OSD-400/OSD-800/OSD-1600
Digital Video Recorder
Installation / User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSD-400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Orion OSD-400

Summary of Contents for Orion OSD-400

  • Page 1 OSD-400/OSD-800/OSD-1600 Digital Video Recorder Installation / User Manual...

  • Page 2: Important Notice

    When installing product, be cautious to locate on safe places where children are unreachable. 8. If Product does not operate properly, please contact the closest Orion distributor for after sales service. Tampering or disassembling the product will void the warranty.
  • Page 3 OSD-400/OSD-800/OSD-1600 10. Rack Mount Instructions - The following or similar rack-mount instructions are included with the installation instructions: 11. Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 4: Table Of Contents

    OSD-400/OSD-800/OSD-1600 Contents KEY FEATURES ........................... 8 INSTALL MANUAL ........................11 FEATURE ..........................11 Supplied Accessories ....................11 Description & Function ....................12 1.2.1 Front .......................... 12 1.2.2 REAR ........................13 1.2.3 REMOTE CONTROLLER ..................14 INSTALLATION ........................16 Installation and Connection................... 16 2.1.1...
  • Page 5 OSD-400/OSD-800/OSD-1600 2.3.3 Connecting and configuring sensor ................27 2.3.3.1 Specification ......................27 2.3.3.2 Connecting relay and setting ................. 28 2.3.3.3 Connecting serial port .................... 29 2.3.3.4 Connection to external device via Serial port ............32 2.3.3.5 USB Device Connection ..................34 2.3.3.6...
  • Page 6 OSD-400/OSD-800/OSD-1600 4.9.5 Auxiliary On ....................... 52 4.9.6 Auxiliary Off ....................... 52 4.9.7 Menu.......................... 53 PLAYBACK ........................... 54 Playback Mode ......................54 5.1.1 Playback on Standard monitor (16 / 9 division) ............54 5.1.2 Playback function ...................... 54 Search Mode ......................... 54 5.2.1...
  • Page 7 OSD-400/OSD-800/OSD-1600 6.4.1.5 Brightness/Contrast ....................79 6.4.1.6 Privacy ........................79 6.4.2 Monitor Setup ......................80 6.4.3 Audio Setup ....................... 81 6.4.4 Text Setup ......................... 82 6.4.5 Serial Setup ....................... 84 6.4.5.1 PTZ Setup ......................84 Event Setup ........................85 6.5.1 Event Check ......................85 6.5.2...
  • Page 8 OSD-400/OSD-800/OSD-1600 7.5.11 Closing Video Channel .................... 108 Playback........................109 7.6.1 Video Division & Changing Channel ............... 109 7.6.2 Image recording ...................... 109 7.6.3 Printing ........................110 7.6.4 Backup ........................110 7.6.5 Web Monitor ......................110 7.6.6 Channel On/Off ......................111 7.6.7...

  • Page 9: Key Features

    OSD-400: 1/4 channel mode Auto Switching OSD-1600: Composite x 2, VGA x 1 OSD-800: Composite x 2, VGA x 1 OSD-400: Composite x 2, VGA x 1 Audio Recording Supports real-time audio input and recording Simultaneous 4ch audio input & recording available...
  • Page 10 OSD-400/OSD-800/OSD-1600 H.264 Video recording with High-Quality OSD-1600: CIF(360x240) 400ips OSD-800: 2CIF(360x240) 240ips OSD-400: 4CIF(360x240) 100ips Supprots manual & schedule recording Video loss detection Supprots archiving event list event (Sensor, Video Loss, Motion detection, Text) Available record Max 5 seconds before triggering an event per each channel Search/ Playback It supports variable and convenient functions for search &...
  • Page 11 OSD-400/OSD-800/OSD-1600 E-mail notification through TCP/IP, DHCP in case of triggering an event Live monitoring form remote site (Whole screen or available to select quad screen) Available to playback, recording, search and DVR management through network viewer in PC. Available to record, search & playback by time from remote site.

  • Page 12: Install Manual

    OSD-400/OSD-800/OSD-1600 Install Manual 1 Feature 1.1 Supplied Accessories Unpack and check all the items as below Install & User Manual - Firmware 3.X...

  • Page 13: Description & Function

    OSD-400/OSD-800/OSD-1600 1.2 Description & Function 1.2.1 Front Item Description DVD-Multi (For Back up use for recorded data by DVD/CD media Back up) Channel Button To select video input channel STEP function control, Playback direction change, Jog/ Shuttle Playback speed control...

  • Page 14: Rear

    Input/ Output name Description Power connector Socket for AC100V~AC240V power cord CH1~16(8/4) BNC input for camera connection OSD-1600: 16EA, OSD-800: 8EA, OSD-400: 4EA Loop out BNC output(Loop) for camera connection Monitor/ Spot BNC connection for monitor output Audio Input(RCA) RCA connection for Audio input...

  • Page 15: Remote Controller

    OSD-400/OSD-800/OSD-1600 Input/ Output name Description VGA OUTPUT Output for PC connection Termination Ohm Termination Ohm for Com2, Com3 Relay/Serial Connection for Relay and Serial(RS-485) Sensor IN Input for external sensor eSATA External device connection (eSATA) 1.2.3 REMOTE CONTROLLER It is available to use all functions of DVR. If several DVR are set with unique ID numbers, they can be controlled with one remote controller.
  • Page 16 OSD-400/OSD-800/OSD-1600 COPY To indicate copy menu, copy recorded data to USB BACKUP Not use RELAY ON To manually ON RELAY OFF To manually OFF Auto sequencing MULTI To change division ZOOM To run digital zoom SEARCH To indicate search menu...

