WatchNet ERTSH Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WatchNet
ERTSH DVR Manual
WATCHNETDVR LAB.
1

Advertisement

Table of Contents
loading

Related Manuals for WatchNet ERTSH

Summary of Contents for WatchNet ERTSH

  • Page 1 WatchNet ERTSH DVR Manual WATCHNETDVR LAB.

  • Page 2: Table Of Contents

    Table of Contents FEATURES AND SPECIFICATIONS ..............10 Overview ............................... 10 Features ..............................10 Specification ............................11 OVERVIEW AND CONTROLS ................. 16 Front Panel ............................16 Rear Panel ............................17 Connection Sample ..........................18 Remote Control ............................ 19 Mouse Control ............................21 Virtual Keyboard &...
  • Page 3 Connecting Power Supply ........................23 Connecting Video Input and Output Devices .................. 23 3.5.1 Connecting Video Input ........................23 3.5.2 Connecting Video Output ....................... 24 Connecting Audio Input & Output, Bidirectional Audio ..............24 3.6.1 Audio Input ............................24 3.6.2 Audio Output ............................
  • Page 4 4.3.3 Calendar ............................37 Schedule ............................... 38 4.4.1 Schedule Menu ............................ 38 4.4.2 Snapshot ............................39 4.4.3 Image FTP ............................40 Detect ..............................41 4.5.1 Go to Detect Menu ..........................41 4.5.2 Motion Detect ............................41 4.5.2.1 Point To Zoom ........................... 43 4.5.3 Video Loss.............................
  • Page 5 Menu Tree ............................56 Main Menu ............................56 DVR Setup ............................57 5.3.1 System .............................. 57 5.3.2 Encode ............................. 59 5.3.3 Schedule ............................60 5.3.4 RS232 ............................... 60 5.3.5 Network ............................61 5.3.6 Alarm..............................68 5.3.7 Detect ............................... 68 5.3.8 Pan/Tilt/Zoom ..........................
  • Page 6 Login ..............................81 6.2.1 Real-time Monitor ..........................84 6.2.2 PTZ ..............................86 6.2.3 Color ..............................88 6.2.4 Picture Path and Record Path ...................... 88 Configure .............................. 89 6.3.1 System Information ......................... 89 6.3.2 System Configuration ........................92 6.3.3 Advanced ............................110 6.3.4 Additional Function ........................
  • Page 7 APPENDIX E COMPATIBLE DISPLAYER LIST ..........134 APPENDIX F EARTHING ......ERROR! BOOKMARK NOT DEFINED.
  • Page 8 Welcome Thank you for purchasing our DVR! This operating manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 9: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

  • Page 10: Features And Specifications

    1 FEATURES AND SPECIFICATIONS 1.1 Overview This series product is an excellent digital monitor product. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detail analysis.

  • Page 11: Specification

     Network operation Support network remote real-time monitor, remote record search and remote PTZ control.  Alarm activation function Several relay alarm outputs to realize alarm activation and on-site light control. The alarm input port and output has the protection circuit to guarantee device safety. ...
  • Page 12 1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. Video monitor Video 1-ch VGA output. Output 1-ch HDMI output. Support TV/VGA/HDMI video output at the same time. Video PAL (625 line, 50f/s), NTSC (525 line, 60f/s) Standard Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s Record per channel Speed...
  • Page 13 Manual recording, motion detection recording, schedule recording and Recording alarm recording Mode Priority: Manual recording> alarm recording>motion detection Record and recording>schedule recording. playback Recording 1 to 120 minutes single record duration (Default setup is 60 minutes) Length Playback Repeat When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel.
  • Page 14 16-ch alarm input 4-ch alarm input（You 8-ch alarm input（You （You can set can set normal open or can set normal open or normal close type to normal close type to normal open or Alarm Input select the alarm type. ） select the alarm type.
  • Page 15 Installation Desktop installation Mode...

  • Page 16: Overview And Controls

    2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. Front Panel Please refer to the following sheet for front panel button information. Name Icon Function...

  • Page 17: Rear Panel

    Various fast speeds and normal playback.  Fast play/7 In text mode, input number 7 (English character P/Q/R/S). Play In playback mode, playback the previous video  previous/0 In text mode, input number 0. In normal playback or pause mode, click this button to reverse Reverse/Pau playback...

