- Page 1 Hustler 5" Reels 1500 Riding Greens Parts Manual ••••••• Excel Industries, Inc. ••••• P.O. Box 7000 ••• Hesston, Kansas • 67062-2097...
-
Page 3: Table Of Contents
General Information ........1-1 Section 2 Front Roller . - Page 4 114675_0311...
-
Page 5: General Information
General Information This Manual covers Hustler Riding Greens 5" Reel models Frequently Ordered Parts PART NO. DESCRIPTION 042532078 TAPER ROLLER BEARING 050203130 OIL SEAL A70320020 ADJUSTING KNOB A99432090 ADJUSTING STUD A99480030 BEDKNIFE SCREW M6 X 12 SEE BEDKNIFE OPTIONS ON PAGE 2-7 Service Literature PART NO. - Page 6 114675_0311...
- Page 7 Section 2 Front Roller ..........2-2 Reel Blade .
-
Page 8: Front Roller
Front Roller 15 16 17 23 24 114675_0311... - Page 9 Front Roller INDEX NO. 114675_0311 PART NO. QTY. DESCRIPTION A70320020 ADJUSTING KNOB A99432090 ADJUSTING STUD 020700008 A99460230 027100010 M10 LOCK WASHER A99240200 WASHER A98510640 BUSHING 026100012 WASHER A99432100 BOLT A99431840 BOLT - BRACKET A72160890 RS ROLLER BRACKET A72160880 LS ROLLER BRACKET A99210010 SPACER 010310830...
-
Page 10: Reel Blade
Reel Blade 5 12 15 16 17 114675_0311... - Page 11 Reel Blade INDEX NO. 114675_0311 PART NO. QTY. DESCRIPTION A70151460 5"D 11-BLADE RH DRIVE REEL A70151380 5"D 7-BLADE RH DRIVE REEL A22360310 REEL COUPLER 036100028 SNAP RING 042532078 TAPER ROLLER BEARING 060609002 GREASE FITTING 060609006 GREASE FITTING A98510120 BUSH A22260971 RS BEARING HOUSING 050203130 OIL SEAL...
-
Page 12: Bedknife
Bedknife 114675_0311... - Page 13 Bedknife INDEX NO. BEDKNIFE DESCRIPTION TOURNAMENT FAIRWAY/TEES FAIRWAY/TEES FAIRWAY/TEES 114675_0311 PART NO. QTY. DESCRIPTION A70320150 ADJUSTING NUT 010709061 BOLT 026100012 WASHER A98221130 SPRING A99231710 COLLAR A70310120 ADJUSTER BOLT 060609002 GREASE FITTING A99430330 BOLT 022409012 026200014 WASHER A98221140 SPRING A99231230 COLLAR A99432080 BOLT A70110430...
-
Page 14: Rear Roller
Rear Roller 114675_0311... - Page 15 Rear Roller INDEX NO. REAR ROLLER ASSEMBLY INCLUDES THE FOLLOWING: 114675_0311 PART NO. QTY. DESCRIPTION 011510825 BOLT 026100008 WASHER, M8 X 16 X 1.6 A72170060 CAM BOSS A72160800 RS BRACKET 011510820 BOLT, M8 X 1.25 X 20 020300006 010709063 SCREW A72160790 LS BRACKET 060609002...
-
Page 16: Gear Motor Weight
Gear Motor Weight INDEX NO. PART NO. QTY. DESCRIPTION A62110400 WEIGHT 011511030 BOLT, M10 X 30 026100010 WASHER, M10 X 20 X 2 A22990230 GASKET 026100008 WASHER, M8 X 16 X 1.6 011510825 BOLT NOTES: 2-10 114675_0311... -
Page 17: Reel Cover-11 Blade Count Reels
Reel Cover—11 Blade Count Reels INDEX NO. 114675_0311 PART NO. QTY. DESCRIPTION A74251120 COVER A74350410 BAFFLE PLATE 022300008 M8 U-NUT 026100008 WASHER, M8 X 16 X 1.6 A98221120 SPRING 010310845 BOLT 021500008 NOTES: 2-11... -
Page 18: Reel Cover-7 Blade Count Reels
Reel Cover—7 Blade Count Reels INDEX NO. PART NO. QTY. DESCRIPTION 011510845 BOLT, M8 X 45 026100008 WASHER, M8 X 16 X 1.6 021300006 026100006 WASHER, M6 X 12 X 1.6 022300008 M8 U-NUT A98221120 SPRING A74250950 FRONT CUTTER COVER A74350350 COVER PLATE A74260970... -
Page 19: Index
Numerical Index Part Page Index 010110645 2-12 010131225 010310830 010310845 2-11 010709061 010709063 011150612 2-12 011510820 011510825 2-10 011510845 2-12 011511030 2-10 015209029 015209030 015300510 020300006 020700008 021300006 2-12 021500008 2-11 022300008 2-11 2-12 022409012 026100006 2-12 026100008 2-10 2-11 2-12 026100010 2-10...
