Auto On / Auto Off
From the main screen press MENU. Using the LEFT/RIGHT buttons go to SYSTEM and press ENTER
Using the LEFT/RIGHT buttons scroll to the right until the screen above appears and select AUTO
Press ENTER to setup mode, Auto-On Auto-Off should appear on the display
With the cursor on Auto-On press ENTER, Enable PM 12:00 should appear on the display
Use the UP/DOWN buttons to scroll between Enable & Disable, if you selected Disable press MENU button to exit
If you selected Enable, use the RIGHT button to select PM then use the UP/DOWN buttons to select AM or PM
Use the RIGHT button to select the time and use the UP/DOWN buttons to set the hour and minutes you would like
the system to come on. Press ENTER to your settings.
If you Enabled the Auto-On feature, you may want to have the system shut off automatically. To do this use the
RIGHT button to select Auto-Off and press ENTER to the setup mode. Then follow the same procedure for setting up
the Auto-Off feature as you did for the Auto-On feature above. Once set, press ENTER to save your settings and the
MENU button 3 times to return to the main screen

Firmware

For trouble shooting purposes, it may be necessary to look up the revision of the system firmware.
From the main screen press MENU and using the LEFT/RIGHT buttons select SYSTEM and press ENTER
Using the LEFT/RIGHT buttons to select Firmware on the display and press the ENTER button. The revision level of
the Firmware will display on the screen. To exit simply press ENTER.
Pressing the MENU button 2 times will return the system to the main screen

Auxiliary Input Setup

From the main screen press MENU. Using the LEFT/RIGHT buttons select SYSTEM and press ENTER.
Using the LEFT/RIGHT buttons select AUX and press the ENTER button
VOLUME, BASS and TREBLE will appear on the display, using the LEFT/RIGHT buttons select BASS and press ENTER
The bass level will appear as 00, using the UP/DOWN buttons set the bass to the desired level, press ENTER
Using the LEFT/RIGHT buttons scroll to treble and press ENTER, the treble level will appear as 00, using the
UP/DOWN buttons set the treble to the desired level and press ENTER
Using the LEFT/RIGHT buttons select volume and press ENTER, using the UP/DOWN buttons set the volume to the
desired level and press ENTER to
Press the MENU button 3 times to return to the main screen
Intrasonic Technology, Inc. l 610 Presidential Dr. Suite 104 l Richardson, Texas 75081 l 877-435-0670
SYSTEM-SETUP
FIRMWARE
AUTO
RESET
SYSTEM-SETUP
FIRMWARE
AUTO
SYSTEM-SETUP
Intercom
RADIO
Page 9 of 15
RESET
AUX
MENU
ENTER
MENU
ENTER
MENU
ENTER
