H.264MP-MegaPixels RTSP Streaming User's Manual
H.264 Main Profile RTSP Steaming
Stand Alone
MegaPixels IP Camera
MANUAL
Firmware 2.2.1.3 Version
Revision Date : 2009.09.01
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEC-C1228H and is the answer not in the manual?

Questions and answers

Related Manuals for Solwise SEC-C1228H

Summary of Contents for Solwise SEC-C1228H

  • Page 1 H.264MP-MegaPixels RTSP Streaming User’s Manual H.264 Main Profile RTSP Steaming Stand Alone MegaPixels IP Camera MANUAL Firmware 2.2.1.3 Version Revision Date : 2009.09.01...
  • Page 2 H.264MP-MegaPixels RTSP Streaming User’s Manual WARNING: If the actions indicated in a “WARNING” are not complied with, injury or major equipment damage could result. A warning statement typically describes the hazard, its possible effect, and the measures that must be taken to reduce the hazard.
  • Page 3 H.264MP-MegaPixels RTSP Streaming User’s Manual All the safety and operating instructions must be read before the unit is operated. • Make sure not to connect the power before you install the camera. • There is great chance of damaging your camera if the camera is opened by an unqualified service engineer or installer.

  • Page 4: Table Of Contents

    H.264MP-MegaPixels RTSP Streaming User’s Manual Table of Contents Chapter 1 Features....................................5 Chapter 2 Packing Detail ...................................8 Chapter 3 Cable and Connectors..............................9 3.1 FRONT VIEW ............................ 9 3.2 REAR VIEW ............................ 11 Chapter 4 System Requirement ..............................14 4.1 The lowest hardware configuration....................14 4.2 The recommended hardware configuration ..................

  • Page 5: Chapter 1 Features

    H.264MP-MegaPixels RTSP Streaming User’s Manual Features Chapter 1 H.264 Main Profile Encoding, Duplex Audio Optional Wi-Fi, POE & Hi Power white LEDs Clairvoyant mega-pixels IP Cameras offer cost-effective, indoor/ outdoor (Wi-Fi) IP surveillance solution for remote monitoring and stand alone alarming over a local area network or the Internet.
  • Page 6 H.264MP-MegaPixels RTSP Streaming User’s Manual - Management software that can manage up to 1728 cameras in 48 groups, display maximum 36 cameras video on single screen, support video lost、motion detection and sensors alarm functions - Support masks function to mask sensitive area to protect privacy. - Support active &...
  • Page 7 H.264MP-MegaPixels RTSP Streaming User’s Manual Outdoor dome IP Camera : 2.5kgs Input Power Supply: Optional POE-PSE Less than 8W, optional Maximum Power: DC 48V POE-PD -10 ~ +55 ℃ Operating Temperature: -20 ~ +70 ℃ Storage Temperature: IP64 (Outdoor bullet IP Camera) Weather Proof: System Requirements: Operation System:...

  • Page 8: Chapter 2 Packing Detail

    H.264MP-MegaPixels RTSP Streaming User’s Manual Packing Detail Chapter 2 1. IP Camera 2. Installation Software utilities CD 3. AC Adaptor & Power Cord 1. IP Camera (optional Wi-Fi or POE) 2. Installation Software utilities & Central Management Software CD 3. AC Adaptor (DC12V/ 2A) &...

  • Page 9: Chapter 3 Cable And Connectors

    H.264MP-MegaPixels RTSP Streaming User’s Manual Cable and Connectors Chapter 3 3.1 Tail Wire Connectors Video 1. Terminal (A+/ B-) : RS-485 A+/ B-; D+/ D- to control PTZ 2. Reset Terminal : Restore to factory default settings 3. RCA connectors : Female audio outputs to Speakers 4.
  • Page 10 H.264MP-MegaPixels RTSP Streaming User’s Manual Installing...

  • Page 11: Rear View

    H.264MP-MegaPixels RTSP Streaming User’s Manual 3.2 Optionals Port Name Description Detachable 5 dBi omni antenna RSMA Connector ○ Optional high gain directional antenna Tail Cable 3 feet wire ○ Connect BNC output to monitors RS-485 port can be used to connect the external PAN/ TILT Seat DESCRIPTION 485A(TX+) RS485:Transmit data...
  • Page 12 H.264MP-MegaPixels RTSP Streaming User’s Manual Alarm input: To connect the Active Infrared Sensor to IP CAMERAR camera ALARM IN, will trigger alarm when light beams interrupted.
  • Page 13 H.264MP-MegaPixels RTSP Streaming User’s Manual Alarm output: WARNING: If connect higher power loading (> 1A) directly to camera alarm out will cause damage the camera. Higher current (>0.5A) will accelerate aging of the relay on camera PCB, external relay box is always recommended to protect the camera.