  • Page 18: Connection Sample

    The 16-ch real panel is shown as below. See Figure 2-4. Figure 2-3 Please refer to the following sheet for detail information. Video input Audio input Video CVBS output Audio output Network port USB port HDMI port RS232 port Video VGA output Alarm input/alarm output/RS485 port Power input port Power button...

  • Page 19: Remote Control

    Figure 2-4 2.4 Remote Control The remote control interface is shown as in Figure 2-6 X282H282H282H Please note remote control is not our standard accessory and it is not included in the accessory bag.
  • Page 20 Figure 2-5 Serial Number Name Function Address Click it to input device serial number, so that you can control Multiple-window switch Please refer to the multiple- window switch button in the front panel (MULT) 0-9 number key Input password, channel or switch channel.

  • Page 21: Mouse Control

    button in the front panel. To end Jump to the end. To beginning Jump to the beginning. 2.5 Mouse Control System pops up password input dialogue box if you click “Setup” button and Left click mouse have not logged in. After login, you can go to the main menu.

  • Page 22: Installation And Connections

    3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.

  • Page 23: Connecting Power Supply

    7. Connect the HDD cable and 8. Place the upper cover back power cable. and screw firmly. After completing HDD installation, please check connection of data ribbon and power cord. 3.4 Connecting Power Supply Please check input voltage and device power button match or not. We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral equipments operation such as cameras.

  • Page 24: Connecting Video Output

    Figure 3-1 3.5.2 Connecting Video Output BNC(PAL/NTSC BNC（1.0VP- P， 75Ω）output and a VGA output. Video output includes a System supports BNC, VGA and HDMI output at the same time. See Figure 3-2 X284H284H284H When you are using pc-type monitor to replace the monitor, please pay attention to the following points: ...

  • Page 25: Audio Output

    Figure 3-3 3.6.2 Audio Output The audio output signal parameter is usually over 200mv 1KΩ (BNC). It can directly connect to low impedance earphone, active sound box or amplifier-drive audio output device. If the sound box and the pick-up cannot be separated spatially, it is easy to arouse squeaking. In this case you can adopt the following measures: ...

  • Page 26: Alarm Input And Output Connection

    3.7 Alarm Input and Output Connection Please refer to the following sheet for alarm input and output connection. See Figure 3-5. X287H287H 287H Figure 3-5 There are two alarm input types for you to select: normal open (NO) and normal close (NC). 1.

  • Page 27: Alarm Input And Output Details

    3.7.1 Alarm Input and Output Details You can refer to the following sheet and Figure 3-6 for alarm input and output information. X288H288H288H AB Connection port Figure 3-6 Parameter Grounding Alarm Ground line 1, 2, …, 8. It becomes valid in low voltage. Alarm Input Three NO activation outputs.

  • Page 28: Alarm Output Port

    3.7.3 Alarm Output Port  3 ways relay alarm output (NO contact). Provide external power to external alarm device.  To avoid overloading, please read the following relay parameters sheet carefully.  RS485 A/B cable is for the A/B cable of the PTZ decoder. Relay Specification JRC-27F Model:...

  • Page 29: Other Interfaces

    1. Connect RS485 A,B on the DVR rear panel. 2. Connect the other end of the cable to the proper pins in the connector on the camera. 3. Please follow the instructions to configure a camera to enable each PTZ device on the DVR. 485 Port Figure 3-8 3.10 Other Interfaces...

  • Page 30: Overview Of Navigation And Controls

    4 Overview of Navigation and Controls Before operation, please make sure:  You have properly installed HDD and all the cable connections.  The provided input power and the device power are matched.  The external power shall be DC +12V 3.3A. ...

  • Page 31: Main Menu

    Figure 4-1 4.1.2 Main Menu After you logged in, the system main menu is shown as below. See Figure 4-2 X292H292H292H There are total six icons: search, information, DVR Setup, backup, advanced setup and system shutdown. You can move the cursor to highlight the icon, and then single click mouse to enter the sub- menu.

