U.S. Range REGAL SERIES Parts List

Hide thumbs Also See for REGAL SERIES:

Advertisement

Quick Links

See also: Installation, Operating and Service Instructions , Operation & Installation Manual
R R E E G G A A L L S S E E R R I I E E S S
Toll Free Phone, (US & Canada): (800) 427-6668
Toll Free Fax, (US & Canada): (800) 361-7745
www.garland-group.com
Regal Series (Rev.06)

Advertisement

loading
Need help?

Need help?

Do you have a question about the REGAL SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U.S. Range REGAL SERIES

Summary of Contents for U.S. Range REGAL SERIES

  • Page 1 R R E E G G A A L L S S E E R R I I E E S S Toll Free Phone, (US & Canada): (800) 427-6668 Toll Free Fax, (US & Canada): (800) 361-7745 www.garland-group.com Regal Series (Rev.06)
  • Page 2 Page 2 Regal Series (Rev.06)

  • Page 3: Table Of Contents

    RGTA SERIES THERMOSTATICALLY CONTROLLED GRIDDLES RGTA THERMOSTATICALLY CONTROLLED GRIDDLES W/OPEN BURNERS RHPA SERIES - HEAVY DUTY HOT PLATES RBA SERIES CHAR-BROILER C-HDS-A / RG-HDS-A / C-JR CHAR GLO SERIES RGTSA - SNAP-ACTION THERMOSTAT CONTROLLED GRIDDLES.........24 REVISION HISTORY........................27 Page 3 Regal Series (Rev.06)
  • Page 4 MANUALLY CONTROLLED RGM SERIES REV. 0 MAN CONTRO RGM SERIES.dwg Page 4 Regal Series (Rev.06)
  • Page 5 253037-5 Front Top 72" 253051-2 Valve Panel 24" 253051-4 Valve Panel 36" 253051-5 Valve Panel 48" 253051-6 Valve Panel 60" 253051-7 Valve Panel 72" 1196302 253046 Grease Tray 1019012 Regulator Natural 2127500 Gas Regulator Propane Page 5 Regal Series (Rev.06)
  • Page 6 RGM SERIES MANUALLY CONTROLLED WITH OPEN BURNERS REV. 0 RGM GRID MAN CONTRL OPEN BURNER.dwg Page 6 Regal Series (Rev.06)
  • Page 7 253051-4 Valve Panel 36" 253051-5 Valve Panel 48" 253051-6 Valve Panel 60" 253051-7 Valve Panel 72" 1196302 253046 Grease Tray 253060-5 Drip Pan 24 1/4 X 8 1/2 1019012 Regulator Natural 2127500 Gas Regulator Propane Page 7 Regal Series (Rev.06)
  • Page 8 RGTA SERIES THERMOSTATICALLY CONTROLLED GRIDDLE RGTA SERIES THERMO CONTL.dwg Page 8 Regal Series (Rev.06)

  • Page 9: Rgta Series Thermostatically Controlled Griddles

    U.S. RANGE PARTS IDENTIFICATION RGTA SERIES THERMOSTATICALLY CONTROLLED ITEM PART # DESCRIPTION 2424-1 2436-1 2448-1 2460-1 2472-1 253052-16 Gridde Plate 24" GXT2 253052-17 Griddle Plate Assembly 253052-18 Griddle Plate Assembly 253052-19 Griddle Plate Assembly 253052-20 Griddle Plate Assembly 252336 Griddle Burner Assembly...
  • Page 10 RGTA THERMOSTATICALLY CONTROLLED WITH OPEN BURNER REV. 0 RGTA THERMOSTATICALLY CONTROLLED WITH OPEN BURNER Page 10 Regal Series (Rev.06)

  • Page 11: Rgta Thermostatically Controlled Griddles W/Open Burners

    U.S. RANGE PARTS IDENTIFICATION RGTA THERMOSTATICALLY CONTROLLED GRIDDLES W/OPEN BURNERS ITEM PART # DESCRIPTION 2424-1-2 2436-1-2 2448-1-2 2460-1-2 2472-1-2 253052-22 Plate Assembly RGTA-2424-1-2 253052-23 Plate Assembly RGTA-2436-1-2 253052-24 Plate Assembly RGTA-2448-1-2 253052-25 Plate Assembly RGTA-2460-1-2 253052-26 Plate Assembly RGTA-2472-1-2 222186 Regal Cast Top Grate 12"...

