Carrier Deluxe 38YZA Product Data

Deluxe 12 seer split-system heat pump with puron refrigerant
Hide thumbs Also See for Deluxe 38YZA:

Advertisement

Table of Contents

Copyright 2003 Carrier Corporation
Product
Data
Deluxe 12 SEER Split-System
Heat Pump with Puron
has risen to a new level with the
development of the 38YZA Heat
Pump, the outdoor section of a
superior split heat pump system. This
leadership effort has yielded a
product that appeals to consumers for
all of its unique benefits.
Puron®, the environmentally sound
refrigerant — The first unique feature
of the 38YZA is the environmentally
sound nature of Puron, which provides
the homeowner with additional peace
of mind because their heating and
cooling system's refrigerant has zero
ozone-depletion potential.
Second, thanks to the performance
advantage of Puron-refrigerant, the
38YZA is extremely efficient. In fact,
the 38YZA features some of the lowest
energy usages of single speed heat
pumps available from Carrier.
Maximum performance and
efficiency are made possible through
the use of the FX4A and FV4A fan
coils, Custom Made for applications
with Puron refrigerant.
Third, the cost of service will
potentially be reduced in the future as
the industry's older refrigerant, R-22
is gradually phased out through
Federally legislated production
limitations.
FEATURES/BENEFITS
Silencer System/Quiet Operation —
The Silencer System features the
Silencer™ top design, energy-efficient
fan and motor, sound hood and
discharge muffler. The Silencer Design
improves airflow patterns and requires
less energy. The energy efficient fan
and fan motor add to quiet operation
while moving air more efficiently. The
38YZA (60Hz)
Refrigerant
Sizes 018 thru 060
Carrier's technological leadership
Form 38YZA-4PD
®