  • Page 32: Auto Resume After Power Failure

    Figure 4-3 There are several options for you. See Figure 4-4 X294H294H294H Figure 4-4 The other ways is single click the “Logout” button at the right side of the main view. 4.1.4 Auto Resume after Power Failure The system can automatically backup video and resume previous working status after power failure.
  • Page 33 You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. 4.2.2.1 Manual record menu You can open the manual record dialog via “Main menu -> Advanced Setup -> Manual Record” Manual record menu is shown as in Figure 4-5 X295H295H295H...
  • Page 34 Highlight ○ below All, you can enable all channel recording.  All channel schedule record Please highlight “ALL” after “Schedule”. See Figure 4-7 X297H297H297H When system is in schedule recording, all channels will record as you have previously set (Main menu->Setting->Schedule). The corresponding indication light in front panel will turn on.

  • Page 35: Search & Playback

    Figure 4-9 4.3 Search & Playback 4.3.1 Search Menu Click search button in the main menu, search interface is shown as below. See Figure 4-10. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file. ...

  • Page 36: Basic Operation

    Function Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file Next file Search Backup 4.3.2 Basic Operation 4.3.2.1 Playback Open the calendar, select a day, they all the video record will mapping in the grid about this day, different color means different record type: Green: regular record type.

  • Page 37: Calendar

    Fast play button  In playback mode, click this button to Frame rate may switch between various fast play modes vary due to such as fast play 1,fast play 2 and more. different versions. Slow play button ► In playback mode, click this button to switch between various slow play modes such as slow play 1 or slow play 2.

  • Page 38: Schedule

    4.4 Schedule After system booted up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. 4.4.1 Schedule Menu In the main menu, from setting to schedule, you can go to schedule menu. See Figure 4-12 X301H301H301H ...

  • Page 39: Snapshot

    This function allows you to copy one channel setup to another. After setting in channel 1, you can click paste button and turn to channel 2 and then click copy button. You can finish setting for one channel and then click save button or you can finish all setup and then click save button to memorize all the settings.

  • Page 40: Image Ftp

    Figure 4-14 4.4.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot. 4.4.3 Image FTP In Network interface, you can set FTP server information.

  • Page 41: Detect

    4.5 Detect 4.5.1 Go to Detect Menu In the main menu, from Setting to Detect, you can see motion detect interface. See Figure X302H302H302H 4-16 . There are three detection types: motion detection, video loss, camera masking. 4.5.2 Motion Detect Detection menu is shown as below.
  • Page 42 Figure 4-17 , you can left click mouse and then drag it to set a region for motion detection. X309H309H309H Click Fn to switch between arm/withdraw motion detection. After setting, click enter button to exit. Figure 4-16 Figure 4-17 Figure 4-18...

  • Page 43: Point To Zoom

    Figure 4-19 Figure 4-20 4.5.2.1 Point To Zoom In “Detect” window, there have a option named “Reference Camera” at the right top corner, mouse single click and enable it, then a “Set” button appear, looks like following : If enable this option, that means current channel has been set as a reference camera, reference should a fixed camera, and it’s visual field should wide enough.
  • Page 44 many area for the reference camera, and if some area have motion event happen, then it will trigger other dome camera or PTZ camera execute preset. Click the “Set” button for detail setup, looks like following: At the first line, we can select trigger camera, for example, we select camera 2. At the second line, we can setup for the area, here we max support 8 area, for example, we select area 1 area 2 and area 3, then click “Set”...

  • Page 45: Video Loss

    have motion event happen, then it will trigger these alarm input active. It looks like following. For example, here we set area 1 trigger alarm input 1, area 2 trigger alarm input 2, area 3 trigger alarm input 3. At the 5 line, here we can setup a simple schedule for this function, for example, here we setup to 00:00 ~ 24:00.

  • Page 46: Camera Masking

    Figure 4-21 4.5.4 Camera Masking When someone viciously masks lens, the system can alert you to guarantee video continuity. Camera masking interface is shown as in Figure 4-22 X312H312H312H Tips: You can enable preset/tour/pattern activation operation when video loss occurs. Please refer to chapter 4.5.2 motion detection for detail information.

  • Page 47: Go To Alarm Setup Interface

    4.6.1 Go to alarm setup interface In the main menu, from Setting to Alarm, you can see alarm setup interface. See Figure X313H313H313H 4-23 4.6.2 Alarm setup Alarm interface is shown as below. See Figure 4-23 X314H314H314H  Alarm in: Here is for you to select channel number. ...
  • Page 48 Figure 4-23 Figure 4-24 Figure 4-25...

