Page 1 Contents OWNER'S MANUAL. MINI CONVERTIBLE. Online Edition for Part no. 01402983394 - X/17...
Page 3 The more familiar you are with your vehicle, the better control you will have on the road. We therefore strongly suggest: Read this Owner's Manual before starting off in your new MINI. Also use the Integrated Owner's Manual in your vehicle. It con‐...
Page 4 © 2017 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Reprinting, including excerpts, only with the written consent of BMW AG, Munich. US English ID4 X/17, 11 17 490 Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling. Online Edition for Part no. 01402983394 - X/17...
Page 5: Table Of Contents
Wheels and tires Communication can be called up via the follow‐ Engine compartment ing Owner's Manuals: Integrated Owner's Engine oil Manual in the vehicle, Online Owner's Manual, Coolant MINI Driver's Guide app. Maintenance Replacing components Breakdown assistance Information Care AT A GLANCE...
Page 6: The Fastest Way To Find Information On A Partic
Internet the first chapter. The Owner's Manual and general Information Updates made after the editorial about MINI, for example on technology, are deadline available on the Internet: www.miniusa.com. Due to updates after the editorial deadline, dif‐ Integrated Owner's Manual in the ferences may exist between the printed Own‐...
Page 7: Information
Information Symbols and displays Vehicle features and op‐ tions Symbols in the Owner's Manual This Owner's Manual describes all models and Symbol Meaning all standard, country-specific and optional equipment that is offered in the model series. Precautions that must be followed. To Therefore, this Owner's Manual also describes avoid the possibility of personal injury and illustrates features and functions that are...
Page 8 ▷ MINI Motorer’s Guide App. MINI dealer’s service center. If you choose to Notes on updates can be found in the appendix use another service facility, the manufacturer of of the printed Owner's Manual for the vehicle.
Page 9 Your vehicle is covered by the fol‐ damage to the vehicle. Such damage is not lowing warranties: covered by the MINI New Vehicle Limited War‐ ▷ New Vehicle Limited Warranty. ranty. ▷...
Page 10 Information ▷ Malfunctions and faults in important system hicle by means of the service history and trans‐ components, for instance lights and brakes. ferred to the vehicle manufacturer. The vehicle owner can contact a dealer's service center to ▷ Information on vehicle-damaging events. object to the data being stored and transferred ▷...
Page 11 Information Control via mobile devices there too. Personal data may be used to per‐ form online services. Data is exchanged over a Depending on the vehicle equipment, mobile secure connection, for instance with the IT sys‐ devices connected to the vehicle, for instance tems of the vehicle manufacturer intended for smartphones, can be controlled via the vehicle this purpose.
Page 12 Information Vehicle identification standing how a vehicle’s systems performed. The EDR is designed to record data related to number vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: ▷...
Page 13 National Highway Traffic Safety Administration NHTSA, in addition to notifying MINI of North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Telephone 1-800-831-1117.
Page 14 WATCH ME. Online Edition for Part no. 01402983394 - X/17...
Page 15: At A Glance
AT A GLANCE CONTROLS DRIVING TIPS MOBILITY REFERENCE Online Edition for Part no. 01402983394 - X/17...
Page 16: Cockpit
AT A GLANCE Cockpit Cockpit Vehicle features and op‐ necessarily available in your vehicle, e. g., due to the selected options or country versions. This tions also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country- the applicable laws and regulations must be specific and optional features offered with the...
Page 17 AT A GLANCE Cockpit Automatic headlight control 112 Roadside parking lights 112 Cornering light 113 High-beam Assistant 113 Onboard Computer 102 Instrument lighting 115 Instrument cluster 93 Steering wheel buttons, left Steering column stalk, right Camera-based cruise control on/ Windshield wipers 81 off 142 Cruise control on/off 147 Rain sensor 81 Cruise control: store speed Cleaning windows 79...
Page 18 In the vicinity of the center console Hazard warning system 242 Start/stop the engine and switch the ignition on/off 72 Intelligent Safety 128 DSC Dynamic Stability Con‐ trol 137 MINI Driving Modes switch 139 Control Display 20 Radio/Multimedia Glove compartment 175 Steptronic transmission selector lever 85 Climate control 160 Manual transmission selector lever 84...
Page 19 AT A GLANCE Cockpit All around the interior mirror Emergency Request Ambient light 115 Indicator light, front-seat passen‐ Convertible top 52 airbag 119 Reading lights 115 Interior lights 115 Online Edition for Part no. 01402983394 - X/17...
Page 20: Central Information Display (Cid)
AT A GLANCE Central Information Display (CID) Central Information Display (CID) Vehicle features and op‐ Overview of control ele‐ tions ments This chapter describes all standard, country- Control elements specific and optional features offered with the series. It also describes features that are not necessarily available in your vehicle, e.
Page 21 AT A GLANCE Central Information Display (CID) Switching on Switch on the ignition. Press the Controller. Switching off Press button. "Turn off control display" ▷ Move in four directions. Controller with navigation system The buttons can be used to open the menus di‐ Buttons on the Controller rectly.
Page 22 AT A GLANCE Central Information Display (CID) Operating concept Opening the main menu Press button. ▷ Press. The main menu is displayed. All Central Information Display (CID) functions can be called up via the main menu. Selecting menu items ▷ Move in two directions.
Page 23 AT A GLANCE Central Information Display (CID) ▷ Move the Controller to the left. ▷ Control options for the selected main menu, for instance for "Radio". Closes the current display and shows the previous display. ▷ If applicable, further operating options for the selected menu, for instance "Store Reopens previous display by pressing BACK station".
Page 24 AT A GLANCE Central Information Display (CID) Changing settings ▷ "Interactive map": use the interactive map. You can use the touchpad to change Control ▷ "Audio feedback": pronounces entered Display settings, for instance volume. Swipe left letters and numbers. or right to do this. Entering letters and numbers Example: setting the Entering letters requires some practice at the...
Page 25 AT A GLANCE Central Information Display (CID) Turn the Controller to set the hours, and Symbol Meaning then press the Controller. Check the SIM card. Turn the Controller to set the minutes, and SIM card is blocked. then press the Controller. SIM card is missing.
Page 26 AT A GLANCE Central Information Display (CID) Selecting the display Running a function On the Control Display: Press button. The function will work immediately. Press button. This means, for instance that the number is di‐ aled when a phone number is selected. "Split screen"...
Page 27 AT A GLANCE Central Information Display (CID) Switching between upper/lower case, ▷ Stored programmable memory buttons. numbers and characters ▷ Travel and Onboard Computer information. Depending on the menu, you can switch be‐ ▷ Music collection. tween entering upper and lower case letters ▷...
Page 28: Voice Activation System
AT A GLANCE Voice activation system Voice activation system Vehicle features and op‐ Functional requirements tions Via the Control Display, set a language that is also supported by the voice activation system This chapter describes all standard, country- so that the spoken commands can be identi‐ specific and optional features offered with the fied.
Page 29 AT A GLANCE Voice activation system Example: opening the The available commands depend on the menu that is currently displayed on the Control Dis‐ tone settings play. There are short commands for many functions. Via the main menu You may select list entries such as phone list The commands of the menu items are spoken entries via voice activation.
Page 30 This can unnecessarily delay the establishment of a phone connection. Environmental condi‐ tions ▷ Keep the doors, windows, and convertible top closed to prevent noise interference. ▷ Avoid making other noise in the vehicle while speaking. Online Edition for Part no. 01402983394 - X/17...
Page 31: Owner's Manual Media
Selecting the Owner's Manual ▷ Integrated Owner's Manual in the vehicle, refer to page 31. Press button. ▷ MINI Motorer’s Guide App, refer to Turn the Controller: open "Vehicle page 33. info". ▷ Online Owner's Manual, refer to page 33.
Page 32 AT A GLANCE Owner's Manual media ▷ "Owner's Manual" "Display Owner's Manual" Opening when a Check Control message is displayed Directly from the Check Control message on the Control Display: "Display Owner's Manual" Changing between a function and the Owner's Manual To switch from a function, for instance radio, to Leafing through the Owner's Manual the Owner's Manual on the Control Display and...
Page 33 The Owner's Manual is displayed im‐ The Online Owner's Manual can be displayed in mediately. any of today's browsers. General information MINI Motorer’s Guide app The Online Owner's Manual is available in many countries. An account on the customer Concept portal may be required.
Page 34 AT A GLANCE Owner's Manual media Search by illustrations Videos Based on illustrations, image search provides The videos explain the main functions of the information and descriptions. This is helpful systems. when the terminology for a feature is not at Smart Scan hand.
Page 35 AT A GLANCE Owner's Manual media Online Edition for Part no. 01402983394 - X/17...
Page 36 HANDLE ME. Online Edition for Part no. 01402983394 - X/17...
Page 37: Controls
AT A GLANCE CONTROLS DRIVING TIPS MOBILITY REFERENCE Online Edition for Part no. 01402983394 - X/17...
