3001L
Security System
installation guide
N N o o t t e e : : This product is intended for installation by a profes-
sional installer only! Any attempt to install this product by
any person other than a trained professional may result in
severe damage to a vehicle's electrical system and com-
ponents.
© 2009 Directed Electronics, Vista, CA N3001L 2009-04

Advertisement

Table of Contents
loading

Related Manuals for Avital 3001L

Summary of Contents for Avital 3001L

  • Page 1 3001L Security System installation guide N N o o t t e e : : This product is intended for installation by a profes- sional installer only! Any attempt to install this product by any person other than a trained professional may result in severe damage to a vehicle’s electrical system and com-...
  • Page 2 Bitwriter®, Code Hopping™, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®, Stinger®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of Directed Electronics. The Bitwriter® (p/n 998U) requires chip version 2.5 or newer to program this unit.

  • Page 3: Table Of Contents

    Contents What is new Four-pin optional sensor harness RED wire What is included BLACK wire Control module BLUE, GREEN wires Installation points to remember Door lock learn routine Before you begin installation To learn lock: After the install To learn unlock Tools required To exit the learn routine Deciding on component location...

  • Page 5: What Is New

    What is new The shock sensor is pre-set, but can be fine-tuned with the Bitwriter (see page 34) What is included Control module 4-pin sensor harness 12-pin main harness Valet switch and LED 7-pin door monitor/ 3-pin door lock Aux harness harness Control module DEALER...

  • Page 6: Installation Points To Remember

    Installation points to remember This product represents many years of research and development. It is very sophisticated and should be installed by experienced security installers only. Please do not attempt installation of this product without reading this guide. The system has been designed to provide the ulti- mate in security, coupled with limitless convenience and expansion options.

  • Page 7: After The Install

    After the install Test all functions. The “Using Your System” section of the Owner’s Guide is very helpful when testing. When testing, don’t forget that this system is equipped with Nuisance Pre- ™ vention Circuitry. NPC can bypass both sensor zones, making them seem to stop working.

  • Page 8: Deciding On Component Location

    Deciding on component location Control module Never put the control module in the engine compartment! The first step in hot-wiring a vehicle is removing the driver's side under- dash panel to access the starter and ignition wires. If the control module is placed just behind the driver's side dash it can easily be disconnect- When locating the control module, try to find a secure location that will not require you to extend the harnesses’...

  • Page 9: Led And Valet Switch

    LED and Valet switch Things to remember when positioning the LED and Valet switch: • The LED should be visible from both sides and the rear of the vehicle, if possible. • The LED and Valet switch should be at least 1-1/2"...

  • Page 10: Connecting Your Wires

    Connecting your wires Now that you have decided where each component will be located, you’re going to find the wires in the car that the security system will be connected to. I I m m p p o o r r t t a a n n t t ! ! Do not use a 12V test light or logic probe to find these wires! All testing described in this manual is described using a digital multimeter.
  • Page 11 Finding the 12V switch ignition wire The ignition wire is powered when the key is in the run or start position. This is because the ignition wire powers the ignition system (spark plugs, coil) as well as the fuel delivery system (fuel pump, fuel injection comput- er).

  • Page 12: Find A Parking Light Wire

    Finding a parking light wire The parking light wire is often found near the switch. Many cars have the switch built into the turn signal lever, and the parking light wire can be found in the steering column. The same wire is often available in the kick panel or running board.

  • Page 13: Find The Door Pin Switch Circuit

    Finding the door pin switch circuit The best places to find the door switch wire are: At the pin switch: When testing at the pin switch, check the wire to ensure that it “sees” all the doors. Often, the passenger switch will cover all the doors even if the driver’s switch will not.

  • Page 14: Main Harness Wire Guide

    Main harness wire connection guide Main harness wiring diagram ORANGE (-)500mA Ground When Armed H1/1 WHITE (+)Default/(-) Light Flash Output H1/2 H1/3 WHITE/BLUE No Function BLACK/WHITE (-) 200mA Domelight Supervison Output H1/4 GREEN (-) Door Trigger Input H1/5 BLUE (-) Instant Trigger (Hood and Trunk Pin) H1/6 VIOLET (+) Door Trigger Input...