  • Page 14: Chapter 4 System Requirement

    H.264MP-MegaPixels RTSP Streaming User’s Manual System Requirement Chapter 4 4.1 The lowest hardware configuration ◆CPU: Intel Pentium 2.0GHz (Don’t support AMD CPU) ◆Memory:1,024MB ◆Graphics Card: TNT2 ◆Sound Card: Speaker, Mic ◆Hard Disk: Recording Image，no less than 40G 4.2 The recommended hardware configuration ◆CPU: Intel Core2 DUAL 2.0GMhz or above ◆Memory: 2,048MB ◆Graphics Card: Nvidia Geforce FX9400 or ATI RADEON 9000 series 256MB video...

  • Page 15: Chapter 5 Installation

    H.264MP-MegaPixels RTSP Streaming User’s Manual INSTALLATION Chapter 5 5.1 CONNECT to PC or LAN CAUTION: Please use the DC power adapter that is provided with the camera. Connecting camera to other power source will cause permanent damage to the camera. NOTE: Please use straight Ethernet cable (CAT.
  • Page 16 H.264MP-MegaPixels RTSP Streaming User’s Manual Click “Search Camera” on Utility CD auto-play menu*, will find all the Clairvoyant IP cameras in your local network. * To use SearchNVS software to search and modify network parameters (IP address, Subnet mask, Gateway etc.). NOTE: A: Find the SearchNVS.exe in 【tool software】...
  • Page 17 H.264MP-MegaPixels RTSP Streaming User’s Manual prompt”, press “Enter” button, you will get your PC Type “ipconfig” at command IP address/ Subnet mask/ Gateway Network Interface Card information.
  • Page 18 H.264MP-MegaPixels RTSP Streaming User’s Manual Please remember the IP Address，Subnet Mask, Default Gateway，then setup the IP Camera IP address according to your PC IP address to ensure computer & IP Camera IP “in the same subnet” addresses are For example : Set IP Camera IP addresses to 192.168.1.100. Default Gateway & Subnet Mask same as PC.
  • Page 19 H.264MP-MegaPixels RTSP Streaming User’s Manual same subnet (LAN) correctly. If the screen displays other information, please confirm the IP address settings and check the network cables again. Warning: Please consult your office network administrator to get a free IP for your IP Camera, duplicated IP address will cause undesired problems.

  • Page 20: Connect To Wan

    H.264MP-MegaPixels RTSP Streaming User’s Manual 5.2 CONNECT to WAN Connect IP Camera to your broadband router or NAT gateway. Do the following setup: 1. Setup Virtual Server/ forward port on your router to camera, 2. or set your Camera IP to router DMZ 3.

  • Page 21: Install Activex And Login

    H.264MP-MegaPixels RTSP Streaming User’s Manual Note: a. Broadband router is firewall in nature will block all accesses from Internet, you will need to set virtual server (port forwarding) on your router, normally we will always suggest to use port 80 or port > 1024 for web port to avoid conflicts, port <1024 are frequently used by other applications.
  • Page 22 H.264MP-MegaPixels RTSP Streaming User’s Manual Remember to un-check the “Require Server verification (https:) for all sites in this zone” Type in http://CameraIP_address or URL to “Add this website to the zone:” field, click on “Add” button.
  • Page 23 H.264MP-MegaPixels RTSP Streaming User’s Manual You can add you LAN subnet to your trusted sites by adding http://192.168.0.* if your LAN subnet is 192.168.0.xxx. Choose Custom level and enable all ActiveX features of Trusted sites zone IE browser “Tool” “Internet Options” “Security“ “Custom Level” ”ActiveX control and Plug-ins”...
  • Page 24 H.264MP-MegaPixels RTSP Streaming User’s Manual After installed CAMERA ActiveX controls, enable “Run ActiveX controls and plu-ins”, you can view camera video as followed: Type IP address of the IP camera in Internet Explore address field; Click “Enter” to bring up the camera Login page as illustrated below:...
  • Page 25 H.264MP-MegaPixels RTSP Streaming User’s Manual Download ActiveX Click【File】to download the ActiveX： A new dialogue box will pop-up, click 【Run】to start Installing ActiveX: Close current Internet Explorer Window, close all IE Windows. click “Install” button， after installed the ActiveX will show “Install OK”.
  • Page 26 H.264MP-MegaPixels RTSP Streaming User’s Manual Again, type IP address of the IP camera in Internet Explore address field; Click “Enter” to bring up the camera Login page as illustrated below: admin Input User name (Default: admin)、 Password (Default: admin)， click “Submit” to bring up camera video page: Live View System...