Page 38 CONTROLS Opening and closing Opening and closing Vehicle features and op‐ WARNING Unlocking from the inside is only possible tions with special knowledge. This chapter describes all standard, country- Persons who spend a lengthy time in the vehi‐ specific and optional features offered with the cle while being exposed to extreme tempera‐...
Page 39 Press button on the remote control. With Comfort Access: If close to the vehicle, the convertible top can Depending on the settings, refer to page 48, also be opened. the following access points are unlocked.
Page 40 Adjusting the settings, refer to page 48. Body parts can be jammed when opening and closing the convertible top. There is a risk Safety information of injury. When opening and closing the convertible top, observe the movement and...
Page 41 CONTROLS Opening and closing Malfunction Slide the integrated key in the cover of the battery compartment and raise the cover. General information A Check Control message is displayed. Remote control detection by the vehicle may malfunction under the following circumstances: ▷...
Page 42 CONTROLS Opening and closing It is not possible to switch on the drive-ready to property. Remove the integrated key before state if the remote control has not been de‐ pulling the outside door handle.◀ tected. Removing Proceed as follows in this case: Hold the remote control as shown against the marked area on the steering column.
Page 43 CONTROLS Opening and closing Comfort Access detection of the remote control, refer to page 41. Concept The vehicle can be accessed without activating Buttons for the central the remote control. locking system All you need to do is to have the remote control with you, such as in your pants pocket.
Page 44 WARNING Body parts can be jammed when opening and closing the convertible top. There is a risk of injury. When opening and closing the convertible top, observe the movement and keep the area of movement clear.◀...
Page 45 CONTROLS Opening and closing Opening Tailgate General information To avoid locking it in the vehicle, do not place the remote control in the cargo area. Depending on your vehicle's equipment and the country version, it is possible to specify whether the doors are also unlocked when un‐ locking with the remote control.
Page 46 CONTROLS Opening and closing Opening from the inside if the vehicle has been used in the meantime by a person with a different remote control. With the vehicle stationary, press the Changes to the settings are automatically button in the driver's floor area. stored in the driver profile currently activated.
Page 47 ▷ Rearview camera. ▷ Head-up Display. A personal name can be assigned to every pro‐ file to avoid confusion between the profiles. ▷ MINI Driving Modes. Via the Central Information Display (CID): ▷ Intelligent Safety. "Settings" Profile management "Profiles" The active profile is selected.
Page 48 CONTROLS Opening and closing Unlocking Via the Central Information Display (CID): "Settings" Doors "Profiles" Via the Central Information Display (CID): "Import profile" "Settings" "USB device" "Doors/key" Display profile list during start Select the symbol. The profile list can be displayed during each Select the desired function.
Page 49 CONTROLS Opening and closing The vehicle locks automatically after a ▷ By switching on the hazard warning system. short period of time if no door is ▷ By flashing the daytime running lights. opened after unlocking. Overview ▷ "Lock after start driving" The vehicle locks automatically after you drive off.
Page 50 Falling ob‐ using the button on the driver's side or pas‐ jects such as leaves can trigger the alarm unin‐...
Page 51 CONTROLS Opening and closing Power windows ▷ Press the switch to the resistance point. General information All side windows open simultaneously while If an accident of a certain severity occurs, the the switch is being held. windows are automatically closed except a gap.
Page 52 Depending on the degree of overheating, it may only be possible to close the window or it may not be possible to operate it at all. Convertible top, sliding sun roof switch In this case: allow the power window motor to cool down.
Page 53 ▷ Do not open the convertible top, if it is wet, ▷ Even when the convertible top is closed, covered in snow, iced up, or dirty.
Page 54 The voltage of the vehicle electrical system Body parts can be jammed when opening is sufficient. and closing the convertible top. There is a risk of injury. When opening and closing the ▷ The convertible top drive is not overheat‐...
Page 55 231. Operating from the outside When equipped with Comfort Access the Unlocking the convertible top convertible top can also be operated from out‐ Loosen and remove the screw on both side. sides of the vehicle using the hexagon ▷...
Page 56 Lift out the convertible top simultaneously on both sides and swivel forward onto the windshield panel. To take out the convertible top, pull force‐ fully on the side frame. Begin with an up‐ ward movement and then change to a for‐...
Page 57 The wind deflector reduces the air movement Turn the hexagon wrench counterclockwise in the car's interior when driving with the to open the side frame lock. convertible top down. Safety information NOTE When moving the front seats back, the wind deflector can be damaged. There is a risk of damage to property.
Page 58 CONTROLS Opening and closing Fully unfold the wind deflector so that the Press the wind deflector downward, while handle, arrow 1, folds down and locks the inserting the pins in the corresponding fix‐ wind deflector. ing points, arrows 2. Open the rear side window, if necessary. Press the wind deflector downward in the middle, until the handle engages, arrows 1.
Page 59 CONTROLS Settings Settings Vehicle features and op‐ WARNING With a backrest inclined too far to the tions rear, the efficacy of safety gear, including safety belts can no longer be ensured. There is a risk This chapter describes all standard, country- of sliding under the safety belt in an accident.
Page 60 CONTROLS Settings Forward/backward Lumbar support The curvature of the seat backrest can be ad‐ justed in a way that it supports the lumbar re‐ gion of the spine. The lower back and the spine are supported for upright posture. Pull the lever and slide the seat in the desired direction.
Page 61 CONTROLS Settings Front seat heating WARNING Unexpected movements of the backrest Overview while driving may occur due to an unlocked backrest. Vehicle control could be lost. There is a risk of injury. Fold back and lock the backrests before driving.◀ Folding down the backrest Pull lever up to the stop.
Page 62 CONTROLS Settings though airbags enhance safety by providing Have the safety belts checked after an accident added protection, they are not a substitute for at the dealer’s service center or another quali‐ safety belts. fied service center or repair shop.◀ The upper shoulder strap's anchorage point will Correct use of safety belts be correct for adult seat occupants of every...
Page 63 CONTROLS Settings Rear belt guide WARNING Body parts can be jammed when moving the head restraint. There is a risk of injury. Make sure that the area of movement is clear when moving the head restraint.◀ WARNING Objects on the head restraint reduce the protective effect in the head and neck area.
Page 64 CONTROLS Settings Removing: John Cooper Works sport ▷ Adjust the distance so that the head re‐ seat straint is as close as possible to the back of the head. Adjust the distance via the back‐ The head restraints cannot be removed. rest tilt as needed.◀...
Page 65 CONTROLS Settings Removing Overview Only remove the head restraint if no one will be sitting in the seat in question. Settings Selecting a mirror, Automatic Curb Monitor Fold down the rear seat backrest, refer to Folding in and out page 180, in question. Pull head restraint up against the resist‐...
Page 66 CONTROLS Settings Interior mirror, manually dimmable ▷ In vehicle washes. ▷ On narrow roads. Flip lever Mirrors that were folded in are folded out auto‐ matically at a speed of approx. 25 mph/40 km/h. Automatic heating Both exterior mirrors are automatically heated whenever the ignition is switched on.
Page 67 CONTROLS Settings ▷ In the mirror glass. ▷ On the back of the mirror. Functional requirements ▷ Keep the photocells clean. ▷ Do not cover the area between the interior mirror and the windshield. Steering wheel Safety information WARNING Steering wheel adjustments while driving can lead to unexpected steering wheel move‐...
Page 68 CONTROLS Transporting children safely Transporting children safely Vehicle features and op‐ necessarily available in your vehicle, e. g., due to the selected options or country versions. This tions also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country- the applicable laws and regulations must be specific and optional features offered with the...
Page 69 CONTROLS Transporting children safely Safety information vers. There is a risk of injuries or danger to life. Have damaged child restraint systems or of WARNING child restraint systems exposed to an accident Active front-seat passenger airbags can and their fastening systems checked and possi‐ injure a child in a child restraint system when bly replaced by the dealer’s service center or the airbags are activated.
Page 70 CONTROLS Transporting children safely Seat position and height Locking the safety belt Before installing a child restraint system, move Pull out the belt strap completely. the front passenger seat as far back as possible Secure the child restraint system with the and adjust its height to the highest and thus safety belt.
Page 71 CONTROLS Transporting children safely Position Symbol Meaning The corresponding symbol shows the mounts for the lower LATCH anchors. Seats equipped with lower an‐ chors are marked with a pair, 2, of LATCH symbols. Before installing LATCH child restraint fixing systems Pull the safety belt away from the area of the child restraint system.
Page 72 CONTROLS Driving Driving Vehicle features and op‐ To save battery power when the engine is off, switch off the ignition and any unnecessary tions electronic systems/power consumers. This chapter describes all standard, country- Ignition off specific and optional features offered with the Manual transmission: press the Start/Stop but‐...
Page 73 CONTROLS Driving Starting the engine engaged automatically if the selector lever po‐ sition D or R is engaged. Safety information Radio-ready state DANGER General information If the exhaust pipe is blocked or ventila‐ tion is insufficient, harmful exhaust gases can In the radio-ready state, certain power con‐...