  • Page 17: Installation

    OSD-400/OSD-800/OSD-1600 Installation 2.1 Installation and Connection 2.1.1 Connecting & Running 2.1.1.1 Connecting camera Connect CCTV camera to DVR with BNC cable as below The video type for all channels should be either NTSC or PAL, not be combined both •...

  • Page 18: Connecting Audio

    OSD-400/OSD-800/OSD-1600 2.1.1.3 Connecting Audio Connect audio signal to DVR with using RCA cable or D-SUB as below; 2.1.1.4 Supplying Power Connect power cable as below; When supplying power, DVR starts booting automatically. • In order to cut off power, press power switch on DVR front during 5 seconds, then select •...

  • Page 19: Running Osd Menu

    OSD-400/OSD-800/OSD-1600 2.2 Running OSD menu 2.2.1 OSD menu configuration Press [MENU] in keypad of front to open the main menu; Select one of menus to enter the configuration menu as below: Main Sub Menu Configuration 1. Main Menu: The selected tab is show in bright colour and the related sub-menu will be shown left- below the tab.

  • Page 20: Dialogue Box To Edit A Word

    OSD-400/OSD-800/OSD-1600 set with using [ ] or [▲/▼]. Press [ESC] button when the value is set and also [ESC] ◀ ▶ button is available to upper sub-menu. 2.2.1.1 Dialogue box to edit a word Dialogue box to edit a word is image shown as below; it is available to input both word and bumper.

  • Page 21: Selecting Id

    OSD-400/OSD-800/OSD-1600 <Reference> Up to 16DVRs can be controlled with a single remote controller. When not using remote controller, set the Remote Control ID as “Off” 2.2.2.2 Selecting ID If several DVRs are with unique ID numbers, they can be controller with one remote controller. To select a specific DVR, keep pressing the ID button of remote controller until a buzzer sounds during 2 seconds.

  • Page 22: Install Examples

    OSD-400/OSD-800/OSD-1600 2.2.3 Install examples 2.2.3.1 Basic configuration 2.2.3.2 Advanced configuration 2.2.3.3 External storage & Back up configuration Install & User Manual - Firmware 3.X...

  • Page 23: Internet/ Intranet Configuration

    OSD-400/OSD-800/OSD-1600 2.2.3.4 Internet/ Intranet configuration 2.2.4 Basic Setting 2.2.4.1 Viewing Image When power is on, DVR starts automatically and displayed in basic 16ch-split screen after booting. <Reference> If user password is set, a prompt for entering the password will be appeared. Factory default is reserved as not responding keypad on DVR front (It is not from factory default).

  • Page 24: Setting Date & Time

    OSD-400/OSD-800/OSD-1600 2.2.4.2 Setting Date & Time Press [MENU] button and select “ System” when OSD menu is appeared. • Select “Date/Time” and press [Enter] button. • Time Zone Select “Time Zone” using [ ] or [▲/▼] arrow button and press [Enter] button.
  • Page 25 OSD-400/OSD-800/OSD-1600 1. Select NTP Function 2. Select “Client or Server or Both” using [ ] or [▲/▼] arrow button and press [Enter] button. ◀ ▶ 3. Select “Public or Both” using [ ] arrow button and press [ESC] button ◀...

  • Page 26: Record Setting

    OSD-400/OSD-800/OSD-1600 2. Select using [ ] or [▲/▼] arrow button and select “YES”, then, press [ENTER] button. To ◀ ▶ cancel, press [ESC] button. 2.2.4.3 Record Setting Select “Record” pressing menu button in front. Program Setting Set resolution, frame rate, quality by each channel that user want record in “Program” of record menu.

  • Page 27: Connecting And Configuring Dio Ports

    OSD-400/OSD-800/OSD-1600 Schedule Setting Set recording mode as “Schedule & Event” and set by date/ time. Checking method for recording <Reference> If recording setting is finished correctly, “REC LED” in front is flickering. In addition, it is marked [S] indicating that all channels are recording.

  • Page 28: Inserting & Removing Wire

    2.3.3 Connecting and configuring sensor 2.3.3.1 Specification In order to run sensor input DVR normally, the following conditions are required. Input Ch 16EA Transistor input (OSD-1600) (OSD-800: 8EA, OSD-400: 4EA) Spec Input type N.C, N.O support Supported sensor Dry contact sensor...

  • Page 29: Connecting Relay And Setting

    OSD-400/OSD-800/OSD-1600 Setting Sensor 1. Press [Menu] button and select “Event” when OSD menu is appeared. 2. Move to sub menu pressing [Enter] or using [▼] button and select [Enter] All sensor It is used when setting for all sensors and set off, or Normal Open (N.O.) / Normal Close (N.C.) type.

