Orion OSHD-410H Installation & User Manual

Orion digital video recorders - installation /user manual
Table of Contents

Advertisement

Quick Links

OSHD-410H & OSHD-810 & OSHD-1610
OSHD-410H/OSHD-810/OSHD-1610
Digital Video Recorder
Installation / User Manual
Install & User Manual - Firmware 3.X
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSHD-410H and is the answer not in the manual?

Questions and answers

Summary of Contents for Orion OSHD-410H

  • Page 1 OSHD-410H & OSHD-810 & OSHD-1610 OSHD-410H/OSHD-810/OSHD-1610 Digital Video Recorder Installation / User Manual Install & User Manual - Firmware 3.X...
  • Page 2 HD-CCTV DVR Install & User Guide HD-CCTV DVR Manual. Thank you for purchasing a Orion Technology A/S Digital Video Recorder. Before installation or operation please become familiar with the user manual and other referenced manuals mentioned in the booklet. User manual, software and hardware described here are protected by copyright by law. With the exception of copying for general use within fair use, copying and reprinting of the user manual, either partially or in entirety, or translating it into any another language without the consent of our Corporate office is strictly prohibited.
  • Page 3 To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system. Copyright ©2012 ORION TECHNOLOGY A/S. All rights reserved. Install & User Manual - Firmware 3.X...
  • Page 4: C O N T E N T S 0. Introduction

    Product is made of metal you can hurt another human if you throw or used as a weapon. Keep away from the reach of children.  If Product does not operate properly, please contact the closest ORION TECHNOLOGY A/S distributor for service. Tampering or disassembling the product will void the warranty. ...
  • Page 5: Table Of Contents

    OSHD-410H & OSHD-810 & OSHD-1610 INTRODUCTION ......................3 0.1. Warning ..............................3 KEY FEATURES ......................9 1.1. Accessories .............................. 12 1.2. Description & Function ..........................13 1.2.1. Front ..............................13 1.2.2. Rear ..............................15 1.2.3. Remote Controller ..........................15 1.2.3.1.
  • Page 6 OSHD-410H & OSHD-810 & OSHD-1610 3.2. Function Menu ............................27 3.3. Factory Reset ............................27 3.4. OSD menu configuration .......................... 28 3.4.1. Menu structure ..........................28 3.4.2. Basic Setting ............................. 29 3.4.2.1. Viewing Image..........................29 3.4.2.2. Setting Date & Time ........................29 3.4.2.3.
  • Page 7 OSHD-410H & OSHD-810 & OSHD-1610 4.10.7. Auxiliary Off ........................... 38 4.10.8. Menu ............................. 38 SEARCH & PLAYBACK ....................39 5.1. Playback ..............................39 5.1.1. Playback with Basic Screen ......................39 5.1.2. Playback Function ..........................39 5.2. Search Mode ............................40 5.2.1.
  • Page 8 OSHD-410H & OSHD-810 & OSHD-1610 6.3.5.1. PTZ Setup ............................. 61 6.4. Event Setup .............................. 62 6.4.1. Event Check ............................62 6.4.2. Sync Event ............................62 6.4.2.1. Relay 1~4 ............................63 6.4.2.2. Buzzer ............................63 6.4.2.3. E-Mail Setup ..........................63 6.4.2.4.
  • Page 9 OSHD-410H & OSHD-810 & OSHD-1610 7.6.3. Print ..............................78 7.6.4. Back up ............................. 78 7.6.5. Web Monitor Movement ........................78 7.6.6. Channel On/Off ..........................78 7.6.7. Saving time & Checking Rec, Capacity .................... 79 7.6.8. Calendar Search ..........................79 7.6.9.
  • Page 10: Key Features

