Product
Data
WEATHERMASTER® 50HJQ004-016
WEATHERMAKER® 50TFQ004-012
Standard and High Efficiency
50HJQ004-007
50TFQ004-007
50HJQ008-012
50TFQ008-012
50HJQ014,016
905
Single-Package Rooftop
Heat Pump Units
3 to 15 Nominal Tons
Standard-Efficiency (TFQ), and
High-Efficiency (HJQ) heat pump
units offer:
• Pre-painted galvanized steel cabinet
for long life and quality appearance
• Commercial strength base rails with
built-in rigging capability
• Convertible design for vertical or
horizontal supply/return
• Non-corrosive, sloped condensate
drain pan, meets ASHRAE 62 (IAQ)
• Two-inch return-air filters
• A wide assortment of factory-
installed options available, including
high-static drives that provide
additional performance range
• Factory-installed PremierLink™
digital communicating controls
→
• Factory-installed optional gear driven
EconoMi$er IV (vertical return for
sizes 004-014 only) for use with
standard rooftop unit controls (in-
cludes CO sensor control capability)
2
• Factory-installed optional gear driven
EconoMi$er2 (vertical return only)
for use with PremierLink DDC
controls (includes 4 to 20 mA
actuator for demand control
ventilation)
• State-of-the-art defrost system
• Dependable 4-way valve operation
Heat Options
• Field-installed electric heat available
• Glycol hydronic coils
Features/Benefits
Every compact one-piece
unit arrives fully assembled,
charged, tested, and ready to
run.
Quiet, efficient operation and
dependable performance
Compressors have vibration isolators
for quiet operation. Efficient fan and
motor design permits operation at low
sound levels.
