MINI Cooper S
Owner's Manual
Do not return to store. Call toll free (877) 741-6154 for assistance
and replacement parts.
The owner's manual contains assembly, use and maintenance
instructions. The Kid Trax MINI Copper S must be assembled by an
adult who has read and understands the instructions in this manual.
Keep the packaging away from children and dispose all packaging
before use.
Styles and Colors may vary
Made in China
model number: KT1052TR
Keep instructions for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kid Trax Toys KT1052TR
Summary of Contents for Kid Trax Toys KT1052TR
- Page 1 The Kid Trax MINI Copper S must be assembled by an adult who has read and understands the instructions in this manual. Keep the packaging away from children and dispose all packaging before use. Styles and Colors may vary Made in China model number: KT1052TR Keep instructions for future reference.
-
Page 3: Thank You
The MINI Copper S will bring your child fun and riding enjoyment for years to come. Please call us at Kid Trax Toys Consumer Relations at 877-741-6154 with comments or questions. Customer Service hours are 8AM - 5PM Monday thru Friday CST. -
Page 4: Table Of Contents
Contents Safety........1 Parts ........2 Assembly . -
Page 5: Safety
Safety WARNING! The following safety hazards may result in serious injury or death to the user of the MINI Copper S: • This product contains small parts that are for adult assembly only. Keep small children away when assembling. Remove and dispose of all protective material and poly bags before assembly. -
Page 6: Parts
Parts 12V12AH... -
Page 7: Parts List
Parts List: 1. Battery Charger 13. Steering wheel 2. Soft-back 14. Large Washer (2) 3. Car Seats (2) 15. Small Washer (4) 4. Car Body (includes 16. Large Nut (4) the 12 volt battery) 17. Nut (1) 5. Mirror (2) 18. -
Page 8: Assembly
• Use of a battery or charger other than the supplied Kid Trax Toys 12V rechargeable battery and charger may cause a fire or explosion. Only use the supplied Kid Trax Toys 12V rechargeable battery and charger with the vehicle. - Page 9 WARNING! • Contact or exposure to battery leakage (lead acid) may cause serious injury. If contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes, flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water or milk.
-
Page 10: Charging The Battery
Charging the Battery 1. Plug the charger connector into the battery connector on the battery. Only use the Kid Trax toys 12V charger included with the MINI Copper S (Input: AC 120V, 60Hz Output: DC 12V). 2. Plug the charger into a standard 120V wall outlet. -
Page 11: Attach The Front Wheels
Attach the Front Wheels 1. Slide a large washer onto the front axle. Note: The washer may already be on the axle. 2. Slide a wheel onto the axle with FRONT facing toward vehicle. 3. Slide a wheel cover onto the axle, fitting the two locating pins into the holes of the wheel. -
Page 12: Attach The Rear Wheels
Attach the Rear Wheels 1. Locate a rear wheel (marked Rear with gear-shaped protrusion). 2. Slide the wheel onto the axle with protrusion facing toward vehicle. 3. Fit the gear shaped protrusion into the gear box. 4. Align the two locating pins on the inside of the wheel cover into the wheel holes, and push the wheel cover into place. -
Page 13: Attach The Windshield To The Dashboard
Attach the Windshield to the Dashboard 1. Align the four tabs on the back of the dashboard with the four slots in the windshield. 2. Press the two pieces together. windshield slots dashboard tabs 3. While holding the windshield/dashboard assembly together, turn the windshield/dashboard assembly upside down. -
Page 14: Attach The Dashboard
Attach the Dashboard 1. Connect the wire connectors from the bottom of the dashboard to the wire connector coming from the center of the upper body. under-dashboard connection upper-body connection 2. Open the doors all the way. 3. Align the tabs on the dashboard with the slots on the body. 4. -
Page 15: Insert The Steering Rod
Insert the Steering Rod 1. Place the vehicle on soft material that will protect it from scratching or damage. Carefully turn the vehicle onto its side. Note: It is helpful to have a second person assisting you with these steps. 2. -
Page 16: Attach The Steering Wheel
Attach the Steering Wheel WARNING! • DO NOT mix old and new batteries. • DO NOT mix alkaline, standard (carbon-zinc), or rechargeable (nickel- cadmium) batteries. 1. Remove the battery compartment cover and insert (2) AA batteries into the top of the steering wheel. Place and screw the cover back on. -
Page 17: Attach The Soft-Back
Attach the Soft-back 1. Align the six tabs on the soft-back with the six slots on the back of the body. 2. Snap the soft-back down into place. Note: soft-back there are two tabs in the front, and four tabs in the back of the soft-back soft-back tabs... -
Page 18: Connect The Battery