Page 74 CONTROLS Driving The ignition is activated automatically for a ▷ On uphill grades or on a downhill slope, brief time and is stopped as soon as the engine turn the front wheels in the direction of the starts. curb. ▷ On uphill grades or on a downhill slope, Manual transmission also secure the vehicle, for instance with a...
Page 75 CONTROLS Driving Functional limitations Depending on the selected driving mode, refer to page 139, the system is automatically acti‐ The engine is not switched off automatically in vated or deactivated. the following situations: ▷ External temperature too low. Engine stop ▷...
Page 76 CONTROLS Driving Some indicator lights light up for a varied ▷ LED comes on: auto Start/Stop function is length of time. deactivated. The engine can only be started via the Start/ The engine is started during an automatic Stop button. engine stop.
Page 77 CONTROLS Driving Releasing Parking brake Safety information WARNING An unsecured vehicle can begin to move and possibly roll away. There is a risk of an acci‐ dent. Before exiting, secure the vehicle against rolling. In order to ensure that the vehicle is secured against rolling away, follow the following: Raise lever slightly, press the button and guide ▷...
Page 78 CONTROLS Driving "Triple turn signal" the wipers are in the folded away state and the wipers are folded in when switching on.◀ The setting is stored for the driver profile cur‐ rently used. NOTE If the wipers are frozen to the windshield, Signaling briefly the wiper blades can be torn off and the wiper Press the lever to the resistance point and hold...
Page 79 CONTROLS Driving Deactivating ▷ Switching off: press the lever down until it reaches its standard position. Press the lever back into the standard position. ▷ Brief wipe: press the lever down from the Setting the frequency or sensitivity of standard position. the rain sensor The lever automatically returns to its initial position when released.
Page 80 CONTROLS Driving Cleaning the windshield is a risk of damage to property. Defrost the windshield prior to switching the wipers on.◀ Folding away the wipers Switch the ignition on and off again. Press and hold the wiper level down, until the wipers stop in a close to vertical posi‐...
Page 81 CONTROLS Driving Switching off and brief wipe Canada: wiper system General information Do not use the wipers if the windshield is dry, as this may damage the wiper blades or cause them to become worn more quickly. Safety information WARNING If the wipers start moving in the folded Press the lever down.
Page 82 CONTROLS Driving Activating/deactivating Windshield washer system Safety information WARNING The washer fluid can freeze onto the win‐ dow at low temperatures and obstruct the view. There is a risk of an accident. Only use the washer systems, if the washer fluid cannot freeze.
Page 83 CONTROLS Driving General information Fold the wipers all the way away from the windshield. Helpful when changing the wiper blades or un‐ der frosty conditions, for instance. Safety information WARNING If the wipers start moving in the folded away state, body parts can be jammed or dam‐ age may occur to parts of the vehicle.
Page 84 CONTROLS Driving Overview ating materials into different bottles. Store op‐ erating materials out of reach of children. United States: the washer fluid mixture ratio is regulated by the U.S. EPA and many individual states; do not exceed the allowable washer fluid dilution ratio limits that apply.
Page 85 CONTROLS Driving Steptronic transmission or 6th gear, press the gearshift lever to the right.◀ Concept Schematic diagram The Steptronic transmission combines the func‐ tions of an automatic transmission with the possibility of manual shifting, if needed. Safety information WARNING An unsecured vehicle can begin to move and possibly roll away.
Page 86 CONTROLS Driving respective selector lever position. The selector The transmission blocks the drive wheels in se‐ lever engages in the selector lever positions. lector lever position P. Engage selector lever position P only when the vehicle is stationary. Transmission with a tap-operated selector lever Before exiting the vehicle, make sure that se‐...
Page 87 CONTROLS Driving Functional requirements deactivated and the shift command will not be executed. Only when the brake pedal is depressed is it A selector lever lock prevents the following possible to change from selector lever posi‐ faulty operation: tion P to another selector lever position. ▷...
Page 88 CONTROLS Driving Engaging selector lever position P Touch the selector lever lock and engage selector lever position N. Switch the engine off. In this way, the ignition remains switched on, and a Check-Control message is dis‐ played. The vehicle may roll. NOTE Selector lever position P is automatically engaged when the ignition is switched off.
Page 89 Once a particular engine speed is attained, M/S manual mode is automatically upshifted as Manual mode M/S needed. MINI John Cooper Works: once particular en‐ Concept gine speeds are attained, upshifting is not auto‐ Manual gear-shifting is possible in manual matically performed in M/S manual mode.
Page 90 CONTROLS Driving Shifting D is displayed in the instrument cluster. Shift paddles for Steptronic Sport transmission Concept The shift paddles on the steering wheel allow you to shift gears quickly while keeping both hands on the steering wheel. General information ▷...
Page 91 CONTROLS Driving ter console. To do so, pull the retaining ring Before unlocking the transmission lock, set the upward at the rear edge. parking brake to prevent the vehicle from roll‐ ing away. Engaging selector lever position N Unlocking is possible, if the starter can spin the engine.
Page 92 Launch Control. Start with launch control While the engine is running: Press button and select SPORT with the MINI Driving Modes switch. The instrument cluster displays TRACTION in combination with SPORT. The DSC OFF indicator light lights up. Engage selector lever position S.
Page 93 CONTROLS Displays Displays Vehicle features and op‐ necessarily available in your vehicle, e. g., due to the selected options or country versions. This tions also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country- the applicable laws and regulations must be specific and optional features offered with the observed.
Page 94 Selector lever position 85 External temperature 98 Gear shift indicator 100 Selection lists 102 MINI Driving Modes switch status 139 Indicator/warning lights Check Control General information Concept The indicator/warning lights can light up in a The Check Control system monitors functions in variety of combinations and colors.
Page 95 CONTROLS Displays Orange lights Make sure that the safety belts are positioned correctly. Active Cruise Control Airbag system The number bars shows the selected distance from the vehicle driving ahead. Airbag system and belt tensioner are Camera-based cruise control, refer to not working.
Page 96 CONTROLS Displays DSC Dynamic Stability Control is deactivated Have the system checked by a dealer’s service or DTC Dynamic Traction Control is activated center or another qualified service center or re‐ pair shop. DSC is deactivated or DTC is activated. DSC, refer to page 137, and DTC, refer Emissions to page 138.
Page 97 CONTROLS Displays Front fog lights The messages can be hidden for approx. 8 sec‐ onds. After this time, they are displayed again Front fog lights are switched on. automatically. Front fog lights, refer to page 114. Temporary display High-beam Assistant Some Check Control messages are hidden auto‐...
Page 98 CONTROLS Displays Reset the trip odometer ▷ Display additional information about the Check Control message in the Press the button. Integrated Owner's Manual. ▷ The odometer is displayed ▷ "Service request" when the ignition is switched Contact a dealer’s service center or another off.
Page 99 CONTROLS Displays Date Current fuel consump‐ tion The date is displayed in the in‐ strument cluster. Concept The date can be set via the Cen‐ Displays the current fuel consumption. Check tral Information Display (CID). whether you are currently driving in an efficient and environmentally-friendly manner.
Page 100 CONTROLS Displays General information Required maintenance procedures and le‐ gally mandated inspections are displayed. Depending on the vehicle's features and coun‐ Select an entry to call up detailed informa‐ try-specific version, the gear shift indicator is tion. active in the manual mode of the Steptronic transmission and with manual transmission.
Page 101 CONTROLS Displays the rain sensor, and will be displayed depend‐ ing on the situation. With the navigation system, the system takes into account the information stored in the navi‐ gation data and also displays speed limits present on routes without signs. Without a navigation system, the system is sub‐...
Page 102 CONTROLS Displays Activating a list and adjusting the ▷ When driving very close to the vehicle in setting front of you. ▷ When driving toward bright lights or strong Button on the steering Function reflections. wheel ▷ When the windshield in front of the interior Move selection up.
Page 103 CONTROLS Displays Information is displayed in the Info Display of Via the Central Information Display (CID): the instrument cluster. "Settings" "Instrument cluster" Information at a glance Select the desired information. Settings are stored for the profile currently Info Display used. Repeatedly pressing the button on the turn signal lever calls up Information in detail...
Page 104 The Always Open Timer displays the current permitted speed in the instrument cluster. driving time and total driving time with the convertible top open in minutes and hours. Onboard Computer on the Control Display Always Open Timer via the Central Information Display (CID), refer to page 110.
Page 105 "Automatically reset": all values are reset "Vehicle info" approx. 4 hours after the vehicle has come "Driving Excitement" to a standstill. "Vehicle and surroundings" Via MINI Driving Modes switch: Driving Excitement Activate SPORT. "Driving Excitement" Concept "Vehicle and surroundings" On the Control Display, sport instruments can be displayed, and the vehicle state can be checked before the use of the SPORT program.
Page 106 CONTROLS Displays Setting the time format Turn the Controller until the desired speed warning is displayed. "Settings" Press the Controller. "Time/Date" "Format:" Activating/deactivating the speed Select the desired format. warning The time format is stored. Via the Central Information Display (CID): "Settings"...
