    Operator’s manual (EPA II) 323E 325E X-series Please read these instructions carefully and make English sure you understand them before using the machine.

  • Page 2: Symbols

    EXPLANATION OF SYMBOLS Symbols WARNING! The edger can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. Read through the Operator's Manu- al carefully and understand the content before using the machine. Always use: •...

  • Page 3: Table Of Contents

    Husqvarna AB has a policy of continuous product development and therefore reserves the right to modify the design and ap- pearance of products without prior notice. Maintenance, replacement, or repair of the emission control devices and systems may be performed by any nonroad engine repair establishment or individual.

  • Page 4: Safety Instructions

    Personal protective equipment IMPORTANT INFORMATION • An edger used incorrectly or carelessly can become a dangerous tool, that can cause serious or fatal injury to the operator or others. It is extremely important that you read and understand the content of this manual. •...

  • Page 5

    4. Vibration damping system Your machine is equipped with a vibration damping system, which is designed to give as vibration-free and comfortable use as possible. The use of incorrect cutting equipment increases the level of vibration. The machineʼs vibration damp- ing system reduces the trans- fer of vibrations between the engine unit/cutting equipment...

  • Page 6: Control, Maintenance And Service Of The Machineʻs Safety Equipment

    Control, maintenance and service of the machineʼs safety equipment IMPORTANT INFORMATION • All service and repairs to the machine require special training. • This applies especially to the machineʼs safety equipment. If the machine does not meet any of the controls listed below you should contact your serv- ice workshop.

  • Page 7: Cutting Equipment

    6. Cutting equipment The two basic rules: Only use the cutting equip- ment we recommend! See chapter “Technical data”. Check the cutting equip- ment with regard to dam- age and crack formation. Damaged cutting equip- ment should always be replaced. WARNING! Always stop the engine before starting work on any part of the cutting equipment.

  • Page 8: General Safety Instructions

    General safety instructions IMPORTANT INFORMATION • The machine is only designed for cutting the edges of lawns. • The only accessories to be used with the engine unit as a drive source are the cutting units we recommend in the chapter “Technical data”. •...

  • Page 9: Transport And Storage

    Start WARNING! When the engine starts with the choke lever in the choke or starter throttle position the cutting tool (blade or trimmer) starts to rotate immediately. • The complete clutch cover with shaft must be fi tted be- fore the machine is started,...

  • Page 10: General Working Instructions

    General working instructions IMPORTANT INFORMATION • This section takes up the basic safety precautions for working with the edger. • If you encounter a situation where you are uncertain how to proceed you should ask an expert. Contact your dealer or your service workshop. •...

  • Page 11

    Safety instructions after completing work • Ensure the blade has stopped before cleaning, car- rying out repairs or an inspec- tion. Remove the spark plug cable from the spark plug. • Wear heavy-duty gloves when carrying out repairs on the edger. •...

  • Page 12: What Is What

    What is what on the edger? Blade Grease fi ller cap Angle gear Blade guard Shaft Loop handlebar Throttle Stop switch Throttle trigger lock 10. Cylinder cover 11. Starter handle 12. Fuel tank 13. Choke 14. Air purge – English WHAT IS WHAT? 15.

  • Page 13: Assembly

    Assembling the loop handlebar • Position the handle on the shaft. Note that the handle must be mounted below the arrow on the shaft. • Fit the bolt, securing plate and wing nut as shown in the diagram. • Tighten the wing nut. Assembling the angle gear •...

  • Page 14: Fuel Handling

    • When working at continuous high revs a higher octane rat- ing is recommended. Two-stroke oil • For the best results use HUSQVARNA two-stroke oil, which has been specially developed for two-stroke engines. Mixing ratio 1:50 (2%). • Never use two-stroke oil...

  • Page 15: Start And Stop

    WARNING! When the engine starts with the choke lever in the choke or starter throttle position the cutting tool (blade or trimmer) starts to rotate immediately. Hold the body of the machine on the ground using your left hand (CAUTION! Not with your foot!).

  • Page 16: Maintenance

    Carburetor Your Husqvarna product has been designed and manufactured to specifi cations that reduce harmful emissions. After your unit has been run 8-10 tanks of fuel the engine has broken in. To ensure that your unit is at peak performance and...

  • Page 17

    Final setting of the idling speed T Adjust the idling speed with the screw T, if it is necessary to re- adjust. First turn the idle speed adjusting screw T clockwise until the cutting attachment starts to rotate/move. Then turn, counter-clockwise until the cutting attachment stops.

  • Page 18: Muffl Er With Catalytic Converter

    Muffl er with catalytic converter A muffl er fi tted with a catalytic converter reduces the extent of the following substances in the exhaust fumes: • Hydrocarbons (HC). Some hydrocarbons in gasoline and the exhaust are carcinogenic. • Nitric oxides (NO). Irritating for the breathing air-ways. •...

  • Page 19: Air fi Lter

    “Oiling the air fi lter“. Oiling the air fi lter Always use HUSQVARNA fi lter oil, order no. 503 47 73-01. The fi lter oil contains a solvent to make it spread evenly through the fi...

  • Page 20: Maintenance Schedule

    NOTE: Use only HUSQVARNA replacement parts. Use of other brands of replacement parts can cause damage to your unit or injury to the operator or others. Your warranty does not cover damage or liability caused by the use of accessories and/or at- tachments not specifi...

  • Page 21: Technical Data

    Technical data Engine Displacement, cu. in/cm Cylinder bore, inch/mm Stroke length, inch/mm Recommended max. speed, rpm Idling speed, rpm Speed of output shaft, rpm Max. engine output, acc. to ISO 8893 Catalytic converter muffl er Speed-regulated ignition system Ignition system Manufacturer/type of ignition system Spark plug Electrode gap, inch/mm...

  • Page 22: Emission Control Warranty Statement

    WHAT IS COVERED REPAIR OR REPLACEMENT OF PARTS Repair or replacement of any warranted part will be perfor- med at no charge to the owner at an approved Husqvarna Forest & Garden servicing dealer. ´®z+H:y¶5T¨ ´®z+H:y¶5T¨...

  • Page 23

    NOTES English –...

  • Page 24

    114 02 68-95 ´®z+H:y¶5T¨ ´®z+H:y¶5T¨ 2004W13...