  • Page 49: Backup

    Figure 4-26 4.7 Backup DVR support USB device backup and network download. Here we introduce USB backup first. You can refer to Chapter 7 Web Client Operation for network download backup operation. 4.7.1 Detect Device Click backup button, you can see an interface is shown as in Figure 4-27 .Here is for you to X319H319H319H...

  • Page 50: Ptz Control And Color Setup

    Figure 4-28 Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. See Figure 4-29 X321H321H32 1H Figures 4-29 The file name format usually is: SN_CH+channel number+time Y+M+D+H+M+S. In the file name, the YDM format is the same as you set in general interface.

  • Page 51: Cable Connection

    4.8.1 Cable Connection Please follow the procedures below to go on cable connection  Connect the dome RS485 port to DVR 485 port.  Connect dome video output cable to DVR video input port.  Connect power adapter to the dome. 4.8.2 PTZ Setup Note: The camera video should be in the current screen.

  • Page 52: Intelligent Positioning Key

    Figure 4-30 Figure 4-32 , please click direction arrows (See Figure 4-33 ) to adjust PTZ position. There X325H325H 325H X326H326H326H are total 8 direction arrows. Figure 4-31 4.8.3 3D Intelligent Positioning Key In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure X327H327H327H 4-34.
  • Page 53  Preset  Tour  Pattern  Border Figure 4-33 Figure 4-32 , click page switch button, the interface is shown as in Figure 4-36 X330H330H 330H X331H331H331H Here you can activate the following functions:  Preset  Tour  Pattern ...

  • Page 54: 1Preset Setup

    4.9.1Preset Setup Figure 4-32 , use eight direction arrows to adjust camera to the proper position. X335H335H 335H Figure 4-35 , click preset button and input preset number. The interface is shown as in X336H336H 336H Figure 4-37 X337H337H33 7H Now you can add this preset to one tour.

  • Page 55: Auto Scan Setup

    4.9.7 Auto Scan Setup Figure 4-35 , click border button. The interface is shown as in Figure 4-30 X347H347H 347H X348H348H348H Please go to Figure 4-32 , use direction arrows to select camera left limit X349H349H349H Then please go to and click left limit button Repeat the above procedures to set right limit.

  • Page 56: Understanding Of Menu Operations And Controls

    5 Understanding of Menu Operations and Controls 5.1 Menu Tree This series DVR menu tree is shown as below. Backup Information HDD Info Version Online Users Default Setting General Encode Schedule RS232 Menu Network Alarm Detect Pan/ Tilt/Zoom Display Search Advanced HDD Management Alarm Output...

  • Page 57: Dvr Setup

    Figure 5-1 5.3 DVR Setup In main menu, highlight setting icon and double click mouse. System setting interface is shown as below. See Figure 5-2. X356H356H356H Figure 5-2 5.3.1 System General setting includes the following items. See Figure 5-3 X357H357H357H ...
  • Page 58 end time by setting corresponding week setup. In Figure 5-4 , enable date button, you can X359H359H359H see an interface is shown as in Figure 5-5 . Here you can set start time and end time by X360H360H360H setting corresponding date setup. ...

  • Page 59: Encode

    Figure 5-5 5.3.2 Encode Encode setting includes the following items. See Figure 5-6. X361H361H361 H Please note some series do not support extra stream.  Channel: Select the channel you want.  Compression: System supports H.264.  Resolution: System supports various resolutions, you can select from the dropdown list. For this model, main stream supports D1/CIF/QCIF.

  • Page 60: Schedule

    Figure 5-6 Figure 5-7 5.3.3 Schedule Please refer to chapter 4.4 schedule. 5.3.4 RS232 RS232 interface is shown as below. There are five items. See Figure 5-8 X363H363H363H  Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program.