    OSHD-410H & OSHD-810 & OSHD-1610 Key Features FULL HD image supports The product supports live monitoring and playback for HD-SDI SD : D1 high quality video of 1080p (1920x1080) / 720p (1280x720) resolution. Max 240 frames per second can be saved and Max 15 HD : 720p second recordable before event triggeres.
  • Page 11 OSHD-410H & OSHD-810 & OSHD-1610 Monitoring screen Supports real live video with high resolution per each channel and variable display mode. Also COVERT(hiding image) feature will secure privacy.  Various monitoring mode  Single, Multi screen division  Auto switching (Sequence) ...
  • Page 12 OSHD-410H & OSHD-810 & OSHD-1610  Max 1024 DVRs management  Supports User friendly GUI and mouse function  Easy and simple firmware upgrade by USB memory  Record data backup function thru USB  PTZ control, PRESET support  Available to control up to 16 DVRs with one remote controller...
  • Page 13: Accessories

    OSHD-410H & OSHD-810 & OSHD-1610 1.1. Accessories Check if below items are included. Remote Controller Mouse Battery Rack Bracket & Screw Screw for HDD installation AC code SW & Manual CD Quick Guide User’s Manual Install & User Manual - Firmware 3.X...
  • Page 14: Description & Function

    OSHD-410H & OSHD-810 & OSHD-1610 1.2. Description & Function 1.2.1. Front Category Function DVD-Multi for backup Back up use for recorded data by DVD/CD media Jog / shuttle Playback direction change and speed control. Touch channel button Select channel by touch during live and playback.
  • Page 15 OSHD-410H & OSHD-810 & OSHD-1610 ◀▶(PLAY) To select playback mode and change playback direction. ▶▶(FWD) To move or select in menu and change replay speed to forward direction in playback mode. l▶(SFWD) To move to forward direction by one frame...
  • Page 16: Rear

    OSHD-410H & OSHD-810 & OSHD-1610 1.2.2. Rear In/Out port name Function Power connector Socket for AC100V~AC240V power cord.. Sensor IN Input for external sensor. Relay Relay Connection terminal. Com2,3 RS-485 device connection RS-485 termination Set RS-485 termination Ground Ground between DVR & external device.
  • Page 17: Remote Controller Id Setup

    OSHD-410H & OSHD-810 & OSHD-1610 RELAY ON BACKUP Alarm ON manually No use LOCK Lock monitor screen Select Remote ID COPY RELAY OFF Save record data into USB or CD/DVD Alarm OFF manually SEARCH Auto screen switch Display search menu...
  • Page 18: Installation

    OSHD-410H & OSHD-810 & OSHD-1610 Installation 2.1. Before Installation DVR is high quality security device having large capacity of HDD and important curcuits. So any high temperature occurred internally could make DVR work abnormally so please read through below installation advice before installation.
  • Page 19: Add Hdd

    OSHD-410H & OSHD-810 & OSHD-1610 2. Push HDD bracket to the marked direction to separate it from fixed position. 3. Lift HDD bracket out of bottom of DVR. 4. Insert HDD into bracket and engate 4 screws to hold HDD.
  • Page 20: Connecting Other Devices

    OSHD-410H & OSHD-810 & OSHD-1610 Please refer to nearby vendor of the product from it was purchased from to know more about additional HDD installation. ◈ Note about data loss Be aware of data damage of HDD. Check HDD compatibility before installing additional HDD.
  • Page 21: Connecting Camera

    OSHD-410H & OSHD-810 & OSHD-1610 2.2.1.2. Connecting camera Connect DVR with HD-SDI cable using recommended coax cable. Input video type is recognized upon turning on DVR. There is no limitation on same resolution cameras but in case 1080p and 720p are mixed to input, 720p must be connected on lower channel numbers while 1080p on higher number channel.
  • Page 22: Connection Map With Other Devices

    OSHD-410H & OSHD-810 & OSHD-1610 2.2.2. Connection map with other devices 2.2.3. Connecting external device 2.2.3.1. Connecting USB Device USB port can be used for copy of recorded data and for mouse. USB Device spec will not be over following specification.
  • Page 23: Connecting Osn-04St

    OSHD-410H & OSHD-810 & OSHD-1610 4) Turn off eSATA then connect it with DVR. 5) Turn of eSATA. 6) Turn on DVR. 2.2.4. Connecting OSN-04ST 2.2.4.1. Connecting OSN-04ST with DVR (1) Connect OSN-04ST with DVR using Gigabit Ethernet Cable. (2) Connect OSN-04ST with DVR directly thru storage port of DVR.
  • Page 24: Inserting & Removing Wire

