Carrier INDUCED-COMBUSTION GAS FURNACE Quick Manual

Carrier INDUCED-COMBUSTION GAS FURNACE Quick Manual

Induced-combustion gas furnace
Hide thumbs
Table of Contents

Advertisement

Quick Links

NOTE TO INSTALLER:
THIS MANUAL MUST BE LEFT WITH THE
EQUIPMENT USER.
!
WARNING:
Fire or Explosion Hazard. Failure to follow safety
warnings exactly could result in serious injury
death or property damage.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
!
WARNING:
Carbon Monoxide is invisible, odorless, and toxic!
Carrier Corporation recommends a carbon mon-
oxide alarm in your home, even if you do not own
a gas appliance. Locate the carbon monoxide
alarm in the living area of your home and away
from gas appliances and doorways to attached
garages. Follow the alarm manufacturer's instruc-
tion included with the alarm.
INDUCED-COMBUSTION

GAS FURNACE

USER: Please read all manuals and
retain manuals for future reference.
Do not use this furnace if any part has been
under water. Immediately call a qualified
service technician to inspect the furnace and
to replace any part of the control system and
gas control which has been under water.
WeatherMa ker
8000 TS

Advertisement

Table of Contents
loading

Related Manuals for Carrier INDUCED-COMBUSTION GAS FURNACE

Summary of Contents for Carrier INDUCED-COMBUSTION GAS FURNACE

  • Page 1: Gas Furnace

    WARNING: Carbon Monoxide is invisible, odorless, and toxic! Carrier Corporation recommends a carbon mon- oxide alarm in your home, even if you do not own Do not use this furnace if any part has been a gas appliance. Locate the carbon monoxide alarm in the living area of your home and away under water.

  • Page 2: Welcome To Today'sgeneration Of Comfort

    WELCOME TO TODAY’S GENERATION OF COMFORT Congratulations! Your new, higher efficiency gas furnace is a sound investment which will reward you and your family with years of warm memories winter after winter. Not only is your new furnace energy efficient, it is also extremely reliable.

  • Page 3: Important Facts (Do's And Don'ts)

    IMPORTANT FACTS (DO’S AND factory-authorized replacement parts, kits, and accessories when modifying this product. DON’TS) This furnace contains safety devices which must be manu- •DO: READ AND UNDERSTAND THIS MANUAL. ally reset. If the furnace is left unattended for an extended period of time, have it checked periodically for proper oper- •DO: Have your furnace and vent system inspected annually ation.

  • Page 4: Steps For Starting Your Furnace

    in the safety information above on this label. If you don’t you do not smell gas, go to the next step. smell gas, go to the next step.” 7. Turn the control switch to ON (See Fig. 10.) • If a suspected malfunction occurs with your gas control system, such as the burners do not light when they should, refer to the shutdown procedures on the furnace, or in the next section, to turn off your system, then call your dealer as...

  • Page 5: Shutting Down Your Furnace

    SHUTTING DOWN YOUR FURNACE Should you ever suspect a malfunction in your furnace, you will need to turn the furnace off. The following procedures must be followed: 1. Set your room thermostat to the lowest temperature setting. (See Fig. 14.) 2.

  • Page 6: Filtering Out Trouble

    NOTE: is found on this and the following pages. However, before begin- If side return ducts are used, 2 filters may be required ning maintenance, follow these safety precautions: in some models.The procedure listed above may be used to remove side filters. WARNING FILTER QUANTITY Turn off electrical power supply to your furnace...
  • Page 7 WARNING If holes are found or if the vent pipe is obstructed or is not connected, toxic fumes can escape into your home. DO NOT OPERATE YOUR FURNACE. Call your dealer for service. A failure to follow this warning could result in personal injury or death. 3.

  • Page 8: Installation Data

    7310 West Morris St. Indianapolis, IN 46231 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations . Copyright 2002 Carrier Corporation Form: OM58-102 Replaces OM58-101 Printed in the U.S.A.
