Listed to standards
ULC-S610 and UL-127
MONACO FIREPLACE
INSTALLATION AND OPERATION MANUAL
READ AND KEEP THIS MANUAL FOR REFERENCE
STOVE BUILDER INTERNATIONAL INC.
250, de Copenhague, Saint-Augustin-de-Desmaures (Quebec), Canada G3A 2H3
Tel: (418) 878-3040 Fax: (418) 878-3001
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
45182A
Printed in Canada
18-04-2013