  • Page 12: Rhpa Series Heavy Duty Hot Plates

    RHPA SERIES HEAVY DUTY HOT PLATES 6, 7 REV. 0 RHPA HEAVY DUTY HOT PLATES.dwg Page 12 Regal Series (Rev.06)
  • Page 13 Drip Pan 24 1/4 X 8 1/2 253060-6 Drip Pan 24 1/4 X 20 1/2 253060-7 Drip Pan RHPA-636 253060-8 Drip Pan 44 1/2 X 24 1/2 253060-9 Drip Pan RHPA 1060 1196302 1019012 Regulator Natural 2127500 Gas Regulator Propane Page 13 Regal Series (Rev.06)

  • Page 14: Rba Series Char-Broiler

    RBA SERIES CHAR - BROILER Effective Feb 24-03, Two 24" trays instead of one 48". Tray also deeper. RBA CHAR-BROILER.dwg Page 14 Regal Series (Rev.06)
  • Page 15 U.S. RANGE PARTS IDENTIFICATION RBA SERIES CHAR-BROILER ITEM PART # DESCRIPTION 24" 30" 36" 48" 60" 72" 222040 Top Grate(3BAR)21-3/16 X 2-7/8 222041 4-Bar Grate NLA-USE 222040 222024 Cast Iron Radiant 222079-1 Burner Straight ASSY,22-5/8 223005-10 Air Shutter 26878XX Valve Assembly Less Hood LML-15...
  • Page 16 U.S. RANGE PARTS IDENTIFICATION RBA SERIES CHAR-BROILER ITEM PART # DESCRIPTION 24" 30" 36" 48" 60" 72" 253022-1 Valve Cover RBA - 24" 253022-2 Valve Cover 253022-3 Valve Cover 36" RBA 253051-12 Valve Cover 48" (Panel) 253051-13 Valve Cover 60" (Panel) 253051-14 Valve Cover 72"...
  • Page 17 NOTES Page 17 Regal Series (Rev.06)
  • Page 18 C-HDS-A CHAR - GLO SERIES Regal Series (Rev.06) Page 18...
  • Page 19 RG-HDS-A CHAR - GLO SERIES Page 19 Regal Series (Rev.06)
  • Page 20 C-JR CHAR - GLO SERIES 4/4A C-JR CHAR GLO SERIES.dwg REV. 0 Page 20 Regal Series (Rev.06)

  • Page 21: C-Hds-A / Rg-Hds-A / C-Jr Char Glo Series

    Side Support ASS'Y 153834 Lift Plate (HDS) 151877 Pivot Plate ASS'Y 153651 Pivot Plate Assembly NLA 154131 Push Rod Assembly (CHDS) 153832 Push Rod - 10 1/8" 153627 Push Rod Assembly C-JR 153835 Drag Link Page 21 Regal Series (Rev.06)
  • Page 22 151096-1 Pilot Tube Assembly 6 1/2" 151096-2 Pilot Tubing Assembly 8"NLA 154508 Drain Tube Ass'y NLA 153886 Perf.. Screen, 24" (HDS) 154087 Perforated Screen, 30" (HDS) 154090 Perforated Screen 36" 154488 Preforated.Screen,11 1/8"X14 1/2 NLA Page 22 Regal Series (Rev.06)
  • Page 23 U.S. RANGE PARTS IDENTIFICATION C-HDS-A / RG-HDS-A / C-JR CHAR GLO SERIES ITEM PART # DESCRIPTION C-HDS-A RG-HDS-A C-JR 24 30 36 48 60 24 30 36 48 60 21 30 154489 Preforated Screen NLA 153882 Slide Pan 24" (HDS) 153936-1 Slide Pan ASM,30"&...

  • Page 24: Rgtsa - Snap-Action Thermostat Controlled Griddles

    RGTSA SERIES SNAP-ACTION THERMOSTAT CONTROLLED GRIDDLES Page 24 Regal Series (Rev.06)
  • Page 25 U.S. RANGE PARTS IDENTIFICATION RGTSA - SNAP-ACTION THERMOSTAT CONTROLLED GRIDDLES ITEM PART # DESCRIPTION 24" 36" 48" 24" 36" 48" (5/8") (5/8") (5/8") 253805-1 253805-2 253805-3 Griddle Plate Weld Ass'y 253805-4 253805-5 253805-6 252336 Burner Assembly Complete 223005-4 Air Shutter Only...
  • Page 26 Plate Adj. Nut - Front 223232 Legs - 4" 225053-1 Manifold Ass'y Nut 225054 Manifold Ass'y Washer 253838-1 253838-2 Wire Package 253838-3 228046-1 Wire Tie 253851-1 Gas Valve Heat Shield * NOT ILLUSTRATED RECOMMENDED STOCK PARTS Page 26 Regal Series (Rev.06)

  • Page 27: Revision History

    Feb 18/04 New Part number added (223011) 8, 9 Item # 13 Added Part Number Corrected - Item # 19 Feb 19/04 Item # 6b & 8 Added 6, 7 Quantity changed Part Number Deleted Page 27 Regal Series (Rev.06)
  • Page 28 Regal Series (Rev.06)