Connect the Battery Important! Before using the MINI Copper S for the first time the battery needs to be charged for a full 24 hours (see page 6 for battery charging instructions). 1. Fasten the Battery connector to the Main Harness. Note: to correcty attach the two connectors, turn each connector upside down from each other, and slide together. -
Page 19: Install The Car Seats
Install the Car Seats 1. Align the back panel of the car seat with the opening on top of the car seat bracket. 2. Lower the seat into place. 3. Lock the car seat in place by using a coin to tighten the two plastic screws located in the center of the car seat bottom. -
Page 20: Attach The Mirrors
Attach the Mirrors 1. Align the bottom prongs of the mirror with the hole on the car door. 2. Snap down into place. 3. Repeat steps one and two for the remaining mirror. Mirror Car door hole... -
Page 21: Use
Important! Before using the MINI Copper S for the first time the battery needs to be charged for a full 24 hours. Only an adult who has read and understands the safety warnings (see Assembly) should handle, charge or recharge of the battery. Read the Assembly and Maintenance sections before use of the vehicle. -
Page 22: Vehicle Controls
Vehicle Controls 1. Steering wheel: Use to steer the vehicle. 2. Power Switch: Turns the vehicle ON and OFF. 3. Battery Power Indicator: When pressed, the three lights above the Battery Power button Indicate the battery power level. 4. Pressing the button on the right side of the steering wheel will make a horn sound effect. -
Page 23: Maintenance
Water will damage the motor, electrical system and battery. • Kid Trax Toys recommends that you take the vehicle to an authorized service center for periodic maintenance and service. Call Kid Trax Toys Consumer Relations at 877-741- 6154 for an authorized service center. -
Page 24: Battery Storage
• Check the battery and charger (supply chord, connector) for wear and damage before charging. Do not charge the battery if damage has occurred. Only replace with a Kid Trax Toys 12V rechargeable battery and charger. The battery should be charged after each use, or if not used regularly, once a month at a minimum. -
Page 25: Battery Replacement And Disposal
Do not throw the battery away with your regular household trash! 6. Replace the battery with a Kid Trax Toys 12V battery and reconnect the connectors. 7. Replace the metal battery bracket. -
Page 26: Battery Fuse
Battery Fuse The Kid Trax Toys features a thermal fuse with a reset fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 5 Minutes and then turned ON again. -
Page 27: Troubleshooting Guide
The following are examples of potential problems. Completely read through this manual and the troubleshooting guide table before calling Kid Trax Toys Consumer Relations. If you still need help resolving the problem please call 877-741-6154. Kid Trax Toys recommends that you take the vehicle to an authorized service center for periodic maintenance and service. - Page 28 Problem Possible Cause Remedy Vehicle does not Battery is under Check that the battery run very long charged connectors are firmly plugged into each other when recharging (see Battery: Recharge Interval and Time) Battery is old Replace battery (see Battery: Replacement and Disposal) Vehicle runs Battery low on...
- Page 29 Problem Possible Cause Remedy Difficult shifting Attempting to shift Completely stop the from forward to while the vehicle is vehicle and shift (see Use: reverse or visa- in motion Manual Operation) versa Loud grinding or Motor or gears are Call Consumer Relations at 877-741-6154 for an clicking noises damaged...
-
Page 30: Services Repairs And Parts
Services, Repairs and Parts Do not return this product to the place of purchase. If your MINI Cooper S needs service, repairs or replacement parts, call: Kid Trax Toys Consumer Relations Hours: 8:00am – 5:00pm (CST) Monday - Friday Phone: 877-741-6154 Email: customerservice@kidtraxtoys.com... -
Page 31: Fcc Information
FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 32: Warranty
To make a claim under this warranty you may contact us at www. kidtraxtoys.com; fax us at 1-800-858-2800, 24 hours a day; write to Kid Trax Consumer Relations Department, Kid Trax Toys, P.O. Box 344 Olney, IL 62450 or call 1-877-741-6154 from 8 a.m. to 5 p.m., Monday through Friday, CST. -
Page 33: Limitation Of Damages
Limitation of Damages: The warranty and remedies as set forth are exclusive and in lieu of all others, oral or written, expressed or implied. In no event will PC or the dealer selling this product be liable to you for any damages, including incidental or consequential damages, arising out of the use or inability to use this product. -
Page 34: Contact Information
Contact Information If you have any questions or comments please contact us at: In U.S.A. Pacific-Cycle Inc. 4902 Hammersly Rd. Madison, WI 53711 Customer Service: 877-741-6154 customerservice@kidtraxtoys.com www.kidtraxtoys.com ©2010 Pacific Cycle Inc. 4902 Hammersley Rd. Madison, WI 53711 United States of America Phone: (877) 741-6154 www.kidtraxtoys.com The MINI logo, the MINI wordmark and the MINI model...
