- Page 1 MEDIUM DUTY MEDIUM DUTY MEDIUM DUTY MEDIUM DUTY ELECTRIC FRYER ELECTRIC FRYER ELECTRIC FRYER ELECTRIC FRYER OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL Manual Part No: 930155-01 MD Electric Fryer - 1 – Manual Rev No: 4...
-
Page 2: Manual Part No
Model No. Product Description Rev. Date Electric Fryers MLE30F-F 300 Fryer 14/01/08 MLE30F-F-C 300 Fryer with castors 14/01/08 MLE60F-F 600 Fryer 14/01/08 MLE60F-F-C 600 Fryer with castors 14/01/08 Manual Part No: 930155-01 MD Electric Fryer - 2 – Manual Rev No: 4... -
Page 3: Table Of Contents
INDEX INDEX INDEX INDEX Page Cover Sheet: Revision Sheet: Index: Introduction: 4 & 5 General Introduction Important Note Specification: 6 & 9 Electric Supply/Connection Overall Dimensions 6 & 7 Wiring Diagrams 8 & 9 Installation: 10 & 11 Important Note Positioning Electrical Connection Checking &... -
Page 4: Manual Rev No
INTRODUCTION INTRODUCTION INTRODUCTION INTRODUCTION This manual contains all the required information to ensure that your new appliance is installed correctly and that you have all the information necessary to identify and order spare parts. It also contains comprehensive instructions for the user and for cleaning the appliance. To maintain peak performance, it is recommended that the appliance be regularly serviced and that when ordering spare parts, reference be made to the appropriate list quoting the Part No. -
Page 5: Introduction
Introduction Introduction (cont.) (cont.) Introduction Introduction (cont.) (cont.) Important Before installing any item please refer to the installation instructions. We recommend that all servicing other than routine cleaning be carried out by our authorised service agents and will accept no responsibility for work carried out by other persons. For satisfactory operation parts of catering equipment become hot. -
Page 6: Specification
SPECIFICATION SPECIFICATION SPECIFICATION SPECIFICATION 300 Fryer - MLE30F-F 600 Fryer - MLE60F-F Electricity Supply E30F-F E60F-F 230V 1 Phase 400V 3 Phase 4 wire Supply 50 Hz 50 Hz Heat Input 8.3 kW 19.3KW Dimensions 300 Fryer 600 Fryer Width... -
Page 7: Overall Dimensions
Specification Specification (cont.) Specification Specification Overall Dimensions Manual Part No: 930155-01 MD Electric Fryer - 7 – Manual Rev No: 4... -
Page 8: Wiring Diagrams
S S S S pecification pecification pecification pecification (cont.) Wiring Diagram – MLE60F-F Manual Part No: 930155-01 MD Electric Fryer - 8 – Manual Rev No: 4... -
Page 9: Specification
Specification (cont.) Specification (cont.) Specification (cont.) Specification (cont.) Wiring Diagram – MLE30F-F Manual Part No: 930155-01 MD Electric Fryer - 9 – Manual Rev No: 4... -
Page 10: Important Note
INSTALLATION INSTALLATION INSTALLATION INSTALLATION Important MUST be installed by a competent person in accordance with these and any other relevant This appliance regulations. MUST comply with the latest I.E.E. Regulations. The installation wiring WARNING: WARNING: THIS APPLIANCE MUST BE ELECTRICALLY EARTHED . WARNING: WARNING: Before Installation... -
Page 11: Installation
ENSURE THAT THE CONDUIT IS CLEAR OF THE FLOOR WHEN THE APPLIANCE IS IN POSITION . MLE30F-F A 230V, 50Hz, 1 Phase Supply is required, made through the 25mm conduit entry at the rear, suitably fused at an easily accessible fused switch isolator. -
Page 12: User Instructions
USERS INSTRUCTIONS USERS INSTRUCTIONS USERS INSTRUCTIONS USERS INSTRUCTIONS Important Note! MUST be installed by a competent The attention of the user is drawn to the fact that this appliance person in accordance with the latest I.E.E. REGULATIONS. See also the section of this manual referring to Cleaning and General Maintenance. Safety Note This appliance is intended for professional use and shall only be used by qualified personnel . -
Page 13: Operation
Users Instructions (cont.) Users Instructions Users Instructions Users Instructions Controls An isolating switch will have been fitted adjacent to the appliance to enable the power to be switched off when servicing work is being carried out. The isolating switch should also be switched off when the appliance is not going to be used for a long period, e.g. - Page 14 Users Instructions (cont.) Users Instructions Users Instructions Users Instructions Operating Instructions (cont.) To Turn Off OFF " position G. For short periods, turn the thermostat knob to the " UNATTENDED ), turn the thermostat to the “ OFF ” For longer periods, (or if the fryer is to be left ON/OFF switch “...