Page 107 CONTROLS Displays Units of measurement Event displays Functions that are only displayed temporarily, Setting the units of measurement for instance the volume or temperature set‐ To set the units for fuel consumption, route/ tings, can be set as event displays. distance and temperature: Several vehicle assistance functions can also be displayed on the LED ring.
Page 108 CONTROLS Displays Setting the brightness system. Do not move the moving parts man‐ ually.◀ The brightness can be adjusted when night lighting is active in the instrument cluster. Overview Via the Central Information Display (CID): "Settings" "Center Instrument" "Brightness at night" Turn the Controller.
Page 109 CONTROLS Displays Selecting displays in the Head-up Setting the rotation Display The screen of the Head-up Display can be ro‐ Via the Central Information Display (CID): tated around its own axis. Via the Central Information Display (CID): "Settings" "Head-Up Display" "Settings"...
Page 110 Displays Display Always Open Timer Concept The Always Open Timer displays the driving times with open convertible top on the Control Display and in the Onboard Computer, refer to page 102. General information With the respective equipment, the Always Speed Open Timer can also be displayed as light ani‐...
Page 111 CONTROLS Lights Lights Vehicle features and op‐ Symbol Function tions Lights off. Daytime running lights. This chapter describes all standard, country- specific and optional features offered with the Parking lights. series. It also describes features that are not necessarily available in your vehicle, e. g., due to the selected options or country versions.
Page 112 CONTROLS Lights Canada: roadside parking light "Welcome lights" The setting is stored for the driver profile cur‐ Concept rently used. The vehicle can be illuminated on one side. Headlight courtesy delay feature Switching on General information The low beams stay lit for a short while if the headlight flasher is switched on after the vehi‐...
Page 113 CONTROLS Lights System limits The cornering light is automatically switched on depending on the steering angle or the use of The automatic headlight control cannot serve turn signals. as a substitute for your personal judgment of lighting conditions. For example, the sensors are unable to detect Adaptive headlight fog or hazy weather.
Page 114 CONTROLS Lights Activating/deactivating ▷ In tight curves, on hilltops or in depressions, in cross traffic or half-obscured oncoming traffic on highways. ▷ In poorly-lit towns and cities and in the presence of highly reflective signs. ▷ When the windshield in front of the interior mirror is fogged over, dirty or covered with stickers, etc.
Page 115 CONTROLS Lights Switching on/off Overview Press button. The yellow indicator light lights up when the rear fog light is switched on. If the automatic headlight control, refer to page 112, is activated, the low beams will come on automatically when you switch on the rear fog light.
Page 116 CONTROLS Lights Changing color Push the switch forward or back: manual color change. Press the switch forward or backward and hold for approx. 3 seconds, until the ambient light illuminates several times: au‐ tomatic color change. Push the switch again to end color changes.
Page 117 CONTROLS Safety Safety Vehicle features and op‐ necessarily available in your vehicle, e. g., due to the selected options or country versions. This tions also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country- the applicable laws and regulations must be specific and optional features offered with the observed.
Page 118 Vehicle modifications for a person with disabili‐ gered. ties may affect the air bag system; contact MINI Customer Relations for further information. ▷ Make sure that the front passenger is sitting correctly, i.e., keeps his or her feet and legs...
Page 119 CONTROLS Safety Malfunction of the automatic risk of injuries or danger to life. Have the airbag deactivation system system checked, repaired, dismantled and scrapped by a dealer’s service center or an‐ When transporting older children and adults, other qualified service center or repair shop.◀...
Page 120 CONTROLS Safety ▷ The indicator light lights up An appropriate Check Control message is dis‐ when a child is properly played. seated in a child restraint Move the respective seat all the way for‐ system or when the seat is ward.
Page 121 Tire inflation pressure, refer to With an extended rollover protection sys‐ page 202. tem, the area of movement of the convertible Functional requirements top is limited. There is a risk of injury or risk of damage to property. When the rollover protec‐...
Page 122 CONTROLS Safety Via the Central Information Display (CID): Reset the tire inflation pressure using "Perform reset". "Vehicle info" Drive away. "Vehicle status" The wheels are displayed in gray and the fol‐ "Tire Pressure Monitor (TPM)" lowing is displayed "Resetting Tire Pressure The current status is displayed.
Page 123 CONTROLS Safety If there is a significant loss of tire Symbol Possible cause inflation pressure The system has detected a wheel change, but no reset was done. Message No reset was performed for the sys‐ A yellow warning light is illuminated in tem.
Page 124 CONTROLS Safety If identification of flat tire damage is not Possible driving range with a depressurized possible, please contact a dealer’s service tire center or another qualified service center or The possible driving range varies depending on repair shop. the how the vehicle is loaded and used, e.g., Repair the flat tire, e.g., with a flat tire kit or speed, road conditions, external temperature.
Page 125 CONTROLS Safety These circumstances may cause a warning pressure label, you should determine the when temperatures fall very sharply. proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been Sudden tire pressure loss equipped with a tire pressure monitoring sys‐ tem (TPMS) that illuminates a low tire pressure The system cannot indicate sudden serious tire telltale when one or more of your tires is signifi‐...
Page 126 CONTROLS Safety Performing initialization FTM Flat Tire Monitor When initializing, the set tire inflation pressures serve as reference values in order to detect a Concept flat tire. Initialization is started by confirming The system detects tire inflation pressure loss the tire inflation pressures. on the basis of rotation speed differences be‐...
Page 127 CONTROLS Safety Run-flat tires In addition, a symbol with a Check Control mes‐ sage appears on the Control Display. Safety information Symbol Possible cause WARNING There is a flat tire or a major loss in Your vehicle handles differently with a tire inflation pressure.
Page 128 CONTROLS Safety Intelligent Safety Vehicle handling with damaged tires Vehicles driven with a damaged tire will handle differently, potentially leading to conditions Concept such as the following: Intelligent Safety enables central operation of ▷ Greater likelihood of swerving off course. the driver assistance system.
Page 129 CONTROLS Safety Overview Approach control warn‐ ing with city light brak‐ Button in the vehicle ing function Concept The system can help prevent accidents. If an accident cannot be prevented, the system will help reduce the collision speed. The system sounds a warning before an immi‐ nent collision and activates brakes independ‐...
Page 130 CONTROLS Safety Detection range Overview Button in the vehicle Objects that the system can detect are taken into account. Intelligent Safety button Safety information WARNING Camera The system does not relieve from per‐ sonal responsibility to assess visibility and traffic situation.
Page 131 CONTROLS Safety Prewarning ▷ LED lights up orange or goes out respective to their individual settings. This warning is issued, for instance when there Adjust as needed. The individual settings are is the impending danger of a collision or the stored for the driver profile currently in use.
Page 132 CONTROLS Safety System limits Warning sensitivity The more sensitive the warning settings are, Safety information the more warnings are displayed. Therefore, there may also be an excess of premature or WARNING unjustified warnings and reactions. The system can react not at all, too late, incorrectly, or without justification due to the system limits.
Page 133 CONTROLS Safety Overview ▷ Central area, arrow 1, directly in front of the vehicle. Button in the vehicle ▷ Expanded area, arrow 2, to the right and left of the central area. A collision is imminent if pedestrians are lo‐ cated within the central area.
Page 134 CONTROLS Safety ▷ LED lights up orange or goes out respective The driver may cancel the braking intervention to their individual settings. by stepping on the accelerator pedal or by ac‐ tively moving the steering wheel. Adjust as needed. The individual settings are stored for the driver profile currently in use.
Page 135 CONTROLS Safety Safety information ▷ Up to 10 seconds after the start of the en‐ gine via the Start/Stop button. WARNING ▷ During calibration of the camera immedi‐ The system does not relieve from per‐ ately after vehicle delivery. sonal responsibility to assess one's physical ▷...
Page 136 CONTROLS Safety ▷ When the vehicle speed is mainly below about 43 mph/70 km/h. ▷ With a sporty driving style, such as during rapid acceleration or when cornering fast. ▷ In active driving situations, such as when changing lanes frequently. ▷...
Page 137 CONTROLS Driving stability control systems Driving stability control systems Vehicle features and op‐ DSC Dynamic Stability tions Control This chapter describes all standard, country- Concept specific and optional features offered with the Within the physical limits, the system helps to series.
Page 138 CONTROLS Driving stability control systems Deactivating DSC: DSC OFF DTC Dynamic Traction Control General information When DSC is deactivated, driving stability is re‐ Concept duced during acceleration and when driving in DTC is a version of the DSC Dynamic Stability curves.
Page 139 The tuning of the suspension can be changed with the system. GREEN The system offers several different programs. The programs are selected via the MINI Driving Concept Modes switch. GREEN, refer to page 190, provides consistent tuning to maximize range.
Page 140 The configuration is stored for the driver profile currently in use. Activating SPORT Selected program Press the MINI Driving Modes switch upward The instrument cluster displays until SPORT is displayed in the instrument clus‐ the selected program. ter.
Page 141 CONTROLS Driving stability control systems After the foot brake is released, the vehicle is held in place for approx. 2 seconds. Servotronic Servotronic is a speed-dependent power steer‐ ing function. The system provides the steering force with more support at low speeds than at higher ones.