    OSHD-410H & OSHD-810 & OSHD-1610 2.2.5.2. Inserting & removing wire To insert & remove wire in Terminal Block, use a screw driver in the diagram like below. 2.2.5.3. Connecting sensor Spec In order to run sensor input DVR normally, the following conditions are required.
  • Page 25: Connecting Com1 Serial Port With External Devices

    OSHD-410H & OSHD-810 & OSHD-1610 Connecting relay Connect R1 ~ R4 with referring to the following images, it shows to connect a warning light. Please refer the “Wire Handling” 2.2.5.5. Connecting COM1 serial port with external devices Text input device connection (ATM / POS / Access Control) Using COM1/RS232, TEXT DATA can be recorded with synchronizing POS/ATM.
  • Page 26: Configuring An Extension Of Ptz & Keybaord

    OSHD-410H & OSHD-810 & OSHD-1610 Connecting Serial Port for Transparent device This is function to support direct connection between serial port of PC and COM port of DVR and this is for development of Application throughout SDK. This is not used in general case so please contact customer service for more details about this function Serial communication port diagram <Note>...
  • Page 27 OSHD-410H & OSHD-810 & OSHD-1610 Serial Cable Video Cable DOME 1 DOME 2 DOME 16 COM2 COM3 DVR 1 DVR 2 DOME 1 DOME 2 DOME 16 Master DVR 3 DOME 1 DOME 2 DOME 16 DVR 255 DOME 1 DOME 2...
  • Page 28: Menu Usage

    OSHD-410H & OSHD-810 & OSHD-1610 Menu Usage 3.1. Menu Structure The menu structure will be shown like below image, and each menu setting method is described in explanation of set items. Date/Time Network Camera Event Record Disk xDSL Monitor Motion...
  • Page 29: Osd Menu Configuration

    OSHD-410H & OSHD-810 & OSHD-1610 3.4. OSD menu configuration Press [MENU] in keypad of front to open the main menu; 3.4.1. Menu structure Press [MENU] key in front panel or press [Main Menu] Main menu button to get into setup menu.
  • Page 30: Basic Setting

    OSHD-410H & OSHD-810 & OSHD-1610 Keep pressing [▲/▼], [◀/▶] arrow button until the word is looking for and press [Enter] or click the mouse. If need to delet a word press [], spacing words press [] button. To exit from dialogue box, press [Enter] or click [Enter] button .
  • Page 31: Record Setting

    OSHD-410H & OSHD-810 & OSHD-1610 Daylight Saving This menu is linked with “time zone” setting. For example, if the daylight savings applies in the country turn to “ON” but in other counties were it does not applieds for daylight saving used the “OFF” option and additionally the user can configure the daylight saving option manually for the counties that were not applied, and in this case, you can use “Custom”...
  • Page 32: Use Of Input/Output Devices

    OSHD-410H & OSHD-810 & OSHD-1610 <Reference> In case of Manual Setting, user needs to check recording indicate status on the front panel. If there are no recording indicate please press REC button to start recording. [Record Schedule] [Record Program] Schedule Recording Set the recording schedule by each channel that user want record in “Program”...
  • Page 33: Sensor Setting

    OSHD-410H & OSHD-810 & OSHD-1610 Select channel to copy. Default value is Set All. 3.5.2. Sensor Setting MENU  EVENT  SENSOR 3.5.2.1. All Sensor It is used when setting for all sensors and set “Off”, or Normal Open (N.O.) / Normal Close (N.C.) type.
  • Page 34: Text Setting

    OSHD-410H & OSHD-810 & OSHD-1610 1) Selecting COM1 port and configure “Text”in Device 2) Setup the value of Baud Rate/Parity/Stop bit/Data bit with the device. 3.5.4.2. Text Setting MENU  DEVICE  TEXT 1) Configure relevant text information. <Reference> Since external device cannot be recognized, before installing reffered back to Vendor.
  • Page 35: Remote Monitoring & Control