- Page 15 Users Instructions (cont.) Cooking Chart The following chart is for guidance only. Maximum basket load not to exceed 2 kg. Food Time Temperature Chicken Pieces 5 – 8 Minutes 175ºC Chipped Potatoes (Blanched) 3 Minutes 165ºC Chipped Potatoes (Browning) 1 – 2 Minutes 190ºC Chipped Potatoes (Raw) 4 –5 Minutes...
-
Page 16: Cleaning
Users Instructions Users Instructions (cont.) Users Instructions Users Instructions Cleaning DISCONNECT THIS APPLIANCE AT THE MAINS ISOLATING SWITCH BEFORE CLEANING OR SERVICING . WARNING: WARNING: WARNING: WARNING: THIS APPLIANCE MUST NOT BE CLEANED BY A SPRAY OR JET It will be found that it takes less time and effort if appliances are cleaned every day, particularly while they are still warm and before grease and spillage are burnt on. -
Page 17: User Instructions
Users Instructions (cont.) Users Instructions Users Instructions Users Instructions General Maintenance and Care This equipment is designed and manufactured to give you long, satisfactory service at low cost, provided that it is given proper care and attention at all times. Frequent cleaning and regular checking of correct adjustments will be rewarded by reduced operating and maintenance costs, minimum downtime, and regular results from your cooking. -
Page 18: Service & Maintenance
SERVICE AND MAINTENANCE INSTRUCTIONS SERVICE AND MAINTENANCE INSTRUCTIONS SERVICE AND MAINTENANCE INSTRUCTIONS SERVICE AND MAINTENANCE INSTRUCTIONS ENSURE THAT THE ELECTRICITY SUPPLY TO THE APPLIANCE HAS BEEN TURNED OFF BEFORE DISMANTLING ANY COMPONENTS. MUST only be carried out by a competent person. Maintenance Routine Maintenance Procedure 1) Turn “... -
Page 19: Fault Finding
Service and Maintenance Instructions (cont.) Service and Maintenance Instructions Service and Maintenance Instructions Service and Maintenance Instructions Fault Finding Fault Possible Cause Remedy Mains Pilot Lamp not alight. OFF ” ON ” a) Mains Isolator “ a) Switch “ b) 5 Amp fuse blown b) Check wiring for short. -
Page 20: Instructions
Service and Maintenance Instructions Service and Maintenance Instructions (cont.) Service and Maintenance Instructions Service and Maintenance Instructions Removal of Elements 1) Drain the fryer of oil and remove the Batter Plate. 2) Lift up the elements to gain access to the Cover Plate securing screws. 3) Remove the screws and withdraw the Cover Plate. -
Page 21: Service & Maintenance
Service and Maintenance Instructions Service and Maintenance Instructions ( ( ( ( cont.) Service and Maintenance Instructions Service and Maintenance Instructions Removal of ON/OFF Switch 1) Remove the control panel, secured by two fixing screws. 2) Pull off the wires to the switch (noting their positions). 3) Squeeze together the two securing tabs and then push the switch away from the control panel. -
Page 22: Spare Parts
SPARE PARTS LIST SPARE PARTS LIST SPARE PARTS LIST SPARE PARTS LIST Part Number Description Quantity 924045-18 Control Knob 73000840 Control Knob Clip 926173-01 Amber Neon 926173-02 Green Neon 927447-01 On/Off Switch (E30F-F/E60F-F) 928967-01 Operating Thermostat 928967-02 Override Thermostat EM38 Fuse –... - Page 23 W W W W A A A A R R R R R R R R A A A A N N N N T T T T Y Y Y Y C C C C O O O O V V V V E E E E R R R R...
