- Page 1 Bedienungsanleitung User manual Manuel d’utilisation Manuale d’uso Instrucciones para el uso Handleiding...
- Page 2 Einschalten Switching on Activation Accensione Encendido Inschakelen Logbuch Logbook Carnet de plongée Logbook Diario de inmersiones Logboek UWATEC Digital 330m...
-
Page 3: Table Of Contents
UWATEC Digital 330m - English Table of contents: 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 2 Remarks about safety . - Page 4 5 .1 Maintenance and care of the Digital 330m . . . . . . . . . . . . . . . .
-
Page 5: Introduction
. With features such as continuously updated average depth and ascent speed display, it was designed with the technical diver in mind . The Digital 330m is manufactured with state of the art electronic components and is tested with highly sophisticated equipment . -
Page 6: Remarks About Safety
2 Remarks about safety The Digital 330m is a valuable companion for safe diving as long as you observe WARNING the following: • the Digital 330m does neither replace diver training nor replace a diving partner; • the Digital 330m does not calculate any decompression data . However, it pro- vides accurate information for the calculation of decompression procedures us- ing dive tables . -
Page 7: Diving With The Digital 330M
Digital 330m if some segments do not light up . DEPTH DIVE TIME After the 5 seconds in diagnostic mode, the Digital 330m switches into ready mode . Temp After 3 minutes without operation from the ready mode, the Digital 330m turns off ºC... -
Page 8: Current Depth
. The depth measurement is calibrated for fresh water according to international standards . Therefore when diving in salt water, the Digital 330m will show a depth slightly greater than actual (2-3% higher) . Note that when imperial Temp units are chosen, depths deeper than 999 ft are shown without the leading “1”... -
Page 9: Dive Time
3.4 Dive time In the upper right corner of the screen, the Digital 330m indicates the time the diver has spent below a depth of 1 .2 m / 4 ft . The dive time is indicated in hours DEPTH DIVE TIME and minutes, up to 999 hours and 59 minutes . -
Page 10: Temperature And Average Depth
. The ascent speed is displayed in meters per minute or feet per minute . As soon as the Digital 330m does not detect an ascent anymore, temperature and average depth information appear again . -
Page 11: Diving In Mountain Lakes
(ft/min) 3.7 Diving in mountain lakes The Digital 330m has an unlimited altitude range . Whereas mechanical depth gaug- es are dependent on atmospheric pressure and become less accurate with altitude, the Digital 330m accounts for variations in atmospheric pressure and maintains its accuracy throughout . -
Page 12: Surface Functions
. The surface interval will be indicated until it has reached ºC 24 hours or until another dive is performed . In surface mode, the Digital 330m indicates air temperature . After 3 minutes without operation, the Digital 330m switches off to preserve bat- tery energy . -
Page 13: Logbook
Upon touching contacts A and C with moistened fingers during surface mode, the Digital 330m enters the logbook mode . The Digital 330m stores the relevant data for the most recent 19 dives . A dive is only entered into the logbook if it was deeper than 1 .2 m / 4 ft and longer than 2 minutes . -
Page 14: Low Battery Warning
4.3 Low battery warning During the start-up phase, the Digital 330m verifies the status of the battery . If the remaining battery charge is 10% or less of the initial charge, the battery symbol will appear on the display for 10 seconds . In this case, the unit must be replaced immediately . -
Page 15: Technical Specifications
Temperature display resolution: 1 °C (1 °F) Temperature accuracy: ±1 °C (±2 °F) Operating temperature range: -10 °C to +50 °C (14°F to 122°F) Battery life: Dives per year Battery life 13 years 12 years 10 years UWATEC Digital 330m - English... -
Page 16: Warranty
• the warranty becomes null and void if the damage is caused by external agents or accidents or if there has been intervention by unauthorized persons; • pressure chamber tests must be carried out only in water . If the Digital 330m is subjected to pressure under dry conditions, the warranty becomes null and void . - Page 17 PN 06.202.439 scubapro-uwatec.com 3.07 UWATEC AG, Riedstrasse 368 CH-5705 Hallwil, Switzerland...
