Carrier Deluxe 38YZA Product Data

Carrier Deluxe 38YZA Product Data

Deluxe 12 seer split-system heat pump with puron refrigerant
Hide thumbs Also See for Deluxe 38YZA:
Table of Contents

Advertisement

Quick Links

See also: Product Data
Copyright 1999 Carrier Corporation
Product
Data
INTRODUCING THE WEATHERMAKER 38YZA HEAT PUMP
THE ENVIRONMENTALLY SOUND REFRIGERANT
Deluxe 12 SEER Split-System
Heat Pump with Puron
has risen to a new level with the
development of the 38YZA Heat
Pump, the outdoor section of a
superior split heat pump system. This
leadership effort has yielded a
product that appeals to consumers for
all of its unique benefits.
Puron®, the environmentally sound
refrigerant — The first unique feature
of the 38YZA is the environmentally
sound nature of Puron, which provides
the homeowner with additional peace
of mind because their heating and
cooling system's refrigerant has zero
ozone-depletion potential.
Second, thanks to the performance
advantage of Puron, the 38YZA is
extremely efficient. In fact, the
38YZA features some of the lowest
energy usages of single speed heat
pumps available from Carrier.
Maximum performance and
efficiency are made possible through
the use of the FX4A and FV4A fan
coils, Custom Made for Puron
applications.
Third, the cost of service will
potentially be reduced in the future as
the industry's older refrigerant, R-22
is gradually phased out through
Federally legislated production
limitations.
AVAILABLE OPTIONS
Silencer System/Quiet Operation —
The Silencer System features the
Silencer™ top design, energy-efficient
fan and motor, sound hood and
discharge muffler. The Silencer Design
improves airflow patterns and requires
less energy. The energy efficient fan
and fan motor add to quiet operation
while moving air more efficiently. The
38YZA (60Hz)
Refrigerant
Sizes 024 thru 060
FEATURING PURON
Carrier's technological leadership
Form 38YZA-2PD
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deluxe 38YZA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier Deluxe 38YZA

Summary of Contents for Carrier Deluxe 38YZA

  • Page 1 Puron, the 38YZA is extremely efficient. In fact, the 38YZA features some of the lowest energy usages of single speed heat pumps available from Carrier. Maximum performance and efficiency are made possible through the use of the FX4A and FV4A fan coils, Custom Made for Puron applications.

  • Page 2: Model Number Nomenclature

    sound hood muffles noise from the for loss of charge protection. Reliable rust-resistant, quality appearance. operation. The discharge muffler operation is also optimized with a heavy —The coil is protected with an minimizes low frequency duty, quiet and easy to service reversing enhanced WeatherArmor™...

  • Page 3: Physical Data

    ® CERTIFICATION APPLIES ONLY WHEN THE COMPLETE SYSTEM IS LISTED WITH ARI. REGISTERED As an ENERGY STAR® Partner, Carrier Corporation has deter- mined that this product meets the ENERGY STAR® guidelines QUALITY SYSTEM for energy efficiency. Physical data UNIT SIZE-SERIES...
  • Page 4 ** Outdoor temperature sensor is an accessory for all Carrier electronic thermostats, except the non-programmable air conditioner version and builder’s thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat.

  • Page 5: Accessory Usage Guideline

    11. Outdoor Air Temperature Sensor A device that allows the temperature at a remote location (outdoors) to be displayed at the thermostat. SUGGESTED USE: All Carrier programmable thermostats. 12. Outdoor Thermostat An SPDT temperature actuated switch which turns on supplemental electric heaters when outdoor air temperature drops below set point.

  • Page 6: Electrical Data

    Accessory description and usage (Listed alphabetically) continued 17. Thermostatic Expansion Valve (TXV) — Bi-Flow A modulating flow control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the evaporator. Kit includes valve, adapter tubes, external equalizer tube.
  • Page 7 Dimensions...
  • Page 8 BUILDING HEAT LOSS, 1000 BTU/HR UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR...