  • Page 27: Chapter 6 Software Configurations

    H.264MP-MegaPixels RTSP Streaming User’s Manual Software Configurations Chapter 6 6.1 Menu Tree Snap Record Live view Replay System/ NTP/ Storage Settings Call Speaker Video/ Audio Settings Motion Alarm Alarm Set Sensor Network Fault Zoom in Basic Set Full Screen Network Set Advanced Images Set User management...

  • Page 28: Live View Page

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.2 Live View Page In the Live view webpage, administrator can do operations : Taking Snapshots, Recording, Playback, Talk-Back, Speaker, Alarm on/ off and Image Parameters Settings. 【Snap】 click “Snap”, take the current image snapshot, which can be stored in your computer hard drive in JPG format.
  • Page 29 H.264MP-MegaPixels RTSP Streaming User’s Manual 【Full Screen】Enlarge to full screen 【Pan control】up, down, left, right, Automatic, speed adjusting 【Image Parameters】 CCD IP Camera: brightness, contrast, chroma, saturation adjustment as follows: 【Lens Control】It can be adjusted Zoom, Focus, Aperture, Light, Clip, Preset, and Pan operation.

  • Page 30: Error Message

    H.264MP-MegaPixels RTSP Streaming User’s Manual Error Message Note: If you see above screen, which indicate your hardware is not powerful enough, please choose PC with more advanced processor. Minimum system requirement are: CPU: PIII 2.0GHz or above; AMD processors are not supported Display card : DirectX 9c compliant.
  • Page 31 H.264MP-MegaPixels RTSP Streaming User’s Manual...

  • Page 32: Video Playback

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.3 Video Playback Click【Replay】button: , to bring up the following webpage User can search the recorded image files or snapshot pictures in local PC or SD card according to date. 【Date】User can check the recorded video files or snapshot pictures according to the selected date, click the button : calendar appears: Click “《...
  • Page 33 H.264MP-MegaPixels RTSP Streaming User’s Manual 【PC】check the recorded video files or snapshot pictures in local PC according to the selected date. 【SD Card】check the recorded video files or snapshot pictures in SD Card according to the selected date. 【File List】Shows the selected recorded video files or snapshot pictures in the File List. Check the current recorded video files or snapshot pictures in the list as follows: There are two Lists: Record &...

  • Page 34: System Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual Click【Pause】to pause download manually，click【Start】to continue downloading the remaining files，click【Delete】to del the file，click【Close】to close the download information window. 6.4 System Settings System Clock: click: “Time Sync”, The camera time will be synchronized with your computer. 【NTP Parameter】: Please input the correct NTP server address and select the correct time zone.
  • Page 35 H.264MP-MegaPixels RTSP Streaming User’s Manual 【System Information】Display name, ID number and camera type (NTSC/ PAL). Note: Rename the IP Camera name and save it, the camera will reboot. 【Restore Default】Resume all the IP Camera parameters (Including Network parameter except MAC address) to default factory settings. Note: Be careful when use this function.

  • Page 36: Video Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.5 Video Settings 【Image】: Set image resolution Prefered Stream : 1600 x1200, 1280 x 960, 1280 x 720, 800 x 600 Alternate Stream : 640 x 352, 320 x 176, 160 x 120 【Quality】: Options for Fine, Normal, Basic and there is advanced image setting. 【Advanced image setting】...
  • Page 37 H.264MP-MegaPixels RTSP Streaming User’s Manual Choose LAN or WAN defaults to get best applicable settings Note: Why can't get image from H.264 IP Cameras? But can access MJPEG IP camera images with the same broadband WAN/ Internet connection? IP Cameras with H.264 compression won't display video if I frame lost, received frames won't display without I frame, at bad network connection, packets may lost or out of sequence, video won't start until a full I frame arrived.

  • Page 38: Motion Alarm Setting

    H.264MP-MegaPixels RTSP Streaming User’s Manual 【Audio】 Set audio ON/OFF（Default: OFF）,there are two models: Microphone and Line input. If users don’t need audio status; please close audio input to save the DSP resource and network resource. 【Mask Area Set】 Mask all image or Mask part image, the whole image divided into 22 * 18 blocks.

