SCHEMATIC

02929-194276_Regulated-Tex
IGNITION SWITCH
POSITION CIRCUIT
OFF M+G+A1
B+A1
RUN/OVERRIDE
RUN B+A1
START B + S + A1

TRACTOR - MODEL NO. 917.279200 (YTH2448T)

RED
WHITE
S
M
B
A1
G
A2
L
BLUE
3 6
2 5
"MAKE"
1 4
CHASSIS HARNESS
L+A2
CONNECTOR
02929
(MATING SIDE)
BATTERY
SOLENOID
RED
FUSE
WHITE
RED
RED
BLACK
PTO SWITCH
(DISENGAGED)
BLACK
BLACK
2
BLACK
3
BLACK
1
6
JUNCTION
CONNECTOR
CHASSIS
HARNESS
IGNITION
UNIT
(OPTIONAL)
BLUE HOUR
METER
FUEL
LINE
CHARGING SYSTEM OUTPUT
16 AMP DC @ 36 RPM
FUEL SHUT-OFF
SOLENOID
(IF SO EQUIPPED)
REGULATOR
RED
BROWN
LIGHT
SWITCH
6 3
5 2
4 1
DASH HARNESS
CONNECTOR
(MATING SIDE)
29
STARTER
M M
BLACK
ELECTRIC CLUTCH
WHITE
CLUTCH/BRAKE
(PEDAL UP)
REVERSE SWITCH
(NOT IN REVERSE)
BLACK
SEAT SWITCH
(NOT OCCUPIED)
BLACK
BLACK
GRAY
SHORTING
CONNECTOR
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
BLACK
12V
POWER OUTLET
(IF SO EQUIPPED)
STATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
HEADLIGHTS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
BLACK
GRAY
BLACK
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
