- Page 1 Standalone, fully automated CD/DVD Duplication System User Manual 5542 Brisa Street, Suite F • Livermore, CA 94550 Tel: 925-447-8484 • Fax: 925-447-8811 • www.all-pro-sol.com...
-
Page 2: Table Of Contents
HERA Series CD/DVD Duplication System / User Manual Table Of Contents Introduction........................1 Quick Start ......................... 2 Getting Started ………………………………………………………………………………..2 Mounting Tower …………...……………………………………………………………...3 Operating Environment ......................3 Connecting Power ……………………………………………………………………………..5 Operation …………………………………………………………………………………7 Main Function ………………………………………………………………………….10 1. Copy .………………………………………………………………………………………10 2. Copy + Compare .….………………………………………………………………………11... -
Page 3: Trouble Shooting
Automated CD-R Duplicator System / CD-2, CD-4 &CD-7 Series / User Manual Maintenance …………………………………………………………………………….22 Trouble Shooting ……………………………………………………………………….23... -
Page 4: Introduction
HERA Series CD/DVD Duplication System / User Manual Thank you for choosing the HERA Series duplication systems. Hopefully this equipment will bring you satisfaction and great pleasure in CD/DVD duplication. Features: • Stand-alone design, no PC nor software required. • Easy operation, no training required. -
Page 5: Quick Start
Getting started Carefully remove your system from the shipping box and verify that all parts are present. If there are missing or damaged parts contact All Pro Solutions or an authorized distributor immediately to correct any miss-packed or missing parts. -
Page 6: Mounting The Tower
HERA Series CD/DVD Duplication System / User Manual Operating Environment Your CD/DVD System should be used in a climate-controlled environment free of dirt, dust, excess humidity, excessive heat or electro-magnetic interference. Allow at least four (4) inches of clearance around the sides and back of the system for ventilation. - Page 7 HERA Series CD/DVD Duplication System / User Manual Fig. 1 System unassembled (Hera-3 and 6) Fig.2 Fig. 3 Tower alignment Side view...
-
Page 8: Connecting Power
HERA Series CD/DVD Duplication System / User Manual Connecting power Plug one power cable into the tower system, and the other one into the autoloader. Plug each power cable into the proper power source and connect Serial Cable as shown in Fig. 4b for Hera-3 and 6 or Fig. - Page 9 HERA Series CD/DVD Duplication System / User Manual Fig. 5 Hera-9 (system unassembled) Fig. 6a Fig. 6b Hera-9 (system assembled) Hera-9 (back view – cables)
-
Page 10: Operation
HERA Series CD/DVD Duplication System / User Manual The autoloader is equipped with input/output hoppers. First, the picker takes the blank media from hopper # 1 and loads the drives. When all copies have been made, will pick up media from the drives and brings it to the output hopper. - Page 11 HERA Series CD/DVD Duplication System / User Manual 2.1.1. Picker will take the master from input hopper, loads it into drive # 1, goes back to the input hopper to take blank media and loads the rest of the drives.
- Page 12 HERA Series CD/DVD Duplication System / User Manual 2.2.5. Failed discs will remain in respective writers. Drives containing failed discs will open automatically, the picker will unload the drives and place failed media into the reject bin. Empty drives will close.
-
Page 13: Main Function
HERA Series CD/DVD Duplication System / User Manual Main functions explained below are based on factory’s default setting. Different settings will cause duplicator to react differently. Please press and hold down MODE while turning on the power; the duplicator will return to factory’s default setting. -
Page 14: Copy + Compare
HERA Series CD/DVD Duplication System / User Manual 2. Copy + Compare This function will copy and compare the good discs with the master. Under this function, the discs that passed in copying will be ejected and re-inserted automatically for compare purpose. The passed discs will be ejected automatically after comparison. -
Page 15: Quick Erase
HERA Series CD/DVD Duplication System / User Manual 6. Quick Erase This function is only used for a rewritable disc with existing data. It would quickly erase the rewritable disc and data will disappear after running this function. 7. Verify This function does verification of target discs. -
Page 16: Sub-Function
HERA Series CD/DVD Duplication System / User Manual In main menu, press and hold down MODE for five seconds (you will hear a da-da-da sound). The menu will be switched to sub-function menu and vice versa. 1. Setup As there are different settings under the setup function to control the duplicator’s operation, we suggest using the original default settings for optimal operation. - Page 17 HERA Series CD/DVD Duplication System / User Manual speed. Under this circumstance, please lower the writing speed under this setting to get higher successful rate in CD/DVD writing. Press MODE to change the setting and GO to exit. 1.4. Autoloader Default setting is CLASS2.
- Page 18 HERA Series CD/DVD Duplication System / User Manual the setting is “Yes”, there will be no message shown even there is an error in reading. You can use this function to copy some discs with errors. Press MODE switch to change and GO to exit.
- Page 19 HERA Series CD/DVD Duplication System / User Manual This function is built for ultimate burning speed, removing unnecessary interrupt detection in BIOS programming. Several conditions have to be met to make this option work: (a) For DVD only; (b) Hard drive to be connected at IDE#1; (c) Abort during operation is canceled.
- Page 20 HERA Series CD/DVD Duplication System / User Manual stored in current partition of hard drive. This option will not be saved and will be restored to “No” during rebooting. You will have to change the setting again after rebooting if you wish to use on- the-fly direct copy.
- Page 21 HERA Series CD/DVD Duplication System / User Manual Press MODE to change the setting and GO to exit. 1.22. HD to DVD Write Speed This setting controls the maximum DVD writing speed of writers installed. Default setting is “MAX” which will use the highest DVD writing speed. Sometimes maximum writing speed will cause higher failure rate that may be due to poor DVD quality or unstable DVD writing in high speed.
-
Page 22: Edit
HERA Series CD/DVD Duplication System / User Manual Edit function, in sub-function, is a track-selecting function that can combine tracks on different master discs into one single disc. For example, you can make a collection of favorite songs from different master music discs and store them into one disc. -
Page 23: Delete
HERA Series CD/DVD Duplication System / User Manual g. When “End track” is displayed on the LCD, press GO switch to quit directly since first song number is 4. h. Press MODE to number 6 at “Begin track” and quit. -
Page 24: Burn In
HERA Series CD/DVD Duplication System / User Manual By using this function, users can get information from the media discs loaded in the writers, such as max. write speed, capacity, etc. 6. Burn in This function is a burn-in test function. It will run the emulate write function continuously. Between each cycle of emulate write, the blank discs in writers will be ejected automatically and re-inserted again for continuous testing. - Page 25 HERA Series CD/DVD Duplication System / User Manual You can select different menus (MAINTENANCE menu) by pressing the Mode button next to the LCD panel for about 5 seconds. The order is as follows: Menu Default setting CD to CD...
- Page 26 HERA Series CD/DVD Duplication System / User Manual 1. No display or only black squares on LCD display and the unit does not boot when powered on. Please check the power cable connection and if the environment of power outlet is normal.
- Page 27 HERA Series CD/DVD Duplication System / User Manual 5. COPY completed but CD/DVD disc is not readable / executable? Use compare to check. Change another CD/DVD drive to test. 6. The failure rate is high. Lower the speed of writers and try again.
