5) SATA3 0/1 (SATA 6Gb/s Connectors)
The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA
1.5Gb/s standard. Each SATA connector supports a single SATA device.
1
1
SATA3
0 1
7
7
6) SATA2 2/3 (SATA 3Gb/s Connectors)
The SATA connectors conform to SATA 3Gb/s standard and are compatible with SATA 1.5Gb/s standard.
Each SATA connector supports a single SATA device.
7
SATA2
3
2
1
To enable hot-plugging for the SATA ports, refer to Chapter 2, "BIOS Setup," "Peripherals\SATA Configuration,"
for more information.
7) F_PANEL (Front Panel Header)
Connect the power switch, reset switch, and system status indicator on the chassis to this header according
to the pin assignments below. Note the positive and negative pins before connecting the cables.
Power LED
Power Switch
2
10
1
9
NC
Hard Drive
Reset
Activity LED
Switch
• RES (Reset Switch, Green):
Connects to the reset switch on the chassis front panel. Press the reset switch to restart the computer if the
computer freezes and fails to perform a normal restart.
• NC (Purple): No connection.
The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch,
power LED, hard drive activity LED and etc. When connecting your chassis front panel module to this header,
make sure the wire assignments and the pin assignments are matched correctly.
Pin No. Definition
Pin No. Definition
1
GND
2
TXP
3
TXN
4
GND
Pin No. Definition
Pin No. Definition
1
GND
2
TXP
3
TXN
4
GND
• PLED (Power LED, Yellow):
Connects to the power status indicator on the
System
LED
chassis front panel. The LED is on when the
Status
system is operating. The LED is off when the
S0
On
system is in S3/S4 sleep state or powered off (S5).
S3/S4/S5
Off
• PW (Power Switch, Red):
Connects to the power switch on the chassis front panel. You may configure
the way to turn off your system using the power switch (refer to Chapter 2,
"BIOS Setup," "Power Management," for more information).
• HD (Hard Drive Activity LED, Blue):
Connects to the hard drive activity LED on the chassis front panel. The
LED is on when the hard drive is reading or writing data.
- 13 -
5
RXN
6
RXP
7
GND
5
RXN
6
RXP
7
GND
