triton CoSession Host,
6. PRODIGY
7. America Online SM
8. SofNet FaxWorks 3.0
9. Taxi
10. Second Nature Screen Saver
11. Farallon Replica
12. AlphaNet FollowFax
13. Sedona REPRINT
14. COMPEL Personal Edition
15. Reuters SM Money Network
FEATURES OF 360 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalized nameplate in molded indentation
External VGA is ISO capable (75 Hz)
Upgradeable disks: 170 MB, 250 MB, 340MB,
540 MB, 810 MB (all 2.5 inch)
Battery life indicator
Non-disruptive battery exchange
US EPA Energy Star compliant
HELPWARE
1 year warranty
International Warranty Service
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBM or dealer warranty/service
Online Housecall (remote diagnostics)
30 day money back guarantee
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