  • Page 30: Connecting Serial Port

    OSD-400/OSD-800/OSD-1600 125V 0.5A Connecting relay out Connect R1 ~ R2 with referring to the following images, it shows to connect a warning light. Please refer the “Wire Handling”. Relay setting It is available to run relay selecting from sensor, motion detection, Video Loss which is normal event source and Disk error, Disk full, authentication fail, WRS registration fail which is system event source.
  • Page 31 OSD-400/OSD-800/OSD-1600 shows how to connect PTZ camera to RS485 (COM2). When using another serial port, connect it with referring to each connection diagram below. Please refer the “Wire Handling”. Serial communication port diagram COM1 Connection (RS-232) COM2/COM3 Connection (RS-485) Install & User Manual - Firmware 3.X...
  • Page 32 OSD-400/OSD-800/OSD-1600 Available PTZ is same as below table. Model name Manufacturer Webgate Keyboard KBD300A, WGI SPD1800/2600 Webgate WKC-100 keyboard Bosch BOSCH AutoDome, TC8560X-4 PELCO(P), PELCO(D) Pelco Honeywell 755/655, HRX-2000, ScanDome2 Honeywell Sony Sony EVI-D3x VT VPT-4x SDZ160/330, Samsung SPD, Samsung Techwin...

  • Page 33: Connection To External Device Via Serial Port

    OSD-400/OSD-800/OSD-1600 Tokina Tokina Kodicom KRE Kodicom Nuvico Nuvico Serial Setting You can setup both serial port and PTZ from remote menu under device menu. From serial setting, you can set protocol, port, baud rate, parity bit, stop bit and data bit.
  • Page 34 OSD-400/OSD-800/OSD-1600 Like above picture, connect COM1/RS232 (9pin D-Sub) in Device menu and configure Serial and Text. Serial (COM1) Setup 1. Select “Device” in OSD menu and move to sub menu. 2. Selecting COM1 and configure “Text” in Device 3. Setup the value of Baud Rate/Parity/Stop bit/Data bit with the device.

  • Page 35: Usb Device Connection

    OSD-400/OSD-800/OSD-1600 <Reference> Since external device cannot be recognized, before installing, please, ask to the shop. 2.3.3.5 USB Device Connection USB port is for the simple video copy (within 1 hour) on USB Flash memory. Its recommended specification is same as below.
  • Page 36 OSD-400/OSD-800/OSD-1600 Below and Set copy range Select Drive Execute Copy. [CD/DVD Copy] [RE4 Copy] Select the channel to copy Install & User Manual - Firmware 3.X...

  • Page 37: Video In/Out Connection

    OSD-400/OSD-800/OSD-1600 [AVI Copy] <Reference> A USB Flash memory which should install additional program on Windows OS, cannot be recognized. 2.3.3.6 Video In/Out connection Video Input/Output is Loop through and check the connectivity automatically and set end resistance. For instance, if connected by Video input, end resistance is configured by 75 and if Video in/output is same;...

  • Page 38: Hdd Registration And Format

    OSD-400/OSD-800/OSD-1600 2.3.4.1 HDD registration and format After mounting HDD and booting system, “Disk Manager” will execute automatically. If not, please, check the connectivity of HDD. 1. Press [Enter] button in “Disk Manager” 2. Using [▲/▼] Key, select new HDD(Displayed [No] on Enabled item) and press [Enter] 3.

  • Page 39: Remote Monitor And Control

    OSD-400/OSD-800/OSD-1600 key then you will see the pop-up message “This disk can be added without format/Nevertheless, do you want format this disk?” and select “NO” for re-use without format, and select “YES” for format. 2.3.5 Remote monitor and control Via Internet/Intranet, in remote site, user can access with PC.

  • Page 40: Network Configuration

    OSD-400/OSD-800/OSD-1600 2.3.5.2 Network configuration Ethernet Set type as Ethernet and input IP, Net mask, Gateway, DNS. The way to input is using directional key or mouse wheel. PPPoE Set type xDSL, and move to xDSL menu. First, change Ethernet Port Please, input ID and Password for PPPoE.

  • Page 41: External Device Connection

    OSD-400/OSD-800/OSD-1600 2.3.6 External device connection DVR has external 1 piece of eSATA port. Using eSATA port, user can expand Storage capacity up to 8TB. <Note> Since some of eSATA device can not be compatible with DVR, before the usage, please, contact the seller and check its compatibility in advance.

  • Page 42: User Manual

    OSD-400/OSD-800/OSD-1600 User Manual 3 Menu Use 3.1 Menu Structure The menu structure will be shown like below image, and each menu setting method described from chapter 4 to chapter 6. 3.2 Function Menu The Function menu can be controlled by mouse.