Page 142 CONTROLS Driving comfort Driving comfort Safety information Vehicle features and op‐ tions WARNING The system does not relieve from per‐ This chapter describes all standard, country- sonal responsibility to assess the traffic situa‐ specific and optional features offered with the tion.
Page 143 CONTROLS Driving comfort Active cruise control is paused below approx. Button Function 20 mph/30 km/h. The system does not brake to Pause cruise control, refer to a stop. page 143. Continue cruise control with the last Switching on/off and interrupting cruise setting, refer to page 144.
Page 144 CONTROLS Driving comfort Adjusting distance ▷ If DSC Dynamic Stability Control intervenes. ▷ If the detection range of the camera is im‐ Safety information paired, for instance by soiling, heavy pre‐ cipitation or glare effects from the sun. WARNING ▷ If the vehicle in front decelerates below a The system does not relieve from per‐...
Page 145 CONTROLS Driving comfort Calling up stored speed and distance ▷ Display lights up orange: system is inter‐ rupted, the display indicates the stored Press button with the system inter‐ speed. rupted. Cruise control is continued with ▷ No display: system is switched off. the stored values.
Page 146 CONTROLS Driving comfort Symbol flashes red and a signal sounds: ▷ For oncoming traffic. Brake and make an evasive maneuver, ▷ Unlit vehicles or vehicles with nonworking if necessary. lighting at night. The system has been interrupted or dis‐ Swerving vehicles tance control is temporarily suppressed because the accelerator pedal is being pressed;...
Page 147 CONTROLS Driving comfort Malfunction The system has a limited detection range. Sit‐ uations can arise in tight curves where a vehicle A Check Control message is displayed if the sys‐ driving ahead will not be detected or will be tem fails or was automatically deactivated. detected very late.
Page 148 CONTROLS Driving comfort WARNING The current speed is adopted as the de‐ sired speed and is displayed with the The use of the system can lead to an in‐ symbol in the instrument cluster. creased risk of accidents in the following situa‐ tions, for instance: Cruise control is active and maintains the set ▷...
Page 149 CONTROLS Driving comfort The stored speed is displayed in the instrument The stored speed is reached again and main‐ cluster. tained. DSC Dynamic Stability Control is switched on, if Displays in the instrument cluster necessary. The speed can also be stored as follows: Indicator light Press button.
Page 150 CONTROLS Driving comfort Overview ▷ Signal tones. ▷ Visual display. With front PDC: button in vehicle General information The ultrasound sensors for measuring the dis‐ tances are located in the bumpers. The maneuvering range, depending on obsta‐ cles and environmental conditions, is approx. 6 ft/2 m.
Page 151 CONTROLS Driving comfort With front PDC: automatic activation on obsta‐ The signal tone is switched off, when selector cle detection can be switched off. Via the Cen‐ lever position P is engaged on vehicles with tral Information Display (CID): Steptronic transmission. "Settings"...
Page 152 CONTROLS Driving comfort Limits of ultrasonic measurement ▷ In large buildings with right angles and smooth walls, for instance in underground Ultrasonic measuring might not function under garages. the following circumstances: ▷ In automatic vehicle washes. ▷ For small children and animals. ▷...
Page 153 CONTROLS Driving comfort Automatic deactivation during forward ing style to traffic conditions. Watch traffic and travel vehicle surroundings closely and actively inter‐ vene where appropriate.◀ The system switches off when a certain driving distance or speed is exceeded. Overview Switch the system back on, if needed. If the vehicle is equipped accordingly: If the vehicle is equipped accordingly: button in the vehicle...
Page 154 CONTROLS Driving comfort Obstacle marking "Obstacle marking" If the vehicle is equipped accordingly, ob‐ stacles are highlighted. Pathway lines If the vehicle is equipped accordingly, obstacle markings can be faded into the image of the rearview camera. The colored thresholds of the obstacle mark‐ Pathway lines can be superimposed on the im‐...
Page 155 CONTROLS Driving comfort Display settings Parking assistant Brightness Concept With the rearview camera switched on: Select the symbol. Turn the Controller until the desired setting is reached and press the Controller. Contrast With the rearview camera switched on: Select the symbol. Turn the Controller until the desired setting This system assists the driver in parking parallel is reached and press the Controller.
Page 156 CONTROLS Driving comfort NOTE ▷ Keep the sensors clean and unobstructed. The parking assistant can steer the vehi‐ For measuring parking spaces cle over or onto curbs. There is a risk of damage to property. Watch traffic closely and actively ▷...
Page 157 CONTROLS Driving comfort Indicator on the Control Display Parking using the parking assistant System activated/deactivated Parking Symbol Meaning Press the park assistance button or shift into reverse gear to switch on the Gray: the system is not available. parking assistant, refer to page 156. Acti‐ White: the system is available but not vate the parking assistant, if needed.
Page 158 CONTROLS Driving comfort ▷ Possibly on snow-covered or slippery road ▷ On bumpy road surfaces such as gravel surfaces. roads. ▷ If a maximum number of parking attempts ▷ On slippery ground. or the time taken for parking is exceeded. ▷...
Page 159 CONTROLS Driving comfort Tire size The parking position may vary depending on the tire size. Malfunction A Check Control message is displayed. The parking assistant failed. Have the system checked by a dealer’s service center or another qualified service center or repair shop. Online Edition for Part no.
Page 160 CONTROLS Climate control Climate control Vehicle features and op‐ Interior air quality tions The air quality inside the vehicle is improved by an emissions-tested interior, a microfilter, and a This chapter describes all standard, country- climate-control system for regulating tempera‐ specific and optional features offered with the ture, air flow, and recirculated-air mode.
Page 161 CONTROLS Climate control Seat heating, left 61 Climate control functions in detail Depending on the weather, the windshield may fog up briefly when the engine is started. Switching the system on/off The air conditioner produces condensation wa‐ ter, refer to page 187, that will exit from below Switching on the vehicle.
Page 162 CONTROLS Climate control Operation ▷ Direct the air distribution onto the win‐ dows. Turn the ring to set the desired ▷ Increasing the air flow. air flow. ▷ Increase the temperature. The higher the air flow, the more effective the heating or cooling ▷...
Page 163 CONTROLS Climate control Automatic climate control Temperature, left Maximum cooling Display 10 Air conditioning Air flow, AUTO intensity 11 Recirculated-air mode AUTO program 12 Rear window defroster Air distribution, manual 13 Windshield defroster Display 14 Defrosting windows and removing conden‐ sation Temperature, right 15 Seat heating,...
Page 164 CONTROLS Climate control by using the maximum cooling or heating General information power, and then keeps it constant. The function is available with external tempera‐ tures beyond approx. 32 ℉/0 ℃ and with the Settings engine running. Turn the ring to set the desired Air flows out of the vents to the upper body re‐...
Page 165 To manually adjust air flow switch off AUTO convertible program, the automatic climate program first. control is optimized for driving with the convertible top open. In addition, the air flow is Operation increased as the vehicle speed increases. Turn the ring to set the desired The efficiency of the convertible program can air flow.
Page 166 CONTROLS Climate control Defrosting windows and removing Ventilation condensation Setting Concept The air flow directions can be individually ad‐ Ice and condensation are quickly removed justed: from the windshield and the front side win‐ ▷ Direct ventilation: dows. The air flow is directly pointed onto the per‐ son.
Page 167 CONTROLS Climate control Functional requirements The symbol on the automatic climate con‐ trol flashes when the system has been switched ▷ Direct operation: vehicle is in radio-ready state. The system will only be switched on within the ▷ Direct operation or preset activation time: next 24 hours.
Page 168 CONTROLS Interior equipment Interior equipment Vehicle features and op‐ during programming and operation. Also follow the safety information of the hand-held trans‐ tions mitter.◀ This chapter describes all standard, country- Compatibility specific and optional features offered with the series. It also describes features that are not If this symbol is printed on the packag‐...
Page 169 CONTROLS Interior equipment proximately 20 seconds until the LED on flashing rapidly and then stays lit constantly for the interior mirror flashes. This erases all 2 seconds, the system features a rolling code programming of the buttons on the interior radio system.
Page 170 CONTROLS Interior equipment Likewise, press and hold the button of the 20 seconds until the LED on the interior mirror desired function on the hand-held trans‐ flashes rapidly. All stored functions will be de‐ mitter. leted. The functions cannot be deleted individ‐ ually.
Page 171 The set zone is stored automatically. The com‐ pass is ready for use again after approximately Set the currently applicable compass zone. 10 seconds. Make sure that the convertible top is com‐ pletely closed. Calibrating the digital compass Press and hold the control button for ap‐...
Page 172 Ashtray/cigarette the "C" is replaced by the points of the compass. lighter Open convertible top completely. Press and hold the control button for ap‐ Overview prox. 6 to 7 seconds so that "C" appears on the display. Next, drive in a complete circle at least once at a speed of no more than 4 mph/7 km/h.