    OSHD-410H & OSHD-810 & OSHD-1610 <Note> 1. HDD Re-using (Add Used) You can use HDD that has been used before from DVR, in this case you do not need to do format and delete the data. How to use it? Please install previous HDD in the DVR, and go to “Disk Manager” menu and select the HDD that you wish to re-use which is you just installed HDD, and press “Enter”...
  • Page 36: Monitoring

    OSHD-410H & OSHD-810 & OSHD-1610 User can configure “Time Interva”l from 1 min to 24 hours. With WRS time interval set, WRS will be “ON” and DVR will be registered automatically. WRS server address should be kept in default and enter GROUP ID. We recommend using user own GROUP ID to avoid duplication.
  • Page 37: Auto Switch Mode(Sequence)

    OSHD-410H & OSHD-810 & OSHD-1610 When Motion is triggered, the channel name is changed to green, sensor to red, and text to white. 4.6. Auto Switch Mode(Sequence) Auto switch screen mode is a feature in which the selected channel or multi screen division switches in order.
  • Page 38: Pause Live Screen

    OSHD-410H & OSHD-810 & OSHD-1610 4.9. Pause Live Screen Live screen can pause like PlayBack. Press ll(PAUSE) to pause live screen and press ll(PAUSE) to return live screen. 4.10. PTZ Control Connect PTZ controller to DVR and set relevant protocol from “Serial” menu, then PTZ can operate while monitoring live images.
  • Page 39: Pan/Tilt/Zoom

    OSHD-410H & OSHD-810 & OSHD-1610 4.10.3. Pan/Tilt/Zoom This menu is used to control Pan / Tilt / Zoom function. Select relevant channel to control PTZ which is connected with PTZ. 4.10.4. Load Preset Press [PTZ] button in PTZ screen to activate Load Preset menu.
  • Page 40: Search & Playback

    OSHD-410H & OSHD-810 & OSHD-1610 Search & Playback 5.1. Playback 5.1.1. Playback with Basic Screen  Press [PLAY] button in monitoring mode or mouse click play button in Function menu to playback  If [PLAY] button is pressed, the last playback will run at 1x speed.
  • Page 41: Search Mode

    OSHD-410H & OSHD-810 & OSHD-1610 5.2. Search Mode This menu is to playback specific time data from the time frame and searching log at Playback mode. Theres Time, Calendar, Event, and Thumbnail mode. Press Search button on the front panel or click in Function menu.
  • Page 42: Thumbnail Search

    OSHD-410H & OSHD-810 & OSHD-1610 5.2.4. Thumbnail Search Search certain channel by thumbnail type. If a searched thumbnail is selected, selected date and time video will be played back. If thumbnail search is excuted, 16 cycles will be shown based on start time.
  • Page 43: Avi

    OSHD-410H & OSHD-810 & OSHD-1610 Name Description Type Select RE4 using Up/Down key in front panel or moust wheel. Channel Select the channel location and press Enter or use mouse wheel to pop-up FAT32 Format Format USB memory or HDD by FAT32 type. Press Enter or click mouse button Caution : If a file is not backed up completely, it is not available to playback in PC.
  • Page 44: Configuration

    OSHD-410H & OSHD-810 & OSHD-1610 6. Configuration 6.1. System Setup Time, disk, and authorization can be configured. 6.1.1. Date/Time MENU  SYSTEM  DATE/TIME Time set should be configured prior to the recording. Time configuration is very important to protect the recording data.
  • Page 45: Ntp Setup

    OSHD-410H & OSHD-810 & OSHD-1610 <Caution> Except date/time configuration, other records automatically, but “date/time” configuration influences critical effect to HDD recording file system, It doesn’t record automatically. To apply the changed value, user must press [Apply] button. 6.1.1.2. NTP Setup MENU ...
  • Page 46: Disk

    OSHD-410H & OSHD-810 & OSHD-1610 6.1.2. Disk MENU  SYSTEM  DISK It explains how to add or remove or format internal or external HDD. Over Write(Auto Deletion) If there is no space in HDD, old data will be deleted automatically.
  • Page 47: Disk Manager

