- Page 1 DUAL ACTION POLISHER USER’S GUIDE Safety NoteS • featureS • INStruCtIoNS • MaINteNaNCe & Care...
-
Page 2: Table Of Contents
Velcro Backing Plate Change Pads Quickly Random Orbital Action Prevents Swirl Marks Pad oscillates and rotates on 2500-6500 OPM Motor varying orbits Orbits at Ideal Speed Pads sold separately. Extra Long 20 Foot Cord Allows Additional Convenience Dual Action Polisher User’s Guide... -
Page 3: Safety Notes
• Always disconnect the plug from the socket before carrying out any work on the machine. • Only plug-in when machine is switched off. • Keep power cord clear from working range of the machine. • Always lead the cable away behind you. • Never reach into the spinning area of the machine when it is running. • Only use tools whose permitted speed is at least as high as the highest no-load speed of the machine. • Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. • Always remove jewelry and other clothing or objects which may scratch the surface as you polish. intenDeD Use The machine is intended for polishing and sanding of painted or fiberglass surfaces. For reasons of electrical safety the machine must not be damp or operated in a humid environment. The machine may only be used for dry sanding, buffing or polishing. www.shurhold.com... -
Page 4: Basic Instructions
AnD stOP tOOl make certain that the switch is in the “Off” position, and the power source is the same as that specified on the tool’s nameplate. a. Connect the tool to the power source. b. To start tool slide the power switch for- ward until it locks in the on position. To stop tool press rear of power switch to unlock and slide to rear off position. Dual Action Polisher User’s Guide... - Page 5 - one hand on auxiliary handle and one on the motor housing. d. Position the polisher with the polishing pad against the work surface and start the polisher. never run or stop the tool when it is not in contact with the work surface. e. Move the polisher back and forth in a sweeping motion, over-lapping each previ- ous pass. See diagram on page 9. f. DO NOT apply additional pressure. Allow the polisher to work under its own weight. g. DO NOT mix products (wax, polish, cleaner, etc.) on the same pad. Label each pad to prevent confusion. www.shurhold.com...
-
Page 6: Maintenance & Care
MAINTENANCE & CARE Always remove the power supply plug from the socket before carrying out any work on the machine. The cool air openings in the motor casing must always be kept clean and unobstruct- ed to ensure air circulation. With the exception of carbon brush replacement (see instruction manual), all main- tenance and repair work which requires the motor casing to be opened may only be carried out by an authorized service center. Keep unit clean and dry. Wipe down and clean after each use. Do not submerse in water. For best results always start with clean dry pads. See pad manufacturer for pad cleaning directions. Dual Action Polisher User’s Guide... -
Page 7: Tips From The Pros
TIPS FROM THE PROS IMPROVEMENT & MAINTENANCE OF GLOSS Shurhold offers the various compound and premium buffing pads necessary to get the job done. Use of an aggressive pad and compound may remove severe damage, but the high gloss shine must be achieved with further polishing. A step-by-step process of aggressive to mild pads and compounds will get the professional results you demand. When the surface still looks new, use of mild compounds and pads is all that is necessary to maintain that new vehicle shine. Polish your boat, car or other vehicle 2-3 times a year to protect its surface and shine. For more information visit www.shurhold.com. REMOVAL OF DEFECTS IN PAINT & GEL COAT OXIDATION Your Shurhold Dual Action Polisher is the perfect tool for removing minor defects in paint and gel coat. Defects such as scratches, oxidation, scuffs, chemical etching, swirl and sanding marks, can be repaired during polishing with the proper pads and compounds. Great attention must be paid to the amount of paint, clear coat and/or clear coat remains on the surface prior to this process. For more information visit www.shurhold.com. WAXING WITH POLISHER The benefits of applying wax by machine include speed, even coverage, less waste, ease of application, ease of removal and brighter shine. Using the pattern described on the opposite page, apply wax at a speed of 1 or 2 in a thin layer for an easily buffed surface and high-gloss shine. - Page 8 Although you may use wax, Shurhold recommends that a polish, such as Shurhold’s Pro Polish, be used for the most significant improvement in the surface’s appearance. Pro Polish is a paint and fiberglass/ gel coat cleaner, sealant and polish with UV inhibitors that produces an ultra high gloss finish in one easy step. Formu- lated with cosmetic grade ingredients, it contains no fillers or talc, protecting your finish against sun, salt, acid rain and other harsh environmental elements. Be sure to use a separate pad for each compound. Avoid using different compounds on the same pad. A plastic baggie is a good storage source for pads to be used again after proper cleaning of pad. Be sure to work in an environment with good lighting, such as fluorescent or halogen. Direct sunlight should be avoided. For best results, use Shurhold’s Pro Polish and follow these steps: STEP 1 Choose the pad for the job, we recommend Shurhold’s Pro Polish black foam pad. STEP 2 Apply Pro Polish to the pad. STEP 3 Apply Pro Polish evenly on the surface to be polished. Dabbing over the entire surface is ideal, too much compound in one area will cause it to fling off the pad. Using the tool in the off position, dab the pad against a small work area to distribute the polish. STEP 4 Be sure Polisher is off. Turn speed dial to a speed of 1 or 2. Hold pad against surface to be polished, and switch Polisher on. Once the polish has absorbed into the pad, the Polisher can be used at a higher speed such as 3 or 4. Dual Action Polisher User’s Guide...