Page 173 CONTROLS Interior equipment Operation NOTE If metal objects fall into the socket, they Push in the cigarette lighter. can cause a short circuit. There is a risk of dam‐ The cigarette lighter can be re‐ age to property. Replace the cigarette lighter or moved as soon as it pops back socket cover again after using the socket.◀...
Page 174 CONTROLS Interior equipment General information ▷ Protect the USB storage device against me‐ chanical damage. The following devices can be connected: ▷ Due to the large number of USB media ▷ Mobile phones supported by the USB inter‐ available on the market, it cannot be guar‐ face.
Page 175 CONTROLS Storage compartments Storage compartments Vehicle features and op‐ ▷ Storage compartment in front of the cup holders. tions ▷ Storage compartments in the cargo area. This chapter describes all standard, country- ▷ Storage tray in the center console. specific and optional features offered with the ▷...
Page 176 CONTROLS Storage compartments Locking Adjusting the height The glove compartment can be locked with an integrated key to separately secure the tail‐ gate, for instance. This prevents access to the glove compartment and to the cargo area. After the glove compartment is locked, the re‐ mote control can be handed over, such as at a hotel, without the integrated key.
Page 177 CONTROLS Storage compartments Rear In front of the rear seats. Online Edition for Part no. 01402983394 - X/17...
Page 178 CONTROLS Cargo area Cargo area Vehicle features and op‐ WARNING Improperly stowed objects can shift and tions be thrown into the car's interior, for instance in the event of an accident or during braking and This chapter describes all standard, country- evasive maneuvers.
Page 179 Heavy cargo: stow as far forward as possi‐ Opening the loading aid ble, directly behind and at the bottom of the rear passenger seat backrests. Unlock the convertible top using the han‐ dles, arrows 1. ▷ Very heavy cargo: when the rear seat is not occupied, secure each of the outer safety belts in the opposite buckle.
Page 180 Cargo area Enlarging the cargo Push the handles outward to lock the convertible top. area Check that the convertible top is locked. Concept The cargo area can be enlarged as follows: Lashing eyes in the cargo ▷ The rear seat backrests can be folded area down.
Page 181 179, and lock it. Fold the rear seat backrest forward. Return the cargo area partition into the lower position so that the convertible top can be Fold back the backrest used. Fold up the backrest and press it into the latch.
Page 182 DRIVE ME. Online Edition for Part no. 01402983394 - X/17...
Page 183 AT A GLANCE CONTROLS DRIVING TIPS MOBILITY REFERENCE Online Edition for Part no. 01402983394 - X/17...
Page 184: Things To Remember When Driving
DRIVING TIPS Things to remember when driving Things to remember when driving Vehicle features and op‐ ▷ For gasoline engine 4,500 rpm and 100 mph/160 km/h. tions Avoid full load or kickdown under all circum‐ stances. This chapter describes all standard, country- specific and optional features offered with the From 1,200 miles/2,000 km series.
Page 185 It is characterized by a partial or complete avoided: loss of contact between the tires and the road ▷ If the convertible top is closed, close all surface, ultimately undermining your ability to windows and the sliding sun roof. steer and brake the vehicle.
Page 186 DRIVING TIPS Things to remember when driving Braking safely Hills General information General information The vehicle is equipped with ABS as a standard Drive long or steep downhill gradients in the feature. gear that requires least braking effort. Other‐ wise, the brakes may overheat and reduce Perform an emergency stop in situations that brake efficiency.
Page 187 DRIVING TIPS Things to remember when driving Condensation water under the parked COOPER S vehicle When using the automatic climate control, con‐ densation water develops and collects under‐ neath the vehicle. Ground clearance NOTE If ground clearance is insufficient, there might be contact with the front or rear spoiler, for instance when driving over curbs or enter‐...
Page 188 DRIVING TIPS Things to remember when driving Driving on racetracks Higher mechanical and thermal loads during racetrack operation lead to increased wear. This wear is not covered by the warranty. The vehicle is not designed for use in motor sports competition.
Page 189: Saving Fuel
DRIVING TIPS Saving fuel Saving fuel Vehicle features and op‐ Closing the windows tions Open windows increase air resistance and therefore lead to greater fuel consumption. This chapter describes all standard, country- specific and optional features offered with the series. It also describes features that are not Tires necessarily available in your vehicle, e.
Page 190 MINI recommends that maintenance work be performed by a MINI service center. The flow of fuel is interrupted while coasting. Also note the MINI maintenance systems, refer to page 229. Switch off the engine during longer stops...
Page 191 Setting the speed for the GREEN Limit: page 193. "Tip at:" Activating GREEN Mode Select the desired speed. Press the MINI Driving Modes GREEN climate control switch downward until GREEN is displayed in the instrument clus‐ Climate control is set to be fuel-efficient.
Page 192 DRIVING TIPS Saving fuel Efficiency display GREEN tip, symbols An additional symbol and text instructions are A bar display in the instrument displayed. cluster indicates your current driving efficiency. Symbol Measure Mark in the left area, arrow 1: For an efficient driving style, look well display for energy recovered by ahead when driving, accelerate con‐...
Page 193 Display in the instrument cluster Coasting is automatically activated when the The bar display below the tach‐ GREEN driving mode is called via the MINI Driv‐ ometer is filled in green and the ing Modes switch, refer to page 139.
Page 194 ▷ The battery charge state is temporarily too the roof of a MINI and a table of values. low. The fish and the movements of the water in the ▷...
Page 195 DRIVING TIPS Saving fuel displayed below the table of values. The more efficient the driving style, the faster the bonus range increases. To assist with an efficient driving style, GREEN tips are displayed while driving. Tips for an energy-saving driving style, Saving fuel, refer to page 189.
Page 196 MOVE ME. Online Edition for Part no. 01402983394 - X/17...
Page 197: Mobility
AT A GLANCE CONTROLS DRIVING TIPS MOBILITY REFERENCE Online Edition for Part no. 01402983394 - X/17...
Page 198: Refueling
MOBILITY Refueling Refueling Vehicle features and op‐ Fuel cap tions Opening This chapter describes all standard, country- Grasp the fuel filler flap at the rear edge specific and optional features offered with the and open it. series. It also describes features that are not necessarily available in your vehicle, e.
Page 199 MOBILITY Refueling Closing ment. There is a risk of damage to property. Avoid overfilling.◀ WARNING The retaining strap of the fuel cap can be jammed and crushed during closing. The cap cannot be correctly closed. Fuel or fuel vapors can escape. There is a risk of injury or risk of damage to property.
Page 200: Fuel
M100.◀ Gasoline NOTE General information Fuel that does not comply with the mini‐ For the best fuel efficiency, the gasoline should mum quality can compromise engine function be sulfur-free or very low in sulfur content. or cause engine damage. There is a risk of Fuels that are marked on the gas pump as con‐...
Page 201 Failure to comply with these recommendations may result in the need for unscheduled mainte‐ nance.◀ Recommended fuel grade MINI recommends AKI 91. John Cooper Works: MINI recommends AKI 93. Refuel with this gasoline to achieve the rated performance and consumption values.
Page 202: Wheels And Tires
MOBILITY Wheels and tires Wheels and tires Tire inflation pressure specifications Vehicle features and op‐ tions In the tire inflation pressure table The tire inflation pressure table, refer to This chapter describes all standard, country- page 203, contains all tire inflation pressure specific and optional features offered with the specifications for the specified tire sizes at the series.
Page 203 MOBILITY Wheels and tires ▷ If the vehicle has not moved again for at Do not exceed a speed of 100 mph/160 km/h. least 2 hours after a trip. Tire inflation pressure values up to Determine, refer to page 202, the intended 100 mph/160 km/h tire inflation pressure levels for the mounted tires.
Page 204 MOBILITY Wheels and tires COOPER S JOHN COOPER WORKS Tire size Pressure specifications in Tire size Pressure specifications in bar/PSI bar/PSI Specifications in Specifications in bar/PSI with cold bar/PSI with cold tires tires 195/55 R 16 87 H 2.6 / 38 2.4 / 35 185/50 R 17 86 H 2.9 / 42...
Page 205 MOBILITY Wheels and tires Tire inflation pressure values over COOPER S 100 mph/160 km/h Tire size Pressure specifications in bar/PSI COOPER Specifications in bar/PSI with cold Tire size Pressure specifications in bar/PSI tires Specifications in bar/PSI with cold 195/55 R 16 87 H 2.8 / 41 2.6 / 38 tires...
Page 206 MOBILITY Wheels and tires On 3-door models: JOHN COOPER Axle Weight Rating – GAWR. Note, front vs. rear WORKS GAWR and tire loads, respectively. Tire size Pressure specifications in Speed letter bar/PSI Q = up to 100 mph/160 km/h Specifications in R = 106 mph/170 km/h bar/PSI with cold S = up to 112 mph/180 km/h...
Page 207 MOBILITY Wheels and tires DOT Quality Grades sudden tire failure. The grade C corresponds to a level of performance which all passenger ve‐ Treadwear hicle tires must meet under the Federal Motor Traction AA A B C Vehicle Safety Standard No. 109. Grades Band A Temperature A B C represent higher levels of performance on the laboratory test wheel than the minimum re‐...