    OSHD-410H & OSHD-810 & OSHD-1610 6.1.2.1. Disk Manager MENU  SYSTEM  DISK  DISK MANAGER This is menu for the management of internal or external HDD. Manage status, bad block, size, Yes or No etc. Name Description Type Display location or type of disk.
  • Page 48: Disk Status

    OSHD-410H & OSHD-810 & OSHD-1610 6.1.2.2. Disk Status MENU  SYSTEM  DISK  DISK STATUS Temperature and status of HDD installed in system will be shown. Name Description Temp (C) Represents Celsius temperature for HDD Temp (F) Represents Fahrenheit temperature for HDD S.M.A.R.T...
  • Page 49 OSHD-410H & OSHD-810 & OSHD-1610 1) HDDs will be set like the above. 2) Recording data of HDD-3 is mirroring with HDD-1 and recording data of HDD-4 is mirroring to HDD-2. 3) If there are 4 ea of HDDs are mounted on DVR and starts recording, HDD-4 will start recording.
  • Page 50: Mirroring Hdd Replacement

    OSHD-410H & OSHD-810 & OSHD-1610 IntA ATA WDCWD5000AV 476940 IntB ATA ST3250820AS 238475 IntC TA WDCWD5000AV 476940 IntD ATA ST3250820AS 238475 2) Abnormal Mirroring case or not recommended.(different model and size) Type Model Bad Blk Size(MB) Enabled IntA ATA WDCWD5000AV...
  • Page 51: User Setup

    OSHD-410H & OSHD-810 & OSHD-1610 If HDD has free space, it show “Mirror” and if it is 0%, it will show “Replace” for alarming State HDD change. <Note> a) For Mirroring HDD replacement, user must do it in HDD Change menu.
  • Page 52: Utility

    OSHD-410H & OSHD-810 & OSHD-1610 Channel Authorization Administrator has all rights to all channels and it can not be changed. He can allocate the right for access to each channel per user. Function Authorization Administrator has all rights to all functions.
  • Page 53 OSHD-410H & OSHD-810 & OSHD-1610 DVR Keyboard ID This menu is to set the address of keyboard when using all functions of DVR by keyboard. Factory default is “1”. If user wants to control various DVR by one keyboard, its address should be set with the different value. If designated address is configured same as keyboard, user can control DVR function.
  • Page 54: Network

    OSHD-410H & OSHD-810 & OSHD-1610 Config Import/Export Export – Save Configuration data in DVR to USB Import – Apply exported Configuration data to relevant DVR or another DVR. System Information Display recording status and system configuration of DVR Caution : This function is allowed only for system administrator.
  • Page 55 OSHD-410H & OSHD-810 & OSHD-1610 IP Address IP Address is for the connection between DVR and Control Center and also for web connection from Webviewer. (But, Net Mask, Gateway should be configured.) Net Mask Net Mask makes range of IP address available. It should be received from network administrator.
  • Page 56: Xdsl

    OSHD-410H & OSHD-810 & OSHD-1610 6.2.1. xDSL MENU  NETWORK  xDSL DVR is connected to xDSL line and use PPPoE type, please change type by xDSL and configure user ID and Password. User ID and Password should be same as xDSL User ID/Password Configure user ID and Password.
  • Page 57: Radius

    OSHD-410H & OSHD-810 & OSHD-1610 6.2.3. Radius MENU  NETWORK  RADIUS It makes to manage account information from several different DVRs to one account using Radius server. Please ask to Administrator before you use it.. To set Radius, Status, IP Address, Port should be set.
  • Page 58: Using Channel

    OSHD-410H & OSHD-810 & OSHD-1610 6.3.1.1. Using Channel Configure whether the camera is used or not. If you want to exclude certain cameras even with video signal, user should set status off. 6.3.1.2. Title Configure camera name. Text input box could be different depending on menu but its setting method is the same.
  • Page 59 OSHD-410H & OSHD-810 & OSHD-1610 Display Information Display information is to configure which information will be shown on live view and playback view. In live view, there are the Channel name, Text, and Status Bar. In playback view, time, channel name, event, text Command show and hiding can be configured.
  • Page 60: Audio Setup