- Page 9 TIPS FROM THE PROS STEP 5 To work the polish into the surface, increase the Polisher’s speed to 3 or 4. Hold pad flat against surface, and slowly move the pad in the pattern shown below. Overlap each pass halfway, while polishing up and down, then left to right. STEP 6 Once you’ve polished enough that only a thin layer of polish remains, you may stop. Check to see you’ve covered all the areas necessary. The remainder of the polish can be removed with a microfiber towel. BEGIN HERE www.shurhold.com...
-
Page 10: Recommended Compounds & Accessories
COMPOUNDS The Shurhold Industries line of compounds are specifically formulated to achieve the finest finish with the least amount of material and effort. Since the six core items replace over 20 items from the competitors, this allows you to purchase half as many compounds, saving time and money. Used by Fiberglass Shops, Professional Boat Builders, and Repair Shops, our profes- sional grade, affordable products allow you to Polish Like A Pro every time. the ShurhoLD SySteM IS your totaL SurfaCe Care SoLutIoN! CLEANING BETWEEN DETAILS brite wash multi surface soap ® Brite Wash is scientifically formulated to clean fiberglass, metal, rubber and painted surfaces. Brite Wash is environmentally friendly and perfect for cleaning dirt, grease, salt and more without dulling your finish or stripping your wax or polish. Available in 32 oz. (948 mL) and 1 gal. (3.78 L) sizes. - Page 11 ACCESSORIES SHURHOLD HANDLES Shurhold’s exclusive SHUR-LOK quick release system positively locks any Shurhold handle quickly and easily with all Shurhold accessories. All handles are made of high strength, corrosion resistant, lightweight aluminum. PREMIUM BRUSHES Our premium deck brushes feature an angled head and flared bristles from extra soft to stiff. They are made from premium hard woods, the bristles are set with rust proof “Nickel Silver” stapling wire and feature wrap around safety bumpers. The most popular soft deck brush! The specially designed split end fibers hold more soap and water. This brush is safe on gel coat, fiber- glass, and paint. MESH SPONGE Bug & Tar Remover. Non-abrasive mesh covered sponge removes bugs, stains, tar, grit, and grime faster and easier. WASH MITTS Shaped thumb and elastic band for a comfortable fit. Made from genuine lambs wool. Great for washing and polishing. Can be used wet or dry. HOSE NOzzLE Ergonomic Grip. Die-cast zinc nozzle body with soft black vinyl grip. Includes a hold open clip and stainless steel spring. PREMIUM BUFFING PADS The right pad for any job. All pads feature a hook and loop system for a quick change. Buff Magic Pad is a general purpose, light cutting pad made of premium wool. Perfect for removal of oxidation. Pro Polish Pad is a black foam finessing pad. It’s unique patent pending dimple design decreases polish absorption, improves user control, prevents pad skipping and reduces heat and friction. MICROFIBER TOWELS Wet It, Wring It, Wipe It! •...
-
Page 12: Dual Action Polisher
DUAL ACTION POLISHER 3119 S.W. 42nd Avenue, Palm City, Florida 34990-5558 Tel: 772-287-1313 Toll Free: 800-962-6241 Fax: 772-286-9620 email: info@shurhold.com website: www.shurhold.com ©2009, Shurhold Industries, Inc. All rights reserved. We reserve the right to make changes to the technical data contained in this information as a result of ongoing research and development work.