Page 208 MOBILITY Wheels and tires Minimum tread depth ▷ Tire inflation pressure too low. ▷ Vehicle overloading. ▷ Incorrect tire storage. Safety information WARNING Damaged tires can lose tire inflation pres‐ sure, which can lead to loss of vehicle control. There is a risk of an accident. If tire damage is suspected while driving, immediately reduce Wear indicators are distributed around the tire's speed and stop.
Page 209 MOBILITY Wheels and tires New tires about the correct wheel/tire combination and wheel rim versions for the vehicle. Tire traction is not optimal due to manufactur‐ ing circumstances when tires are brand-new; Safety information they achieve their full traction potential after a break-in time.
Page 210 MOBILITY Wheels and tires Rotating wheels between axles Safety information Different wear patterns can occur on the front WARNING and rear axles depending on individual driving Your vehicle handles differently with a conditions. The tires can be rotated in pairs be‐ run-flat with no or low inflation pressure;...
Page 211 MOBILITY Wheels and tires Sealant container Mobility System Concept With the Mobility System, minor tire damage can be sealed temporarily to enable continued travel. To accomplish this, sealant is pumped into the tires, which seals the damage from the inside. General information ▷...
Page 212 MOBILITY Wheels and tires ▷ Turn the steering wheel until the front Pull filling hose completely out of the cover wheels are in the straight-ahead position of the sealant container. Do not kink the and engage the steering wheel lock. hose.
Page 213 MOBILITY Wheels and tires Removing and stowing the sealant With the compressor switched off, insert container the plug into the power socket inside the vehicle. Unscrew the filling hose of the sealant con‐ tainer from the tire valve. Press the red unlocking device. Remove the sealant container from the compressor.
Page 214 MOBILITY Wheels and tires If a tire inflation pressure of at least 2 bar Insert the connector into the power socket cannot be reached, contact your dealer’s inside the vehicle. service center or another qualified service center or repair shop. If a tire inflation pressure of at least 2 bar is reached, see Minimum tire inflation pres‐...
Page 215 MOBILITY Wheels and tires Maximum speed with snow chains cidents or risk of damage to property. Only mount snow chains on tires that are designated Do not exceed a speed of 30 mph/50 km/h by their manufacturer as suitable for the use of when using snow chains.
Page 216 MOBILITY Wheels and tires On a level surface jammed or damaged. There is a risk of injury and risk of damage to property. Only use the jack to attach an emergency or spare wheel in the event of a breakdown.◀ WARNING On soft, uneven or slippery ground, for example snow, ice, tiles, etc., the vehicle jack...
Page 217 MOBILITY Wheels and tires ▷ If necessary, set up a warning triangle or portable hazard warning light at an appro‐ priate distance. ▷ Secure the vehicle additionally against roll‐ ing. ▷ Loosen the lug bolts a half turn. Jacking points for the vehicle jack ▷...
Page 218 MOBILITY Wheels and tires do not change this position while using the ve‐ Make sure that the vehicle jack foot stands hicle jack.◀ vertically and at a right angle beneath the jacking point. Hold the vehicle jack with one hand, ar‐ row 1, and grasp the vehicle jack crank or lever with your other hand, arrow 2.
Page 219 MOBILITY Wheels and tires Safety information Hand-tighten the remaining lug bolts and tighten all lug bolts well in a crosswise pat‐ WARNING tern. The emergency wheel has particular di‐ Turn the vehicle jack crank counterclock‐ mensions. When driving with an emergency wise to retract the vehicle jack and lower wheel, changed driving properties may occur, the vehicle.
Page 220 MOBILITY Wheels and tires Screw wheel lug wrench onto the thread and hold in place with one hand. Unlock the locking hexagon of the emer‐ gency wheel well using the hexagon at‐ tached to retaining plate. Lower the emergency wheel with the wheel wrench.
Page 221: Engine Compartment
MOBILITY Engine compartment Engine compartment Vehicle features and op‐ necessarily available in your vehicle, e. g., due to the selected options or country versions. This tions also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country- the applicable laws and regulations must be specific and optional features offered with the...
Page 222 MOBILITY Engine compartment WARNING Hood is unlocked. The engine compartment accommodates moving components. Certain components in the engine compartment can also move with the vehicle switched off, for instance the radia‐ tor fan. There is a risk of injury. Do not reach into the area of moving parts.
Page 223: Engine Oil
MOBILITY Engine oil Engine oil Vehicle features and op‐ NOTE Too much engine oil can damage the en‐ tions gine or the catalytic converter. There is a risk of damage to property. Do not add too much en‐ This chapter describes all standard, country- gine oil.
Page 224 MOBILITY Engine oil Displaying the engine oil level Performing a detailed measurement Via the Central Information Display (CID): Via the Central Information Display (CID): "Vehicle info" "Vehicle info" "Vehicle status" "Vehicle status" "Engine oil level" "Measure engine oil level" The engine oil level is displayed. "Start measurement"...
Page 225 MOBILITY Engine oil NOTE NOTE Too much engine oil can damage the en‐ Incorrect engine oil can cause malfunc‐ gine or the catalytic converter. There is a risk of tions in the engine or damage it. There is a risk damage to property.
Page 226 MOBILITY Engine oil quested from a dealer’s service center or an‐ other qualified service center or repair shop. Engine oil change NOTE Engine oil that is not changed in timely fashion can cause increased engine wear and thus engine damage. There is a risk of damage to property.
Page 227: Coolant
MOBILITY Coolant Coolant Vehicle features and op‐ Coolant level tions Overview This chapter describes all standard, country- The coolant reservoir is in the engine compart‐ specific and optional features offered with the ment, refer to page 221. series. It also describes features that are not Open the hood, refer to page 221.
Page 228 MOBILITY Coolant Adding Let the engine cool. Turn the lid of the coolant reservoir slightly counterclockwise to allow any excess pres‐ sure to dissipate, then open it. If the coolant is low, slowly add coolant up to the specified level; do not overfill. Close the cap.
Page 229: Maintenance
Therefore, hand the service advisor the remote control with which the vehicle was driven most recently. MINI maintenance system Storage periods The maintenance system indicates required Storage periods during which the vehicle bat‐ maintenance measures, and thereby provides tery was disconnected are not taken into ac‐...
Page 230 MOBILITY Maintenance Emissions dealer’s service center or another qualified service center or repair shop. Records of regu‐ ▷ The warning light lights up: lar maintenance and repair work should be re‐ Emissions are deteriorating. Have tained. the vehicle checked as soon as pos‐ sible.
Page 231: Replacing Components
MOBILITY Replacing components Replacing components Vehicle features and op‐ Hold the wiper firmly when changing the wiper blade. Do not fold or switch on the wiper with‐ tions out a wiper blade installed.◀ This chapter describes all standard, country- NOTE specific and optional features offered with the Folded-away wipers can be jammed series.
Page 232 MOBILITY Replacing components Insert and latch a new wiper blade in re‐ WARNING verse order. Work on switched-on lighting systems Fold down the wiper arm. can cause short circuits. There is a risk of injury or risk of damage to property. When working on the lighting system, switch off the lights in Light/bulb replacement question.
Page 233 MOBILITY Replacing components Front halogen lights, bulb replacement Bulbs: H4 Open the hood, refer to page 222. Overview Turn the lid counterclockwise, arrow, and remove. Halogen headlights Pull off the connector. Low beams/high beams Unclip spring clip, arrow, and fold down. Turn signal Bug light Remove the bulb from the headlight hous‐...
Page 234 MOBILITY Replacing components Parking lights/fog lights/daytime With white turn signal lights: PWY24W running lights Turn the steering wheel. Follow the general instructions on lights and Turn the lid counterclockwise, arrow 1, and bulbs, refer to page 232. remove. Bulbs: ▷ Parking lights for halogen headlights: W5W Parking lights for LED headlights: W5W NBV.
Page 235 MOBILITY Replacing components Overview ▷ Fog lights: turn the bulb holder, ar‐ row 3, counterclockwise and remove. Position of the headlights Pull the bulb out of the fixture. Daytime running lights Insert the new bulb and install the cover in the reverse order.
Page 236 MOBILITY Replacing components Tail lights, bulb replacement With white turn signal lights: PWY24W Turn the steering wheel. Overview Turn the lid counterclockwise, arrow 1, and remove. Vehicles with a rear fog light Unscrew the inner cover counterclockwise, Side tail lights and remove it.
Page 237 MOBILITY Replacing components Side tail lights Bulbs: P21W Opening tailgate. Remove left or right cover. Brake lights/tail lights Turn signal Reversing lights Through the opening, loosen the plug con‐ nector, arrow 2 on the bulb holder. Side LED tail lights Press the latches together, arrows 1, and remove the bulb holder.
Page 238 MOBILITY Replacing components ▷ Arrow 3: reversing light. Turn the bulb socket counterclockwise and remove. The wire is long enough to guide the socket down and through between any heat shield that may be installed and the bumper. Proceed in the reverse order to insert the new bulb and attach the bulb holder.