  • Page 43: Factory Reset

    OSD-400/OSD-800/OSD-1600 Function of Playback 3.3 Factory Reset In order to reset value to factory value, go to System Setting->System->Setting, and once press Factory Reset then the warning message will be appear, click “Yes” to reset the DVR value to factory.
  • Page 44 OSD-400/OSD-800/OSD-1600 User No Password used Setup DVR Alias DVR0 DVR Keyboard ID Remote Controller Utility Language English Firmware Update >> System Log >> Factory Reset >> Network Type Ethernet DHCP IP address Default IP Net Mask Default Net Mask Gateway...
  • Page 45 OSD-400/OSD-800/OSD-1600 Contrast PTZ Home PTZ Idle Time PTZ Port None PTZ Address Monitor Alarm Pop-up(Sec) User Sequence << Configuration Monitor SEQ Time(Sec) Covert >> Multi Mode 4E, >> VGA Mode 800x600@56Hz Info Level >> Audio Channel Audio Recording Audio Audio Gain...
  • Page 46 OSD-400/OSD-800/OSD-1600 Event Event Check Always Event Action Relay1 Action Duration 10 Sec Event Normal Event >> Source System Event >> Source Motion Sensitivity Area Set All Sensor Sensor All, N.O. Channel Number Preset Preset Sensor1, Preset1 Record Record Mode Manual & Event...
  • Page 47 OSD-400/OSD-800/OSD-1600 4CIF 4CIF 4CIF 4CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF 2CIF Install & User Manual - Firmware 3.X...

  • Page 48: Monitoring

    Press [MULTI] button every time, screen mode is changed to 4A, 4B, 4C, 4E, 9A, 9B, 10A, 16 channel division. (OSD- 800: 4E, OSD-400: not supported). 4.4 Screen Description The status bar from monitoring screen, it shows DVR’s current status that included Date/Time, Record, Motion/Sensor Detection, Manual Record, Text input and HDD’s record capacity.

  • Page 49: System Standard Mode

    OSD-400/OSD-800/OSD-1600 4.5.1 System Standard Mode By [Auto] button, it can monitor auto switching of all channels. Press [MENU] for the setting switching term or using mouse click menu icon from function menu. Move to “Device” “Monitor” from OSD menu. Select “Seq. Switching(sec)” and set value from 1 sec. to 60 sec. At OFF set, auto switch mode does not operate.

  • Page 50: Event Screen

    OSD-400/OSD-800/OSD-1600 User mode can define to max. 16 channel. As shown above picture, the 16ch DVR can be define between channel 1~16, the 8ch DVR from 1~8 and the 4ch DVR from 1~4. 4.6 Event Screen When there is an event occurred, the green colour [M] and red colour [S] will be display from status bar.

  • Page 51: Zoom Screen Mode

    OSD-400/OSD-800/OSD-1600 4.7 Zoom Screen Mode From single full screen mode, press [FUNC] • D-Zoom button then select + button to activate zooming the image. • Default zoom screen locates to main centre when press [ZOOM] button. Zoom image can •...
  • Page 52 OSD-400/OSD-800/OSD-1600 Below lists are protocols available in DVR Model name Manufacturer Keyboard KBD300A, WGI SPD1800/2600 Webgate Webgate WKC-100 keyboard Bosch BOSCH AutoDome, TC8560X-4 Pelco PELCO(P), PELCO(D) Honeywell Honeywell 755/655, HRX-2000, ScanDome2 Sony Sony EVI-D3x VT VPT-4x SDZ160/330, Samsung SPD, Samsung Techwin...

  • Page 53: Pan/Tilt

    OSD-400/OSD-800/OSD-1600 Press desired channel button. • Press PTZ button from front panel or click PTZ icon from function menu with mouse. • PTZ menu (Pan/Tilt, Zoom/Focus, Load Preset, Save Preset) will be appear. • Then press [Enter] button or click from mouse.

  • Page 54: Menu

    OSD-400/OSD-800/OSD-1600 Using up / down button or mouse wheel to select the Aux Number. • Select Off and press Enter button or click from mouse. • 4.9.7 Menu It is to go into connected PTZ’s menu, using up/down/left/right and enter key from front panel for setting the menu, and press ESC button for exit the menu.

  • Page 55: Playback

    OSD-400/OSD-800/OSD-1600 5 Playback 5.1 Playback Mode 5.1.1 Playback on Standard monitor (16 / 9 division) Push play button in monitoring mode or mouse click play button in Function menu. • If pushing Play button or FWD button, video playbacks in forward direction at 1×speed.

  • Page 56: Time Search

    OSD-400/OSD-800/OSD-1600 There are Time, Calendar, Event, Thumbnail mode. Please, push Search button on the front panel or click in Function menu. 5.2.1 Time Search Select date and time to search and playback video will be moved to the selected point.

  • Page 57: Event Search

    Event Channel Select the channel for search OSD-1600: from Ch1 to Ch16 OSD-800 from Ch1 to Ch8 OSD-400 from Ch1 to Ch4 Event Type Select the event type for search There are all events, motion detection, sensor, video loss, text type...

  • Page 58: Thumbnail Search

    OSD-400/OSD-800/OSD-1600 5.2.4 Thumbnail Search Search certain channel by thumbnail type. If select the searched thumbnail, selected date and time video will be played back. Channel Select the channel and change the value by direction key or mouse wheel. Input the date and time for starting search and change the value using Start Time up-down direction key or mouse wheel.

  • Page 59: Copy

    OSD-400/OSD-800/OSD-1600 5.3 Copy This is for copying recorded video. There are CD/DVD and RE4 and AVI type. Copy function is supported to be used by user who has the authorization. For authority configuration, please, refer to 6.9.3 Security. To use copy function, press [COPY] or Click Copy button in Function menu.

  • Page 60: Re4

    OSD-400/OSD-800/OSD-1600 Select Disk Select the media to copy using Enter button on Select Disk. Start Start Copy. Press Start button with Enter or click the left button of the mouse. FAT32 format Format USB memory or HDD by FAT32 type.