  • Page 39: Sensor Alarm Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 【Alarm record in PC】Automatically recording video and stored it on PC storage when alarming if no SD card in camera. 【Alarm snapshot in SD Card】Automatically capturing image and stored it in SD when alarming. If there are continuous alarms, the interval time of capturing is the delay time.
  • Page 40 H.264MP-MegaPixels RTSP Streaming User’s Manual snapshots is the delay time. For example, the alarm delay is 10 seconds; it will capture an image store on SD card every 10 seconds. The snapshots on SD card can be downloaded to PC when 【replay】 . And when the SD is full, the old file will be over-written automatically.

  • Page 41: Network Setting

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.8 Network Setting Setting IP Camera address, Subnet mask, Gateway, MAC, Data port、HTTP port、DNS address. The device will restart after setting and save. If IP camera is connected to Wi-Fi network, please don’t use the same subnet IP addresses for both wired & Wi-Fi. Please make sure the IP camera IP is set to the same “subnet”...
  • Page 42 H.264MP-MegaPixels RTSP Streaming User’s Manual No one can access your LAN IP through Internet or you will be in big security threat, Hackers can access your bank account and secrets stored in your LAN PC 1. Broadband router is firewall in nature will block all accesses from Internet, you will need to set virtual server (port forwarding) on your router, normally we will always suggest to use port >...
  • Page 43 H.264MP-MegaPixels RTSP Streaming User’s Manual 【DDNS Port】Default :30000. 【Data Port Map No】 Default :5000, is the TCP/IP port open on your Gateway/ Firewall which will forward to your camera. 【HTTP Port Map No】Default :80, is the TCP/IP port open on your Gateway/ Firewall which will forward http access to your camera.

  • Page 44: Advanced Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.9 Advanced Settings Mail Setting： When there is a motion alarm, the camera will send the alarm mail to the designated email box automatically 【SMTP Server】Your Email server address, for example:hinet mail, the SMTP server is msa.hinet.net 【Mail From】sender email address.
  • Page 45 H.264MP-MegaPixels RTSP Streaming User’s Manual function will map port for camera automatically. 【UPNP Network Card】The camera interface connect to UPNP Gateway/ Firewall. 【UPNP mode】There are Designate and Auto modes: Designate mode: Camera will designate the data port and web port to UPNP Gateway/ Firewall.

  • Page 46: User Management

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.10 User Management There are two user accounts. One is Administrator another is Guest. Administrator can change parameters of IP Camera. Guest is not allowed to change parameter of IP Camera. Note: Username/ Password are case sensitive, consisted of letters, numbers, underline or dot up to 16 characters.

  • Page 47: Rs-485 Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.11 RS-485 Settings Optional Keyboard can be connected to RS485 terminal. Correct Address, Protocol, Baudrate, Date bit, Stop bit, Perity Check, Flow Control must be set. C1228H PTZ address: 1 Baudrate : 2400bps Data bits Stop bits Check type : none Flow ctrl...

  • Page 48: Storage Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.12 Storage Settings CAUTION: Never hot-swap SD card or valuable recording stored in SD card will be lost!!
  • Page 49 H.264MP-MegaPixels RTSP Streaming User’s Manual...

  • Page 50: Local Settings

    H.264MP-MegaPixels RTSP Streaming User’s Manual 6.13 Local Settings 【Code stream】Select primary stream to display on IE 【Preview mode】Choose real time for least delay 【Record file path】Setting storage path for recorded video file and captured snapshot file. Default path: C:\XDNVS...

  • Page 51: Appendix 1 Network Port For Ip Camera

    H.264MP-MegaPixels RTSP Streaming User’s Manual Network Port for IP Camera Appendix 1 80 (Web port) 5000 (Communication port, Audio/ Video data transmitting Port, Talk data transmitting Port) 5000 Audio/Video data transmitting Port Network Factory Defaults Appendix 2 Wired network defaults: IP Address: 192.168.55.160 Data port: 5000...

  • Page 52: Appendix 3 Cross Ethernet Cable Making Tip

    H.264MP-MegaPixels RTSP Streaming User’s Manual Cross Ethernet Cable Making Tip Appendix 3 I. LAN Plug Pin: 1 ~ 8 II. LAN Cable PART-A PART-B III. Connection Method a. Connect LAN Cable Part-A and LAN plug by order as one to one . b.
  • Page 53 H.264MP-MegaPixels RTSP Streaming User’s Manual ========================== The End =========================...
