INSTALLATION
INSTRUCTIONS
PARTS LIST
Cassette player
Owner's manual
5 Washer-screws
Wire tie (not used)
Harness clip
TOOLS REQUIRED
Phillips screwdriver
Small flat-tip screwdriver
INSTALLATION
1.
Make sure you have the anti-theft code for the radio,
then write down the frequencies for the preset
buttons.
2.
Disconnect the negative cable from the battery.
© 2000 American Honda Motor Co., Inc - All Rights Reserved.
Accessory
CASSETTE PLAYER
P/N 08A03-5B1-050
3.
AII 22028 (0008)
Y0581-D
Application
ODYSSEY (EX)
Remove the console cover:
Move the gear selector lever to the 1 position.
Using a small flat-tip screwdriver around a shop
towel, gently pry out and remove the cover.
Reach inside the cover hole, gently pull along the
bottom to release the lower clips, and work
toward the top to release all 10 clips.
Pull out on the console panel, unplug the
connectors, and remove the panel.
CONSOLE PANEL
SMALL
FLAT-TIP
SCREWDRIVER
Publications No.
AII 22028
Issue Date
AUG 2000
CONNECTOR
CLIP
TAB
COVER
1 of 3
08A03-S0X-1001-91

Advertisement

   Also See for Honda ODYSSEY

   Summary of Contents for Honda ODYSSEY

  • Page 1

    Make sure you have the anti-theft code for the radio, FLAT-TIP then write down the frequencies for the preset SCREWDRIVER buttons. Disconnect the negative cable from the battery. AII 22028 (0008) 1 of 3 08A03-S0X-1001-91 © 2000 American Honda Motor Co., Inc - All Rights Reserved. Y0581-D...

  • Page 2

    Set the pocket aside, it will not be reused. BUS CABLE 5 x 8 mm HARNESS CLIP WASHER- SCREW 2 of 3 AII 22028 (0008) © 2000 American Honda Motor Co., Inc - All Rights Reserved.

  • Page 3

    CD CHANGER BUS CABLE (If equipped) 10. Reinstall the console panel; be careful not to damage the tabs. CONNECTOR CLIP CONSOLE PANEL COVER AII 22028 (0008) 3 of 3 © 2000 American Honda Motor Co., Inc - All Rights Reserved.