  • Page 61: Avi

    OSD-400/OSD-800/OSD-1600 [OSD-1600] Type Select RE4 using up-down button or mouse wheel. To pop up the channel selection window, press Enter or use mouse Channel wheel. Select Channel Use can select some or all channels and after selecting channel, press Enter or click mouse left button.
  • Page 62 OSD-400/OSD-800/OSD-1600 Type Select AVI using up-down key or mouse wheel. Channel Select the channel to copy by up-down key or mouse wheel. From Set start date and time to copy. Time and Year by left/right button and date/time by up/down button. With mouse, click left button first and use wheel.

  • Page 63: Configuration

    OSD-400/OSD-800/OSD-1600 6 Configuration 6.1 Recording Structure There are 4 modes in DVR recording. Configuration relation structure is like below. Please, refer to the below each item for detailed recording configuration. 6.2 System Setup Time and Disk and authority can be configured.

  • Page 64: Time Setup

    OSD-400/OSD-800/OSD-1600 6.2.1.1 Time Setup Caution: under recording, if user changes Time, it will affect time change on previously recorded video data in accordance with. Therefore, we recommend backup before time change. Press Main Menu of Function or [MENU] button on the front panel.

  • Page 65: Ntp Setup

    OSD-400/OSD-800/OSD-1600 <Caution> Except date/time configuration, other configuration records automatically, but “date/time” configuration influences critical effect to HDD recording file system, It doesn’t record automatically. To apply the changed value, user must press [apply] button. 6.2.1.2 NTP Setup NTP (Network Time Protocol) make time of connected devices synchronized. There are NTP server and client which get time signal from the server.

  • Page 66: Disk

    OSD-400/OSD-800/OSD-1600 NTP Mode Configure NTP mode of DVR – Client / Server / All NTP Server Loc. When NTP mode is client, it is on Enable. Configure yes or no whether NTP server is in Local Network or Public. NTP Local server IP In NTP local server Enable, configure server IP.

  • Page 67: Disk Manager

    OSD-400/OSD-800/OSD-1600 Block Playback This function makes recording data seen during the limited area. For instance, if setting block playback by 2 day (Drawing 2) among 10 days, Just allowed 2 days data can be played back. Block Recording This option is to record only the date you selected.

  • Page 68: Disk Status

    OSD-400/OSD-800/OSD-1600 Bad Block Display bad block. In HDD. If no problem, “0” will be displayed. Others are Not shown anything at all. Size Display HDD size by MB unit Enabled Make HDD enable mode or disable mode. Yes: enable / No: Disable In case HDD YES Enabled: Press [Enter] in No mode or scroll mouse wheel.

  • Page 69: User Setup

    OSD-400/OSD-800/OSD-1600 6.2.3 User Setup There is administrator and user and administrator can use all functions. The max. number of user is 10 person. Each user can use the function allowed. Check If Check item is configured all by X [Check-1], all users can use all functions.
  • Page 70 OSD-400/OSD-800/OSD-1600 Password change Select user Input password and press change Press Yes Password input box is displayed. Password can be input with front figure button or text input window. After inputting 8 digit figure, click “Change” button. After that, message pop up window will be shown and press “Yes”.

  • Page 71: Utility

    OSD-400/OSD-800/OSD-1600 6.2.4 Utility Configure the name of DVR, remote controller ID, Language. DVR Alias Set the name of DVR. DVR Keyboard ID This menu is to set the address of keyboard when using all functions of DVR by keyboard. Factory default is “1”.
  • Page 72 OSD-400/OSD-800/OSD-1600 Firmware Update Firmware can be updated by USB Memory. Insert USB memory to USB port. • Press Firmware Update button. • Select [YES] on the pop up window. • System will reboot. • Firmware update is done. • System Log System Log shows boot status of system and user and configuration etc.
  • Page 73 OSD-400/OSD-800/OSD-1600 Factory Reset Change all configuration value by factory default. Caution: Only administrator is allowed. Config Import/Export This function can allow user to save the configuration DVR by USB, and can export its value to other DVR. Config Export can save the configuration value of DVR by USB.
  • Page 74 OSD-400/OSD-800/OSD-1600 Config Import menu can import the configuration value of the saved DVR. Insert USB memory which containing Export configuration data to USB port of the DVR, click import button on Config Import/Export menu. All relevant configuration value will be updated to the DVR at once.

  • Page 75: Network

    OSD-400/OSD-800/OSD-1600 System Information Display recording status and system configuration of DVR Caution: This function is allowed only for system administrator. 6.3 Network This is menu for configuring network. Type Configure type of Network (Ethernet/xDSL). If connected to cable modem or Lan directly to DVR, configure by “Ethernet”.

  • Page 76: Xdsl

    OSD-400/OSD-800/OSD-1600 temporary. If LAN has DHCP server and it is active, DHCP server allocate IP address to DVR. IP Address IP Address is for the connection between DVR and Control Centre and also for web connection from Webviewer. (But, Net Mask, Gateway should be configured.) Net Mask Net Mask makes range of available IP address.

  • Page 77: Wrs

    OSD-400/OSD-800/OSD-1600 User ID/Password Configure user ID and Password. Status It shows connection status of DVR. 6.3.2 WRS If DVR is connected to Cable modem or xDSL modem, IP address is changed at every connection to ISP. In this case, changed IP address cannot be known. If DVR using static IP register into WRS server, changed IP address can be known easily when it connects to DVR.

