Yealink VP530 Quick Installation Manual

1. Press the key when the phone is idle to get the IP address of your phone.
2. Open the web browser of your computer, enter the IP address into the address bar (e.g.
"http://192.168.0.10" or "192.168.0.10") and click
3. Enter the user name (default: admin) and password (default: admin) in the pop-up dialogue
box and click .
Please locate your computer in the same network segment of the IP phone (192.168.0.X) to access the
web user interface. Contact your system administrator for more information.
Click on
You can configure the network settings in the following ways:
(Obtion an IP Address Automatically): By default, the phone attempts to contact a DHCP
server in your network in order to obtain its valid network settings, e.g. IP address, subnet
mask, gateway, DNS server.
(Configure IP Address manually): If your phone can not contact a DHCP server
for any reason, you need to configure IP address, subnet mask, gateway,
primary DNS and secondary DNS for the phone manually.
(Behind xDSL Modem): If you are using an xDSL modem, you can connect your phone to
the Internet via PPPoE mode. Contact the ITSP for the account and password.
The wrong network setting may result in inaccessibility of your phone and may have an impact on your
network performance. Contact your system administrator for more information.
Click on ->
Register Status: It shows the register status of the current account.
Account Active: You can select Enable/Disable to active/disactive the account.
It is shown on the LCD to identify the account.
Label:
It is shown as Caller ID when placing a call.
Display Name:
It is authenticated ID for authentication provided by ITSP (required).
Register Name:
User Name: It is provided by ITSP for registration (required).
It is provided by ITSP for registration (required).
Password:
It is provided by ITSP for registration (required).
SIP Server:
Check with your system administrator if any error appears during the registration process or if a specific
configuration is required for your registration.
Tap when the phone is idle, tap
to configure the network settings.
Tap when the phone is idle, tap
Contact your system administrator for the password for
Refer to
For more information, refer to the User Guide available online:
c
Copyright 2014 YEALINK NETWORK TECHNOLOGY CO.,LTD.
.
(X=1,2,3,4)
-> ->
-> to configure the account settings.
.
for the parameter informantion.
Quick Installation Guide
www.yealink.com
(V70.2)