  • Page 9: Combination Ratings

    Combination ratings* ARI STANDARD RATINGS* Cooling Heating Seasonal Efficiency SEER Field-Supplied High-Temp Low-Temp Factory- Accessory‡ Supplied UNIT SIZE- INDOOR Enhance- Standard Puron Puron TXV SERIES UNIT CFM†† ment Rating HSPF & TDR** FX4ANF030† 24,400 TXV+TDR 12.00 — — 10.30 24,600 3.28 15,500 2.24...
  • Page 10 Combination ratings* continued ARI STANDARD RATINGS* Cooling Heating Seasonal Efficiency SEER Field-Supplied High-Temp Low-Temp Factory- Accessory‡ Supplied UNIT SIZE- INDOOR Enhance- Standard Puron Puron TXV SERIES UNIT CFM†† ment Rating HSPF & TDR** COILS + 58MVP080-20 VARIABLE SPEED FURNACE CD5AW036 1000 27,400 —...
  • Page 11 Combination ratings* continued ARI STANDARD RATINGS* Cooling Heating Seasonal Efficiency SEER Field-Supplied High-Temp Low-Temp Factory- Accessory‡ Supplied UNIT SIZE- INDOOR Enhance- Standard Puron Puron TXV SERIES UNIT CFM†† ment Rating HSPF & TDR** COILS + 58MVP120-20 VARIABLE SPEED FURNACE CC5A/CD5AA042 1000 34,200 —...
  • Page 12 Combination ratings* continued ARI STANDARD RATINGS* Cooling Heating Seasonal Efficiency SEER Field-Supplied High-Temp Low-Temp Factory- Accessory‡ Supplied UNIT SIZE- INDOOR Enhance- Standard Puron Puron TXV SERIES UNIT CFM†† ment Rating HSPF & TDR** COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE CC5A/CD5AW048 1225 40,000 —...
  • Page 13 * Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on: Cooling Standard: 80°F (27°C) db 67°F (19°C) wb indoor entering air temperature and 95°F (35°C) db air entering outdoor unit. High-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 47°F (8°C) db 43°F (6°C) wb air entering outdoor unit.

  • Page 14: Detailed Cooling Capacities

    Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total MBtuh† Sys- MBtuh† Sys- MBtuh† Sys- MBtuh† Sys- MBtuh† Sys- MBtuh† Sys- Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡...
  • Page 15 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† System System System System System System Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡...
  • Page 16 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† System System System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡...
  • Page 17 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† System System System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡...
  • Page 18 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† System System System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡...
  • Page 19 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† System System System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡...

  • Page 20: Heat Pump Heating Performance

    Heat pump heating performance OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† 38YZA024-31 Outdoor Section With FX4ANF030 Indoor Section 10.9 10.0 1.85 13.0 11.9 1.86 15.3 14.0 1.89 17.8 15.8 1.93 20.7 18.8 1.99 23.9 23.9 2.05 27.5 27.1 2.29 28.8 28.8 2.38 11.1 10.2 1.90 13.2 12.1 1.88 15.5 14.2 1.90 18.1 16.1 1.92 21.0 19.1 1.96 24.3 24.3 2.02 27.7 27.7 2.23 28.9 28.9 2.27...
  • Page 21 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† 38YZA030-31 Outdoor Section With FX4ANF030 Indoor Section 12.1 11.1 2.01 14.8 13.6 2.04 17.9 16.3 2.08 21.4 19.0 2.14 25.4 23.1 2.21 29.8 29.8 2.29 30.3 33.0 2.45 31.8 31.8 2.51 1050...
  • Page 22 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Total Total Total Total Total Total Total Total Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh)
  • Page 23 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Total Total Total Total Total Total Total Total Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh)
  • Page 24 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Total Total Total Total Total Total Total Total Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh)
  • Page 25 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Total Total Total Total Total Total Total Total Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- Capacity Pow- (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh) (MBtuh)

  • Page 26: System Design

    Matched system HEAT PUMP COMFORT VENTILATOR ™ COMFORT ZONE II EQUIPMENT CONTROLLER HUMIDIFIER FAN COIL AIR CLEANER A98535 System Design 1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc. 2.
  • Page 28 • Carrier Corporation Indianapolis, IN 46231 3-00 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 28 Catalog No. 523-772 Printed in U.S.A. PC 101 Form 38YZA-2PD...