  • Page 78: Radius

    OSD-400/OSD-800/OSD-1600 WRS URL This menu is to set server address to register. WRS addresses that Orion Technology operates now are www.orion-technology.dk or mycam.to. 6.3.3 Radius It makes to manage account information from several different DVRs to one account using Radius server (e.g.

  • Page 79: Camera Setup

    OSD-400/OSD-800/OSD-1600 6.4.1 Camera Setup Select the camera to configure in Channel menu. Select Status Off (disable) or On (enable) 6.4.1.1 Title Configure camera name. If pressing [Enter] button or click mouse, test menu will be shown. For text string, text input box will be shown.

  • Page 80: Ptz

    OSD-400/OSD-800/OSD-1600 6.4.1.3 PTZ In the PTZ menu it is possible to configure the PTZ communication. PTZ-Home go - to Home Preset (on or off). • PTZ Idle Time - select a value between 5 and 60 sec. • PTZ Port - select which Serial port and Protocol the camera is using.

  • Page 81: Monitor Setup

    OSD-400/OSD-800/OSD-1600 With direction key, select area and press [Enter] or click mouse. And press “ESC” button or click right mouse button, shift to the previous menu. Exit the menu and save changes. Then enter the Privacy again the privacy areal is yellow.

  • Page 82: Audio Setup

    60seconds. Multi mode OSD-1600 has 3 predefined screen modes. 4C (4channels), 9C(basic 7 channels and additional 2 channels),10C(10 channels). In case of OSD-800, it can use only 4C(4channels) and OSD-400 doesn’t provide multi mode. The way to composing The way to compose screen is selecting the target and after selecting right window and press [Enter] button or use mouse.

  • Page 83: Text Setup

    OSD-400/OSD-800/OSD-1600 Voice Channel Select audio to use Recording Configure yes or no of using audio recording. If no, audio will be out only in live view and if yes, Audio will be out in both view modes. Volume Configure volume by +, - direction Synchronize Video Channel Configure which channel is matched with the input audio.
  • Page 84 OSD-400/OSD-800/OSD-1600 Recording Set On/Off of recording against Text input Sync Text with Select channel to synchronize with text. Header check There is a various types of data input from the external device (Access Control, POS, ATM etc). Like the “Star Finger 007” protocol. If the device has implemented the protocol, it is just to connect the device to the OSD.

  • Page 85: Serial Setup

    OSD-400/OSD-800/OSD-1600 shorter than other ATM users. It is to decide the last line of the one data register as final complete data to save after an hour’s consideration of register later because DVR can not recognize it automatically. Lines Define how many lines will be shown.

  • Page 86: Event Setup

    OSD-400/OSD-800/OSD-1600 PTZ Home Shift to Preset assigned, if it has no movement in certain time while PTZ control. PTZ Idle Time If it has no movement during configured time, shift to PTZ Home. PTZ Port Select Port for PTZ PTZ Address Configure the address configured in PTZ.
  • Page 87 OSD-400/OSD-800/OSD-1600 In case of Custom, with similar configuration window like schedule, user can configure event per weekday/time. INDEX: Schedule configuration from 1 to 50 • Weekday • Time • Delete: delete INDEX • How to configure If configuring INDEX, weekday, time, they are displayed on the table.

  • Page 88: Sync Event

    OSD-400/OSD-800/OSD-1600 6.5.2 Sync Event Configuration for the Event synchronization. Event Action There are 7 actions – relay 1 to 4, buzz, E-Mail, FTP. Action Duration Action Duration runs if relay and buzz are configured, and goes on during the configured time. E-mail works by configured time interval.
  • Page 89 OSD-400/OSD-800/OSD-1600 System Event source System Event source can configure Bad block, Disk full, Fan error, authorization failure, WRS registration failure. E-Mail There are two ways for E-mail transmission – SMTP server authentication and non-authentication. Install & User Manual - Firmware 3.X...
  • Page 90 OSD-400/OSD-800/OSD-1600 USE (SMTP-Auth) If user selects Authentication in USE, SMTP-Auth function will work. SMTP-Auth method is the way that E-mail will be authorized by SMTP server and then it will be transmitted to receiver. E-Mail Address Input E-mail address of receiver.
  • Page 91 OSD-400/OSD-800/OSD-1600 Input E-mail address of receiver. Sender Address Not mandatory but necessary for receiver to find out which DVR sends event. Authentication Select NOT USE. Including Picture In general event, when sensor, MD, V-loss events are generated, the event information and channel video will be sent to e-mail together.
  • Page 92 OSD-400/OSD-800/OSD-1600 Server URL Input FTP server address. User ID Input ID information for FTP server Password Input Password for FTP server access. FTP Directory Please, configure the saving location of FTP server. If user does not configure any directory value for saving, Image will be saved as default route.

  • Page 93: Motion Detection

    OSD-400/OSD-800/OSD-1600 6.5.3 Motion Detection Channel All or certain channel. Sensitivity Sensitivity can be configured from min.1 to max 10. Area Select detection area. User can select all or certain channel. User Area When selecting per channel, it can be configured.

