SERVICE MANUAL
(DOMESTIC)
IMPINGER CONVEYOR OVENS
LOW PROFILE 1600 SERIES ADVANTAGE
Lincoln Foodservice Products, LLC
1111 North Hadley Road
Fort Wayne, Indiana 46804
United States of America
Phone : (800) 374-3004
U.S. Fax: (888) 790-8193 • Int'l Fax: (260) 436-0735
Technical Service Hot Line
(800) 678-9511
www.lincolnfp.com
1600advsvc
REV: 1/8/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOW PROFILE 1600 SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Lincoln Electric LOW PROFILE 1600 SERIES

Summary of Contents for Lincoln Electric LOW PROFILE 1600 SERIES

  • Page 1 SERVICE MANUAL (DOMESTIC) IMPINGER CONVEYOR OVENS LOW PROFILE 1600 SERIES ADVANTAGE Lincoln Foodservice Products, LLC 1111 North Hadley Road Fort Wayne, Indiana 46804 United States of America Phone : (800) 374-3004 U.S. Fax: (888) 790-8193 • Int’l Fax: (260) 436-0735...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS..............................2 SEQUENCE OF OPERATIONS / 1600-000-A , 1601-000-A ..................3 TROUBLESHOOTING GUIDE ...........................4 SCHEMATIC / 1600-000-A, 1601-000-A........................10 REMOVAL, INSTALLATION & ADJUSTMENTS .....................11 PARTS / GENERAL - 1600-000-A ADVANTAGE SERIES..................18 BLOW UP / GENERAL – 1600-000-A ADVANTAGE SERIES ................19 PARTS / CONTROL BOX, RIGHT - 1600-000-A, 1601-000-A ................20 BLOW UP / CONTROL BOX, RIGHT - 1600-000-A, 1601-000-A ................21 PARTS / CONTROL BOX, LEFT - 1600-000-A, 1601-000-A...................22...

  • Page 3: Sequence Of Operations / 1600-000-A, 1601-000-A

    SEQUENCE OF OPERATIONS / 1600-000-A, 1601-000-A MODEL 1600-000-A / 120 VAC / 60 HZ / NATURAL GAS MODEL 1601-000-A / 120 VAC / 60 HZ / L.P. GAS POWER SUPPLY Electrical power to be supplied to the oven by a three conductor cordset. Voltage from the black conductor to the white conductor to be 120 VAC.

  • Page 4: Troubleshooting Guide

    TROUBLESHOOTING GUIDE GAS OVENS MODEL 1600-000-A / NATURAL GAS / 120 VAC / 60 HZ / 1 PHASE MODEL 1601-000-A / L.P. GAS / 120 VAC / 60 HZ / 1 PHASE NOTE: When checking components on left side of unit, be sure to check for proper connections in power connector, (marked P.
  • Page 5 Cooling Fan(s) 120 VAC should be at the motor. If voltage is present, check motor for shorts, opens, or grounds. WITH POWER OFF: check for locked rotor. Oven will not heat Gas Supply Check for adequate gas supply and closed manual gas valves. Also, check flexible gas line connection.
  • Page 6 are no obstructions, replace gas control valves. Flame will not stay lit Hot Surface Igniter The ignition control will keep the gas control valves energized for 6 seconds. At the end of 6 seconds, the hot surface igniter must sense a flame, or, the ignition control will go into lockout. (The ignition control requires a minimum of 0.8 microamps D.C.) To check the flame sensing operation, connect a digital multimeter (capable of measuring D.C.
  • Page 7 Intermittent Heating Thermal/Overload of The main fan motors and the burner blower motors are Main Fan and Burner equipped with internal thermal protection and will cease to Blower Motors operate if overheating occurs. As the motors overheat and then cool, this will cause the units to cycle on and off intermittently.
  • Page 8 Conveyor speed Power Supply Check power supply at the DC control board for the 120 VAC varying or intermittent at board terminals L1 and L2. Motor Control Board Place the test meter probes on terminals A+ and A-. (With speed potentiometer set to maximum speed (Approximately 2 min.) The meter reading should be approximately 100 VDC ( 3%), if voltage is not steady within limits, then the board is probably bad.
  • Page 9 Temp. display Display Transformer Measure the transformer primary for a nominal 120 VAC input, inoperative if voltage is not present, trace wiring back to the oven power source. Measure the secondary output, which will normally be 12-15 VAC. Voltage across terminals 1 and 3 on the temp. display should read 12-15 VAC.

  • Page 10: Schematic / 1600-000-A, 1601-000-A

    SCHEMATIC / 1600-000-A, 1601-000-A Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...

