WARNING: Do NOT operate the filter or SolarArc while the filter is in the CLOSED position or there are any plugs in
the inlet or outlet as this can create dangerous levels of pressure. Ensure the entire system is open and the filter is in
the FILTER position prior to running the system.
To run the solar heater, simply ensure the filter is in the FILTER position and turn it to the ON position. Run the system
during hours of peak sunlight to maximize heating potential. The use of a solar blanket at night will assist in retaining
the heat generated by the Arc.
This section does NOT cover the winterization of your pool or filter system. Reference your pool and filter manuals or
contact your pool professional for information on how to winterize your pool and filter system.
1) Plug the return fitting to the pool to ensure there is no water loss (Figure 7).
2) Turn the filter to the OFF position and turn the valve to the CLOSED position. The skimmer can also be plugged to
ensure water does not drain from the pool when the return hose is disconnected (Figure 8).
3) Loosen the hose clamps (or threaded coupling for some soft-sided hoses) that connect the pool hoses to the pipe
adapters of the collector.
4) Loosen the end caps to allow the water to drain out of the headers.
5) Turn the unit on its side to ensure all the water is removed from the collector.
6) Once all the water has be evacuated, store the Arc in a dry area that remains above freezing temperatures.
Problems
SolarArc does not appear to be heating the pool.
Bubbles continue to appear from the pool water inlet during

operation.*

SolarArc leaks
* NOTE: Bubbles are normal, as air in the system will need to be expelled during initial startup.
Operation

Winterization

Troubleshooting

Possibilities/Solutions
• Make sure that water is flowing through SolarArc by checking the flow
at the pool return.
• Note the weather - has it been cloudy or raining?
• Use your pool cover at night to reduce heat loss.
• Refer to our order guide - pool size may require additional SolarArcs
• Check the connections for leaks.
• Check the flow rate.
• Check the tubing for leaks or clogging.
• Make sure connectors and hose clamps are tight and not defective.
• Additional Teflon tape on headers and fittings may be required.
5 www.smartpool.com