  • Page 94: Sensor

    6.5.4 Sensor This menu is to setup the existing sensor input and type of sensor. OSD-1600 has 16 input and OSD-800 has 8 input and OSD-400 has 4 input. Sensor has 2 types, Normal Open (N.O.) and Normal Close (N.C.).

  • Page 95: Recording Setup

    OSD-400/OSD-800/OSD-1600 6.6 Recording setup There are 3 mode for recording – schedule recording, manual recording, event recording. Schedule recording; records according to the configured schedule. And manual recording records via pushing “REC” button and event recording records when events are on.
  • Page 96 OSD-400/OSD-800/OSD-1600 Q (Quality) There are 5 recording quality - Q5/Q4/Q3/Q2/Q1. Recommended quality for event recording is Q3. Max R/F Max R/F shows the number of frame available according to the selected resolution. For instance, if it is set by 30fps at CIF, it means that the channel can record up to 30frame at CIF resolution.

  • Page 97: Manual/Schedule Recording Setup

    OSD-400/OSD-800/OSD-1600 6.6.2 Manual/Schedule recording setup With the change of recording mode, manual recording or schedule recording can be at one’s choice. And their resolution, frame rate, quality will be in accordance with the program. 6.6.2.1 Manual Recording Only in "Manual & Event" recording, manual recording works, when pressing [REC] button, the recording starts.
  • Page 98 OSD-400/OSD-800/OSD-1600 Check and select each program default value and select one of 26 programs from A to Z or several programs. Below picture show program B. INDEX: Schedule unit from 1 to 50 • Weekday: Set the day applicable •...

  • Page 99: Event Recording Setup

    OSD-400/OSD-800/OSD-1600 If clicking delete button without INDEX, previously selected INDEX will be deleted first and after that, from the largest INDEX in order. Edition Select INDEX to edit and change weekday, program, time directly. In case that INDEX 50 are all configured, select the time zone to change by mouse click and click the time again, pervious configuration will be deleted and new configuration will be shown.
  • Page 100 OSD-400/OSD-800/OSD-1600 1. Select one of “Manual & Event” or “Schedule & Event”. 2. In program configuration, set frame rate by 0 fps in “Normal mode” and only configure Event frame rate. 3. Set Schedule. Schedule configuration Configure schedule for event recording and there are 2 modes – Always and Custom.
  • Page 101 OSD-400/OSD-800/OSD-1600 Select recording start time and end time in order and its INDEX, weekday, time will be shown. Deletion Select INDEX and click Delete button If clicking delete button without INDEX, previously selected INDEX will be deleted first and after that, from the largest INDEX in order.

  • Page 102: Web Viewer Activex

    OSD-400/OSD-800/OSD-1600 7 Web Viewer ActiveX WebViewer is Web application program loaded to monitor real-time image or to monitor the images recorded through Web browser to PC located remotely. WebViewer is divided into Login page and Monitor to do monitoring real-time images, Playback to replay recorded images.

  • Page 103: Osd-400/Osd-800/Osd

    OSD-400/OSD-800/OSD-1600 Input the set of User ID & Password; click ‘LOGIN’ to access. Select either Java or ActiveX on the login screen If didn’t change the password in Control Center, ID and Password will be admin/12345. ID can not be changed.

  • Page 104: Browser Available

    OSD-400/OSD-800/OSD-1600 7.4 Browser available WebViewer is optimized to Windows Internet Explorer 6.0 or higher in PC for smooth use. WebViewer Installer Login page provides manual installation program to use WebViewer function. PC that access to WebViewer WebViewer first installs ActiveX to use WebViewer’s function. At this time when installation is not smooth, installation program needs to download from Login Page and install manually.

  • Page 105: Move To Playback

    OSD-400/OSD-800/OSD-1600 Double click on one of the playback screen to convert in 1 channel mode. After conversion to 1 channel mode, double click on screen to return to previous division channels. At division screen, it can change screen location. If 3 channel image moves to 6ch, drag 3ch image and drop on 6ch location so as to exchange between 3ch and 6ch image 7.5.2 Move to Playback...

  • Page 106: Channel On/Off

    OSD-400/OSD-800/OSD-1600 7.5.3 Channel On/Off It is On/Off button for the Channel located to left in page. Click the channel wanted to On or Off. And Default is On. 7.5.4 Sensor Indication The icon indicates when sensor occurs in system When it sensored, relevant sensor icon comes to Red, and indicates sensor number of video.

  • Page 107: Event Data

    OSD-400/OSD-800/OSD-1600 7.5.7 Event data It shows real time event data occurred at the bottom of monitoring page. Indicated Event data list are as follow.. (Table. Event Icon) Button Function Motion Detect On Sensor Input Relay Output On No Video, Video Detected 7.5.8 Video Recording &...

  • Page 108: Using Ptz

    OSD-400/OSD-800/OSD-1600 To save video, select the channel and click right button of mouse. Then select “Save As” and point out the location and press “Save” button. 7.5.9 Using PTZ Among the icon on top of video on monitoring, click ‘PTZ’ to activate interfacing to control Pan, Tilt, Zoom, and Focus.