  • Page 11: Removal, Installation & Adjustments

    REMOVAL, INSTALLATION & ADJUSTMENTS MODEL SERIES 1600 ADVANTAGE CAUTION ! BEFORE REMOVING OR INSTALLING ANY COMPONENT IN THE IMPINGER OVEN BE SURE TO DISCONNECT ELECTRICAL POWER AND GAS SUPPLY BURNER CONTROL - HONEYWELL - REPLACEMENT A. Remove appropriate control box cover. B.
  • Page 12 D. Reassemble in reverse order and check system operation. CONVEYOR CONTROL BOARD - CALIBRATION A. Connect digital volt meter to the hall effect sensor. Black meter lead connected to black hall effect sensor lead, red meter lead to white hall effect sensor lead. B.
  • Page 13 GAS VALVE, DUAL SAFETY - REPLACEMENT A. Remove appropriate control box cover. B. Remove incoming gas line. C. Remove screws from incoming nipple mounting bracket. D. Remove incoming nipple. E. Remove bypass tube assy. F. Disconnect pipe union. G. Disconnect wiring from control valve (four [4] push on connectors), make note of wire numbers and location for reinstallation.
  • Page 14 E. Remove assembly and replace main orifice. F. Reassemble in reverse order and check system operation. NOTE: Check all gas line fittings for leaks. TEMPERATURE CONTROL POTENTIOMETER - REPLACEMENT A. Remove control box cover. B. Loosen screw and slide knob off potentiometer shaft. C.
  • Page 15 RELAY - REPLACEMENT A. Remove control box cover. B. Remove wires from relay, note wire numbers and location for reinstallation. C. Remove two (2) screws from relay base and replace relay. D. Reassemble in reverse order making sure wire connectors are properly seated. E.
  • Page 16 COOLING FAN MOTOR - REPLACEMENT A. Remove appropriate control box cover. B. Remove mounting screws. C. Unplug electrical connector and remove fan motor assembly. D. Reassemble in reverse order and check system operation. MAIN FAN MOTOR - REPLACEMENT A. Shut off gas supply and remove gas line and manifold lines from back of oven. B.
  • Page 17 It is possible to check a thermocouple with a properly calibrated D.C. millivolt meter. At 32° F, the millivolt reading should be 0.00. This can be checked by inserting the thermocouple into an ice bath. The millivolt reading at 72°F should be 1.134. When using the following chart, the temperature at the terminal connections must be noted.

  • Page 18: Parts / General - 1600-000-A Advantage Series

    PARTS / GENERAL - 1600-000-A ADVANTAGE SERIES LETTER PART # DESCRIPTION 369110 Access Window Assy 369929 Window Retainer 369926 Window Frame, Bottom 369925 Glass, Access Window 369927 Window Frame, Top 369930 Screw, 10-32x1/4 369211 Thumb Screw 369058 Baffle 370253 Drive Cover L.H. 1609 Oven Top 370252...

  • Page 19: Blow Up / General - 1600-000-A Advantage Series

    BLOW UP / GENERAL – 1600-000-A ADVANTAGE SERIES Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...

  • Page 20: Parts / Control Box, Right - 1600-000-A, 1601-000-A

    PARTS / CONTROL BOX, RIGHT - 1600-000-A, 1601-000-A LETTER PART # DESCRIPTION 369158 Sprocket, 10 Tooth 369705 Thermocouple 369757 Main Orifice, Nat. 370279 Main Orifice, L.P. 369398 Solenoid Valve 369552 Hot Surface Igniter 369755 Venturi, Nat. 369642 Venturi, L.P. 369401 Air Shutter Assy.

  • Page 21: Blow Up / Control Box, Right - 1600-000-A, 1601-000-A

    BLOW UP / CONTROL BOX, RIGHT - 1600-000-A, 1601-000-A Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...

  • Page 22: Parts / Control Box, Left - 1600-000-A, 1601-000-A

    PARTS / CONTROL BOX, LEFT - 1600-000-A, 1601-000-A LETTER PART # DESCRIPTION 369706 Thermocouple with Extension 369507 Thermostat, Cooling Fan 369431 Thermostat, Control Box Hi-Limit 369532 Ignition Control 369531 Transformer, Burner 369012 Fuse holder 369014 Fuse, 10A 369192 Capacitor 369124 Cooling Fan 369556 By-pass Orifice, Nat.

  • Page 23: Blow Up / Control Box, Left - 1600-000-A, 1601-000-A

    BLOW UP / CONTROL BOX, LEFT - 1600-000-A, 1601-000-A Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...

  • Page 24: Parts / Oven Back - 1600-000-A - Series

    PARTS / OVEN BACK - 1600-000-A - SERIES LETTER PART # DESCRIPTION 369547 Wire Form Thermostat Bulb 369724 Fan, Clockwise Rotation 369776 Fan Shroud 369777 Stand-Off 369778 Rear Wall Assy. 369761 Motor Mount 369726 Motor, Main Fan 120V 60 Hz 1627 Duct Cap 369033...

  • Page 25: Blow Up / Oven Back - 1600-000-A - Series

    BLOW UP / OVEN BACK - 1600-000-A - SERIES Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...

  • Page 26: Parts / Conveyor - 1600-000-A - Series

    PARTS / CONVEYOR - 1600-000-A - SERIES LETTER PART # DESCRIPTION 369830 Complete Conveyor 369816 Conveyor Belting 370092 Belt, 1 Foot Section 369825 Retaining Ring 369813 Conveyor Bearing Block 369314 Roll, Conveyor, Notched 369812 Conveyor Idler Shaft 369160 Conveyor Pan Stop 369814 Connecting Link 369811...

  • Page 27: Blow Up / Conveyor - 1600-000-A - Series

    BLOW UP / CONVEYOR - 1600-000-A – SERIES Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...
  • Page 28 Low Profile – 1600-000-A Advantage Series Service Manual – Domestic...