  • Page 15: Main Harness Wiring Guide

    Main harness wiring guide H1/1 ORANGE (-) 500 mA ground-when-armed output: This wire sup- plies a (-) ground as long as the system is armed. This output ceases as soon as the system is disarmed. This wire controls operation of the pre- wired starter kill relay and can be used to control other optional acces- sories.
  • Page 16 H1/2 WHITE light flash output: As shipped, this wire should be connect- ed to the (+) parking light wire. It will supply a (+) 10A output. If the light flash polarity fuse jumper inside the unit is moved to the opposite posi- tion (see Internal Jumpers), this wire supplies a (-) 10A output.
  • Page 17 H1/5 GREEN (-) door trigger input: Most vehicles use negative door trigger circuits. Connect the green wire to a wire which shows ground when any door is opened. In vehicles with factory delays on the dome- light circuit, there is usually a wire that is unaffected by the delay cir- cuitry.
  • Page 18 H1/7 VIOLET (+) door trigger input: This wire is used in vehicles that have a positive (+) switched dome light circuit . Connect the violet wire to a wire that shows (+)12V when any door is opened and ground, when the door is closed H1/8 BLACK (-) chassis ground connection: We recommend that you do not use a factory ground.
  • Page 19 H1/9 YELLOW (+) ignition input: Connect this wire to the (+)12V igni- tion wire. This wire must show (+)12V with the key in Run position and during cranking. Take care to insure that this wire cannot be shorted to the vehicle chassis at any point. H1/10 BROWN (+) siren output: Connect this to the RED wire of the siren.

  • Page 20: Auxiliary Harness Wire Connection Guide

    vide (-) ground when the ignition is turned off and will continue to out- put (-) ground until a door is opened then closed. This can be used to energize the accessory circuit in the vehicle to keep the radio and other accessories on after the ignition is turned off.

  • Page 21: Auxiliary Harness Wiring Guide

    Auxiliary harness wiring guide H2/1 BROWN (-) horn honk output: This wire supplies a 200 mA (-) output that can be used to honk the vehicle’s horn. It provides a pulsed output when the security system is armed/disarmed and in the triggered sequence or in panic mode.
  • Page 22 be used for disarm defeat input. The H2/3 wire connection is not required if using H2/7 YELLOW/BLACK as a disarm defeat wire. H2/4 BLUE disarm input: Connect the BLUE wire to a wire that changes state when the doors are unlocked using the factory keyless entry trans- mitter.

  • Page 23: Keyless Entry System Types

    Keyless entry systems—two types There are two main types of keyless entry systems. Systems that unlock the driver’s door first and Systems that unlock all doors at the same time. drivers priority unlock To test for this type of system unlock the door, by using the factory remote.
  • Page 24 No priority—driver’s door unlock This type of keyless entry system is common in import vehicles as well as many Jeep vehicles. When unlocking the doors with the transmitter all doors unlock at the same time. It is recommended to use H2/7 YEL- LOW/BLACK wire for Disarm Defeat instead of the H2/3 RED wire.

  • Page 25: Door Lock Harness Wire Guide

    Door lock harness wire connection guide These door lock outputs are for Passive arming control of the factory door locks. They can also be used to control the door locks with the ignition switch for vehicles that do not have this feature in the factory RKE system.

  • Page 26: Data Port-Bitwriter

    Data port—Bitwriter ® The black three-pin port can be used for programming the unit using the Directed Bitwriter, a hand held programming tool. The Bitwriter also allows programming of features that are not available in the feature menus. Four-pin optional sensor harness RED wire The red wire supplies constant power to the optional sensor.

  • Page 27: Door Lock Learn Routine

    Door lock learn routine Before the unit will respond to the factory remote keyless system, it must learn the polarity of the door lock wires. To learn the lock polarity: It is important that all the INPUT signals to the control module are in the rest status state (no activity) before entering the learn routine.

  • Page 28: To Exit The Learn Routine

    If the lock/unlock learn was unsuccessful, unplug the 12 pin harness for 15 seconds and re-attempt procedure. The systems learn routine will only be active for ten seconds after power up. If locks are not successfully learned unplug main 12 pin harness for 15 seconds and re-attempt.

