Tail Lamps - Mini COUPE Owner's Manual

Side turn signals
5 watt bulb, W 5 W
1. Push the lamp with the ventilation grate
forward and remove.
2. Unscrew the bulb holder counterclockwise.
3. Pull out and replace the bulb.
4. To insert the new bulb and replace the
cover, proceed in reverse order.

Tail lamps

Turn signals: 21 watt bulb, PY 21 W
Brake light: bulb 21 Watt/5 Watt, W 5 W
Other lights: bulb 21 Watt, P 21 W
1 Turn signal
2
Tail lamp LED
3
Brake light
Online Edition for Part no. 01 40 2 914 807 - © 07/12 BMW AG
Replacing components
Changing
1. Remove the cover from the sidewall of the
cargo area.
MINI Coupe, MINI Roadster:
MINI Convertible:
Move the convertible top to its uppermost
position, refer to Loading aid page 111, and
remove the cover of the luggage compart-
ment side wall.
2. Unscrew the desired bulb counterclockwise,
arrows 1.
Another bulb is located behind the luggage
compartment side wall, arrow 2.
3. To insert the new bulb and replace the
cover, proceed in reverse order.
MOBILITY
225