    OSHD-410H & OSHD-810 & OSHD-1610 6.3.3. Audio Setup MENU  DEVICE  AUDIO With this menu, user can configure Voice Channel, Audio recording, Volume, Synchronization, Mixing. Voice Channel Select audio to use Recording Configure yes or no if using audio recording. If No, audio will be out only in live view and if Yes, Audio will be out in both view modes.
  • Page 61: Text Setup

    OSHD-410H & OSHD-810 & OSHD-1610 6.3.4. Text Setup MENU  DEVICE  TEXT Configure Text in Device menu. Recording Set On/Off of recording against Text input Sync Text with Select channel to synchronize with text. Device Select the device to input text. Manual, Star Finger 007, VSI Pro are available to select.
  • Page 62: Serial Setup

    OSHD-410H & OSHD-810 & OSHD-1610 6.3.5. Serial Setup MENU  DEVICE  SERIAL DVR has 3 serial ports. One is RS-232C(D-Sub) and the other 2 ports are RS-485(Terminal). Serial Port Select Serial port to use among 3 COM Ports Device Select Device connected to DVR serial port.
  • Page 63: Event Setup

    OSHD-410H & OSHD-810 & OSHD-1610 6.4. Event Setup MENU  EVENT  EVENT There are 5 items such as event, Text, Sync Event, Preset and System event 6.4.1. Event Check There are 3 items – Always, not apply, Timezone. “Always” option works always with event and “Custom” works with scheduled event. In case of Timezone, user can configure event per weekday/time.
  • Page 64: Relay 1~4

    OSHD-410H & OSHD-810 & OSHD-1610 Selecting Event Action Notification There are 7 actions – relay 1 to 4, buzz, E-Mail, FTP, & Twitter Action Notification Duration Duration Time starts with relay and buzzer setup and the notification alert will be active within the duration time set by the user.
  • Page 65: Ftp Image Backup

    OSHD-410H & OSHD-810 & OSHD-1610 E-Mail Address Input E-mail address with receiver’s E-mail information. E-mail format should be xxxx@xxxxxx.xxx and the users must only use combination of numbers and the English alphabet. Sender’s E-mail address Sender’s E-mail address is set when user use E-mail for output selection and user setup E-mail address as xxxx@xxxxxx.xxx.
  • Page 66: Twitter Synchronization

    OSHD-410H & OSHD-810 & OSHD-1610 It makes FTP function On or Off. To use FTP sending function, select ‘Normal Event’. Since FTP just transmit image, if there is no image system event, it is not supported. Server URL Enter the FTP server address to send image.
  • Page 67 OSHD-410H & OSHD-810 & OSHD-1610 1) Configure E-mail account to receive URL in E-Mail Setup. 2) Turn “ON” Forward URL with e-mail. 3) Select Generate PIN and run. 4) URL is output on the screen bottom and same URL is transmitted to the configured E-mail. (I don’t understand.)
  • Page 68: Motion Detection

    OSHD-410H & OSHD-810 & OSHD-1610 6.4.3. Motion Detection MENU  EVENT  MOTION The Motion detection can be used to notify user of detected motion on each channel or all channel. Channel Configure All or each channel. Sensitivity Sensitivity can be configured from min.1 to max 10.
  • Page 69: Sensor

    OSHD-410H & OSHD-810 & OSHD-1610 6.4.4. Sensor MENU  EVENT  SENSOR This menu is to setup the existing sensor input and the type of sensors. Users can configure sensor by each channel. If sensor is selected as All, N.O, or N.C. it is applied to all channels. Users can set different options like N.O, N.C, or Off after selecting each...
  • Page 70: Manual Recording

    OSHD-410H & OSHD-810 & OSHD-1610 6.5.1.1. Manual Recording Only in manual & event recording, manual recording runs and when pressing [REC] button, recording starts. If user wants schedule recording, recording mode should be Schedule & Event. 6.5.1.2. Continuous Recording Continuous and event recording mode is set to operate only after the system booting is complete.
  • Page 71: Event Recording Setup

