Pre Event Duration: The unit will record up to 5 seconds of data ahead of the event trigger, at the
Event Record Rate. Select from 0 to 5 seconds.
Post Event Duration: The unit will record up to 250 seconds after the completion of the Event, at the
Event Record Rate. Select from 0 to 250 seconds.
Event Associated Cameras: Enter up to three camera numbers to be associated with this event.
Main Menu → Record → Timelapse Record Rate
The unit records at the Timelapse Record Rate under normal conditions, when there are no alarms,
events, or activity present. Record rates are measured in both Pictures Per Second (pps) and Seconds
Per Picture (spp).
The maximum record rate per camera is inversely proportional to the number of cameras connected to
the unit. The fewer cameras connected, the higher the maximum record rate for each camera, and vice
versa. The maximum record rate for multiple cameras is 24pps (NTSC)(20pps PAL). The maximum
record rate for a single camera is 120pps (NTSC)(25pps PAL).
The bottom right corner of the menu contains a record duration calculator. The top line indicates the
estimated recording time for the unit in Time-lapse record mode only. The bottom line indicates the
estimated recording time, taking into consideration the amount of time the unit will spend in Activity,
Event, and/or Alarm record mode.
1. Rotate the Jog to navigate, and the Shuttle to change the values.
2. To save changes and exit the menu: Select [OK], and then press the Enter button.
3. To exit the menu without making changes: Press the Menu button, or select [CANCEL], then
press the Enter button.
Main Menu → Record → Event Record Rate
The unit will record at the Event Record Rate when an Event is activated. Events can be activated by
RS232 event generation or activity detection. See Event Settings on page 35.
Record rates are measured in both Pictures Per Second (pps) and Seconds Per Picture (spp).
The maximum record rate per camera is inversely proportional to the number of cameras connected to
the unit. The fewer cameras connected, the higher the maximum record rate for each camera, and vice
0150-0294B
Timelapse Record Rate
Camera 1 : 0.40 pps 2.5 spp
Camera 2 : 0.29 pps 3.5 spp
Camera 3 : 0.34 pps 2.9 spp
Camera 4 : 0.57 pps 1.8 spp
:
:
:
Camera 15 : 0.40 pps 2.5 spp
Camera 16 : 0.40 pps 2.5 spp
[CANCEL] [OK]
38
8 days 5 h (TL)
8 days 5 h (Total)