  • Page 61: Network

    System default setup is:  Function: Console  Baud rate:115200  Data bit:8  Stop bit:1  Parity: None After completing all the setups please click save button, system goes back to the previous menu. Figure 5-8 5.3.5 Network Here is for you to input network information. See Figure 5-9.
  • Page 62 Figure 5-9 5.3.5.1 Advanced Setup Advanced setup interface is shown as in Figure 5-10 . Please draw a circle to enable X365H365H365H corresponding function and then double click current item to go to setup interface. Figure 5-10 5.3.5.2 IP Filter IP filter interface is shown as in Figure 5-11 .
  • Page 63 Figure 5-11 5.3.5.3 Multiple Cast Setup Multiple-cast setup interface is shown as in Figure 5-12 X367H367H367H Figure 5-12 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D”...
  • Page 64  Administrative scoped addressees -239.0.0.0-239.255.255.255 -Private address space  Like the single broadcast address of RFC1918  Cannot be used in Internet transmission  Used for multiple cast broadcast in limited space. Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666.
  • Page 65 Bangkok GMT+7 Beijing (Hong Kong) GMT+8 Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-14 5.3.5.6 DDNS Setup DDNS setup interface is shown as in Figure 5-15...
  • Page 66 Figure 5-15 Please note NNDS type includes: CN99 DDNS、NO-IP DDNS、Private DDNS、Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. 5.3.5.7 DNS There are two modes: Manual setup and auto setup ...
  • Page 67 Figure 5-17 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify or delete H140H140H1 40HTU folder or not. See Figure 5-19 X373H373H373H Figure 5-18...

  • Page 68: Alarm

    Figure 5-19 Please highlight the icon in front of Enable to activate FTP function. Here you can input FTP server address, port and remote directory. When remote directory is null, system automatically create folders according to the IP, time and channel. User name and password is the account information for you to login the FTP.

  • Page 69: Display

    Figure 5-20 5.3.9 Display Display setup interface is shown as below. See Figure 5-22 X377H377H377H  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series).

  • Page 70: Default

    Figure 5-21 Figure 5-22 , click modify button after channel. You can see an interface is shown as in X378H378H 378H Figure 5-23 . Please note all your modification here applies to local end only. You need to X379H379H37 9H refresh web or client-end to get the latest channel name.

  • Page 71: Search

     Detect  Pan/tilt/zoom  Display  Channel name Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu. Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! Figure 5-23 5.4 Search...

  • Page 72: Hdd Management

    Figure 5-24 5.5.1 HDD Management Here is for you to view and implement hard disk management. See Figure 5-27 X383H383H383H You can see current HDD type, status, capacity and record time. When HDD is working properly, system is shown as O. When HDD error occurred, system is shown as X. You can select HDD mode from the dropdown list such as read-only or you can erase all data in the HDD.

  • Page 73: Abnormity

    Please highlight icon to select the corresponding function. Figure 5-26 5.5.2 Abnormity Abnormity interface is shown as in Figure 5-29 X385H385H385H  Event type: There are several options for you such as disk error, no disk, disconnection, IP conflict and etc. ...

  • Page 74: Alarm Output

    Figure 5-27 5.5.3 Alarm Output Here is for you to set proper alarm output. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure X386H386H386H 5-30 Figure 5-28...

  • Page 75: Auto Restart

     Add group  Modify group  Modify password. For account management please note:  System account adopts two-level management: group and user. No limit to group or user amount.  For group or user management, there are two levels: admin and user. ...

  • Page 76: Tv Adjust

    Figure 5-30 5.5.7 TV Adjust Here is for you to adjust TV output setup. See Figure 5-33 X389H389H389H Please drag slide bar to adjust each item. After all the setups please click OK button, system goes back to the previous menu. Figure 5-31 5.6 Information Here is for you to view system information.

  • Page 77: Hdd Information

    Figure 5-32 5.6.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure X391H391H391H 5-35 ○ means current HDD is normal. X means there is error. - means there is no HDD. If disk is damaged, system shows as “?”.

  • Page 78: Bps

    Figure 5-33 Tips: Please click Fn button or left click mouse to view HDD record time and HDD type and time. 5.6.2 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). Figure 5-36 X392H392H392H Figure 5-34...

  • Page 79: Online Users

     Alarm in  Alarm out  System version:  Build Date Figure 5-36 5.6.5 Online Users Here is for you manage online users. See Figure 5-39 X395H395H395H You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds.
  • Page 80  Restart application: reboot DVR.  Shutdown: system shuts down and turns off power.  Restart system: system begins rebooting.  Switch user: you can use another account to log in. Figure 5-38...

