M-Vision 1080p-260

GETTING STARTED

Getting to know the projector

Zoom ring
Front Infra-red
window
(remote control)
Focus ring
Remote
reception
angle
40°
40°
(under the
badge)
Lens
Remote
Adjustable feet
control
Lamp cover
Horizontal shift
adjustment
Vertical shift
adjustment
Air outlet
Power
connection
connections
Rev A May 2010
Notes
For complete and detailed
information about how to use
and control the projector, see
the User Manual.
Projector control
panel
Input
Rear Infra-red
window (remote
control)
Air inlet
110-286A
