USER'S GUIDE
satisfont à toutes les dispositions de la Directive N° 1999/5/CE du 07/04/99 du Conseil Européen
comply to all dispositions of the European Council Directives below N° 1999/5/CE
EN 301489-3 V1.4.1 / EN 300330-2 V1.3.1 / EN 50364-1:2001 / EN 60950-1:2006
Boîtier émetteur/Transmitter: EN 301 489-3 / EN 300 330-2 / EN 60950-1 : 2006
Thank you for choosing a NUM'AXES product.
Before using your CANIFUGUE PRO/CANIFUGUE MIX pet fencing system, please read the instructions in
this guide carefully and keep it for future reference.
Before using the pet fencing system, we advise you to have your dog checked by your vet to
ensure it is fit to wear a collar.
Check your dog's neck regularly, the repeated rubbing of the contact points against the
animal's skin may cause irritation. If this happens, remove the collar until all signs of skin
irritation have disappeared.
8 stimulation levels are available on the collar. Start with a low level and define the level from
which your dog reacts by increasing gradually.
User's guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B
DECLARATION « CE » DE CONFORMITE
« EC » DECLARATION OF CONFORMITY
Directive R&TTE 1999/5/CE
déclare que / declares that
les ensembles anti-fugue / the pet fencing systems
CANIFUGUE PRO – CANIFUGUE MIX
et sont conformes aux normes suivantes / and comply with standards below:
Collier récepteur/Receiver collar: ETS 300 683 Ed. 97
EN 60335-1 : 1994 / A11 : 1995 / A1 + A12 : 1996 / A13 + A14 : 1998
745 rue de la Bergeresse – Z.A.C. des Aulnaies – BP 30157
45161 OLIVET CEDEX – FRANCE
Tél. + 33 (0)2 38 63 64 40 / Fax + 33 (0)2 38 63 31 00
18/06/2010 – M. Pascal GOUACHE
NUM'AXES
CANIFUGUE PRO
CANIFUGUE MIX
NUM'AXES
1/16
Advertisement
Table of Contents
Related Manuals for Numaxes Canifugue Pro
Summary of Contents for Numaxes Canifugue Pro
- Page 1 18/06/2010 – M. Pascal GOUACHE Thank you for choosing a NUM’AXES product. Before using your CANIFUGUE PRO/CANIFUGUE MIX pet fencing system, please read the instructions in this guide carefully and keep it for future reference. Before using the pet fencing system, we advise you to have your dog checked by your vet to ensure it is fit to wear a collar.
-
Page 2: Table Of Contents
The CANIFUGUE PRO/CANIFUGUE MIX pet fencing system is a modern and highly effective system enabling you to keep one or more dogs in complete freedom within a perimeter, fenced or unfenced, you have defined. -
Page 3: How The Pet Fencing System Works
CANIFUGUE PRO and CANIFUGUE MIX collars can be used at the same time with the same transmitter. The CANIFUGUE PRO/CANIFUGUE MIX pet fencing system has been designed to give you complete satisfaction with an antenna wire with a maximum length of 800 meters (equivalent to four square hectares). - Page 4 The antenna wire is placed on the ground, buried or raised on an existing fence. For the system to function, the wire must form a continuous loop. Both wires (inward and outward) must be spaced 2 meters apart. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 4/16...
-
Page 5: Canifugue Pro/Canifugue Mix Transmitter
The wire break alarm would alert you to a connexion default (ref. § Safety features). When you disconnect the transmitter, the boundary settings are memorized. Next time you will activate the transmitter, the settings will be the last selected. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 5/16... -
Page 6: Canifugue Pro Receiver Collar
If your dog needs to leave the authorized area, you have to remove the collar or deactivate the transmitter by disconnecting it from the power supply. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 6/16... -
Page 7: Canifugue Mix Receiver Collar
NOTE: the stimulation zone cannot be wider than the warning zone. The following tables indicate the approximate widths of the zones for a 800 m and a 300 m installation: User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 7/16... - Page 8 MAXIMUM warning ~ 4 m Stimulations = 8 Stimulations ~ 2,10 m IMPORTANT: the widths indicated are approximate and vary depending on the configuration of each installation. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 8/16...
-
Page 9: Testing The Pet Fencing System (Boundary Range)
Make sure your dog has enough space to move freely within the defined limits. The wider the zones, the lower the escape risks. Therefore, you have to find a good compromise between zone width and freedom space. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 9/16... -
Page 10: Adjusting The Stimulation Level
In order to test the installation, proceed as follows: Before doing so, make sure the receiver collar is turned Off (CANIFUGUE PRO: green indicator light Off – CANIFUGUE MIX: battery removed from its housing). Fix each wire of the neon test lamp under each contact point (unscrewing them lightly and retightening them so as to pinch the test lamp wires). -
Page 11: Safety Features
warning zone evacuation feature After 10 seconds approx. (CANIFUGUE PRO) / 20 seconds approx. (CANIFUGUE MIX) of continuous presence in the warning zone, your dog will be signalled to leave the zone by the emission of a few short stimulations (stimulation level depending on the selected mode). -
Page 12: Replacing Battery Of Canifugue Mix Receiver Collar
The position of the collar around the neck of the dog should be in the following way: CANIFUGUE PRO: the red mark on the collar is visible and is not in contact with the breast of the dog. CANIFUGUE MIX: the CANIFUGUE label is visible and is not in contact with the breast of the dog. -
Page 13: Getting The Best Results
Your dog’s temperament may not be compatible with the product. Do not hesitate to contact a vet or professional trainer for any further advice. Keep your pet fencing system out of reach of children. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 13/16... -
Page 14: Maintenance
the proof of purchase (invoice or sales receipt) If you omit one of these items, the after sales service will have to invoice you for any repair costs incurred. User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 14/16... -
Page 15: Technical Specifications
(ex. bites, breakage, cracking) use contrary to the instructions or not envisioned therein repairs performed by unauthorized persons User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 15/16... -
Page 16: Spare Parts
745 rue de la Bergeresse – Z.A.C. des Aulnaies – B.P. 30157 45161 OLIVET CEDEX - FRANCE Tél + 33 (0)2 38 63 64 40 / Fax +33 (0)2 38 63 31 00 internationalsales@numaxes.com www.numaxes.com User’s guide – CANIFUGUE PRO/CANIFUGUE MIX pet fencing systems – indice B 16/16...