  • Page 109: Using Audio

    OSD-400/OSD-800/OSD-1600 Reference Supported PTZ camera list can be refereed to ‘4.9 PTZ Control’. 7.5.10 Using Audio In case of Channel setup sync with Audio, press right mouse button on the image to activate pop-up menu to “Listen” or activate Audio listen button. First default is Mute. In case of listening Audio, select pop-up menu or button.

  • Page 110: Playback

    OSD-400/OSD-800/OSD-1600 7.6 Playback This page is to playback recorded images, and user who has authority of ‘HDD’ among user ID or administrator can use this function. Playback that is made up 16 divisions can play the images by searching through calendar by recording period and moving the period.

  • Page 111: Printing

    OSD-400/OSD-800/OSD-1600 Save Image dialog box appears, then it can input message or select channel name, date, event data. Press ‘OK’ to open dialog box for the saving location, then save bmp file. 7.6.3 Printing Select image with mouse for the channel to print image saved, and then click ‘Print’ button.

  • Page 112: Channel On/Off

    OSD-400/OSD-800/OSD-1600 7.6.6 Channel On/Off It is the same function like Channel On/Off function at Web Monitor. It is Channel On/Off button located on right of Page, and click On or Off page for wanted channel. Default is On. Disabled Channel button refers to do not support and relate to this unit.

  • Page 113: Functional Function At The Button Of Monitor

    OSD-400/OSD-800/OSD-1600 7.6.9 Functional function at the button of monitor 1. Indicates playback range of recorded images. 2. Press button as the time set at (5) so as to change the time zone to playback in forwarding and backwarding. 3. From left button, it can ‘Move a frame back’, ‘Play backward’, ‘Stop’, ‘Play’, ‘Move a frame forward’.

  • Page 114: Java Web Viewer

    OSD-400/OSD-800/OSD-1600 8 JAVA Web Viewer Java viewer is a WebViewer to use in Java. Java should be installed in login screen to use Java viewer. After an installation of Java manually, select “Java” in below of Password window and login.

  • Page 115: User Manual For Mobile Viewer

    OSD-400/OSD-800/OSD-1600 9 User manual for Mobile Viewer Mobile viewer is viewer service to monitor video via mobile device. To access mobile viewer, user uses mobile device supporting Wi-Fi or smart phone or 3G. 9.1 Log-In page Below picture is Mobile viewer log-in page.
  • Page 116 OSD-400/OSD-800/OSD-1600 [0] MENU: Move to Log In page [1] CH-: Move to the previous channel. [2] UP: Move to upside of Pan Tilt movement [3] WIDE: Zoom Out action : Move to left side of Pan Tile movement : Move to right side of Pan Tile movement...

  • Page 117: Trouble Shooting

    OSD-400/OSD-800/OSD-1600 10 Trouble shooting 1. DVR booting failure 1. Check the power 2. Check Power cord 2. No video on monitor 1. Check monitor power 2. Check cable between DVR and monitor 3. Check monitor cable port 4. Check DVR power is off 5.
  • Page 118 OSD-400/OSD-800/OSD-1600 2. Check DVR IP 3. Check Computer IP 4. Ping Test 5. Check PC specification if WebViewer video is not shown. 10. The cases necessary to contact the shop 1. In case of extraordinary working(ex: noise, smell or fume) 2.

  • Page 119: The Way To Check The Manufacturing Date

    Internal check number internal check number Model number (1) 1~2 digits: Identify Model name of product (2) 3~8, 8~12 digits: Orion Technology internal number (3) 5~6 digits: Manufacturing year (4) 7 digits: Manufacturing month Please see the below table for manufacturing month.

  • Page 120: Available Hdd

    16Ch. analog video inputs via BNC connector OSD-1600: Max. 480ips(NTSC) / 400ips(PAL) @ Recording performance CIF resolution OSD-800: Max. 240ips(NTSC) / 200ips(PAL) @ 2CIF resolution OSD-400: Max. 120ips(NTSC) / 100ips(PAL) @ 4CIF resolution Recording Resolution CIF, 2CIF, 4CIF Manual(Emergency) recording Manual record triggered by front key...
  • Page 121 External USB memory disk(USB 2.0 compatible) on USB port Frame rate on CCTV monitor: Max. 400fps Monitor displaying performance Quad mode: OSD-1600(1/4/9/10/16), OSD- 800(1/4/9), OSD-400(1/4) Channels Sequence switching: User defined Monitor playback performance Frame rate: Max. 30 ips Quad mode: OSD-1600(1/4/9/10/16), OSD-...
  • Page 122 OSD-400/OSD-800/OSD-1600 Digital zoom 2 times digital zoom (Live mode) Event triggered pop-up video Triggered by motion detection or sensor input PTZ control Ports: RS232(1) , RS485(2) Local user Front panel push button, IR remote, Keyboard Controller, Mouse Remote user On-the-screen PTZ control on PC Preset: 16 points per channel Return home position’...

  • Page 123: Product Size

    OSD-400/OSD-800/OSD-1600 14 Product size Install & User Manual - Firmware 3.X...
  • Page 124 OSD-400/OSD-800/OSD-1600 Hasselager Centervej 11, 8260 Viby J, Denmark Phone: + 45 87 38 86 40 - Fax: + 45 87 38 86 47 www.orion-technology.eu Install & User Manual - Firmware 3.X...

This manual is also suitable for:

Osd-800Osd-1600

Table of Contents