    OSHD-410H & OSHD-810 & OSHD-1610 If selecting recording start time and end time on the table by mouse, its item, weekday,program will be displayed. Copy to All Days Select itmes in weekday and click Copy to All days button. Deletion Select items and click Delete button If clicking delete button without item, previously selected item will be deleted from the latest time order.
  • Page 72 OSHD-410H & OSHD-810 & OSHD-1610 Using [Program], adjust frame rate and quality configure recording program for Continuous&Event, Manual&Event, and Schedule&Event.. Select Program to configure frame rate & resolution. For maximum performance, user can freely allocate the recording resource per channel. This feature enables the user to lower the...
  • Page 73: Web Viewer

    OSHD-410H & OSHD-810 & OSHD-1610 Web Viewer WebViewer is Web application program loaded to monitor real-time image or to monitor the images recorded through Web browser to PC located remotely. 7.1. System requirement Minimum Recommendation Core2Duo / 2.0Ghz Quad Core / 2.6GHz...
  • Page 74: Monitor

    OSHD-410H & OSHD-810 & OSHD-1610 Authority configuration is almost all the same in DVR and Control Center. But quick recording, backup, audio, yes or no of using channel are only possible in Control Center. 7.5. Monitor When it is authorized with User ID & Password input at Login page, it moves to monitor page.
  • Page 75: Move To Playback

    OSHD-410H & OSHD-810 & OSHD-1610 Double click on one of the playback screen to convert in 1 channel mode After conversion to 1channel mode, double click on screen to return to previous division channels. At division screen, it can change screen location using mouse drag If Ch3 image moves to Ch1, drag Ch3 image and drop on Ch1 location so as to exchange between 3ch and 1ch image.
  • Page 76: Using Microphone

    OSHD-410H & OSHD-810 & OSHD-1610 Not activated Relay button means, the product is no supported. Relay is need user’s authority. Refer to user manual in the unit for the setup of User’s authority of Relay. 7.5.6. Using Microphone It can On or Off the use microphone. Default is Off and it is changed from the projected type button to orange when click the button for the use Mic.
  • Page 77: Saving Video

    OSHD-410H & OSHD-810 & OSHD-1610 7.5.8.2. Saving Video There are 3 types for saving Video - jpg, bmp, eye, saving means the function to record 1 frame of current monitoring channel. To save video, select the channel and click right button of mouse. and select “Save As” and point out the location and press Save button.
  • Page 78: Using Audio

    OSHD-410H & OSHD-810 & OSHD-1610 7.5.10. Using Audio In case of Channel setup sync with Audio, press right mouse button on the image to activate pop-up menu to “Listen” and uncheck Mute. Audio Volue adjustment is available using slide bar.
  • Page 79: Print

    OSHD-410H & OSHD-810 & OSHD-1610 It can save playback image to BMP file. Click mouse to channel to save. Dotted line will be surrounding to the selected channel, and click ‘Save’ button Save imamge dialog box appears, then it can input message or select channel name, date, event and data.
  • Page 80: Saving Time & Checking Rec, Capacity

    OSHD-410H & OSHD-810 & OSHD-1610 7.6.7. Saving time & Checking Rec, Capacity It indicates total capacity of HDD & remains and shows Starting date & Last date of recording. Also it shows percentage (%) for HDD capacity. 7.6.8. Calendar Search Recorded date is enabled in black color, and others unrecorded date disabled in grey.
  • Page 81: Java Viewer

    OSHD-410H & OSHD-810 & OSHD-1610 7.7. JAVA Viewer Java viewer is a web viewer to use in Java. Java should be installed in login screen to use Java viewer. After an installation of Java manually, select “Java” in below of Password window and login.
  • Page 82: Appendix

    OSHD-410H & OSHD-810 & OSHD-1610 8. Appendix 8.1. Trouble Shooting [FAQ] Trouble & symptom Way to Solve  No system power and LED in front Check the power of system panel doesn’t work at all  Check power voltage in out Check or replace power supply if power doesn’t turn on after...
  • Page 83 OSHD-410H & OSHD-810 & OSHD-1610  Check if connected protocol and other configuration is set No response in Live screen even [PTZ] button is pressed. correctly for PTZ camera in Menu -> Network -> Remote Device  External HDDs are not recognized as It takes time to be recognized multiple external HDDs.
  • Page 84: Compatible Hdd

