Charging the Battery

seat
Important! Before using the Quad for the first time the battery needs
to be charged for a full twelve hours. Only an adult who has read and
understands the following safety warnings should handle, charge or
recharge of the battery.
1. Remove the seat, as described on page 10.
2. Disconnect the red connectors.
3. Plug the charger connector into the red connector from the battery.
Only use the Kid Trax Toys charger included with the Quad (Input: AC
118V–, 0.5A, 60Hz Output: DC 6V, 0.6A).
4. Plug the charger into a standard 118V wall outlet.
Note: The charger may feel warm during charging. This is normal and
not a cause for concern.
5. After charging is complete (at least 12 hours, but no more than 18)
unplug the charger from the wall outlet.
6. Unplug the charger from the charging connector and connect the
battery connectors.
7. Place the seat back on the vehicle, and lock into place.
12
Open
Close
3
battery
charger
red battery
connector