  • Page 81: Web Client Operation

    6 WEB CLIENT OPERATION Please note all the operations here are based on our 4-ch DVR. There might be slightly difference in the interface due to different series. 6.1 Network Connection Before web client operation, please check the following items: ...
  • Page 82 Figure 6-2 After installation, the interface is shown as below. See Figure 7-3 X430H430H430H Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. Figure 6-3 After you logged in, you can see the main window.
  • Page 83 This main window can be divided into the following sections.  Section 1: there are five function buttons: configuration (chapter 7.3), search (chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out (chapter 7.7).  Section 2: there are channel number and three function buttons: start dialog and local play, refresh.

  • Page 84: Real-Time Monitor

    6.2.1 Real-time Monitor In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP, channel number, network monitor bit stream. Figure 6-7 On the top right corer, there are six unction buttons.
  • Page 85 Figure 6-9 Open All You can click it to open all channels. Refresh You can use button to refresh camera list. Start Dialogue You can click this button to enable audio talk. Click 【▼】 to select bidirectional talk mode. There are two options: DEFAULT/G711a. Please note, the audio input port from the device to the client-end is using the first channel audio input port.

  • Page 86: Ptz

    Figure 6-10 6.2.2 PTZ Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to chapter 7.3.2 Setting-> Pan/Tilt/Zoom). Click PTZ button, the interface is shown as in Figure 7-11 X437H437H437H 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform.
  • Page 87 Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. It can realize PTZ automatically. 6.2.2.2 Speed System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster than speed 1.

  • Page 88: Color

    6.2.2.8 Assistant You can select the assistant item from the dropdown list. See Figure 7-13 X443H443H443H Figure 6-13 6.2.3 Color Click color button in section 3, the interface is shown as Figure 7-14 X444H444H44 4H Here you can select one channel and then adjust its brightness, contrast, hue and saturation. (Current channel border becomes green).

  • Page 89: Configure

    Figure 6-16 Click record path button, you can see an interface is shown as in Figure 7-17 X448H448H448H Please click choose button to modify path. Figure 6-17 Click reboot button, system pops up the following dialogue box. See Figure 7-18, Please click OK to reboot.
  • Page 90 Figure 6-19 6.3.1.2 HDD information Here you can view local storage status and network status including, free capacity and total capacity. See Figure 7-20 X450H450H450H Figure 6-20 6.3.1.3 Log Here you can view system log. See Figure 7-21 X451H451H451H...
  • Page 91 Figure 6-21 Click backup button, the interface is shown as in Figure 7-22 X452H452H452H Figure 6-22 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type management, alarm event, record operation, user management, log clear and file operation.

