Operating Instructions
Tumble dryer
Dear ASKO customer,
Thank you for choosing this quality product from Scandinavia,
which was made in Sweden.
We want you to feel assured that the inside of your new ma-
chine is just as good as the outside and that the ethics and
standards that went into the production of this machine are
just as high as the quality and performance that you will re-
ceive from it. We hope that this product will give you many
years of pleasure.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
ASKO T783C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko T783C
Summary of Contents for Asko T783C
-
Page 1: Operating Instructions
Operating Instructions Tumble dryer Dear ASKO customer, Thank you for choosing this quality product from Scandinavia, which was made in Sweden. We want you to feel assured that the inside of your new ma- chine is just as good as the outside and that the ethics and... -
Page 2: Table Of Contents
Contents Before using your machine for Settings the first time You can carry out the following Do not tumble-dry settings Safety instructions Audible Volume Installation Select language Safety Child-safe Interrupting a program Care and cleaning Transport/Winter storage Cleaning the lint filter Packing material Emptying the condensed water container... - Page 3 Contents Quick guide Fabrics Turn on the main power switch Load the laundry Select a program and any options Press the Start button Drying program finished Once tumble-drying has finished...
-
Page 4: Before Using Your Machine For The First Time
Before using your machine for the first time Do not tumble-dry Certain materials are not suitable for tumble-dry- ing. Always check and follow the instructions on each item's laundry label. You can find more infor- mation in the chapter "Advice and tips before you tumble-dry". -
Page 5: Safety Instructions
Safety instructions Read the operating instructions and Caution! keep them in a safe place! Never stop a tumble dryer before the program is completed unless you immediately remove all the laundry and spread it out so that the heat can disperse. -
Page 6: Packing Material
Safety instructions Packing material on a heat setting. Foam rubber materials can, when heated, produce fire by spontaneous Sort waste materials in accordance with local combustion. guidelines. • Fabric softeners or similar products should not be used in a tumble dryer to eliminate the ef- Recycling fects of static electricity unless this practice is This machine is manufactured and labelled for... -
Page 7: Child Safety
Child safety General Activating/deactivating Child-safe start Do not allow children to play with the tumble dryer. Activating/deactivating Child-safe start 1. Turn off the machine using the main power The tumble dryer does not start automatically switch. when the door closes (e.g. if a child closes the 2. -
Page 8: Description Of The Tumble Dryer
Description of the tumble dryer Main power switch Outer door Condensed water container Fan (behind hatch) Panel Condenser Serial Number Lint filter Lint filter holder... -
Page 9: Front Panel
Front panel Main power switch Options buttons Program selector Start Display window Stop... -
Page 10: Advice And Tips Before You Tumble-Dry
Advice and tips before you tumble-dry Here are some tips that may help you before you Materials that must not be begin tumble-drying. tumble-dried Have the clothes been spun? This symbol means that the material is not suitable for tumble-drying. Certain materials may Items to be tumble-dried should be spun at 1000 melt or become a fire hazard if exposed to heat, rpm or faster. -
Page 11: Tumble Drying
Tumble drying Auto Iron dry Below are step-by-step instructions to help you achieve the best possible tumble-drying results. This program shuts off the heat once the load is just damp enough for ironing or pressing. Sort your fabrics Time program You will achieve the most uniform drying The program length you choose depends on what results if the items are made of the same... -
Page 12: Program Chart
Tumble drying Menu overview 1. Auto extra dry 2.Auto dry Time remaining 3. Auto normal dry 4. Auto Iron dry 1:45 5. Timed dry Stop Start 6. Air fluff programme Low temperature Time saver Anti-crease function Audible Volume Note! The illustration shows an example of a program. Program chart Here we present a few examples of the energy and time consumption of a few different program settings. -
Page 13: Selecting Options
Tumble drying Delayed Start Selecting Options First select which program you want to use and By selecting options, you can tailor a drying then select Delayed Start by pressing the + button. program to suit your requirements. The The display shows Delayed Start in whole hours. machine remembers which options you choose Press the + / - button to select a delayed start of for each program and uses them (with one excep-... -
Page 14: Press The Start Button
Tumble drying Press the Start button Drying program finished The text "END" appears on the display Remaining drying time when the program is finished. If the Anti An estimate of the remaining drying time crease option has been selected, the drum will will be shown on the display a few minutes after rotate for 3 seconds every minute for 2 hours after the drying program starts. -
Page 15: Once Drying Has Finished
Tumble drying Emptying the condensed water container Once drying has finished The condensed water container must be drained Turn off the main power switch. Remove after each load. Remove the condensed water the clothes and close the door to prevent container, empty out the water and replace the small children from climbing into the machine. -
Page 16: Settings
Settings You can carry out the following settings • Audible Volume • Language • Child-safe Audible Volume You can choose to have the machine notify you when a program is finished or if an error has occurred. • Select Audible Volume by pressing the button under the symbol. •... -
Page 17: Care And Cleaning
Care and cleaning Cleaning the lint filter Emptying the condensed water container The lint filter must be cleaned after each load. If you have very hard water, this can cause limescale deposits in the lint filter. Check for any limescale deposits when cleaning the lint filter and, if necessary, wash the filter by hand. -
Page 18: Cleaning The Condenser
Care and cleaning 5. Replace the condenser. When refitting the Cleaning the condenser condenser, check that it is replaced correctly. The condenser should be cleaned at least three The top of the condenser is labelled "upp", "up" times a year. If you have pets, the condenser must and "oben". -
Page 19: Troubleshooting
Troubleshooting The machine will not start Drying takes too long • Empty the condensed water container and Check check that neither the lint filter nor the con- • that the door is properly closed. denser is clogged. See the chapter "Care and •... -
Page 20: Technical Information
Technical information Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight: 47 kg Cylinder volume: 111 l Max. drying capacity: 6 kg Speed: 52 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel. -
Page 21: Service
Service Before contacting the service divi- Model Number Serial sion Number Before contacting the service division, you should find out whether you can resolve the fault yourself. See the "Troubleshooting" and "Care and clean- ing" chapters. If you still need to contact the service division, make sure that you know the model designation, type designation and serial number. -
Page 22: Installation
The tumble dryer can be positioned beside the washing machine. B. Stack The tumble dryer can be placed on top of a ASKO washing machine. In this case you use the stack- 4. Attach the plastic cups for fixing the tumble... -
Page 23: Adjusting The Feet
Installation 5. Fit the plastic cups so that the “tags” marked Adjusting the feet with arrows are against the front edge or side Screw the feet in or out so that the tumble dryer edge of the cover and press them firmly onto is steady and balanced on the floor or on the the cover. -
Page 24: Electrical Installation
Installation Electrical installation The electrical wall socket must be placed outside of the installation area to be easily accessible. The machine must only be connected to an earthed wall socket. If this appliance is supplied from a cord extensions set or electrical portable outlet device, the cord extension ser or electrical portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture. -
Page 25: Door Hanging
Door hanging Hinge pins (top and bottom) Locking hook Cover washer Hinges (left + right side) Plastic plugs (on the upper Plinth and lower edges) -
Page 26: Follow These Instructions
Door hanging You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the plinth. 2. Unscrew the 2 screws on the hinges. 6. Move the plastic plugs on the upper and lower edges of the door. - Page 27 Your notes...
-
Page 28: Quick Guide
Quick guide Fabrics Press the Start button • Dry fabrics of the same type together to ensure that they dry as evenly as possi- ble. Drying program finished Turn on the main power switch • "END" appears on the display when the program is finished.
