- Page 1 Standalone (built-in PC), fully automated asynchronous CD/DVD Duplication System User Manual 1351 East Black Street • Rock Hill, SC 29730 Tel: 803-980-4141 • Fax: 803-980-4145 • www.allprosolutions.com...
- Page 2 If you are uncertain about your rights, contact your legal advisor. WARRANTY____________________________________________________________________ All Pro Solutions, Inc (hereinafter “All Pro Solutions”) warrants its products to be free from defects in materials and workmanship under normal and proper usage for the period stated in your Warranty Card.
-
Page 3: Table Of Contents
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Table Of Contents Quick Start...........................1 Ge tting Starte d …………………………………………………………………………….…..1 Manufacture r Re comme ndations ………………………..……………………………..…..2 Mounting the Towe r …………...……………………………………………………………...2 Mounting the Printe r …………...…………………………………………………………….3 O pe rating Environme nt……………………………………………………………………….4 Conne cting Powe r ……………………………………………………………………………..4... -
Page 4: Quick Start
Carefully remove your system from it’s shipping box and verify that all parts are present. If there are missing or damaged parts contact All Pro Solutions or an authorized distributor immediately to correct any miss-packed or missing parts. You should find the following packaged with your duplicator:... -
Page 5: Manufacturer Recommendations
This packaging was designed specifically for shipping your system. Other packaging may not be as suitable. If you have already disposed of your packaging materials, you can receive a new set from All Pro Solutions for a fee. -
Page 6: Mounting The Printer
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Mounting the Printer This autoloader can be used with Pro III, SpeedJet, EnduraJet II or Teac P55C printers and uses the same mounting system for either one of them. -
Page 7: Operating Environment
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Operating Environment Your APS System should be used in a climate-controlled environment free of dirt, dust, excess humidity, excessive heat or electro-magnetic interference. Your APS System should be placed on a sturdy level surface – away from sources of vibration and excessive lighting. - Page 8 Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Cables supplied with autoloader (power cables not shown) Fig 3b. Autoloader and PC connections Fig 3c. Fig 3d. 4-Drive Tower connections 7/8 Drive Tower connections...
- Page 9 Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Fig 3e. Fig 3f. S peedJet Printer connections Pro III Printer connections Fig 3g. Fig 3h. EnduraJet II Printer connections P55C Printer connections...
-
Page 10: Drive And Printer Alignment
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Drive and Printer alignment Open Align.exe on your desktop and you will see “TES T” under S aved S essions as in fig. 4a. When you open the TEST connection you will have access to the communication port for alignment. - Page 11 Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Once the tower is aligned, gently tighten thumbscrews # 1 on both sides until they touch the adapter and then tighten thumbscrews # 2 (they attach the tower to the autolaoder –...
-
Page 12: Overview
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Overview Before you start using this system, please read the following to ensure proper operation: DVD Duplication Limitations The DVD system will not copy any DVDs that have Copy Protection encoded in the content. -
Page 13: Disc Static And Sticky Me Dia
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Disc Static and Sticky Media Issues The most common problems when using an autoloader are the disc static and sticky media issues. These static charge problems cause multiple discs to stick together, resulting in improper operation and more severely, can shock the robotic arm while loading a disc that causes the system freeze. -
Page 14: Disc Place Me Nt
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Disc Placement Issue Another common problem when using an autoloader is the placement of media into the bins. Placing the media into the bins properly can avoid possible picking errors when operating the autoloader. -
Page 15: Basic Operation
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual 2. It then picks from Input Bin # 3 and places into Input Bin # 2 which becomes Output Bin # 3 and so on. Reject discs are placed on to the deck below the drive trays. -
Page 16: Printer Support
Olympus Series / Automated Standalone Asynchronous CD/DVD Duplication System / User Manual Setting the Media Type for the Input Bins On the menu bar click Configuration and select S ettings Click the Bins tab Where it says Media Type click the drop down box and choose the appropriate...