  • Page 92: System Configuration

    6.3.2 System Configuration Please click save button to save your current setup. 6.3.2.1 General Setup Here you can set system time, record length, video format and etc. See Figure 7-23 X453H453H453H Figure 6-23 Figure 6-24 Figure 6-25 Please refer to the following sheet for detailed information.
  • Page 93 Parameter Function Here is for you to modify system time. Please click Save button after System your completed modification Time Sync PC You can click this button to save the system time as your PC current time. Here you can select data format from the dropdown list. Data Format Please select separator such as –...
  • Page 94 6.3.2.2 Encode Encode interface is shown as in Figure 7-26 X454H454H454H Figure 6-26 Figure 6-27 Please refer to the following sheet for detailed information. Parameter Function Here is for you to select a monitor channel. Channel Here is to display current channel name. You can modify it. Channel Name Compression H.264...
  • Page 95 Parameter Function Main Stream It includes main stream, motion stream and alarm stream. You can select different encode frame rates form different recorded events. System supports active control frame function (ACF). It allows you to record in different frame rates. For example, you can use high frame rate to record important events, record scheduled event in lower frame rate and it allows you to set different frame rates for motion detection record and alarm record.
  • Page 96 Parameter Function Time Title  You can enable this function so that system overlays time information in video window.  OSD transparent value ranges from 0 to 255. 0 means complete transparent.  You can use the mouse to drag the time tile position. Channel Title ...
  • Page 97 Figure 6-29 Figure 6-30 Please refer to the following sheet for detailed information. Parameter Function Please select a channel first. Channel Pre-record Please input pre-record value here. System can record the three to five seconds video before activating the record operation into the file. (Depends on data size).
  • Page 98 Parameter Function Setup  Figure 7-29 , click set button, you can go to the corresponding X458H458H 458H setup interface.  Please set schedule period and then select corresponding record or snapshot type: schedule/snapshot, motion detection/snapshot, and alarm/snapshot.  Please select date (Current setup applies to current day by default. You can draw a circle before the week to apply the setup to the whole week.) ...
  • Page 99 Parameter Function Keyboard: COM control protocol. You can use keyboard to control DVR via COM. The value ranges from 5 to 8. Data Bit There are three options: 1/2. Stop Bit Baud Bit You can select corresponding baud bit here. There are four options: none/odd/even.
  • Page 100 Parameter Function UDP Port Default value is 37778. Max Connection Network user max amount. The value ranges from 0 to 10. O means there is no user can access current device. Remote Multiple Set MULCAST address and port.  Host cast Enable MULCAST function.
  • Page 101 Parameter Function The sender email account password. Password Sender email address. Sender Input email subject here. Subject Input receiver email address here. Max input three addresses. Address DDNS The DDNS interface is shown as in Figure 7-34 X464H464H464H Please make sure your DVR support this function. Figure 6-34 Please refer to the following sheet for detailed information.
  • Page 102 NAS interface is shown as in Figure 7-35 X465H465H465H Please make sure your DVR support this function. Figure 6-35 Please refer to the following sheet for detailed information. Parameter Function Please select network storage protocol and then enable NAS enable NAS function.
  • Page 103 Here you can realize network time synchronization. Please enable current function and then input server IP, port number, time zone and update interval. Please note the SNTP supports TCP transmission only and its port shall be 123.The update interval ranges from 1 to 65535. Default value is 10 minutes.
  • Page 104 Alarm Centre Alarm centre interface is shown as below. Figure 6-37 6.3.2.6 Alarm Alarm setup interface is shown as in Figure 7-38 X467H467H467H Please make sure you have connected the corresponding alarm output device such as the light, buzzer and etc.
  • Page 105 Figure 6-38 Figure 6-39 Please refer to the following sheet for detailed information. Parameter Function Event It includes local alarm/network alarm. Type Local alarm: Device detects alarm from input port. Network: Device detects alarm from network. Alarm in Select corresponding alarm channel. Enable You need to draw a circle here so that system can detect the alarm signal.
  • Page 106 Parameter Function Here you can set PTZ movement when alarm occurs. Such as go to activation preset x when there is an alarm. The PTZ configuration events include preset, tour, and pattern. Capture You need to input capture channel number so that system can backup snapshot file when alarm occurs.
  • Page 107 Figure 6-41 Please refer to the following sheet for detailed information. Parameter Function Event There are three types: Motion detection/video loss/Camera Masking. Type Channel Select channel name from the dropdown list. Enable You need to draw a circle to enable motion detection function. There are six levels.
  • Page 108 Parameter Function System can delay the alarm output for specified time after alarm ended. Alarm The value ranges from 10s to 300s. latch Alarm System can upload the alarm signal to the centre (Including alarm upload centre. Record System auto activates motion detection channel (multiple choices) to channel record once alarm occurs (working with motion detection function).
  • Page 109 Figure 6-42 Please refer to the following sheet for detailed information. Parameter Function You can select monitor channel from the dropdown list. . Channel Select the corresponding dome protocol.(such as PELCOD) Protocol Set corresponding dome address. Default value is 1. Please note your Address setup here shall comply with your dome address;...

  • Page 110: Advanced

    Figure 6-43 Please refer to the following sheet for detailed information. Parameter Function Select All Restore factory default setup. Export Export system configuration to local PC. Configuration Import Import configuration from PC to the system. Configuration 6.3.3 Advanced 6.3.3.1 HDD Management HDD management includes net storage management and local storage management.
  • Page 111 Figure 6-44 Please refer to the following sheet for detailed information. Parameter Function Format Clear data in the disk. Read/write Set current SD card as read/write Read only Set current card as read. Recover Recover dada after error occurs. Please note system needs to reboot to activate current setup. 6.3.3.2 Alarm I/O Here you can search alarm output status.
  • Page 112 Figure 6-45 Important The alarm output port should not be connected to high power load directly (It shall be less than 1A) to avoid high current which may result in relay damage. Please use the co contactor to realize the connection between the alarm output port and the load. Please refer to the following sheet for detailed information.
  • Page 113 Figure 6-46 Please refer to the following sheet for detailed information. Parameter Function System enables auto record function as you set in record schedule Auto setup. Enable corresponding channel to record no matter what period Manual applied in the record setup. Stop current channel record no matter what period applied in the Stop record setup.
  • Page 114 Figure 6-47 6.3.3.5 Auto Maintenance Here you can select auto reboot and auto delete old files interval from the dropdown list. See Figure 7-48 X476H476H47 6H Figure 6-48 6.3.3.6 Snapshot Snapshot interface is shown as in Figure 7-49 X477H477H477H...
  • Page 115 Figure 6-49 Please refer to the following sheet for detailed information. Parameter Function Channel It is the monitor channel. There are two modes: Timing and activation. Snapshot mode You can select from the dropdown list. The value ranges from Frame rate 1f/s to 7f/s.