    OSHD-410H & OSHD-810 & OSHD-1610 size will become high accordingly so HDD capacity will be reduced too. It will lead to short period time of recording. 8.2. Compatible HDD Please ask to seller about HDD compatible with DVR. 8.3. Compatible CD/DVD list...
  • Page 85: Factory Default

    OSHD-410H & OSHD-810 & OSHD-1610 8.4. Factory Default System Time Zone UTC 00:00 Dublin Daylight Saving NTP Function Sync With NTP NTP Mode Client Date / Time NTP Server Loc. Public NTP Local Server IP 0.0.0.0 Interval 1(hour) Date Format...
  • Page 86 OSHD-410H & OSHD-810 & OSHD-1610 DNS Server >> Port CIF, 30fps, Q5 CIF, 30fps, Q5 CIF, 30fps, Q5 CIF, 30fps, Q5 Network Stream CIF, 30fps, Q5 CIF, 30fps, Q5 CIF, 30fps, Q5 CIF, 30fps, Q5 Band Width Limit(Mbps) User ID...
  • Page 87 OSHD-410H & OSHD-810 & OSHD-1610 Audio Gain Audio Mix Mix On Recording Sync Test With Device Manual Seek Header Text Header 1 Header1 Header 2 Header2 Delimiter 0D0A Timeout(ms) 1000 Lines Serial Port Com1 Device None Interface RS232 Serial Baud Rate...
  • Page 88: Reset Value For Recording Program

    OSHD-410H & OSHD-810 & OSHD-1610 Event Input Res 720p30 Rec. Res 720p Frame Rate All 15 Quality All Q5 8.4.1. Reset value for Recording Program Rec. mode Normal Event Item Rec. Res Rec. Res 1080p/720p Q7/Q5 1080p/720p Q7/Q5 1080p/720p Q7/Q5...
  • Page 89: Menu Structure

    OSHD-410H & OSHD-810 & OSHD-1610 8.5. Menu Structure System Date/Time Time zone Standard Time zone Daylight Saving (DST) Time Setting Time Date Format Disk Recording Overwrite Disk Full Alarm Warning Playback Block Playback Block Recording Management Disk Manager Disk Status...
  • Page 90 OSHD-410H & OSHD-810 & OSHD-1610 Interval Connection Information Group Status Radius Connection Information Status IP Address Port Device Camera Channel Number Status Name Input Resolution Monitor Event Pop-up Info Sequence Configuration Audio Audio Input Audio Channel Audio Recording Sync Video Channel...
  • Page 91: Specification

    OSHD-410H & OSHD-810 & OSHD-1610 Sensor Sensor Preset Channel Number Preset Record Record Record Mode Record Mode Program Event Duration Pre Event Duration Post Event Duration Program Program Current Total Data Rate 8.6. Specification OSHD-410H OSHD-810 OSHD-1610 Video input Video input standard...
  • Page 92 OSHD-410H & OSHD-810 & OSHD-1610 Block Playback 24 hours ~ 31days Event & Alarm Event source MD, Sensor, Text Event check schedule 24hrs / 7day Event Action Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up MD Area 22x15 Sensor input dry contact (N.O. or N.C. selectable)
  • Page 93 OSHD-410H & OSHD-810 & OSHD-1610 Serial & I/O Serial port 1 RS-232C, 2 RS-485 Sensor input 4 dry-contact 8 dry-contact 16 dry-contact Relay output 4 relay Controller Device Front panel, IR remote, Joystick KBD, Mouse Software WebViewer Monitoring / Event / PTZ / Playback with IE...
  • Page 94: Product Dimension

    OSHD-410H & OSHD-810 & OSHD-1610 8.7. Product Dimension Install & User Manual - Firmware 3.X...
  • Page 95 OSHD-410H & OSHD-810 & OSHD-1610 Install & User Manual - Firmware 3.X...
