- Page 1 JK Audio THAT-1 Telephone Handset Audio Tap Users Guide Telephone Interface Products...
- Page 2 Unplug the modular handset cord from your telephone base. Using the black handset jumper cord that we have provided, connect the telephone jack of THAT-1 to the handset jack on your telephone base. Plug your handset cord, and handset, into the handset jack on THAT-1.
- Page 3 This is not adjustable. We picked a suitable mix ratio for most telephones. The supplied adapter cable allows you to take the left channel from a 1/8" mini stereo headphone or mono microphone jack and attach it to the RCA jacks on THAT-1.
- Page 4 In any case you can always listen over the handset receiver. Note: Not all telephones are built alike so we can not guarantee THAT-1 will work with any handset design out there. We designed the interface to work with most...
- Page 5 Output Impedance 2800 ohms Level 100 mV RMS Isolation 1500 VRMS Handset and Telephone connectors: Modular 4pin/4wire handset jacks Handset Compatibility: THAT-1 is designed to work with many dynamic and electret handsets. Not for use with handsets that have keypads.
- Page 6 FCC Registration Your new JK Audio product has been registered with the Federal Communications Commission (FCC). This product complies with the standards in Part 68 of the FCC rules. The FCC requires us to provide the following information: Connection and use with the nationwide...
- Page 7 FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your JK Audio product. If such changes are planned, you'll be notified.
- Page 8 Warranty The model THAT-1 is covered by a 2 year warranty to be free from defective workmanship and materials. In the event that the THAT-1 needs repair, you must call us to get an authorization, and then carefully pack and ship it to us. You will pay for shipping to us and we will pay for return back to you, UPS ground.