  • Page 116: Additional Function

    Figure 6-50 Please refer to the following sheet for detailed information. Parameter Function Event  The abnormal events include: no disk, no space, disk error, net error. Type  You need to draw a circle to enable this function. Normal The corresponding alarm activation output channel when alarm occurs, There are three channels.

  • Page 117: Search

    Figure 6-51 6.4 Search Click search button, you can see an interface is shown as in Figure 7-52 X479H479H479H Please select record playback mode, and then select start time, end time and channel. Then please click search button, you can see the corresponding files in the list.
  • Page 118 Figure 6-52 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in Figure 7-53 , then you can specify file name and path to download X480H480H480H the file(s) to your local pc. Figure 6-53 Now you can see system begins download and the download button becomes stop button.
  • Page 119 Figure 6-55 Please refer to the following sheet for detailed information. Type Parameter Function Type Record Search general record, alarm record and motion detection record. Alarm Search alarm record. Motion Search motion detection record. Detection Local Search local record. Snapshot Search snapshot file.

  • Page 120: Alarm

    2: Pause 3: Stop 4: Slow play 5: Fast play Playback device IP address and channel number. Playback control bar Figure 6-56 6.5 Alarm Click alarm function, you can see an interface is shown as in Figure 7-57 X483H483H483H Here you can set device alarm type and alarm sound setup.

  • Page 121: About

    Figure 6-57 Please refer to the following sheet for detailed information. Please make sure current device can upload the alarm. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs, Disk full System alarms when disk is full.

  • Page 122: Log Out

    Figure 6-58 6.7 Log out Click log out button, system goes back to log in interface. See Figure 7-59 X485H485H485H You need to input user name and password to login again. Figure 6-59 6.8 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un- installation might result in error.

  • Page 123: Professional Surveillance System

    7 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.

  • Page 124: Faq

    8 FAQ 1. DVR cannot boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 125  DVR color or brightness setup is not correct. 6. Cannot search local records. There are following possibilities:  HDD ribbon is damaged.  HDD is broken.  Upgraded program is not compatible.  The recorded file has been overwritten. ...
  • Page 126  PTZ decoder and DVR address is not compatible.  When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable. ...
  • Page 127  System uses too much CPU resources. Please stop record first and then begin backup.  Data amount exceeds backup device capacity. It may result in burner error.  Backup device is not compatible.  Backup device is damaged. 17. Keyboard cannot control DVR. There are following possibilities: ...
  • Page 128  There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player.  No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. 23. Forget local menu operation password or network password Please contact your local service engineer or our sales person for help. We can guide you to solve this problem.

  • Page 129: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 130: Appendix B Compatible Usb Drive List

    Appendix B Compatible USB Drive List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. If you use the USB drive, please confirm the format FAT or FAT32. Manufacturer Model Capacity Sandisk Cruzer Micro 512M Sandisk...

  • Page 131: Appendix C Compatible Cd/Dvd Burner List

    Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...

  • Page 132: Appendix D Compatible Sata Hdd List

    Appendix D Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And SATA HDD should be used for the DVR with SATA port. Port Manufacturer Series Model Capacity Mode Seagate Barracuda.10...
  • Page 133 Western Digital Cariar SE16 WD5000KS2 500G SATA Western Digital Cariar SE16 WD4000KD2 400G SATA Western Digital Cariar SE16 WD3200KS2 320G SATA Western Digital Cariar SE16 WD2500KS2 250G SATA Western Digital RE series WD5000ABYS 500G SATA Western Digital Caviar Green series WD20EADS SATA Samsung...

  • Page 134: Appendix E Compatible Displayer List

    Appendix E Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) LENOVO(CRT) LXB-FD17069HB 17-inch...
