System Reset
From the main screen press MENU. Using the LEFT/RIGHT buttons move cursor to SYSTEM and press ENTER
Using the LEFT/RIGHT buttons move the cursor to RESET
With the cursor on Reset, press ENTER, Reset & Reset (ALL) will appear on the display
With the cursor on reset press ENTER, and then press MENU (YES) to confirm reset or ENTER (NO) to cancel reset
Using the LEFT/RIGHT buttons set the cursor on Reset (ALL) and press ENTER
Press MENU (YES) to confirm reset or ENTER (NO) to cancel reset
Press MENU button 3 times to return to the main screen
Privacy
From the main screen press MENU Then using the LEFT/RIGHT buttons select UNIT.
Using the UP/DOWN buttons select which station you want to place in privacy mode and press ENTER
With the cursor on Privacy press ENTER and use the LEFT/RIGHT buttons to select either OFF or ON for the privacy
function at the master and press ENTER to select your choice
Display Backlight
From the main screen press MENU then using the LEFT/RIGHT buttons, select UNIT and press ENTER
Under UNIT-SETUP with Master displayed, press ENTER
Use the LEFT/RIGHT buttons to select LIGHT and press ENTER
Use the LEFT/RIGHT buttons to select either OFF, LOW or HIGH for the brightness of the display, press ENTER to
select your choice
Press MENU 3 times to return to the main screen
Room/Patio Setup
From the main screen press MENU then using the LEFT/RIGHT buttons select UNIT and press ENTER
Use the UP/DOWN buttons to select a room station for setup, press ENTER to setup screen, for the first room station
R01-Setup & Mode Name should appear on the display
With the cursor on Mode press ENTER, you can now use the LEFT/RIGHT buttons to select Normal, Audio, Intercom
or Off, Normal is all functions work at the station, Audio is music only at the station, Intercom is intercom only at the
station and off turns off all functions at the station
Once you have selected the mode of operation press ENTER to keep your selection
Name/Number Room & Patio Stations
Using the LEFT/RIGHT buttons move the cursor to Name and press ENTER, you can now use the LEFT/RIGHT
buttons to select the digit you wish to change and the UP/DOWN buttons to change that digit, you can scroll with the
UP/DOWN buttons and select capital letters, a select set of cymbals or numbers for each digit
Once you have selected the new name or number for the station, press ENTER to your selection
Press MENU to return to the main screen, use the UP/DOWN buttons to scroll through the room stations, patio
stations and door stations stopping on any station that you wish to change either the mode or name, follow the above
steps to set the mode or name of any or all the room, patio or door stations
Intrasonic Technology, Inc. l 610 Presidential Dr. Suite 104 l Richardson, Texas 75081 l 877-435-0670
SYSTEM-SETUP
AUX1
AUX2
MENU-SETUP
SYSTEM
UNIT
Page 10 of 15

RESET

MONITOR

MENU
ENTER
MENU
ENTER