Page 239 MOBILITY Replacing components The wire is long enough to guide the socket ▷ With white lens: WY5W. down and through between any heat shield Open the hood. The covers of the side turn that may be installed and the bumper. signal lights are on the left and right next to the hinges of the hood.
Page 240 MOBILITY Replacing components Vehicle battery The battery may need to be charged in the fol‐ lowing cases: ▷ When making frequent short-distance Maintenance drives. The battery is maintenance-free. ▷ If the vehicle is not used for more than a The added amount of acid is sufficient for the month.
Page 241 MOBILITY Replacing components Fuses Safety information WARNING Incorrect and repaired fuses can overload electrical lines and components. There is a risk of fire. Never attempt to repair a blown fuse. Do not replace a nonworking fuse with a sub‐ stitute of another color or amperage rating.◀...
Page 242: Breakdown Assistance
MOBILITY Breakdown assistance Breakdown assistance Roadside Assistance Vehicle features and op‐ The Roadside Assistance phone number can be tions viewed on the Central Information Display (CID) or a connection to Roadside Assistance can be This chapter describes all standard, country- established directly.
Page 243 MOBILITY Breakdown assistance Safety information DANGER Contact with live components can lead to an electric shock. There is a risk of injuries or danger to life. Do not touch any components that are under voltage.◀ WARNING If the jumper cables are connected in the The body ground or a special nut acts as the incorrect order, sparking may occur.
Page 244 MOBILITY Breakdown assistance Tow truck If the first starting attempt is not successful, wait a few minutes before making another attempt in order to allow the discharged battery to recharge. Let both engines run for several minutes. Disconnect the jumper cables in the reverse order.
Page 245 MOBILITY Breakdown assistance needs to be applied when braking and If the electrical system has failed, clearly iden‐ steering. tify the vehicle being towed by placing a sign or a warning triangle in the rear window. ▷ Larger steering wheel movements are re‐ quired.
Page 246 MOBILITY Breakdown assistance Tow fitting Screw thread for tow fitting General information Threaded holes for the tow fitting are located in the front and rear of the vehicle on the right The screw-in tow fitting should always be car‐ side with respect to the direction of travel. ried in the vehicle.
Page 247 MOBILITY Breakdown assistance Stop at a suitable location, remove the tow bar or rope, and switch off the hazard warning system. Have the vehicle checked by a dealer’s service center or another qualified service center or repair shop. Online Edition for Part no. 01402983394 - X/17...
Page 248: Care
▷ Do not treat the convertible top with wax. pressure or temperatures being too high. There Ensure that a cycle without wax or a special is a risk of damage to property. Maintain suffi‐...
Page 249 Caring for the convertible top smearing and to reduce wiper noises and wiper blade wear. General information The appearance and life of the convertible top depend on correct care and operation. Vehicle care Follow the following instructions: ▷...
Page 250 Finish washing the vehicle in the vehicle time. Do not fold up the convertible top or wash or rinse with ample amounts of water. stow it in its case when it is wet or icy.
Page 251 MOBILITY Care Safety information Fine wood parts Clean fine wood facing and fine wood compo‐ NOTE nents only with a moist rag. Then dry with a Open Velcro® fasteners on articles of soft cloth. clothing can damage the seat covers. There is a risk of damage to property.
Page 252 MOBILITY Care Carpets and floor mats erty. Clean with a clean, antistatic microfiber cloth.◀ WARNING Objects in the driver's floor area can limit NOTE the pedal distance or block a depressed pedal. The surface of displays can be damaged There is a risk of an accident. Stow objects in with improper cleaning.
Page 253 MOBILITY Care Online Edition for Part no. 01402983394 - X/17...
Page 254 FIND ME. Online Edition for Part no. 01402983394 - X/17...
Page 255: Reference
AT A GLANCE CONTROLS DRIVING TIPS MOBILITY REFERENCE Online Edition for Part no. 01402983394 - X/17...
Page 256: Technical Data
The specified heights do not take into account attached parts, for instance a roof antenna, MINI Convertible Width with mirrors inches/mm 76.1/1,932 Width without mirrors...
Page 257 780/354 Approved front axle load Manual transmission lbs/kg 2,110/957 Steptronic transmission lbs/kg 2,150/975 Approved rear axle load lbs/kg 1,790/812 MINI John Cooper Works Convertible Approved gross vehicle weight Manual transmission lbs/kg 3,900/1,769 Steptronic transmission lbs/kg 3,940/1,787 Load lbs/kg 800/363 Approved front axle load...
Page 258 REFERENCE Technical data MINI John Cooper Works Convertible Steptronic transmission lbs/kg 2,169/984 Approved rear axle load lbs/kg 1,821/826 Capacities MINI Convertible US gal/liters Notes Fuel tank, approx. 11.6/44.0 Fuel quality, refer to page 200. Online Edition for Part no. 01402983394 - X/17...
Page 259: Appendix
REFERENCE Appendix Appendix Any updates to the Owner's Manual of the ve‐ hicle are listed here. Updates after the edito‐ rial deadline These chapters of the printed Owner's Manual contain updates made after the editorial dead‐ line: ▷ Information: vehicle identification number, refer to page 12.
Page 260: Everything From A To Z
Anti-slip control, see DSC Axle loads, weights Camera-based cruise con‐ Anti-theft protection, lug trol bolts Adaptive brake lights, see App, MINI Motorer’s Guide Brake force display Approach control warning Backrest curvature, see Lum‐ Additives, oil with city light braking func‐ bar support...
Page 261 Convenient opening Cargo area mounting Convertible, convertible Cargo area, enlarging Child seat, mounting Cargo area, loading Child seats Convertible mode, automatic Cargo area partition Chrome parts, care climate control Cargo area, storage compart‐ Cigarette lighter Convertible program, auto‐ ments Cleaning, displays matic climate control Cargo, stowing and secur‐...
Page 262 REFERENCE Everything from A to Z Convertible top, cargo area Deletion of personal data DSC Dynamic Stability Con‐ partition Destination distance trol Convertible top, emergency Digital clock DTC Dynamic Traction Con‐ operation Digital compass trol Convertible top, rollover pro‐ Dimensions...
Page 263 REFERENCE Everything from A to Z Engine compartment Exterior mirrors, malfunc‐ Front-seat passenger airbags, Engine compartment, working tion automatic deactivation External start Front-seat passenger airbags, Engine coolant External temperature dis‐ indicator light Engine idling when driving, play Front seats coasting External temperature warn‐...
Page 264 REFERENCE Everything from A to Z Handbrake, see Parking Intensity, AUTO program brake Interior equipment Hand-held transmitter, alter‐ Ice warning, see External tem‐ Interior lights nating code perature warning Interior lights during unlock‐ Hands-free kit, see Owner's Icy roads, see External tem‐ Handbook for Navigation, perature warning Interior lights with the vehicle...
Page 265 Monitor, see Control Dis‐ Lighting Manual transmission play Light replacement Manufacturer of the MINI Motorer’s Guide app, see MINI Light replacement, Map update, see Owner's Motorer’s Guide app front 233, Handbook for Navigation, Mounting of child restraint Light replacement, rear Entertainment, Communica‐...
Page 266 REFERENCE Everything from A to Z On-call service, see Roadside Printed onboard literature Assistance Profile, see Personal Pro‐ Navigation, see Owner's Online Owner's Manual file Manual for Navigation, En‐ Opening and closing Programmable memory but‐ tertainment and Communi‐ Opening, from inside tons, Central Information cation Operating menus, Central In‐...
Page 267 Standard equipment grade Settings, mirrors Standard view, Head-up Dis‐ Roof load capacity Settings on Control Dis‐ play Roof, see Convertible top play Start/stop, automatic func‐ Route, navigation, see Own‐ Shift gate rotary switch tion er's Handbook for Naviga‐ Shift paddles on the steering Start/Stop button tion, Entertainment, Com‐...
Page 268 REFERENCE Everything from A to Z Steptronic Sport transmission Temperature, automatic cli‐ Entertainment, Communica‐ with double clutch, see Step‐ mate control tion tronic transmission Temperature display for exter‐ Trailer hitch, care Steptronic transmission nal temperature Transmission lock, electronic Steptronic transmission with Temperature, engine unlocking double clutch, see Steptronic...
Page 269 REFERENCE Everything from A to Z Welcome lights during unlock‐ Vanity mirror Wheel cleaner Vehicle battery Wheels, changing Vehicle battery, replacing Wheels, everything on wheels Vehicle, break-in and tires Vehicle care Wheels, Flat Tire Monitor Vehicle care products Vehicle features and op‐ Wheels, Tire Pressure Monitor tions Vehicle identification num‐...
Page 271 *BL298339400I* DRIVE ME. Online Edition for Part no. 01402983394 - X/17...

Mini CONVERTIBLE Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Mini CONVERTIBLE

Summary of Contents for Mini CONVERTIBLE

Table of Contents