  • Page 29: On-Board Dual Stage Shock Sensor

    On-board dual stage shock sensor There is a dual-stage shock sensor inside the control module. Adjustments are made via programming routine indicated below. Since the shock sen- sor does not work well when mounted firmly to metal, we recommend against screwing down the control module. The full trigger of the onboard shock sensor reports zone 2.
  • Page 30 When the sensitivity increases, two quick, short chirps/honks are heard. Decreased sensitivity is indicated by one quick chirp. If maximum or minimum settings are reached, a long chirp/honk is added. You can test the adjustment setting by striking the outside of the vehicle with varied force levels to trigger the sytem.

  • Page 31: Internal Polarity Jumper

    Internal polarity jumper A 10A fuse is used as both a fuse and a polarity jumper. This jumper determines the light flash output polarity. In the (+) position (default), the on-board relay is enabled and the unit will output (+)12V on the WHITE wire, H1/2.

  • Page 32: Long Term Event History

    Long term event history The control module will store the last 2 triggers in memory that are not erased when the ignition is turned on. This can be helpful for trouble shooting false alarm reports. To access the event history use the follow- ing procedure.

  • Page 33: Feature Programming

    Feature programming The feature programming routine is used to access and change any of the feature settings in the two menus below. The feature settings can be accessed and changed by using one of the following: The Valet switch to enter the feature programming routine. Use of the Directed Electronics Bitwriter is recommended.

  • Page 34: Once A Feature Is Programmed

    5. Within 5-seconds, press and release the Valet switch the number of times corresponding to the desired feature listed below. Then press the Valet switch one more time and hold. The siren/horn will sound the num- ber of times equal to the feature number selected. 6.

  • Page 35: Accessing Feature Menu 2

    Accessing feature menu 2 Release, then press and hold the Valet switch. After 3-seconds, the unit will advance to the next menu and the siren/horn will sound 2 times to indicate feature menu 2 has been entered. Exiting feature programming You can do ONE of the following: Turn the ignition On.

  • Page 36: Bitwriter Only Features

    Bitwriter ONLY features ® Due to memory limitations for this system, the following features can only be programmed using Directed’s Bitwriter programmer. Factory default ® settings are shown in bold (left column). Shock Sensor Adjustment - programmable 0-16 Siren duration - 0 to 180 seconds Channel 3* Validity Latched/Latched reset w/ign/lacth 30 sec- ond timed/2nd unlock/ delayed acc...

  • Page 37: Feature Menu 1

    Feature menu 1 Factory default settings are shown in bold. Feature Lock Button (one chirp) Unlock Button (two chirps) Step Active arming Passive arming Chirps ON Chirps OFF Door Trigger Error Chirp ON Door Trigger Error Chirp OFF Ignition-Controlled Domelight ON Ignition-Controlled Domelight OFF Panic Enabled (OEM upgrade) Auxiliary Output Enabled (OEM upgrade) Auxiliary Output...

  • Page 38: Feature Menu 2

    The delayed accessory output allows selected vehicle accessories to remain on (such as radio) when the ignition is turned off. This output is active for 1 hour until a door is opened and closed - or the system is armed using the factory remote transmitter. Feature menu 2 Factory default settings are shown in bold.

  • Page 39: Troubleshooting

    Troubleshooting Starter kill does not work: Is the correct starter wire being interrupted? If the car starts when the starter kill relay is completely disconnected, the wrong starter wire has been cut and interrupted. • Is the yellow wire connected to “true” ignition? Make sure this wire is connected to a wire that has power in the run and start positions.
  • Page 40 Passive or Ignition controlled door locks operate backwards. • This unit has easily-reversed lock/unlock outputs. Recheck Door lock harness outputs (H3) section, to see if you have reversed these. The siren chirps/horn honks when the unit enters panic mode, but the confirmation chirps/honks do not work when locking and unlocking.
  • Page 41 Door Lock Learn Routine does not work, the unit enters the learn routine then chirps/honks and exits. • Some cars do not lock the doors when the door is open. For these vehicles, to program the unit correctly the door needs to be closed. Unit goes into Programming every time the ignition is turned off.

  • Page 42: Wiring Quick Reference Guide

    Wiring quick reference guide © 2009 Directed Electronics...
  • Page 44 The company behind this system is Directed Electronics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology.
